Applying Complex Event Processing        with Drools Fusion                                Edson Tirelli                  ...
Agendao   Brief introduction on CEP and Terminologyo   Drools Visiono   Drools Fusion: Complex Event Processing extensions...
Terminology: Event“An event is an observable occurrence.”“An event in the Unified Modeling Language is a  notable occurren...
Terminology: EventFor the scope of this presentation: “An event is a significant change of   state at a particular point i...
Terminology: Complex Event    “Complex Event, is an abstraction of other events      called its members.”o   Examples:    ...
Terminology: CEP“Complex Event Processing, or CEP, is primarily  an event processing concept that deals with the  task of ...
Terminology: CEPo   Examples:    o   Emergency Response Systems    o   Credit Card Fraud Detection    o   Logistics Real-T...
Terminology: CEP vs ESP    Complex Event Processing, or CEP, and Event     Stream Processing, or ESP, are two     technolo...
Terminology: CEP and ESPFor the scope of this presentation:    “CEP is used as a common term      meaning both CEP and ESP.”
Terminology: EDA“Event Driven Architecture (EDA) is a software architecture  pattern promoting the production, detection, ...
EDA vs CEP                    CEP is a component of the EDASource: http://elementallinks.typepad.com/.shared/image.html?/p...
EDA vs SOAo   EDA is **not** SOA 2.0o   Complementary architectureso   Metaphor     o In our body:         o SOA is used t...
EDA vs SOASource: http://soa-eda.blogspot.com/2006/11/how-eda-extends-soa-and-why-it-is.html
Complex Event Processingo   A few characteristics of common CEP scenarios:     o Huge volume of events, but only a few of ...
Drools Vision“A common platform to model and govern the     business logic of the enterprise.”
Drools Fusion: Enables…•   Event Detection:     • From an event cloud or set of streams, select all the       meaningful e...
Drools Fusiono   Features:     o Event Semantics as First Class Citizens     o Allow Detection, Correlation and Compositio...
Demoo   Twitter Stream CEP Demo:     o Listen to the Twitter Stream API         Twitter4J API         Listens to a rando...
Event Declaration and Semantics// declaring existing classimport some.package.VoiceCall                                o  ...
Temporal Reasoningo   Semantics for:    o time: discrete    o events: point-in-time and intervalo   Ability to express tem...
Temporal Relationshipsrule “Shipment not picked up in time”when  Shipment( $pickupTime : scheduledPickupTime )  not Shipme...
Temporal Relationshipsrule “Shipment not picked up in time”when  Shipment( $pickupTime : scheduledPickupTime )  not Shipme...
Allen’s 13 Temporal Operators                    Point-Point   Point-Interval   Interval-Interval                A A befor...
Allen’s 13 Temporal Operators                      Point-Point   Point-Interval   Interval-Interval                  A   A...
Streams : Simple Example Scenario
Stream Support (entry-points)o   A scoping abstraction for stream support     o Rule compiler gather all entry-point decla...
Cloud Mode, Stream Mode, Session Clock             CLOUD                             STREAM•   No notion of “flow of time”...
Reference Clocko   Reference clock defines the flow of timeo   Named Session Clock    o is assigned to each session create...
Session Clocko Uses the strategy pattern and multiple implementations:   o Real-time operation   o Tests   o Simulations  ...
Session Clocko Selecting the session clock:   o API:      KnowledgeSessionConfiguration conf = ...      conf.setOption( Cl...
Sliding Window Supporto   Allows reasoning over a moving window of “interest”     o Time     o Length                     ...
Sliding Window Supporto   Allows reasoning over a moving window of “interest”     o Time     o Length                     ...
Sliding Window Supporto   Allows reasoning over a moving window of “interest”     o Time     o Lengthrule “Average Order V...
Delaying Ruleso Negative patterns may require rule firings to be delayed.rule “Order timeout”rule “Order timeout”whenwhen ...
Delaying Ruleso Negative patterns may require rule firings to be delayed.rule “Order timeout”rule “Order timeout”whenwhen ...
Temporal Dimensiono   Requires the support to the temporal dimension    o A rule/query might match in a given point in tim...
Temporal Dimension Supporto   CEP scenarios are stateful by nature.o   Events usually are only interesting during a short ...
Simple Example Rulerule “Bag was lost”rule “Bag was lost”whenwhen      $b : BagScannedEvent() from entry-point “check-in” ...
Abstract Example Rulerule “Abstract event relationship example”rule “Abstract event relationship example”whenwhen      $a ...
Temporal Dependency Matrix        [-2,2]          B          [1,2]                                                        ...
Q&Ao   Drools project site:     o http://www.drools.org ( http://www.jboss.org/drools/ )o   Documentation:     o http://ww...
