Solr @ Etsy - Apache Lucene Eurocon

Things I’m not going to talk about: A/B Testing i18nContinuos Deployment

About Us

10+ Million Listings 500 qps

Architecture Overview

Architecture OverviewThrift

Architecture OverviewThrift struct Listing { 1: i64 listing_id } struct ListingResults { 1: i64 count, 2: list<Listing> listings } service Search { ListingResults search(1:string query) }

Architecture OverviewThriftGenerated Java server code: public class Search { public interface Iface { public ListingResults search(String query) throws TException; }Generated PHP client code: class SearchClient implements SearchIf { /**...**/ public function search($query) { $this->send_search($query); return $this->recv_search(); }

Architecture OverviewThriftWhy use Thrift? • Service Encapsulation • Reduced Network Traﬃc

Architecture OverviewThriftWhy only return IDs? • Index Size • Easy to scale PK lookups

The Search Server

Architecture OverviewSearch Server • Identical Code + Hardware • Roles/Behavior controlled by Env variables • Single Java Process • Solr running as a Jetty Servlet • Thrift Servers • Smoker

Architecture OverviewSearch ServerMaster-speciﬁc processes: • Incremental Indexer • External File Field Updaters

Load Balancing

Load BalancingThrift TSocketPool

Load BalancingServer Aﬃnity

Load Balancing Server Aﬃnity Algorithm$serversNew = array(); [“host2”, “host3”, “host1”, “host4”]$numServers = count($servers);while($numServers > 0) { // Take the first 4 chars of the md5sum of the server count // and the query, mod the available servers $key = hexdec(substr(md5($numServers . + . $query),0,4))%($numServers); $keySet = array_keys($servers); $serverId = $keySet[$key]; // Push the chosen server onto the new list and remove it // from the initial list array_push($serversNew, $servers[$serverId]); unset($servers[$serverId]); --$numServers;}

Load BalancingServer Aﬃnity Algorithm $key = hexdec(substr(md5($query),0,4)) “jewelry” [“host2”, “host3”, “host1”, “host4”] “scarf” [“host2”, “host3”, “host1”, “host4”]

Load BalancingServer Aﬃnity Algorithm $key = hexdec(substr(md5($numServers . + . $query),0,4))%(count($servers)); “jewelry” [“host2”, “host3”, “host1”, “host4”] “scarf” [“host2”, “host1”, “host4”, “host3”]

Load BalancingServer Aﬃnity Results 2% 20%

Load BalancingServer Aﬃnity Caveats • Stemming / Analysis • Be wary of query distribution

Replication

ReplicationThe Problem

ReplicationMulticast Rsync?

ReplicationMulticast Rsync?[15:25] <engineer> patrick: im gonna test multi-rsyncing some indexesfrom host1 to host2 and host3 in prod. Ill be watching the graphs andwhat not, but let me know if you see anything funky with the network[15:26] <patrick> ok....[15:31] <keyur> is the site down?

ReplicationMulticast Rsync?

Hmm...Bit Torrent?

ReplicationBit Torrent POCUsing BitTornado:

ReplicationBit Torrent + SolrFork of TTorent: https://github.com/etsy/ttorrent Multi-File Support Performance Enhancements

ReplicationBit Torrent + Solr

Solr InterOp

QParsers

“writing query strings is for suckers”

Solr InterOpQParsers http://host:8393/solr/person/select/?q=_query_:%22{!dismax %20qf=$fqf%20v=$fnq}%22%20OR%20(_query_:%22{!dismax%20qf=$fiqf %20v=$fiq}%22%20AND%20(_query_:%22{!dismax%20qf=$lwqf%20v=$lwq} %22%20OR%20_query_:%22{!dismax%20qf=$lqf%20v=$lq}%20%22))&fnq= %22giovanni%20fernandez-kincade %22&fqf=full_name^4&fiq=giovanni&fiqf=first_name^2.0%20first_name_s yn&qt=standard&lwq=fernandez-kincade*&lwqf=last_name&lq=fernandez- kincade&lqf=last_name^3

Solr InterOpQParsers http://host:8393/solr/person/select/?q={!personrealqp}giovanni %20fernandez-kincade

Solr InterOpQParsers class PersonNameRealQParser extends QParser { public PersonNameRealQParser(String qstr, SolrParams localParams, SolrParams params, SolrQueryRequest req) { super(qstr, localParams, params, req); }

Solr InterOp QParsers @Override public Query parse() throws ParseException { TermQuery exactFullNameQuery = new TermQuery(new Term("full_name", qstr)); exactFullNameQuery.setBoost(4.0f); String[] userQueryTerms = qstr.split("s+"); Query firstLastQuery = null; if (2 == userQueryTerms.length) firstLastQuery = parseAsFirstAndLast(userQueryTerms[0], userQueryTerms[1]); else firstLastQuery = parseAsFirstOrLast(userQueryTerms); DisjunctionMaxQuery realNameQuery = new DisjunctionMaxQuery(0); realNameQuery.add(exactFullNameQuery); realNameQuery.add(firstLastQuery); return realNameQuery; }

Solr InterOpQParsersThe QParserPlugin that returns our new QParser: public class PersonNameRealQParserPlugin extends QParserPlugin { public static final String NAME = "personrealqp"; @Override public void init(NamedList args) {} @Override public QParser createParser(String qstr, SolrParams localParams, SolrParams params, SolrQueryRequest req) { return new PersonNameRealQParser(qstr, localParams, params, req); } }

Solr InterOpQParsersRegistering the plugin in solrconﬁg.xml: <queryParser name="personrealqp" class="com.etsy.person.solr.PersonNameRealQParserPlugin" />

Custom Stemmer

Solr InterOpCustom Stemmer

Solr InterOpCustom Stemmer banded, banding, birding, bouldering, bounded, buﬃng, bundler, canning,carded, circled, coupler, dangler, doubler, ﬁrring, foiling, hooper, japanned,lipped, napped, papered, pebbled, pitted, pocketed, reductive, ricer, rooter,roper, seeded, shouldered, silvered, skinning, spindling, staining, stitcher, strapped, threaded, yellowing

Solr InterOpCustom StemmerFirst we extend KStemmer and intercept stem calls: public class LStemmer extends KStemmer { /**.....**/ @Override String stem(String term) { String override = overrideStemTransformations.get(term); if(override != null) return override; return super.stem(term); } }

Solr InterOp Custom StemmerThen create a TokenFilter that uses the new Stemmer: final class LStemFilter extends TokenFilter { /**.....**/ protected LStemFilter(TokenStream input, int cacheSize) { super(input); stemmer = new LStemmer(cacheSize); } @Override public boolean incrementToken() throws IOException { /**....**/ }

Solr InterOpCustom StemmerCreate a FilterFactory that exposes it: public class LStemFilterFactory extends BaseTokenFilterFactory { private int cacheSize = 20000; @Override public void init(Map<String, String> args) { super.init(args); String cacheSizeStr = args.get("cacheSize"); if (cacheSizeStr != null) { cacheSize = Integer.parseInt(cacheSizeStr); } } @Override public TokenStream create(TokenStream in) { return new LStemFilter(in, cacheSize); } }

Solr InterOpCustom StemmerAnd ﬁnally plug it into your analysis chain: <analyzer> <tokenizer class="solr.WhitespaceTokenizerFactory"/> <filter class="solr.ASCIIFoldingFilterFactory"/> <filter class="solr.StopFilterFactory" ignoreCase="true" words="solr/common/conf/stopwords.txt"/> <filter class="com.etsy.solr.analysis.LStemFilterFactory" /> <filter class="solr.RemoveDuplicatesTokenFilterFactory"/> </analyzer>

Thanks!
