Ifpl Platmaking Equipment

Photopolymer plate Making Process

Basic information for plate making
Photopolymer Plate

Raw plate structure Protective layer Cover sheet
Photopolymer
Base film

platemaking workflow Back-flash Exposure Main Exposure CL(UVA) Exposure GL(UVC) Exposure Exposure Wash-out Job preparation Drying and Stabilising Post / Anti-tack Exposure Plate Quality Control

platemaking workflow Frame Units Control Job Preparation Vacuum sheet Lamp condition Solvent condition All lamps Cleaning 1 Step Check Preheat

Platemaking workflow Matt Negative film quality check Job Preparation 0.04 max (Fogging) 4.00 min (Solid) DPI %/ LPI Film type Film Density 1 Step Resolution Cleanliness

platemaking workflow Exposure / Backflash 2 Step Floor layer formation inside the plate

platemaking workflow Exposure / Main 2 Step Dot formation and anchorage on base

platemaking workflow Plate Wash-out 3 Step Dissolution of the unhardened photopolymer

platemaking workflow Drying and stabilizing 4 Step Evaporation of the remaining solvent kept in the plate

platemaking workflow Antitack treatment 5 Step Treatment of the surface tackiness by UVC light

platemaking workflow Plate QC Plate Quality Control No Missing dots No Filling in No Tackiness No Cracks No Dusts Relief depth 6 Step Repro Thickness State surface

Printing plate structure Plate thickness Relief depth Floor layer

Innovative Flexotech Pvt. Ltd. www.flexo.co.in
International Standard Technology
High Standard Reproduction Capability
Machinery Manufacturing Expertise More than 20Years In flexo
Prompt After sales Support
Competitive Price
Photopolymer plate making Equipments For
Flexography
Water wash –Flexo
Letterpress
Varnishing
Solvent Recovery
Laserblack Enhancer

@Flexogroup Production Information
Photopolymer plate Making Equipments
Production Catalouge
Regular Line 2430 ,3040 ,4050
Featuers Of Equipments
Four In One Model (SS and Compact)
Solvent Recovery System

Photopolymer Plate Equipment Reguler Line
Model
24 x30 (610 x 762 )
30x40 (762 X 1016)
40x50 ( 1016 x 1270 )
ET Model
Exposure +Treatment
WD Model
Washout +Dryer

Special features Plates suitable: DuPont, Kodak, BASF, Okaflex, AFP, JET etc. For printing: Label, film, paper, corrugated board, paper carton, knitting bag, Tetra pak etc .
Features of Exposure unit -Instant light up Philips high intensity lamps - Unique digital timers for back/main exposure -Excellent lamps cooling / exhausting system - Quick vacuum drawdown pump with indicator
Features of Washout unit -Very easy access design - Special bristle good for all kind plates washout -Suitable for Perc+NBA and Green chemicals - Excellent result for 175 LPI 1% reproduction
Features of Drying unit -Drying drawer with uniform heat distribution - Temperature adjustable by a precise controller -Unique air circulation and exhaustion design - Over heat sensor for safety and protection
Features of Treatment unit Chemical free operation, simple, easy and save - Digital timer for light finishing control Philips UVC high intensity lamps equipped - With powerful air exhausting for big size models

Compact Model Photopolymer plate Making Equipment `
Flexo Graphy
(Exposure +Washout + Dryer +Treatment )
A2SSF 420mmx 594mm
(16.54 x 23.39 inch
A3SSF 297mm mm x 420 mm
(11.69 Inch x 16.54 Inch
Letterpress
(Exposure +Washout + Dryer +Treatment )
A2SS
A3 SS
Complate Stainless Steel

A4 FL
A4 FL
Exposure
Washout
Dryer
Treatment

Solvent Recovery System
@ flexo 60L-RHB
SPECIAL FEATURES Solvent recovery unit for photopolymer flexo plates
A. General description:
@60L-RH is designed for recovery of flexographic photopolymer plate solvent washout chemical and any environmental green chemical with specialties of distilling and cooling, can be connected with in-line processor and any plate washout machine directly. With cold air circulation and drain out of residue for high speed recovery . Super recovering rate in the shortest time, is an ideal and high efficient recovery unit for flexography.
B. Technical information: Recovery volume : 60 / 80 liters Power consume: 220V 4.65KW Diathermic oil : 23 KG Machine dimension: Main body: 1100x 780x1200 mm Recovery rate: 85%

Water wash Flexo
@C-A2SSF
All stainless steel.
Exposing+drying+washout+treatment.
With water circulation & filtration system.
Simple operation, best plate result

Technical Data sheet

@C-A2SSF
All stainless steel.
Exposing+drying+washout+treatment.
With water circulation & filtration system.
Simple operation, best plate result.
MODEL @C-A2SSF
UNIT EXPOSING+DRYING +WASHOUT+TREATMENT
MEASUREMENT(cm) 120 x 100 x 125
N/W 235KG G/W 335KG
WATT 2.8KW

Special features @flexo Photopolymer Plate making machine for Water Wash Flexo Plate (Model : @C-A2SSF / @C-A3SSF / @C-A4SSF / @C-2430 / @C-3040)
For printing: Label, film, paper, corrugated board, paper carton, bag, Tetra pak etc. Exposure + Washout + Drying +Treatment (Light finishing) in complete set
Features of Exposure unit -Instant light up Philips high intensity lamps - Unique digital timers for back/main exposure -Excellent lamps cooling / exhausting system - Quick vacuum drawdown pump with indicator Features of Washout unit -High temperature water washout - With water circulation system -Special arrangements of brush - With residue filtration system
Features of Drying unit -Drying drawer with uniform heat distribution - Temperature adjustable by a precise controller -Unique air circulation and exhaustion design - Over heat sensor for safety and protection Features of Treatment unit Chemical free operation, simple, easy and save - Digital timer for light finishing control Philips UVC high intensity lamps equipped - With powerful air exhausting for big size models

Office :
435,Patel Avenue
Nr. Gurudwara,Thaltej,
Ahmedabad 380059.
Gujarat-India.
Tele:+91-79-26852439
Fax: +91 09824070747
Manufacaturing
Unit : 196 GIDC,
Viramgam Dist:
Ahmedabad
Phone91 2715-235390, 91
Mobile:91-9824096180
(Alpesh Thakar )
MSN : [email_address] Skype : innovativelexo Yahoo : photopolymerindia GMAIL : alpeshthakar123@gmail.com Trade Manager : flexogroup Email : [email_address] www.flexo.co.in
