www.marcus-spectrum.com Michael J. Marcus, Sc.D., F-IEEE Former Associate Chief for Technology FCC Office of Engineering and Technology Director, Marcus Spectrum Solutions, LLC Cabin John, MD, USA www.marcus-spectrum.com Adjunct Professor Department of Electrical & Computer Engineering Virginia Tech N3JMM/ 7J1AKOTechnology Regulation

Overview Will review interaction of regulation and technology in wireless technology How a bipartisan political movement for deregulation unexpectedly removed roadblocks that kept a promising wireless technology & underutilized bands locked in “Pandora’s box”  Serendipity and (generally good) unexpected consequences  Today’s ubiquitous Wi-Fi and Bluetooth and other useful niche applications Technology Regulation

Why Is Wireless Different than OtherTechnologies? Basic spectrum policy concepts were formed in aftermath of Titanic sinking 100 years ago Many regulators resemble Soviet economic planners, projecting demands and allocating resources Classically, entrepreneurs, “disruptive innovation” and niche applications get little attention  Wi-Fi started as a niche application! Technology Regulation

4Birth of Unlicensed in US  US legislation does not provide explicitly for unlicensed use  1st system was a Philco remote control system for radio receivers in late 30s  FCC ruled that since it was unlikely to cause interference license was not needed  Subsequent legislation has noted unlicensed but never explicitly authorized it  ARRL claims FCC has no legal basis for unlicensed Technology Regulation

The Strange Case of iTrip: 5 T The Classic Problem for Unlicensed in Some Countries  Prescriptive nature of spectrum regulation in many countries held back unlicensed innovation, e.g.  iTrip is a low power FM transmitter user to connect iPod music to nearby FM broadcast receivers  In US, FCC has allowed such low power systems for decadeshttp://www.ofcom.org.uk/media/news/2006/11/nr_20061123b  But were banned in Europe for several years because of lack of rules in this area Technology Regulation

Traditional Spectrum Policy  Prioritize uses of spectrum  Controls interference and market entry  Pick technological winners and losers  GSM was extremely successful and came from such a policy environment  Only GSM equipment can be sold in Europe and some other countries (prior to 3G) Technology Regulation

But Wi-Fi and Bluetooth can from a Very Different Background than GSM!  Rest of presentation will explore technical and regulatory roots of of Wi-Fi  If traditional spectrum management is similar to Soviet economic policy, the origins here are basedГосплан on Field of Dreams concepts “If you believe the impossible, the incredible can come true.” Technology Regulation

Roots of Wi-Fi (and Bluetooth) Wi-Fi came about as a result of spectrum deregulation creating a “blank slate” for innovators Spread spectrum (SS) was the basis for creation of spectrum that became the home of Wi-Fi and Bluetooth  Prior to FCC 1981-1985 action, SS was implicitly banned in general  Carter-era FCC sought to remove barriers from technology to stimulate economy  SS was selected as initial area  SS was the core technology of Wi-Fi until 802.11(g) and continues as Bluetooth core Technology Regulation

Hedy Lamarr:Legendary Inventor of Spread Spectrum  As is often reported in popular press, Hedy Lamarr was awarded an early frequency hopping spread spectrum* patent during WWII  But invention was not reduced to practice  Like with the computer, it is probably impossible to identify a single inventor of spread spectrum • Spread spectrum comes in 2 “flavors”: direct sequence/pseudonoise and frequency hopping. Wi-Fi started as DS/PN, Bluetooth is FH Technology Regulation

1953 MIT Lincoln Lab System Developed by Paul Green (later of IBM) as a thesis project One of earliest SS/PN systems  More related to early Wi-Fi and Qualcomm CDMA than Lamarr concept Technology of the day required large size Technology Regulation

Early Literature In the 1950-1970’s spread spectrum generally remained a classified technology with only occasional references in the open literature. My first exposure was at a classified 1972 conference Only textbook-like discussion was a classified Sylvania report for NSA Technology Regulation

Dixon’s Book 1975 First comprehensive, though mathematically inelegant, unclassified treatment of spread spectrum Introduced a generation of designers to the technology Technology Regulation

Commercial Spread Spectrumc. 1979  Magnavox produces a “civil” version of AN/ARC-50/90  Unit shown is modem, separate transceiver needed  Japan MPT purchases and tests for possible civil applications  Concludes no practical value for civil use! Technology Regulation

Setting the Stage for Wi-Fi: Prophets of Deregulation Pres. Carter Alfred Kahn Pres. Reagan Cornell University Professor Former Chairman of New York PUC US Civil Aeronautics Board Technology Regulation

FCC Chairman Ferris (1977-81)Makes Deregulation FCC Focus Translates Kahn’s concepts and Carter’s mandate into more specific program:  Identify technologies that are being held back by anachronistic regulations and “liberate” them - so they can sink or swim under their own merits  Hires former (D)ARPA Director Steve Lukasik to implement program  Spread spectrum identified as a candidate technology Technology Regulation

FCC Chairman Fowler (1981-87)Makes Spread Spectrum Deregulation Part of “Reagan Agenda”  Chmn. Fowler replaces Chmn. Ferris after the Reagan election  While disagreeing with predecessor on many issues, he embraces the spread spectrum initiative seeing its connection to Reagan’s deregulatory agenda – despite mainstream industry opposition  “Looking back, it is clear that adoption of these rules was one of the significant achievements of the Reagan FCC —though I doubt if anyone thought so at the time.” 4/08 Technology Regulation

Early FCC Action 1980 MITRE Corp. report to study options for civil use of spread spectrum Best 70K FCC ever spent!! Raises unlicensed option Available from NTIS as PB81-165284 and on MITRE site Technology Regulation

Early FCC Action 1981 2 initiative begun:  Docket 81-413 – General use  Docket 81-414 – Amateur radio use While H-P (now Agilent) was supportive, most industry opposed IEEE IT Society filed support Technology Regulation

1985  May 9, 1985 FCC adopts spread spectrum rules in ISM bands  1 W limit  PN or FH  Almost any application  But no explicit mention of Wi-Fi-like RLANs  Same basic rules until 2002  incorporated July 1985  CDMA becomes major cellular player  Key part of most 3G mobile systemsTechnology Regulation

“First Light”  In 1988 the first real commercial spread spectrum product appeared – a LAN  “Spontaneous generation” – developer was a Canadian startup aiming at using new FCC rules! Technology Regulation

Creation of IEEE 802.11 5 years after 81-413 decision - after several proprietary products tested the market and explored technologies - 3 pioneering firms joined in IEEE 802.11 to explore 2 niche applications:  Wireless cash registers  Warehouse mobile bar codescanners (building on supermarket scanners) Vic Hayes of NCR’s lab in Holland leads standardization discussions

1991 Snapshot  Many key players went to Quebec woods to discuss the future of spread spectrum  “Myth or Reality”  Future was still not clear Technology Regulation

Wi-Fi Growth Niche applications  worldwide demand!Early Growth Technology Regulation

Unexpected Uses of Wi-Fi & Related Systems Municipal Wi-Fi Supermarket Public system at marina customer product scanning while shoppingBathtub with Wi-Fi iPod music link §15.249 Equipment – Cousin of ISM Band rules Technology Regulation

The FCC Team That Lead ISM Band Policy 1979-1985From left: Robert Powers, Stephen Lukasik, Elliot Maxwell, MM, Marjorie "Peggy" Reed Greene May 2010

Are “Unlicensed” or “802” MagicElixirs of Success? “.com” once seen as magic elixir Some other unlicensed initiatives, some with broad industry support, have had little success:  U-PCS, U-NII, UWB, HiperLan Unlicensed with detailed regulations may not be able to adapt to meet demand 802 efforts to standardize UWB were unsuccessful  802.16 (WiMax) has had mixed success Today’s 802 is very different than 1990

Conclusions “If you believe the impossible, the incredible can come true.” Wi-Fi and Bluetooth had their roots in White House-directed deregulation to stimulate economic growth A major break from previous “Soviet style” planning of radio spectrum where bureaucrats tried to predict markets, technologies, and demands years in advance Deregulatory concepts grew into a new worldwide market serving unanticipated needs for mobility Synergy of unlicensed and regulatory flexibility is powerful approach to facilitate wireless innovation and economic growth Technology Regulation

ns ? s tio ueQ More details and other sources at: http://www.marcus-spectrum.com/SSHistory.htm Technology Regulation
