ChefInfrastructure as code<br />
Chef<br />
Background<br />Opscode (HJK Solutions)<br />
Chef has<br />Recipes<br />Resources<br />Roles<br />Nodes<br />Cookbooks<br />Knife<br />
Fully Automated Infrastructure<br />
Provisioning<br />Bare-metal: Kickstart/jumpstart<br />VM: libvert<br />Cloud: AWS/vCloud<br />Cloud: fog (http://fog.io/)...
Configuration Management<br />
Systems Integration<br />the last mile of fully automated infrastructure<br />Metadata stored & indexed<br />Search API<br />
Chef principles<br />Idempotent<br />Thick Clients, Thin Server<br />Order Matters<br />
Why chef?<br />Economics<br />Efficiency<br />Scalability<br />Community<br />
Flavors of Chef<br />Chef client & Chef server<br />Hosted Chef<br />Chef solo<br />
Architecture<br />
A Chef run<br />
Chef client<br />    Client does all the work, and can run recipes for multiple Nodes.<br />
Chef server<br />API service.<br />Management Console (optional).<br />AMQP Server<br />Search indexer and Search Engine.<...
Chef solo<br />-c, --config CONFIG<br />-j, --json-attributes JSON_ATTRIBS<br />-r, --recipe-url RECIPE_URL<br />
Cookbook<br />
Cookbook<br />    Cookbooks are the fundamental units of distribution in Chef. <br />
Cookbook<br />attributes/<br />definitions/<br />files/<br />libraries/<br />metadata.rb<br />providers/<br />recipes/<br ...
Cookbook<br />Dev in chef-repo<br />Create our own cookbook<br />Or download from community<br />Upload to Chef server<br />
Cookbook command<br />knife cookbook list<br />knife cookbook create COOKBOOK<br />knife cookbook download COOKBOOK<br />k...
 Chef Community Cookbook Site <br />knife cookbook site list<br />knife cookbook site share COOKBOOK CATEGORY<br />knife c...
Cookbook Dependencies <br />In metadata.rb:<br />depends "apache2", ">= 0.99.4"<br />depends "mysql", ">= 1.0.5"<br />
Attributes<br />node.default[:apache][:dir] = "/etc/apache2"<br />node.default[:apache][:listen_ports] = [ "80", "443" ]<b...
Nodes<br />Nodes in Chef are the thing that are configured by Recipes. <br />recipe/role<br />attribute<br />
Roles<br />name "webserver"<br />description "The base role for systems that serve HTTP traffic"<br />run_list "recipe[apa...
Search<br />knife search node "id:foo OR id:abc”<br />search(:node, 'run_list:recipe[foo::bar]') do |matching_node|<br /> ...
Libraries<br />your_cookbook/libraries/your_example_library.rb<br />module YourExampleLibrary<br />  def your_function()<b...
Metadata<br />maintainter "bob"<br />maintainer_email "bob@gmail.com"<br />license "Apache v2.0"<br />description "A cookb...
Templates<br />template "/etc/sudoers" do<br />  source "sudoers.erb"<br />  mode 0440<br />  owner "root"<br />  group "r...
Recipes<br />stored in Cookbooks.<br />executed in the order they appear.<br />evaluated as Ruby code.<br />Recipes from o...
Resources<br />such as:<br />packages<br />services<br />users<br />files<br />directories<br />
Resources: cookbook_file<br />cookbook_file "/tmp/testfile" do<br />  source "testfile" # this is the value that would be ...
Resources: directory<br />%w{dir1 dir2 dir3}.each do |dir|<br />   directory "/tmp/mydirs/#{dir}" do<br />      mode 0775<...
Resources: remote file<br />remote_file "/tmp/testfile" do<br />  source "http://www.example.com/tempfiles/testfile"<br />...
Resources: package<br />package "tar" do<br />  version "1.16.1-1"<br />  action :install<br />end<br />
Resources: script<br />script "install_something" do<br />  interpreter "bash"<br />  user "root"<br />cwd "/tmp"<br />  c...
Quick start<br />
Quick Start<br /><ul><li>Chef server(Host Chef)
Local workstation(MaxOSX)
One node(VM Ubuntu)</li></li></ul><li>Hosted Chef<br /><ul><li>Sign up for Opscode Hosted Chef  </li></ul>https://communit...
Workstation Setup<br /><ul><li>Install pre-requisites</li></ul>         - Ruby 1.8.7+ <br />            - RubyGems1.3.7+<b...
Create Chef repository</li></ul>            - gitclone git://github.com/opscode/chef-repo.git<br /><ul><li>Copy the keys a...
Set up a node as Chef Client<br /><ul><li>Download the chef-client cookbood</li></ul>      knife cookbook site install che...
Verify node data<br />List all the node:<br /> knife node list<br />List the run list for a specific node:<br />knife node...
Working with git<br />
get chef-repo<br />git clone git://github.com/opscode/chef-repo.git<br />
repo tree<br />config/ - Contains the Rake configuration file, rake.rb.<br />cookbooks/ - Cookbooks you download or create...
working with git<br />Building a new cookbook and saving it to the local repository.<br />Downloading an existing cookbook...
Doc & Help<br />
working with git<br />wik: http://wiki.opscode.com/display/chef/Home<br />community:<br />    http://community.opscode.com...
