Insight without InterferenceMonitoring with Scala, Swagger, MongoDB and Wordnik OSS                       Tony Tam        ...
Nagios Dashboard
Monitoring? Disk                    HostSpace                   Checks          IT Ops 101                        SystemNe...
Monitoring? Disk                           HostSpace                          Checks            Necessary          (but in...
Why Insufficient?• What about Services? •   Database running? •   HTTP traffic?• Install Munin Node! •   Some (good) servi...
Your boss    “OH pretty   LOVES charts    colors!”                     “up and                      to the “it MUST       ...
Good vs. Bad?• Database calls avg 1ms? •   Great! DB working well •   But called 1M times per page load/user?• Most tools ...
Enter APM• Application Performance Monitoring• Many flavors, degrees of integration •   Heavy: transaction monitoring, cod...
APM @ Wordnik• Micro Services make the System       Monolithic       application
APM @ Wordnik• Micro Services make the System                           API Calls                          are the unit   ...
Monitoring API Calls• Every API must be  profiled• Other logic as needed •   Database calls •   Connection manager •   etc...
How?• Wordnik-OSS Profiler for Scala  •   Apache 2.0 License, available in Maven Central• Profiling Arbitrary code block:i...
Profiler gives you…• Nearly free*** tracking• Simple aggregation• Trigger mechanism  •   Actions on time spent “doing thin...
Profiler gives you…• Nearly free*** tracking• Simple aggregation• Trigger mechanism  •   Actions on time spent “doing thin...
Accessing Profile Data• Easy to get in code       ProfileScreenPrinter.dump• Output where you want  logger.info(ProfileScr...
Accessing Profile Data• Easier to get via API with Swagger-JAXRSimport com.wordnik.resource.util@Path("/activity.json")@Ap...
Accessing Profile Data
Accessing Profile Data                 Inspect                 without                 bugging                  devs!
Is Aggregate Data Enough?• Probably not• Not Actionable •   Have calls increased? Decreased? •   Faster response? Slower?
Make it Actionable    • “In a 3 hour window, I expect 300,000      views per server”      •   Poll & persist the counters{...
Make it Actionable
Make it Actionable              Your boss            LOVES charts
That’s not Actionable!• Custompretty  But it’s   Time                         APIs to  window                        track...
That’s not Actionable!Custom Time                             APIs towindow                            track?             ...
Make it Actionable• Swagger + a      tiny   bit of engineering •   Let your *product* people create monitors, set     goal...
Make it Actionable• A Service Type: a collection of checks  which make a functional unit  {          "name": "www-api",   ...
Make it Actionable• A Host: “directions” to get to the checks{  "host": "ip-10-132-43-114",  "path": "/v4/health.json/prof...
Make it Actionable• And finally, a simple GUI
Make it Actionable• And finally, a simple GUI
Make it Actionable• Point Nagios at this!serviceHealth.json/status/www-api?explodeOnFailure=true        Metrics from      ...
Make it Actionable
Is this Enough?System monitoringAggregate monitoringWindowed monitoringObject monitoring? •   Action on a specific eve...
Object-level Actions• Any back-end engineer can build this •   But shouldn’t• ETL to a cube?• Run BI queries against produ...
Avoiding Code Invasion• We use MongoDB everywhere• We use > 1 server wherever we use  MongoDB• We have an opLog record aga...
What is the OpLog• All participating members have one• Capped collection of all write ops        t3                  time ...
So What?• It’s a “pseudo-durable global topic  message bus” (PDGTMB)  •   WTF?• All DB transactions in there• It’s persist...
More about this{    "ts" : {         "t" : 1340948921000, "i" : 1    },    "h" : NumberLong("5674919573577531409"),    "op...
Tapping into the Oplog• Made easy for you!https://github.com/wordnik/wordnik-oss
Tapping into the Oplog • Made easy for you! https://github.com/wordnik/wordnik-ossIncremental  Backup                     ...
Tapping into the Oplog    • Create an OpLogProcessorclass OpLogReader extends OplogRecordProcessor {  val recordTriggers =...
Tapping into the Oplog• Attach it to an OpLogTailThreadval util = new OpLogReaderval coll: DBCollection = (MongoDBConnecti...
Tapping into the Oplog• Add some observer functionsutil.recordTriggers +=  new Function1[BasicDBObject, Unit] {      def a...
/* do something here */• Like?• Convert to business objects and act! •   OpLog to domain object is EASY •   Just process t...
Converting OpLog to Object• Jackson makes this trivialcase class User(username: String, email: String,  createdAt: Date)va...
Converting OpLog to Object• Jackson makes this trivial                     “o” is forcase class User(username: String,   e...
Use Case 1: Alert on Action• New account!obj match {  case newAccount: UserAccount => {    /* ring the bell! */  }  case _...
Use case 2: What’s Trending?• Real-time activitycase o: VisitLog => Profile("ActivityMonitor:processVisit", {   wordTracke...
Use case 3: External Analyticscase o: UserProfile => {    getSqlDatabase().executeSql(      "insert into user_profile valu...
Use case 3: External Analyticscase o: UserProfile => {    getSqlDatabase().executeSql(      "insert into user_profile valu...
Use case 4: Cloud analysiscase o: NewUserAccount => {    getSalesforceConnector().create(      Lead(Account.ID, o.firstNam...
Use case 4: Cloud analysiscase o: NewUserAccount => {    getSalesforceConnector().create(      Lead(Account.ID, o.firstNam...
Examples     Polling profile      APIs cross        cluster
Examples       Siphoning        hashtags      from opLog
Examples       Page view      activity from         opLog
Examples      Health check          w/o      engineering
Summary• Don’t mix up monitoring servers & your  application• Leave core engineering alone• Make a tiny engineering invest...
Find out more• Wordnik: developer.wordnik.com• Swagger: swagger.wordnik.com• Wordnik OSS: github.com/wordnik/wordnik-oss• ...
