Flex For Java Architects Ledroff Breizh Jug V Blog Cc

François Le Droff “Just another Java guy” Adobe Technology and Service Innovation Ad b T h l dS i I i 10 years in IT web 1+n.0) OSS geek : OS projects : qsos, xradar , fna, Member of ossgtp, ParisJUG, ParisJBUG Speaker at MAX, et Solution Linux blogs : http://www.droff.com http://blogs.adobe.com/francoisledroff/ p g ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

What about you? Java ! Spring, JEE ? ORM (JPA, EJB, iBatis, Hibernate) ? UnitTest (JUnit, TestNG, …) ? Ant and/or Maven ? Hudson, CC ? Flex ? ActionScript MXML Flex Remoting, AMF e e ot g, And may be BlazeDS, LCDS FlexUnit Cairngorm ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

The RIA leader technology: Adobe Flex 3 ADOBE FLEX 3 Action Script 3 MXML Free, open source framework Less time needed to develop Expressive, highly interactive apps X-platform, consistent deployment ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Adobe Flex Builder 3 Eclipse plugin Code hinting, debugging WYSIWYG Design view Memoruy and performance profilers SDK FB : Charting components advanced components, datagrid Testing Support ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Flex app development and deployment Flex Builder IDE Browser Flex SDK Flash Player MXML ActionScript Flex Class Library SOAP HTTP/S AMF/S RTMP/S Web Server Compile XML/HTTP LC Data Services REST SOAP Web Services J2EE Application Server Existing Applications & Infrastructure ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Flex Frameworks and Tools: Developing Flex IDEs Eclipse FlexBuilder Code completion, refactoring, graphical UI editing, profiling Enterprise Factory IDE Peter Martin’s Cairngorm plug-in (soon) IDEA IntelliJ Netbeans Plugin ? g vi, emacs ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Flex Frameworks and libraries MVC frameworks: PureMVC Cairngorm micro-architecture There are two libraries you can use to create your Cairngorm projects Cairngorm – This is the main Cairngorm library that must always be imported Cairngorm Enterprise - This is an optional library that must be used if you are using LCDS Cairngorm Enterprise was created to remove Cairngorm’s Dependency on LCDS EnterpriseServiceLocator provides support for LCDS Producer and Consumer ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Flex Frameworks and libraries Inversion of Control (IoC) Container : flicc: http://flicc sourceforge net http://flicc.sourceforge.net parsley: http://www.spicefactory.org/parsley smarty pants: http://code.google.com/p/smartypants-ioc LowRA: http://osflash.org/projects/lowra prana: http://www.pranaframework.org SpringActionScript swiz: http://code google com/p/swizframework http://code.google.com/p/swizframework vegas: http://code.google.com/p/vegas fling: http://fling.riaforge.org flex-ioc: http://code.google.com/p/flex-ioc Many others interesting initiatives on top of flex frameworks Anvil Mate ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Flex Frameworks and libraries Lots of AS3 and Flex OS components Lots of commercial Flex components f ll Flex Ecosystem is expanding very quickly following a similar path to Enterprise Java ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Flex Logging and Debugging Similar to LOG4J, Flex 3 includes a logging framework to define custom Log targets. gg ThunderBolt AS3 : custom Flex log target log to Firebug in Firefox or to a stand alone AIR console. Many tools to inspect the component at runtime • try KapIT lab tools • ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Flex code generation and quality tools Code Generation XDoclet : ActionScript Plugin @actionscript.class flex-annotations.aixcept.net annotations: @ActionScript @Cairngorm Flex-mojos JAXB MDA (acceleo plugin made by AC) … Code Quality control FlexPMD (work in progress engaged by AC) AS3NCSS (work in progress engaged by AC) ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Flex Frameworks and Tools: Unit Testing FlexUnit Very similar to JUnit Event test enabled Fluint : http://code.google.com/p/fluint/ p gg p ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Flex Frameworks and Tools: Testing Functional Testing Selenium for Flash Fluint, FlexMonkey, FunFX, … Other commercial products based on Adobe’s Flex Automation API : p Mercury QTP IBM Rational Functional Tester RIATest Load and Stress Testing JMeter, OpenSTA, Grinder Adobe’s Data Services Stress Testing Framework Other commercial (Flex/AMF specific) products : NeoLoad WebLoad ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Flex Frameworks and Tools: Building Ant : FlexAntTasks Ant : Antennae Maven : M • Flex-mojos • Alternatives : • • ServeBox • and Israfil Archetypes • ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Flex Frameworks and Tools: Building : Quality Quality Reports within your build AS3NCSS http://localhost:9999/hudson/job/cairngorm/site/javancss.html FlexPMD http://localhost:9999/hudson/job/cairngorm/12/pmdResult/ ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Feature Comparison BlazeDS LiveCycle Data Services ES Feature √ √ Java Remoting √ √ Web Proxy b √ √ JMS Adapter √ √ AJAX Client Libraries √ √ Administrative Console √ √ Clustered Messaging √ √ Pub/Sub Messaging Web container based messaging service (100 s of container-based (100’s √ √ clients/CPU) √ Dedicated messaging service (1000’s of clients/CPU) √ Per-client Quality of Service √ Data Management Service √ Data Paging √ Flex-LiveCycle Integration √ RIA-to-PDF Generation √ Offline Data Synchronization (AIR) √ WSRP/Portal Integration √ SiteMinder Integration ® 32 Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Fna ! http://code.google.com/p/fna/ Fna is a set of samples, mavenized flex open source contributions (cf. flex-contrib-spring and event-source) and maven archetypes that uses open source tools/frameworks b il on top of J l /f k built f Java and Fl d Flex ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

What’s Maven again ? (very short definition) A build tool • A dependency management tool A documentation and quality • reporting tool l ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

What is Maven anyway ? (its architecture) Plugin jar Projects Plugin Maven Core to build flex-mojos flex mojos Plugin war Local machine Remote repository or local install ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

What is Maven anyway ? (its plug-ins, a few of them…) • Antlr • Ear • Javancss • Release • Ant • Eclipse • Jboss • Repository • AntRun • Ejb • Jcoverage Jdepend • Resources • AspectJ • Ejb3 • Jdiff • Repository • Assembly • Exec • Jelly y • Sablecc • Assembly-report • Flex-mojos • Jetty • Site • Cargo • Flex-annotations • Jpox • Slimdog • Castor • Groovy • Jspc • Source • Changelog • Help • Jxr • Surefire • Changes • Hibernate2 • MAnt • Surefire-report • Commons-attributes • Idea • Native • Taglist • Checkstyle • Install • One • Tomcat • Clean • Issue • Par • Verifier • Clover • It • Plugin • Xslt • Csharp • Jalopy • Pmd • War • Cobertura • Jar • Project-info-reports • Wsdl2java • Compiler p • Javacc • Rar • Xdoclet • Deploy • Javadoc • Xmlbeans • XRadar ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

What is Maven anyway ? (a common project format and organization) Maven is really a process of applying patterns to a build infrastructure in order to provide a coherent view of software projects. A Common project metadata format POM = Project Object Model = pom.xml j j p Contains metadata about the project Location of directories, Developers/Contributors, Issue tracking system, Dependencies, Repositories to use etc use, ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

What is Maven anyway ? (a common project format and organization) A common directory organization Our sample of 6 nested projects : • src/ / – main/ • java/ • flex/ • resources/ • webapp/ – test/ • java/ • flex/ • resources/ – site/ ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

What is Maven anyway ? (a common way to build application) generate- sources mojo j compile mojo test mojo plug-ins package integration- test tt mojo user install mojo e.g. mvn install g bindings g deploy Well-known phases The lifecycle depends on the project type (packaging) Defined in pom.xml (pom, jar, ear, war, etc) Ex: <packaging>swc</packaging> p gg /p gg ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

What is Maven anyway ? (it’s even much more) Artifact repository : Used to store all kind of artifacts SWCs, SWFs, JARs, EARs, WARs, EJBs, ZIPs, plugins, … All project interactions go through the repository No more relative paths! Easy to share between teams A Dependency management Transitive dependency management p y g Snapshot handling B C Multi-module built D Environment dependent builds based on profile Project documentation site and report j Project templating through archetype ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Maven : Archetypes Archetype is a Maven project templating toolkit. an original pattern or model from which all other things of the same kind are made. made provides a great way to enable developers quickly in a way consistent with best practices employed by your project or organization http://maven.apache.org/plugins/maven-archetype-plugin/index.html ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Fna flex-library-archetype-archetype Demo mvn archetype:generate -DarchetypeVersion=1.3-SNAPSHOT -DarchetypeGroupId=com.adobe.ac -DarchetypeArtifactId=flex-library-archetype -DarchetypeRepository=http://fna.googlecode.com/svn/trunk/fna/fna_m2_repository/ DarchetypeRepository=http://fna googlecode com/svn/trunk/fna/fna m2 repository/ ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

flex-library-archetype-archetype : FlexBuilder support Import your generated project into eclipse The eclipse and FB are already generated for you yg y ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

How do I integrate Flex, BlazeDS, and Spring ? (with ( h Maven) ) How do I write less code through maven archetype flex annotation code generation and auto-wiring techniques? ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

I use Fna Blazeds-autowired-spring-hibernate-archetype It helps you generate a multi-module maven project : a f front- flex f end application communicating with the backend through Adobe's BlazeDS It showcases lots of tips and tricks on BlazeDS, Spring Integration ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Spring / BlazeDS / LCDS Spring (Hibernate JPA) with Flex through BlazeDS BlazeDS remoting SpringFactory gp g y Auto-wired spring service bean into BlazeDS remoting NB: Recent fna non-related news on spring : http://www.springsource.org/spring-flex http://blog.springsource.com/2008/12/17/using-spring-blazeds-integration-m1/ http://coenraets.org/blog/2009/01/new-springblazeds-integration-test-drive/ ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Maven and Flex Spring BlazeDS Flex application With Maven (FlexMojos) Code generation through flex-annotation FlexUnit ASDoc, Dependency management, Quality control ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Fna Demo– Project Generation and Build Objectives Generate a project through a maven archetype yp Build, deploy and test (on jetty and hsqldb) ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Generate and Build your project (2mn) mvn archetype:generate -DarchetypeVersion=1.3-SNAPSHOT - • DarchetypeGroupId=com.adobe.ac -DarchetypeArtifactId=blazeds-autowired-spring- hibernate-archetype hibernate archetype - DarchetypeRepository=http://fna.googlecode.com/svn/trunk/fna/fna_m2_repository/ ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

A Maven multi-module project approach Discover your « mavenized » Flex BlazeDS Spring project, its modules : java_* are plain old maven java projects flex_* are flex-mojos project blazeds _service_config is a shared resource handled through maven assembly service config ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Deploy and test your project (2mn) Go to the newly created project root • Launch the build : • mvn install • Go the java web application module root to deploy your web application on • a jetty instance : mvn jetty:run • ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Cairngorm applied to Flex N Spring ToDoList Add a Contact Contact list FrontController Arthur Ford Ford- ford@perfect.com Zaphod – zaphod@email.com Arthur – arthur@dent.com arthur@dent.com Tricia– tricia@mcmillan.com CMD CMD CMD Marvin = marvin@email.com Add a Contact Business Delegate model.getTodoList TodoList TodoListPModel + saveItem + removeItem ToDoList Service Service Spring Auto Wiring Service Service Service Cairngorm Event E t Presentation Domain Layer Integration Tier View Layer Layer L ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

A few magic details : Spring AutoWiring With a simple SpringFactory (and/or JavaAdapter) approach, you need to configure each new Java remote object service in remoting-config.xml. g j g g @RemotingDestination (JDK5 annotation) allows you to autowire Spring beans directly into BlazeDS. ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

A few magic details : Spring AutoWiring The SpringAutowiringBootstrapService checks all @RemotingDestination annotated classes registers them within BlazeDS at runtime. dynamically creates the Spring Factory. ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

VO Code Generation The flex remoted objects are generated through flex-annotations Just add to your java remoted object @ActionScript and @ActionScriptProperty annotations ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Maven and Spring for Flex : Summary This maven and spring integration approach allows you to capitalize on your in-house Java/JEE/Maven/Spring expertise techniques and tools in house expertise, write less code (Most of the integration plumbing is generated) rely on a efficient build (continuous integration, test, dependencies and quality checks, documentation, release) The price to enter : Time consuming t k t i iti t th project : Ti i tasks to initiate the jt set up the project (modules) structure organization Write your build file, your somehow complex pom.xml files : y ,y pp configure/identify the classpath , project dependencies, maven plugins configure the code generation and autowiring tools The Solution: eliminate the ramp-up time by using fna maven archetype You still have to configure Eclipse (and FB) the « maven » way ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Resources: Learning Flex ActionScript Developer Site- http://www.adobe.com/devnet/actionscript/ Flex Developer Site - http://www adobe com/devnet/flex/ http://www.adobe.com/devnet/flex/ Flex Development Guide - http://learn.adobe.com/wiki/display/Flex/Getting+Started Flex 3 Language Reference – http://livedocs.adobe.com/flex/3/langref/ LiveCycle Data Services ES - http://www.adobe.com/products/livecycle/dataservices/ BlazeDS Blaze DS - http://www adobe com/go/opensource blazeds http://www.adobe.com/go/opensource_blazeds Blaze DS Developer Guide - http://livedocs.adobe.com/blazeds/1/blazeds_devguide Blaze DS Javadoc - http://livedocs.adobe.com/blazeds/1/javadoc/ Adobe Labs - http://labs.adobe.com/ ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Resources: Learning LiveCycle Data Services ES LiveCycle Data Services ES - http://www.adobe.com/products/livecycle/dataservices/ LCDS ES Developer Guide - http://www adobe com/go/lcds26 devguide http://www.adobe.com/go/lcds26_devguide LCDS ES Javadoc - http://livedocs.adobe.com/livecycle/8.2/programLC/programmer/javadoc/index. html LiveCycle Data Services ES Language Reference - http://livedocs.adobe.com/livecycle/8.2/programLC/common/langref/index.html LCDS ES Stress Testing Framework - http://labs.adobe.com/wiki/index.php/Flex_Stress_Testing_Framework ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Resources: Frameworks and Tools Frameworks Cairngorm - http://opensource adobe com/wiki/display/cairngorm/Cairngorm http://opensource.adobe.com/wiki/display/cairngorm/Cairngorm PureMVC – http://puremvc.org Prana - http://www.pranaframework.org Code Generation: Flex-annotations http://flex-annotations.aixcept.net/ XDoclet ActionScript plugin http://xdoclet.codehaus.org/Actionscript+plugin Acceleo http://www.acceleo.org/pages/accueil/en Spring flex integration projects @RemotingDestination annotation : http://marceloverdijk.blogspot.com/2008/01/code-by-convention-with-flex-and- http://marceloverdijk blogspot com/2008/01/code by convention with flex and spring.html ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Resources: Frameworks and Tools Building Maven Maven archetype: http://maven.apache.org/plugins/maven-archetype-plugin/index.html Maven presentations : http://blogs.codehaus.org/people/vmassol/ Maven Flex plugins: Flex-mojos htt //d Fl j http://docs.flex-mojos.info/ fl j if/ ServeBox http://www.servebox.com/foundry/doku.php?id=m2f2plugin Israfil http://www.israfil.net/projects/mojo/maven-flex2-plugin p // /p j / j/ pg Maven Flex (flex-mojos) archetypes: http://code.google.com/p/fna/ http://blogs.adobe.com/francoisledroff/ http://code.google.com/p/maven-blazeds-spring-archetype/ Flex-Mojo tutorial Fl M j t t i l The Flex, Spring and BlazeDS full stack http://www.adobe.com/devnet/flex/articles/fullstack_pt3_print.html p _p _p ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

Resources: Frameworks and Tools Building Ant Antennae - http://code google com/p/antennae/ http://code.google.com/p/antennae/ Testing FlexUnit - http://opensource.adobe.com/wiki/display/flexunit/FlexUnit p // p / / p y/ / Flexcover - http://code.google.com/p/flexcover/ ThunderBolt AS3 Console - http://code.google.com/p/flash- thunderbolt/wiki/ThunderBoltAS3Console th d b lt/ iki/Th d B ltAS3C l Libraries Google Code – Lots of Flex libraries and frameworks Flex.org - http://flex.org/software/components ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.

References : Creative Commons and other open source graphics and photos remixed here http://commons.wikimedia.org/wiki/Image:Netbeans-Duke.png https://duke.dev.java.net/images/comfyChair/index.html http://flickr.com/photos/nicozz/1107511223/ http://flickr.com/photos/flattop341/1085739925/ http://flickr com/photos/flattop341/1085739925/ http://blog.xebia.fr/2008/09/16/blazeds/ http://www.breizhjug.org/ jg g ® Copyright 2008 Adobe Systems Incorporated. All rights reserved.
