Groovy DSLs, from Beginner to Expert - Guillaume Laforge and Paul King - SpringOne2GX 2011

Groovy.DSLs(from: beginner, to: expert)Paul KingCore Groovy CommitterASERT DirectorGuillaume LaforgeGroovy Project ManagerSpringSource, a division of VMware© 2011 SpringOne 2GX 2011. All rights reserved. Do not distribute without permission.

Groovy.DSLs(from: beginner, to: expert)Paul King 2 011Core Groovy Committer E ditionASERT DirectorGuillaume LaforgeGroovy Project ManagerSpringSource, a division of VMware© 2011 SpringOne 2GX 2011. All rights reserved. Do not distribute without permission.

Guillaume Laforge• Groovy Project Manager at VMware • Initiator of the Grails framework • Creator of the Gaelyk toolkit• Co-author of Groovy in Action• Speaking worldwide w/ a French accent• Follow me on... • My blog: http://glaforge.appspot.com • Twitter: @glaforge • Google+: http://gplus.to/glaforge2 @glaforge — @paulk_asert

Paul King• Core Groovy Committer• Co-author of Groovy in Action• Leads ASERT, a Brisbane, Australia, company providing software development, training & mentoring support• International speaker• Follow me on • Website: http://www.asert.com.au • Twitter: @paulk_asert3 @glaforge — @paulk_asert

Domain-Specific Languages• Wikipedia definition – A Domain-Speciﬁc Language is a programming language or executable speciﬁcation language that offers, through appropriate notations and abstractions, expressive power focused on, and usually restricted to, a particular problem domain.• In contrast to General Purprose Languages• Somewhere between declarative data and GPLs• Also known as: fluent / human interfaces, language oriented programming, little or mini languages, macros, business4 @glaforge — @paulk_asert

Goals of Domain-Specific Languages• Use a more expressive language than a general-purpose one• Share a common metaphore of understanding between develoeprs and subject matter experts• Have domain experts help with the design of the business logic of an application• Avoid cluttering business code with too much boilerplate technical code thanks to a clean seperation5 @glaforge — @paulk_asert

Antimalaria drug Insurance policy risk HR skillsresistance calculation engine representationsimulation Nuclear safety simulationsMarket data feeds analysis Loan acceptance rules engine

Technical examples Glade XSLT <?xml version="1.0"?> <?xml version="1.0"?> <GTK-Interface> <xsl:stylesheetversion="1.0" <widget> xmlns:xsl="http://www.w3.org/1999/XSL/Transform"> <class>GtkWindow</class> <xsl:output method="xml"/> <name>HelloWindow</name> <xsl:template match="*"> <border_width>5</border_width> <xsl:element name="{name()}"> <Signal> <xsl:for-each select="@*"> Regex <xsl:element name="{name()}"> "x.z?z{1,3}y" <name>destroy</name> <handler>gtk_main_quit</handler> <xsl:value-of select="."/> </Signal> </xsl:element> <title>Hello</title> </xsl:for-each> <type>GTK_WINDOW_TOPLEVEL</type> <xsl:apply-templates select="*|text()"/> <position>GTK_WIN_POS_NONE</position> </xsl:element> <allow_shrink>True</allow_shrink> </xsl:template> <allow_grow>True</allow_grow> </xsl:stylesheet> <auto_shrink>False</auto_shrink> <widget> <class>GtkButton</class> fetchmail <name>Hello World</name> <can_focus>True</can_focus> # Poll this site first each cycle. <label>Hello World</label> poll pop.provider.net proto pop3 </widget> user "jsmith" with pass "secret1" is "smith" here </widget> user jones with pass "secret2" is "jjones" here with options </GTK-Interface> keep SQL # Poll this site second, unless Lord Voldemort zaps us first. poll billywig.hogwarts.com with proto imap: SELECT * FROM TABLE user harry_potter with pass "floo" is harry_potter here WHERE NAME LIKE %SMI # Poll this site third in the cycle. ORDER BY NAME # Password will be fetched from ~/.netrc poll mailhost.net with proto imap: user esr is esr here Troff cat thesis.ms | chem | tbl | refer | grap | pic | eqn | groff -Tps > thesis.ps 8 Source: Applying minilanguages: http://www.faqs.org/docs/artu/ch08s02.html @glaforge — @paulk_asert

Pros and cons of DSLs• Pros – Safety; as long as the – Domain experts can help, language constructs are safe, validate, modify, and often any DSL sentence can be develop DSL programs considered safe – Somewhat self-documenting – Enhance quality, • Cons productivity, reliability, – Learning cost vs. limited maintainability, portability, applicability reusability – Cost of designing, implementing & maintaining DSLs as well as tools/IDEs – Attaining proper scope8 @glaforge — @paulk_asert

• The flexible nature of the language – method call and syntax conventions – native syntax constructs – adding properties to numbers – command chain expressions – operator overloading – hierarchical structures with builders – AST transformations9 © 2011 SpringOne 2GX 2011. All rights reserved. Do not distribute without permission.

Scripts vs classes • Hide all the boilerplate technical code – an end-user doesn’t need to know about classes10 @glaforge — @paulk_asert

Scripts vs classes • Hide all the boilerplate technical code – an end-user doesn’t need to know about classes public class Rule {     public static void main(String[] args) {         System.out.println("Hello");     } }10 @glaforge — @paulk_asert

Scripts vs classes • Hide all the boilerplate technical code – an end-user doesn’t need to know about classes public class Rule {     public static void main(String[] args) {         System.out.println("Hello");     } } println "Hello"10 @glaforge — @paulk_asert

Optional typing • No need to bother with types or even generics – unless you want to! – but strongly typed if you so desire11 @glaforge — @paulk_asert

Optional typing • No need to bother with types or even generics – unless you want to! – but strongly typed if you so desire// given this API methodpublic Rate<LoanType, Duration, BigDecimal>[] lookupTable() { ... }11 @glaforge — @paulk_asert

Optional typing • No need to bother with types or even generics – unless you want to! – but strongly typed if you so desire// given this API methodpublic Rate<LoanType, Duration, BigDecimal>[] lookupTable() { ... } // verbose Java notation Rate<LoanType, Duration, BigDecimal>[] table = lookupTable();11 @glaforge — @paulk_asert

Optional typing • No need to bother with types or even generics – unless you want to! – but strongly typed if you so desire// given this API methodpublic Rate<LoanType, Duration, BigDecimal>[] lookupTable() { ... } // verbose Java notation Rate<LoanType, Duration, BigDecimal>[] table = lookupTable(); // leaner Groovy variant def table = lookupTable()11 @glaforge — @paulk_asert

Native syntax constructs12 @glaforge — @paulk_asert

Native syntax constructs // Lists12 @glaforge — @paulk_asert

Native syntax constructs // Lists def days = [Monday, Tuesday, Wednesday]12 @glaforge — @paulk_asert

Native syntax constructs // Lists def days = [Monday, Tuesday, Wednesday] // Maps12 @glaforge — @paulk_asert

Native syntax constructs // Lists def days = [Monday, Tuesday, Wednesday] // Maps def states = [CA: California, TX: Texas]12 @glaforge — @paulk_asert

Native syntax constructs // Lists def days = [Monday, Tuesday, Wednesday] // Maps def states = [CA: California, TX: Texas] // Ranges (you can create your own)12 @glaforge — @paulk_asert

Native syntax constructs // Lists def days = [Monday, Tuesday, Wednesday] // Maps def states = [CA: California, TX: Texas] // Ranges (you can create your own) def bizDays = Monday..Friday12 @glaforge — @paulk_asert

Native syntax constructs // Lists def days = [Monday, Tuesday, Wednesday] // Maps def states = [CA: California, TX: Texas] // Ranges (you can create your own) def bizDays = Monday..Friday def allowedAge = 18..6512 @glaforge — @paulk_asert

Optional parens & semis• Make statements and expressions look more like natural languages13 @glaforge — @paulk_asert

Optional parens & semis• Make statements and expressions look more like natural languages move(left);13 @glaforge — @paulk_asert

Optional parens & semis• Make statements and expressions look more like natural languages move(left); move left13 @glaforge — @paulk_asert

Adding properties to numbers• Several approaches to adding properties to numbers – through a category class PillsCategory {     static getPills(Number n) { n } } use(PillsCategory) {     2.pills          // 2.getPills() } – through ExpandoMetaClass Number.metaClass.getPills { ‐> delegate } 2.pills                 // 2.getPills()14 @glaforge — @paulk_asert

Named arguments• In Groovy you can mix named and unnamed arguments for method parameters – named params are actually put in a map parameter – plus optional parens & semis   take 2.pills,     of: chloroquinine,  after: 6.hours // Calls a method signature like: def take(Map m, MedicineQuantity mq)15 @glaforge — @paulk_asert

Command chain expressions16 @glaforge — @paulk_asert

Command chain expressions• A grammar improvement allowing you to drop dots & parens when chaining method calls – an extended version of top-level statements like println16 @glaforge — @paulk_asert

Command chain expressions• A grammar improvement allowing you to drop dots & parens when chaining method calls – an extended version of top-level statements like println• Less dots, less parens allow you to – write more readable business rules – in almost plain English sentences • (or any language, of course)16 @glaforge — @paulk_asert

Command chain expressions• A grammar improvement allowing you to drop dots & parens when chaining method calls – an extended version of top-level statements like println• Less dots, less parens allow you to – write more readable business rules – in almost plain English sentences • (or any language, of course)• Let’s have a look at some examples16 @glaforge — @paulk_asert

Command chain expressions  turn left  then right 17 @glaforge — @paulk_asert

Command chain expressions Alternation of method names  turn left  then right 17 @glaforge — @paulk_asert

Command chain expressions Alternation of method names  turn left  then right  and parameters (even named ones)17 @glaforge — @paulk_asert

Command chain expressions  turn left  then right 17 @glaforge — @paulk_asert

Command chain expressions Equivalent to:      (    ).    (     )  turn left  then right 17 @glaforge — @paulk_asert

LookM a!N op are ns,no do ts!

Command chain expressions Before... we used to do... take 2.pills, of: chloroquinine, after: 6.hours19 @glaforge — @paulk_asert

Command chain expressions Before... we used to do... take 2.pills, of: chloroquinine, after: 6.hours Normal argument19 @glaforge — @paulk_asert

Command chain expressions Before... we used to do... take 2.pills, of: chloroquinine, after: 6.hours Normal argument Named arguments19 @glaforge — @paulk_asert

Command chain expressions Before... we used to do... take 2.pills, of: chloroquinine, after: 6.hours Normal argument Named arguments Woud call: def take(Map m, Quantity q)19 @glaforge — @paulk_asert

Command chain expressions Now, even less punctuation! take 2.pills  of  chloroquinine  after  6.hours20 @glaforge — @paulk_asert

Command chain expressions Now, even less punctuation!     (       ).   (             ).      (       ) take 2.pills  of  chloroquinine  after  6.hours20 @glaforge — @paulk_asert

Command chain expressions // environment initialization Integer.metaClass.getPills { ‐> delegate } Integer.metaClass.getHours { ‐> delegate }   // variable injection def chloroquinine = /*...*/   { } // implementing the DSL logic def take(n) {     [of: { drug ‐>         [after: { time ‐> /*...*/ }]     }] } // ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ take 2.pills of chloroquinine after 6.hours21 @glaforge — @paulk_asert

Command chain expressions take 2.pills  of  chloroquinine  after  6.hours22 @glaforge — @paulk_asert

Command chain expressions take 2.pills  of  chloroquinine  after  6.hours ... some dots remain ...22 @glaforge — @paulk_asert

Command chain expressions Yes, we can... get rid of them :-) take 2  pills of  chloroquinine  after  6 hours23 @glaforge — @paulk_asert

Command chain expressions Yes, we can... get rid of them :-)     ( ).     (  ).              (     ). (     ) take 2  pills of  chloroquinine  after  6 hours23 @glaforge — @paulk_asert

Command chain expressions // variable injection def (of, after, hours) = /*...*/   // implementing the DSL logic { } def take(n) {     [pills: { of ‐>         [chloroquinine: { after ‐>             [6: { time ‐> }]         }]     }] } // ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ take 2 pills of chloroquinine after 6 hours24 @glaforge — @paulk_asert

Command chain expressions @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) take coffee  with sugar, milk  and liquor @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) take coffee  with sugar, milk  and liquor // leverage named‐args as punctuation @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) take coffee  with sugar, milk  and liquor // leverage named‐args as punctuation check that: margarita  tastes good @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) take coffee  with sugar, milk  and liquor // leverage named‐args as punctuation check that: margarita  tastes good // closure parameters for new control structures @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) take coffee  with sugar, milk  and liquor // leverage named‐args as punctuation check that: margarita  tastes good // closure parameters for new control structures given {}  when {}  then {} @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) take coffee  with sugar, milk  and liquor // leverage named‐args as punctuation check that: margarita  tastes good // closure parameters for new control structures given {}  when {}  then {} // zero‐arg methods require parens @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) take coffee  with sugar, milk  and liquor // leverage named‐args as punctuation check that: margarita  tastes good // closure parameters for new control structures given {}  when {}  then {} // zero‐arg methods require parens select all  unique() from names @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) take coffee  with sugar, milk  and liquor // leverage named‐args as punctuation check that: margarita  tastes good // closure parameters for new control structures given {}  when {}  then {} // zero‐arg methods require parens select all  unique() from names // possible with an odd number of terms @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) take coffee  with sugar, milk  and liquor // leverage named‐args as punctuation check that: margarita  tastes good // closure parameters for new control structures given {}  when {}  then {} // zero‐arg methods require parens select all  unique() from names // possible with an odd number of terms take 3  cookies @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) take coffee  with sugar, milk  and liquor     (      ).    (           ).   (      ) // leverage named‐args as punctuation check that: margarita  tastes good // closure parameters for new control structures given {}  when {}  then {} // zero‐arg methods require parens select all  unique() from names // possible with an odd number of terms take 3  cookies @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) take coffee  with sugar, milk  and liquor     (      ).    (           ).   (      ) // leverage named‐args as punctuation check that: margarita  tastes good      (               ).      (    ) // closure parameters for new control structures given {}  when {}  then {} // zero‐arg methods require parens select all  unique() from names // possible with an odd number of terms take 3  cookies @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) take coffee  with sugar, milk  and liquor     (      ).    (           ).   (      ) // leverage named‐args as punctuation check that: margarita  tastes good      (               ).      (    ) // closure parameters for new control structures given {}  when {}  then {}      (  ).    (  ).    (  ) // zero‐arg methods require parens select all  unique() from names // possible with an odd number of terms take 3  cookies @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) take coffee  with sugar, milk  and liquor     (      ).    (           ).   (      ) // leverage named‐args as punctuation check that: margarita  tastes good      (               ).      (    ) // closure parameters for new control structures given {}  when {}  then {}      (  ).    (  ).    (  ) // zero‐arg methods require parens select all  unique() from names       (   ).        .    (     ) // possible with an odd number of terms take 3  cookies @glaforge — @paulk_asert 25

Command chain expressions // methods with multiple arguments (commas) take coffee  with sugar, milk  and liquor     (      ).    (           ).   (      ) // leverage named‐args as punctuation check that: margarita  tastes good      (               ).      (    ) // closure parameters for new control structures given {}  when {}  then {}      (  ).    (  ).    (  ) // zero‐arg methods require parens select all  unique() from names       (   ).        .    (     ) // possible with an odd number of terms take 3  cookies     ( ). @glaforge — @paulk_asert 25

Operator overloadinga + b  // a.plus(b)a ‐ b  // a.minus(b) • Currency amountsa * b  // a.multiply(b) – 15.euros + 10.dollarsa / b  // a.divide(b)a % b  // a.modulo(b) • Distance handlinga ** b // a.power(b)a | b  // a.or(b) – 10.kilometers - 10.metersa & b  // a.and(b)a ^ b  // a.xor(b) • Workflow, concurrencya[b]   // a.getAt(b) – taskA | taskB & taskCa << b // a.leftShift(b)a >> b // a.rightShift(b)+a     // a.unaryPlus() • Credit an account‐a     // a.unaryMinus() – account << 10.dollars~a     // a.bitwiseNegate() account += 10.dollars26 @glaforge — @paulk_asert

Builders• For hierachical structures, extend: – BuilderSupport – FactoryBuilderSupport • nice for extending builders with new nodes and attributes import groovy.xml.*  • Roll your own.. def builder = new MarkupBuilder() builder.html { – with invokeMethod()     head { title "Chicago!" } or methodMissing()     body {         div(id: "main") { – with get/setProperty()             p "Groovy rocks!"         } or propertyMissing()     } }27 @glaforge — @paulk_asert

AST Transformations• Hook into the compiler process to do compile-time metaprogramming by modifying the Abstract Syntax Tree Transformation28 @glaforge — @paulk_asert

@InheritConstructors• Classes like Exception are painful when extended, as all the base constructors should be replicated class CustomException extends Exception {     CustomException()                        { super()       }     CustomException(String msg)              { super(msg)    }     CustomException(String msg, Throwable t) { super(msg, t) }     CustomException(Throwable t)             { super(t)      } }29 @glaforge — http://glaforge.appspot.com — http://gplus.to/glaforge

@InheritConstructors• Classes like Exception are painful when extended, as all the base constructors should be replicated import groovy.transform.* @InheritConstructors class CustomException extends Exception {     CustomException()                        { super()       }     CustomException(String msg)              { super(msg)    }     CustomException(String msg, Throwable t) { super(msg, t) }     CustomException(Throwable t)             { super(t)      } }29 @glaforge — http://glaforge.appspot.com — http://gplus.to/glaforge

@InheritConstructor... under the covers// ...ClassNode sNode = cNode.getSuperClass();           for (ConstructorNode cn : sNode.getDeclaredConstructors()) {    Parameter[] params = cn.getParameters();    if (cn.isPrivate()) continue;    Parameter[] newParams = new Parameter[params.length];    List<Expression> args = copyParamsToArgs(params, newParams);    if (isClashing(cNode, newParams)) continue;    BlockStatement body = new BlockStatement();    ConstructorCallExpression callArgs =        new ConstructorCallExpression(ClassNode.SUPER,                                       new ArgumentListExpression(args));    body.addStatement(new ExpressionStatement(callArgs));    cNode.addConstructor(cn.getModifiers(), newParams,                          cn.getExceptions(), body);}// ...30 @glaforge — http://glaforge.appspot.com — http://gplus.to/glaforge

Advanced example with Spockdef "length of Spocks & his friends names"() {    expect:        name.size() == length    where:        name     | length        "Spock"  | 5        "Kirk"   | 4        "Scotty" | 6}31 @glaforge — http://glaforge.appspot.com — http://gplus.to/glaforge

• A week in the life of DSL inc. – find the examples on GitHub: https://github.com/paulk-asert/ DSLsFromBeginnerToExpert32 © 2011 SpringOne 2GX 2011. All rights reserved. Do not distribute without permission.

MONDAY33 @glaforge — @paulk_asert

Currency DSL… From:    customer@acme.org To:      Guillaume Subject: Project Request Dear Guillaume, We would like a DSL for capturing currency  expressions. Just US currency to start with. Thanks, Happy Customer34 @glaforge — @paulk_asert

…Currency DSL... enum Coin {     penny(1), nickel(5), dime(10), quarter(25)     Coin(int value) { this.value = value }     int value } import static Coin.*   assert 2 * quarter.value +        1 * nickel.value +        2 * penny.value == 5735 @glaforge — @paulk_asert

…Currency DSL… From:    customer@acme.org To:      Guillaume Subject: Project Request Dear Guillaume, That works fairly well but can we get rid  of the ‘.value’ part of those expressions.  They are confusing our users. Thanks, Happy Customer36 @glaforge — @paulk_asert

...Currency DSL...// Categoryclass CoinMath {    static multiply(Integer self, Coin c) {        self * c.value    }} use (CoinMath) {    assert 2 * quarter +           1 * nickel +           2 * penny == 57}37 @glaforge — @paulk_asert

...Currency DSL...// Categoryclass CoinMath {    static multiply(Integer self, Coin c) {        self * c.value    }} use (CoinMath) {    assert 2 * quarter +           1 * nickel + // EMC equivalent           2 * penny == 57 Integer.metaClass.multiply = {}     Coin c ‐> delegate * c.value } assert 2 * quarter +         1 * nickel +         2 * penny == 5737 @glaforge — @paulk_asert

…Currency DSL… From:    customer@acme.org To:      Guillaume Subject: Project Request Dear Guillaume, Much better but our users are sometimes  using plural as well as singular  expressions. Is there anything that you  can do about that? Thanks, Happy Customer38 @glaforge — @paulk_asert

... Currency DSLclass CoinValues {    static get(Integer self, String name) {        self * Coin."${singular(name)}".value    }    static singular(String val) {        val.endsWith(ies) ? val[0..‐4] + y : val.endsWith(s) ? val[0..‐2] : val    }} use (CoinValues) {    assert 2.quarters + 1.nickel + 2.pennies == 57}39 @glaforge — @paulk_asert

... Currency DSLclass CoinValues {    static get(Integer self, String name) {        self * Coin."${singular(name)}".value    }    static singular(String val) {        val.endsWith(ies) ? val[0..‐4] + y : val.endsWith(s) ? val[0..‐2] : val    }} use (CoinValues) {    assert 2.quarters + 1.nickel + 2.pennies == 57} // EMC equivalent Integer.metaClass.getProperty = { String name ‐>     def mp = Integer.metaClass.getMetaProperty(name)     if (mp) return mp.getProperty(delegate)     def singular = name.endsWith(ies) ? name[0..‐4] + y :                    name.endsWith(s) ? name[0..‐2] : name     delegate * Coin."$singular".value }   assert 2.quarters + 1.nickel + 2.pennies == 5739 @glaforge — @paulk_asert

TUESDAYhttp://www.google.com/imgres?imgurl=http://i733.photobucket.com/albums/ww336/snake1953/Day_of_Week/Tue/HappyTuesda 40 @glaforge — @paulk_asert%3D1%26hl%3Den%26client%3Dfirefox-a%26sa%3DN%26rls%3Dorg.mozilla:en-US:official%26biw%3D1488%26bih%3D852%

Business logic DSL From:    customer@acme.org To:      Paul King Subject: Project Request Dear Paul, Could you please create us a small DSL for capturing our business rules. We are thinking of something like:     price = 3     quantity = 10     total = price * quantity Perhaps also an ability to check values:     assert total == 30 Thanks, Happy Customer P.S. Will send a couple of more details in a follow‐up email but please consider the requirements as being pretty much locked down.41 @glaforge — @paulk_asert

Business logic DSL• Options – Embedded Groovy – Regex parser – Antlr parser – Split / StringTokenizer – Parser combinators42 @glaforge — @paulk_asert

Business logic DSL From:    customer@acme.org To:      Paul King Subject: Project Request Date:    Mid morning Dear Paul, We were thinking a bit more about it, and it would be good to have just a few more features. Hopefully, they won’t have much impact on your existing design and can be added very quickly. It isn’t much, just the ability to have IF, THEN, ELSE like structures, oh yeah and the ability to have loops, and store stuff in files and get stuff from databases and web services if we need. Thanks, Happy Customer P.S. It would be great if you can be finished by this afternoon. We have a customer who would like this feature RSN. Thanks.43 @glaforge — @paulk_asert

Business logic DSL def shell = new GroovyShell() shell.evaluate(     price = 3     quantity = 10     total = price * quantity     assert total == 30 )44 @glaforge — @paulk_asert

Business logic DSL From:    customer@acme.org To:      Paul King Subject: Project Request Date:    This afternoon Dear Paul, We were really happy with the DSL engine you provided us  with but people started importing all sorts of classes. Can  you stop them from doing that? Maybe just java.lang.Math  only. Also we decided we don’t like “while” loops anymore.  Leave you to it. Thanks, Happy Customer P.S. Have a beer and crab dinner for me at the conference.  Bye.45 @glaforge — @paulk_asert

Business logic DSL class CustomerShell {     Object evaluate(String text) {         try {             def loader = new CustomerClassLoader()             def clazz = loader.parseClass(text)             def script = clazz.newInstance()             return script.run()         } catch (...) { ... }     } }   class CustomerClassLoader extends GroovyClassLoader {     def createCompilationUnit(CompilerConfiguration config, CodeSource codeSource) {         CompilationUnit cu = super.createCompilationUnit(config, codeSource)         cu.addPhaseOperation(new CustomerFilteringNodeOperation(), Phases.SEMANTIC_ANALYSIS)         return cu     } }   private class CustomerFilteringNodeOperation extends PrimaryClassNodeOperation {     // ...     private static final allowedStaticImports = [Math].asImmutable()     void visitStaticMethodCallExpression(StaticMethodCallExpression smce) {         if (!allowedStaticImports.contains(smce.ownerType.getTypeClass())) {             throw new SecurityException("Static method call expressions forbidden in acme shell.")         }     }     void visitWhileLoop(WhileStatement whileStatement) {         throw new SecurityException("While statements forbidden in acme shell.")    }    // ... } 46 @glaforge — @paulk_asertPlease also see the ArithmeticShell which is included under examples in the Groovy distribution

Business logic DSL def shell = new CustomerShell() shell.evaluate(     price = 3     quantity = 10     total = price * quantity     assert total == 30 )47 @glaforge — @paulk_asert

WEDNESDAY 48 @glaforge — @paulk_aserthttp://www.crystalscomments.com/1/days/wednesday/animals/006.jpg

Stock Exchange Order DSL From:    customer@finance‐broker.org To:      Guillaume Subject: Project Request Date:    Wednesday morning Dear Guillaume, For our order processing system we have a need to capture  client orders using a DSL. An order includes the name of  the security to be transacted (buy or sell) as well as  quantity and unit price details to specify any constraint  that the counterparty would like to impose on the price  of transaction. Thanks, Happy CustomerExample inspiredfrom «DSLs in Action»:http://www.manning.com/ghosh/ 49 @glaforge — @paulk_asert

// ‐‐‐‐‐ Implementation of the Fluent API ‐‐‐‐‐… Stock Exchange Order DSL…enum Action { Buy, Sell }  println new Order()class Order {     .sell(150, "IBM")    def security    def quantity, limitPrice     .limitPrice(300)    boolean allOrNone    def valueCalculation     .allOrNone(true)    Action action     .valueAs { qty, unitPrice ‐>     def buy(Integer quantity, String security) {          qty * unitPrice ‐ 100 }        this.quantity = quantity          this.security = security        this.action = Action.Buy println new Order()        return this     .buy(200, "GOOG")    }    def sell(Integer quantity, String security) {     .limitPrice(200)        this.quantity = quantity     .allOrNone(true)        this.security = security        this.action = Action.Sell     .valueAs{ qty, unitPrice ‐>        return this         qty * unitPrice ‐ 500 }    }    def limitPrice(Integer limit) {        this.limitPrice = limit; return this    } Sell 150 shares of IBM at valuation of 44900    def allOrNone(boolean allOrNone) {        this.allOrNone = allOrNone; return this Buy 200 shares of GOOG at valuation of 39500    }    def valueAs(Closure valueCalculation) {        this.valueCalculation = valueCalculation; return this    }    String toString() {        "$action $quantity shares of $security at valuation of ${valueCalculation(quantity, limitPrice)}"    }}50 @glaforge — @paulk_asert

Stock Exchange Order DSL From:    customer@finance‐broker.org To:      Guillaume Subject: Project Request Date:    Wednesday morning Dear Guillaume, That version was great but can you make the DSL a little more fluent. The brokers aren’t programmers after all! Thanks, Happy Customer51 @glaforge — @paulk_asert

Stock Exchange Order DSL class Order {     def security, quantity, limitPrice, allOrNone, value, bs       def buy(securityQuantity, closure) {         bs = Bought         buySell(securityQuantity, closure)     }          def sell(securityQuantity, closure) {         bs = Sold         buySell(securityQuantity, closure)     }       private buySell(securityQuantity, closure) {         // multiple assignment         (security, quantity) = [securityQuantity.security, securityQuantity.quantity]         // better clone the closure to avoid multi‐threading access issues         def c = closure.clone()         // delegate the method calls inside the closure to our methodMissing         c.delegationStrategy = Closure.DELEGATE_ONLY         c.delegate = this         def valuation = c()         println "$bs $quantity $security.name at valuation of $valuation"     }       // methods inside the closure will assign the Order properties     def methodMissing(String name, args) { this."$name" = args[0] }52 @glaforge — @paulk_asert

Stock Exchange Order DSL     def getTo() { this } newOrder.to.buy(100.shares.of(IBM)) {        limitPrice  300     def valueAs(closure) {     allOrNone   true         value = closure(quantity, limitPrice)     valueAs     { qty, unitPrice ‐>     }         qty * unitPrice ‐ 200 } }   } class Security {       String name newOrder.to.sell 200.shares.of(GOOG), { }     limitPrice  200   class Quantity {     allOrNone   false     Security security     valueAs     { qty, unitPrice ‐>     Integer quantity         qty * unitPrice ‐ 500 } } }   Integer.metaClass.getShares = { ‐> delegate } Integer.metaClass.of = { new Quantity(security: it, quantity: delegate) }   class CustomBinding extends Binding {     def getVariable(String symbol) {         // create a new order each time         // for when you pass several orders         if (symbol == "newOrder") new Order()         // otherwise, its an instrument         // trick to avoid using strings: use IBM instead of IBM         else new Security(name: symbol)      } }   // use the script binding for retrieving IBM, etc. binding = new CustomBinding()53 @glaforge — @paulk_asert

Stock Exchange Order DSL From:    customer@finance‐broker.org To:      Guillaume Subject: Project Request Date:    Wednesday lunch time Dear Guillaume, That version was great but can we simplify the constraint to remove the parameters, i.e.: change     { qty, unitPrice ‐> qty * unitPrice ‐ 200 } to this:     { qty * unitPrice ‐ 200 } Thanks, Happy Customer54 @glaforge — @paulk_asert

Stock Exchange Order DSL newOrder.to.buy(100.shares.of(IBM)) {class Order {     limitPrice  300...     allOrNone   true    def allOrNone, valueCalculation, bs     valueAs     { qty * unitPrice ‐ 200 }...    private buySell(securityQuantity, closure) { }...          valueCalculation = c() newOrder.to.sell 200.shares.of(GOOG), {        // debug print resulting order     limitPrice  200        println toString()     allOrNone   false        return this     valueAs     { qty * unitPrice ‐ 500 }    } }...    def valueAs(Closure wrapee) {    // in order to be able to define closures like { qty * unitPrice } without having    // to explicitly pass the parameters to the closure we can wrap the closure inside    // another one and that closure sets a delegate to the qty and unitPrice variables        def wrapped = { qty, unitPrice ‐>            def cloned = wrapee.clone()            cloned.resolveStrategy = Closure.DELEGATE_ONLY            cloned.delegate = [qty: qty, unitPrice: unitPrice]            cloned()        }        return wrapped    }...}55 @glaforge — @paulk_asert

Stock Exchange Order DSL From:    customer@finance‐broker.org To:      Guillaume Subject: Project Request Date:    Wednesday afternoon Dear Guillaume, Fantastic! This is getting better all the  time! But can we get rid most of the ‘.’ and  bracket symbols! Thanks, Happy Customer56 @glaforge — @paulk_asert

Stock Exchange Order DSL     // Characteristics of the order: "of GOOG {...}"     def of(SecurityAndCharacteristics secAndCharact) {         security = secAndCharact.security         def c = secAndCharact.characteristics.clone()         c.delegationStrategy = Closure.DELEGATE_ONLY         c.delegate = this         c()         // debug print of the resulting order         println toString()         return this     }        // Valuation closure: "of { qty, unitPrice ‐> ... }"      def of(Closure valueCalculation) {          // in order to be able to define closures like { qty * unitPrice }          // without having to explicitly pass the parameters to the closure          // we can wrap the closure inside another one          // and that closure sets a delegate to the qty and unitPrice variables          def wrapped = { qty, unitPrice ‐>              def cloned = valueCalculation.clone()              cloned.resolveStrategy = Closure.DELEGATE_ONLY              cloned.delegate = [qty: qty, unitPrice: unitPrice]              cloned()          }          return wrapped     } } 57 @glaforge — @paulk_asert http://groovyconsole.appspot.com/script/226001 by glaforge

Stock Exchange Order DSL class Security {     String name }   class SecurityAndCharacteristics {     Security security     Closure characteristics }   class CustomBinding extends Binding {     def getVariable(String word) {         // return System.out when the script requests to write to out         if (word == "out") System.out         // dont throw an exception and return null         // when a silent sentence word is used,         // like "to" and "the" in our DSL         null     } }   // Script helper method for "GOOG {}", "VMW {}", etc. def methodMissing(String name, args) {     new SecurityAndCharacteristics(         security: new Security(name: name),         characteristics: args[0]     ) }   // Script helper method to make "order to" silent // by just creating our current order def order(to) { new Order() }   // use the script binding for silent sentence words like "to", "the" binding = new CustomBinding() // syntax for 200.shares Integer.metaClass.getShares = { ‐> delegate }58 @glaforge — @paulk_asert

Stock Exchange Order DSL order to buy 200.shares of GOOG {     limitPrice       500     allOrNone        false     at the value of  { qty * unitPrice ‐ 100 } }   order to sell 150.shares of VMW {     limitPrice       80     allOrNone        true     at the value of  { qty * unitPrice } }59 http://groovyconsole.appspot.com/script/226001 @glaforge — @paulk_asert by glaforge

Stock Exchange Order DSL From:    customer@finance‐broker.org To:      Guillaume Subject: Project Request Date:    Wednesday evening Dear Guillaume, Brilliant! Even our CEO could write orders! Thanks, Happy Customer60 @glaforge — @paulk_asert

THURSDAY 61 @glaforge — @paulk_aserthttp://t1.gstatic.com/images?q=tbn:_VBloEP8YC-6IM:http://msp248.photobucket.com/albums/gg171/ingrid2002/TextPL252028

Einstein’s Riddle DSL … From:    customer@acme.org To:      Paul King Subject: Project Request Date:    Early morning Dear Paul, We would like a DSL for capturing our business  rules. Our business rules are captured in the form  of logic clauses. They are very much like those  found in Einstein’s riddle. Thanks, Happy Customer62 @glaforge — @paulk_asert

Einstein’s Riddle• Wikipedia: The zebra puzzle is a well-known logic puzzle – It is often called Einsteins Puzzle or Einsteins Riddle because it is said to have been invented by Albert Einstein as a boy, with the claim that Einstein said “only 2 percent of the worlds population can solve it.” – The puzzle is also sometimes attributed to Lewis Carroll. However, there is no known evidence for Einsteins or Carrolls authorship; and the original puzzle cited below mentions brands of cigarette, such as Kools, that did not exist during Carrolls lifetime or Einsteins boyhood63 @glaforge — @paulk_asert

Einstein’s Riddle• Some premises: – The British person lives in the red house – The Swede keeps dogs as pets – The Dane drinks tea – The green house is on the left of the white house – The green homeowner drinks coffee – The man who smokes Pall Mall keeps birds – The owner of the yellow house smokes Dunhill – The man living in the center house drinks milk – The Norwegian lives in the first house – The man who smokes Blend lives next to the one who keeps cats – The man who keeps the horse lives next to the man who smokes Dunhill – The man who smokes Bluemaster drinks beer – The German smokes Prince – The Norwegian lives next to the blue house64 @glaforge — @paulk_asert

Einstein’s Riddle• Some premises: – The British person lives in the red house • And a question: – The Swede keeps dogs as pets – Who owns the fish? – The Dane drinks tea – The green house is on the left of the white house – The green homeowner drinks coffee – The man who smokes Pall Mall keeps birds – The owner of the yellow house smokes Dunhill – The man living in the center house drinks milk – The Norwegian lives in the first house – The man who smokes Blend lives next to the one who keeps cats – The man who keeps the horse lives next to the man who smokes Dunhill – The man who smokes Bluemaster drinks beer – The German smokes Prince – The Norwegian lives next to the blue house64 @glaforge — @paulk_asert

Einstein’s Riddle : Prolog% from http://www.baptiste‐wicht.com/2010/09/solve‐einsteins‐riddle‐using‐prolog% Preliminary definitionspersons(0, []) :‐ !.persons(N, [(_Men,_Color,_Drink,_Smoke,_Animal)|T]) :‐ N1 is N‐1, persons(N1,T).person(1, [H|_], H) :‐ !.person(N, [_|T], R) :‐ N1 is N‐1, person(N1, T, R).% The Brit lives in a red househint1([(brit,red,_, _, _)|_]).hint1([_|T]) :‐ hint1(T).% The Swede keeps dogs as petshint2([(swede,_,_,_,dog)|_]).hint2([_|T]) :‐ hint2(T).% The Dane drinks teahint3([(dane,_,tea,_,_)|_]).hint3([_|T]) :‐ hint3(T).% The Green house is on the left of the White house hint4([(_,green,_,_,_),(_,white,_,_,_)|_]).hint4([_|T]) :‐ hint4(T).% The owner of the Green house drinks coffee.hint5([(_,green,coffee,_,_)|_]).hint5([_|T]) :‐ hint5(T)....65 @glaforge — @paulk_asert

Einstein’s Riddle DSL From:    customer@acme.org To:      Paul King Subject: Project Request Date:    Early morning Dear Paul, Thanks for your Prolog solution but we don’t have Prolog installed. Do you have a version that runs on the JVM? Thanks, Happy Customer66 @glaforge — @paulk_asert

Einstein’s Riddle : Polyglot@GrabResolver(https://oss.sonatype.org/content/repositories/snapshots/)@Grab(org.prolog4j:prolog4j‐api:0.2.1‐SNAPSHOT)@Grab(org.prolog4j:prolog4j‐tuprolog:0.2.1‐SNAPSHOT)import org.prolog4j.*def p = ProverFactory.proverp.addTheory(new File(/GroovyExamples/tuProlog/src/einstein.pl).text)def sol = p.solve("solution(Persons).")println sol.get(Persons)67 @glaforge — @paulk_asert

Einstein’s Riddle DSL … From:    customer@acme.org To:      Paul King Subject: Project Request Date:    Early morning Dear Paul, Thanks for that version but in terms of  maintaining the rules, we would like a more  fluent expression of the rules rather than  Prolog? Any thoughts? Thanks, Happy Customer68 @glaforge — @paulk_asert

Einstein’s Riddle : Polyglot w/ DSL // define some domain classes and objects enum Pet { dog, cat, bird, fish, horse } enum Color { green, white, red, blue, yellow } enum Smoke { dunhill, blends, pallmall, prince, bluemaster } enum Drink { water, tea, milk, coffee, beer } enum Nationality { Norwegian, Dane, Brit, German, Swede }   dogs = dog; birds = bird; cats = cat; horses = horse a = owner = house = the = abode = person = man = is = to =     side = next = who = different = ignored // some preliminary definitions p = ProverFactory.prover hintNum = 1   p.addTheory(     persons(0, []) :‐ !.     persons(N, [(_Men,_Color,_Drink,_Smoke,_Animal)|T]) :‐ N1 is N‐1, persons(N1,T).     person(1, [H|_], H) :‐ !.     person(N, [_|T], R) :‐ N1 is N‐1, person(N1, T, R). )69 @glaforge — @paulk_asert

Einstein’s Riddle : Polyglot w/ DSL… // define some helper methods (our interface to prolog)  def addPairHint(Map m) {     def from = m.from?.toString()?.toLowerCase()     p.addTheory("""     hint$hintNum([(${from ?: _},${m.color ?: _},${m.drink ?: _},         ${m.smoke ?: _},${m.pet ?: _})|_]).     hint$hintNum([_|T]) :‐ hint$hintNum(T).     """)     hintNum++ }   def addPositionHint(Map m, int pos) {     def from = m.from?.toString()?.toLowerCase()     p.addTheory("""         hint$hintNum(Persons) :‐ person($pos, Persons, (${from ?: _},         ${m.color ?: _},$    {m.drink ?: _},${m.smoke ?: _},${m.pet ?: _})).     """)     hintNum++ }   def addToLeftHint(Map left, Map right) {     p.addTheory("""         hint$hintNum([(_,$left.color,_,_,_),(_,$right.color,_,_,_)|_]).         hint$hintNum([_|T]) :‐ hint$hintNum(T).     """)     hintNum++ } ...70 @glaforge — @paulk_asert

Einstein’s Riddle : Polyglot w/ DSL // now implement DSL in terms of helper methods def the(Nationality n) {     def ctx = [from:n]     [         drinks: { d ‐> addPairHint(ctx + [drink:d]) },         smokes: { s ‐> addPairHint(ctx + [smoke:s]) },         keeps: { p ‐> addPairHint(ctx + [pet:p]) },         rears: { p ‐> addPairHint(ctx + [pet:p]) },         owns: { _the ‐> [first: { house ‐> addPositionHint(ctx, 1) }] },         has: { _a ‐>             [pet: { a ‐> addPairHint(ctx + [pet:a]) }] +                 Color.values().collectEntries { c ‐>                     [c.toString(), { _dummy ‐> addPairHint(ctx + [color:c]) } ]                 }         },         lives: { _next ‐> [to: { _the ‐>             Color.values().collectEntries{ c ‐>                 [c.toString(), { _dummy ‐> addNeighbourHint(ctx, [color:c]) } ]             }         }]}     ] } ...71 @glaforge — @paulk_asert

Einstein’s Riddle : Polyglot w/ DSL// now define the DSLthe man from the centre house drinks milkthe Norwegian owns the first housethe Dane drinks teathe German smokes princethe Swede keeps dogs // alternate ending: has a pet dogthe Brit has a red house  // alternate ending: red abodethe owner of the green house drinks coffeethe owner of the yellow house smokes dunhillthe person known to smoke pallmall rears birds // alternate end: keeps birdsthe man known to smoke bluemaster drinks beerthe green house is on the left side of the white housethe man known to smoke blends lives next to the one who keeps catsthe man known to keep horses lives next to the man who smokes dunhillthe man known to smoke blends lives next to the one who drinks waterthe Norwegian lives next to the blue house72 @glaforge — @paulk_asert

Einstein’s Riddle DSL From:    customer@acme.org To:      Paul King Subject: Project Request Date:    Early morning Dear Paul, That’s great. We even get some code  completion When using an IDE. Is there  anything more we can do to get more  completion? Thanks, Happy Customer73 @glaforge — @paulk_asert

Einstein’s Riddle : Polyglot w/ DSL // now implement DSL in terms of helper methods def the(Nationality n) {     def ctx = [from:n]     [         drinks: { d ‐> addPairHint(ctx + [drink:d]) },         smokes: { s ‐> addPairHint(ctx + [smoke:s]) },         keeps: { p ‐> addPairHint(ctx + [pet:p]) },         ...     ] } ... the German smokes prince the(German).smokes(prince)n = Germanctx = [from: German][drinks: …, smokes: { s ‐> addPairHint([from: German, smoke: s]) }, keeps: …, … addPairHint([from: German, smoke: ] prince]) 74 @glaforge — @paulk_asert

Einstein’s Riddle : Polyglot w/ DSL• Some parts of our DSL are automatically statically inferred, e.g. typing ‘bl’ and then asking for completion yields:• But other parts are not known, e.g. the word ‘house’ in the fragment below: ‘house’ is key for a Map and could be any value75 @glaforge — @paulk_asert

Einstein’s Riddle : Polyglot w/ DSL def the(Color c1) {[     house: { _is ‐> [on: { _the ‐> [left: { _side ‐> [of: { __the ‐>         Color.values().collectEntries{ c2 ‐> [c2.toString(), { _dummy ‐>             addToLeftHint([color:c1], [color:c2])         }]}     }]}]}]} ]} class HousePlaceHolder {     def c1, script     def house(_is) {         [on: { _the ‐> [left: { _side ‐> [of: { __the ‐>             Color.values().collectEntries { c2 ‐>                 [c2.toString(), { _dummy ‐> script.addToLeftHint(                     [color: c1], [color: c2] )}]}         }]}]}]     } } def the(Color c1) { new HousePlaceHolder(c1:c1, script:this) }76 @glaforge — @paulk_asert ‘house’ is now understood

Einstein’s Riddle DSL From:    customer@acme.org To:      Paul King Subject: Project Request Date:    Early morning Dear Paul, That’s fantastic! But we have just started standardizing on Choco as our logic solving engine. I guess we need to start from scratch. Let me know what you think. Thanks, Happy Customer77 @glaforge — @paulk_asert

Einstein’s Riddle : Choco w/ DSL @GrabResolver(http://www.emn.fr/z‐info/choco‐solver/mvn/repository/) @Grab(choco:choco:2.1.1‐SNAPSHOT) import static choco.Choco.* import choco.kernel.model.variables.integer.*   def m = new choco.cp.model.CPModel() m.metaClass.plus = { m.addConstraint(it); m } def s = new choco.cp.solver.CPSolver() choco.Choco.metaClass.static.eq = { c, v ‐> delegate.eq(c, v.ordinal()) } def makeEnumVar(st, arr) {      choco.Choco.makeIntVar(st, 0, arr.size()‐1, choco.Options.V_ENUM) } pets = new IntegerVariable[num] colors = new IntegerVariable[num] smokes = new IntegerVariable[num] drinks = new IntegerVariable[num] nations = new IntegerVariable[num]   (0..<num).each { i ‐>       pets[i] = makeEnumVar("pet$i",   pets)     colors[i] = makeEnumVar("color$i", colors)     smokes[i] = makeEnumVar("smoke$i", smokes)     drinks[i] = makeEnumVar("drink$i", drinks)    nations[i] = makeEnumVar("nation$i",  nations) } ...78 @glaforge — @paulk_asert

Einstein’s Riddle : Choco w/ DSL // define DSL (simplistic non‐refactored version) def neighbours(var1, val1, var2, val2) {     and(         ifOnlyIf(eq(var1[0], val1), eq(var2[1], val2)),         implies(eq(var1[1], val1), or(eq(var2[0], val2), eq(var2[2], val2))),         implies(eq(var1[2], val1), or(eq(var2[1], val2), eq(var2[3], val2))),         implies(eq(var1[3], val1), or(eq(var2[2], val2), eq(var2[4], val2))),         ifOnlyIf(eq(var1[4], val1), eq(var2[3], val2))     ) } iff = { e1, c1, e2, c2 ‐> and(*(0..<num).collect{     ifOnlyIf(eq(e1[it], c1), eq(e2[it], c2)) }) } ... // define the DSL in terms of DSL implementation def the(Nationality n) { def ctx = [nations, n] [     drinks: iff.curry(*ctx, drinks),     smokes: iff.curry(*ctx, smokes),     keeps: iff.curry(*ctx, pets),     rears: iff.curry(*ctx, pets),     owns: { _the ‐> [first: { house ‐> eq(nations[first], n)}] }, ...79 @glaforge — @paulk_asert

Einstein’s Riddle : Choco w/ DSL // define rules m += all pets are different m += all colors are different m += all smokes are different m += all drinks are different m += all nations are different m += the man from the centre house drinks milk m += the Norwegian owns the first house m += the Dane drinks tea m += the German smokes prince m += the Swede keeps dogs // alternate ending: has a pet dog m += the Brit has a red house  // alternate ending: red abode m += the owner of the green house drinks coffee m += the owner of the yellow house smokes dunhill m += the person known to smoke pallmall rears birds // alt end: keeps birds m += the man known to smoke bluemaster drinks beer m += the green house is on the left side of the white house m += the man known to smoke blends lives next to the one who keeps cats m += the man known to keep horses lives next to the man who smokes dunhill m += the man known to smoke blends lives next to the one who drinks water m += the Norwegian lives next to the blue house ...80 @glaforge — @paulk_asert

Einstein’s Riddle : Choco w/ DSL def pretty(s, c, arr, i) {      c.values().find{ it.ordinal() == s.getVar(arr[i])?.value }  }   // invoke logic solver s.read(m) def more = s.solve() while (more) {     for (i in 0..<num) {         print   The              + pretty(s, Nationality, nations, i)         print    has a pet       + pretty(s, Pet, pets, i)         print    smokes          + pretty(s, Smoke, smokes, i)         print    drinks          + pretty(s, Drink, drinks, i)         println  and lives in a  + pretty(s, Color, colors, i) +  house     }     more = s.nextSolution() } Solving Einsteins Riddle: The Norwegian has a pet cat smokes dunhill drinks water and lives in a yellow house The Dane has a pet horse smokes blends drinks tea and lives in a blue house The Brit has a pet bird smokes pallmall drinks milk and lives in a red house The German has a pet fish smokes prince drinks coffee and lives in a green house The Swede has a pet dog smokes bluemaster drinks beer and lives in a white house81 @glaforge — @paulk_asert

FRIDAY 82 @glaforge — @paulk_aserthttp://t3.gstatic.com/images?q=tbn:mgkj1lXpQ2-uWM:http://i298.photobucket.com/albums/mm269/bearyjuicylicious/comments

Nasa Robot From:    customer@acme.org To:      Guillaume Laforge Subject: Project Request Date:    Early morning Dear Guillaume, We’ve got a contract with NASA to send a  rover on Mars. We’d need a DSL to lead  the robot on the rocky soil. Can you  help? Thanks, Happy Customer83 @glaforge — @paulk_asert

Nasa Robot import static Direction.* enum Direction {     left, right, forward, backward } class Robot {     void move(Direction dir) {         println "robot moved $dir"     } } Nothing special here. def robot = new Robot() But can we make it prettier? robot.move left84 @glaforge — @paulk_asert

Nasa Robotpackage projectmars.domainimport static Direction.*enum Direction { left, right, forward, backward }class Robot {    void move(Direction dir) { Some simplistic GroovyShell        println "robot moved $dir"    }} package projectmars.integration def shell = new GroovyShell(this.class.classLoader) shell.evaluate      import projectmars.domain.Robot     import static projectmars.domain.Direction.*          def robot = new Robot()          robot.move left 85 @glaforge — @paulk_asert

…Nasa Robot… package projectmars.domain import static Direction.* enum Direction { left, right, forward, backward } class Robot {     void move(Direction dir) {         println "robot moved $dir"     } } Inject robot into binding def binding = new Binding(robot: new Robot()) def shell = new GroovyShell(this.class.classLoader, binding) shell.evaluate      import static projectmars.domain.Direction.*     robot.move left 86 @glaforge — @paulk_asert

Nasa Robot package projectmars.domain import static Direction.* enum Direction { left, right, forward, backward } class Robot {     void move(Direction dir) {         println "robot moved $dir"     } } /* Inject directions into binding def binding = new Binding(     robot: new Robot(),     left: Direction.left, right: Direction.right,     forward: Direction.forward, backward: Direction.backward) */ def binding = new Binding(     robot: new Robot(),     *:Direction.values().collectEntries { [(it.name()): it] }) def shell = new GroovyShell(this.class.classLoader, binding) shell.evaluate      robot.move left 87 @glaforge — @paulk_asert

…Nasa Robot…package projectmars.domainimport org.codehaus.groovy.control.CompilerConfigurationimport org.codehaus.groovy.control.customizers.*import static Direction.*enum Direction { left, right, forward, backward }class Robot {    void move(Direction dir) { println "robot moved $dir" }}def binding = new Binding(robot: new Robot()) Inject importdef importCustomizer = new ImportCustomizer()importCustomizer.addStaticStars projectmars.domain.Directiondef config = new CompilerConfiguration()config.addCompilationCustomizers importCustomizerdef shell = new GroovyShell(this.class.classLoader, binding, config)shell.evaluate     robot.move left88 @glaforge — @paulk_asert

package projectmars.domain…Nasa Robot…import org.codehaus.groovy.control.CompilerConfiguration import org.codehaus.groovy.control.customizers.* import static Direction.* enum Direction { left, right, forward, backward } class Robot {     void move(Direction dir) { println "robot moved $dir" } } def binding = new Binding(robot: new Robot()) def importCustomizer = new ImportCustomizer() importCustomizer.addStaticStars projectmars.domain.Direction def config = new CompilerConfiguration() config.addCompilationCustomizers importCustomizer def shell = new GroovyShell(this.class.classLoader, binding, config) shell.evaluate      move left  +      def move(dir) {         robot.move dir Can we make ‘robot’ implicit?     } 89 @glaforge — @paulk_asert

package projectmars.domainNasa Robotimport org.codehaus.groovy.control.CompilerConfiguration import org.codehaus.groovy.control.customizers.* import static Direction.* enum Direction { left, right, forward, backward } class Robot {     void move(Direction dir) { println "robot moved $dir" } } def binding = new Binding(robot: new Robot()) def importCustomizer = new ImportCustomizer() importCustomizer.addStaticStars Direction.class.name def config = new CompilerConfiguration() Better ‘robot’ implicit config.addCompilationCustomizers importCustomizer config.scriptBaseClass = RobotBaseScriptClass.class.name def shell = new GroovyShell(this.class.classLoader, binding, config) shell.evaluate      move left abstract class RobotBaseScriptClass extends Script {     void move(Direction dir) {         this.binding.robot.move dir     } }90 @glaforge — @paulk_asert

package projectmars.domainNasa Robotimport org.codehaus.groovy.control.CompilerConfigurationimport org.codehaus.groovy.control.customizers.*import static Direction.*enum Direction { left, right, forward, backward }class Robot {    void move(Direction dir) { println "robot moved $dir" }} Better ‘robot’ implicitdef robot = new Robot()def binding = new Binding(robot: robot, move: robot.&move)def importCustomizer = new ImportCustomizer()importCustomizer.addStaticStars Direction.class.namedef config = new CompilerConfiguration()config.addCompilationCustomizers importCustomizerdef shell = new GroovyShell(this.class.classLoader, binding, config)shell.evaluate     move left91 @glaforge — @paulk_asert

…Nasa Robot shell.evaluate      mOvE lefT Case insensitive? abstract class RobotBaseScriptClass extends Script {     @Delegate @Lazy Robot robot = this.binding.robot          def invokeMethod(String name, args) {         robot."${name.toLowerCase()}"(*args)     } } class CustomBinding extends Binding {     private Map variables          CustomBinding(Map vars) {         this.variables = [             *:vars,              *:Direction.values().collectEntries { [(it.name()): it] }         ]     }          def getVariable(String name) {         variables[name.toLowerCase()]     }92 } @glaforge — @paulk_asert

package projectmars.domainNasa Robot import org.codehaus.groovy.control.CompilerConfiguration import org.codehaus.groovy.control.customizers.* import groovy.transform.TupleConstructor import static Direction.* import static Duration.* enum Direction {     left, right, forward, backward } enum Unit {     centimeter (cm, 0.01), Going further?     meter      ( m,    1),     kilometer  (km, 1000)         String abbreviation     double multiplier          Unit(String abbr, double mult) {         this.abbreviation = abbr         this.multiplier = mult     }          String toString() { abbreviation } } …93 @glaforge — @paulk_asert

… …Nasa Robot…enum Duration { hour }@TupleConstructor …class Distance { class DistanceCategory {    double amount     static Distance getCentimeters(Number num) {    Unit unit         new Distance(num, Unit.centimeter)         }    Speed div(Duration dur) {     static Distance getMeters(Number num) {        new Speed(amount, unit)         new Distance(num, Unit.meter)    }     }         static Distance getKilometers(Number num) {    String toString() { "$amount$unit" }         new Distance(num, Unit.kilometer)}     }     static Distance getCm(Number num) { getCentimeters(num) }@TupleConstructor     static Distance getM(Number num)  { getMeters(num) }class Speed {     static Distance getKm(Number num) { getKilometers(num) }    double amount }    Unit unit     class Robot {    String toString() { "$amount $unit/h" }     void move(Direction dir) {}         println "robot moved $dir"…     }     void move(Direction dir, Distance d) {         println "robot moved $dir by $d"     }     void move(Map m, Direction dir) {         println "robot moved $dir by $m.by at ${m.at ?: 1 km     } } … 94 @glaforge — @paulk_asert

…Nasa Robot… … def binding = new Binding(robot: new Robot(), h: Duration.hour) def importCustomizer = new ImportCustomizer() importCustomizer.addStaticStars Direction.class.name def config = new CompilerConfiguration() config.addCompilationCustomizers importCustomizer config.scriptBaseClass = RobotBaseScriptClass.class.name def shell = new GroovyShell(this.class.classLoader, binding, config) use(DistanceCategory) { shell.evaluate      move left     move right, 3.meters     move right, by: 3.meters     move right, by: 3.meters, at: 5.km/h } abstract class RobotBaseScriptClass extends Script {     @Delegate @Lazy Robot robot = this.binding.robot }95 @glaforge — @paulk_asert

Nasa Robot Going even further? shell.evaluate      move left     move right, 3.meters       move right, by: 3.meters     move right, by: 3.meters, at: 5.km/h       move right by 3.meters at 5.km/h         deploy left arm 96 @glaforge — @paulk_asert

Domain-Specific Language Descriptors• DSLs are nice, but what about support in my IDE?• DSLD to the rescue – Domain-Speciﬁc Language Descriptors – for Eclipse STS (but GDLS concent available in IntelliJ IDEA too)• Idea: a DSL for describing DSLs, in order to provide – code-completion – code navigation – documentation hovers97 @glaforge — @paulk_asert

Domain-Specific Language Descriptors98 @glaforge — @paulk_asert

Domain-Specific Language Descriptors currentType( subType( Number ) ).accept {     [m: "meter", yd: "yard", cm: "centimeter", mi: "mile", km: "kilometer"].each {         property name:it.key, type:"Distance",             doc: """A <code>${it.value}</code> from <a href="$url">$url</a>"""     } }98 @glaforge — @paulk_asert

Important business meetings all afternoon! 99 @glaforge — @paulk_aserthttp://www.flickr.com/photos/bobswanson/5093775403/sizes/l/in/pool-52240148330@N01/

@paulk _asert@ glaforge

Image credits• Pros and Cons: http://allrmc.com/images/pros_cons.gif• Bicycle: http://drunkcyclist.com/gallery/main.php?g2_view=core.DownloadItem&g2_itemId=2131&g2_serialNumber=2• Pills: http://www.we-ew.com/wp-content/uploads/2011/01/plan-b-pills.jpg• Chains: http://2.bp.blogspot.com/-GXDVqUYSCa0/TVdBsON4tdI/AAAAAAAAAW4/EgJOUmAxB28/s1600/breaking-chains5_copy9611.jpg• Stock exchange graph: http://www.inet.mn/ispages/isimage/inetnews/y80ni17/42349_77215.jpeg• Nuclear plant: http://www.exponent.com/files/Uploads/Images/Energy/nuclear%20plant.jpg• Dollars: http://padma-bali.com/wp-content/uploads/2011/04/Online-Payday-Loan-1.jpg• Insurance: http://lemeilleurtauxcredit.fr/wp-content/uploads/insurance.jpg• HR: http://www.montekservices.com/wp-content/uploads/2011/08/HR-outsourcing.jpg• Bacteria: http://www.editionsmondialis.com/wp-content/uploads/2010/11/malaria-red.jpg• Email: http://www.tenso.fr/emarketing/wp-content/uploads/2011/02/email.jpg• Thank you: http://www.teachermum.com/wp-content/uploads/2011/07/thank-you1.jpg•102 @glaforge — @paulk_asert
