  • IO issues8 EC2 servers => 1 physical
  • Don’t use RS, version 1.0 of feature, plus no supportfor authentication
  • Slaves are smarter
  • Tweets, may want hot (shard on id)Random access, need equi depthRedistributing shards is tricky

Transcript

  • 1. Managing a MongoDB deployment
    Tony Tam @fehguy
  • 2. Areas of discussion
    Many drivers to go non-relational
    Maybe you already are?
    SOA?
    “Yes we should!” Now what?
    Implementation details, best practices
    Depends on what system you choose
    Operational Architecture
    Making your deployment “maintainable”
    Maximizing performance
    Software + Hardware tuning
  • 3. Wordnik Says Yes to MongoDB
    And we’re alive to talk about it
    Our stats
    14 M REST API calls yesterday
    7 ms avg. response
    3 TB of MongoDB data
    Mostly all “un-cached” responses
  • 4. Software Architecture
    Java/Scala/Jetty application servers
    Share (almost) nothing
    All roads in must speak REST
  • 5. Deployment architecture
    Wordnik uses physical servers
  • 6. Operational Constraints
    Fundamental question to answer
    Can we support this?
    You need to consider
    If you want it to scale
    If you have a SLA to support
    If you carry the pager
    Also important if
    You have customers
    You like your job
  • 7. Operational Constraints
    Core items for Wordnik
    Redundancy with master/slave
    Multi-datacenter deployment possible?
    Design for read-only mode
    Control at the driver level
    Blocking
    When is it OK?
    Steps around with MongoDB
    Consistency
    When does it matter?
    Scale-out
    What limits our speed/size?
    Other?
    Some features => opportunity
  • 8. Redundancy
    MongoDB supports MS and Replica Sets
    RS is like MS with auto-failover
    Driver intelligence
    Still one master, elected by peers
    Master
    Slave
    Master
    Master
    Slave
    Slave
    Slave
    Slave
    Slave
    Slave
    Slave
  • 9. Redundancy
    Master/Slave fine for us but…
    Not fine for multi operational datacenters
    resync?
    Your data drives the appropriate solution
    Custom tools to support this
    https://github.com/wordnik/wordnik-oss
    Primary Datacenter
    Hot Datacenter
    Incremental Backup Files
    Master
    Master
    Replay Util
    SCP
  • 10. Redundancy
    Multi-datacenter deployment
    Some data need not be consistent
    Some does
    Replication tricks for master-master
    db.documents
    documents.src == 1
    Master 1
    Master 2
    db.documents
    documents.src == 2
  • 11. Controlling blocking operations
    Important to know what blocks
    Some situations can create global locks
    Know what happens with:
    Adding data
    Deleting data
    Modifying data
    …Then toss in 100 reads/sec
    Only access your DB “the right way”
    Enforce by good software design
    The right way == “right way for your db”
  • 12. Controlling blocking operations
    Wordnik Solution
    MongoDB access via service layer
    Only allow queries you want run
    All others => non-production server, Hadoop
    Smart driver manager
    Slave bias
    $inc:{page_views:1} => $set{page_views:10038}
    Read-only mode
    Hot-remove server from pool
  • 13. Handling eventual consistency
    EC makes things fast
    May create timing issues
    Sometimes need current data
    val db:DB = getReadWriteConnection()
    Avoid this a much as possible
    But if you must…
    Write then call “getLastError”
    Forces commit to DB
    RS allows “replicate to n nodes”
    Forces commit to master, n slaves
  • 14. Scale-out
    What are you scaling?
    Size of data
    Size of indexes
    Operations
    Add slave servers
    Won’t help if size > index/server capacity
    Sharding if done right
    Autoshard solution
    Roll your own
  • 15. Scale-out
    Selecting a shard key
    Can be tricky
    Depends on what you need
  • 16. Keeping it running
    Backups
    Export with “mongodump”
    No incremental backup solution included
    Wordnik tools
    https://github.com/wordnik/wordnik-oss
  • 17. Wordnik OSS tools
    Take our tools-They work!!!
    SnapshotUtil
    Selectively snapshot in BSON
    Index info too!
    IncrementalBackupUtil
    Tail the oplog, stream to disk
    Only the collections you want!
    Compress & rotate
    RestoreUtil
    Recover your snapshots
    Apply indexes yourself
    ReplayUtil
    Apply your Incremental backups
  • 18. What if Scenarios
    One collection gets corrupt?
    Restore it
    Apply all operations to it
    “My top developer dropped a collection!”
    Restore just that one
    Apply operations to it until that POT
    “We got hacked!”
    Restore it all
    Apply operations until that POT
  • 19. Wrap up: We like MongoDB
    See more @ http://developer.wordnik.com
    Questions?
