Eberhard Wolff, adesso AGTen Advices for Architects
About me•    Eberhard Wolff•    Architecture & Technology Manager at adesso•    adesso is a leading IT consultancy in Germ...
Why?•  Educating architects internally at adesso•  What should they know?•  What is the bare minimum?
Software ArchitectSoftware architect is a general termwith many accepted definitionswhich refers to a broad range of roles...
Software ArchitectureThe software architecture of a system is the set of                        structuresneeded to reason...
Why We Care    DefinesStructures                    PerformanceSoftware elementsnon-functionalRelationsProperties         ...
Software Architect:              Responsibilities•  Manager•  Responsibility: non-functional   requirements / quality•  To...
YOU ARE NOT ANARCHITECT!
Agile Development i.e. ScrumWhere is    Scrum Master          Removes obstacles            Enforces rules  theArchitect   ...
You Are Not An Architect!•    No manager•    Need to convince not manage•    Therefore: Not that different from a develope...
Is “Architect” a Good Metaphor?•  Buildings are physical entities   –  Hard to change•  Construction industry is establish...
Different Way to Think About  1999           Roles                     2001
Software Craftsmanship Manifesto             (2009)•  As aspiring Software Craftsmen we are raising the bar   of professio...
Architect as a Master Craftsman•  More experienced•  Knows the tools very   well•  Guides and helps others•  Incorporates ...
YOUR OPINION MATTERS!
Your Opinion Matters!•  You need to have your own opinion•  …about technologies•  …about architecture approaches•  Listen ...
•  http://lemmings.mytrash.tv/
Your Opinion Matters!•  This applies to this conference•  …and this talk•  If it does not make sense to you  –  say so•  Y...
PEOPLE WANT TO IMPROVE!
People Want to Improve!•  Technical people take pride in   their skills•  …often also quality•  They want to improve and c...
What You Can Do…•    Education•    Review•    Pairing•    Talks•    …
What If They Don’t Want to              Improve?•  You are screwed•  No way to create high quality with   those people•  E...
ARCHITECTURE = TRADE OFF
Architecture = Trade Off•  There are numerous ways to architect   each system•  There is no one single right   architectur...
Example for Trade Off:            Persistence•  Option: SQL  –  More control  –  Less infrastructure•  Option: O/R mapper ...
IMPROVE YOURVOCABULARY
Vocabulary•  Approaches to architecting a   system•  Defines what kind of architectures   and systems you can express•  Th...
How to Improve Your Vocabulary•  Patterns  –  Fowler: Patterns of Enterprise     Application Architecture  –  Gamma et al:...
How to Improve Your Vocabulary•  Technologies  –  How many Persistence     approaches do you know?  –  Should at least hav...
Again: Persistence•  “Patterns of Enterprise Application   Architecture” lists persistence approaches•  Ruby on Rails uses...
EAT YOUR OWN DOG FOOD!
Eat Your Own Dog Food!•  Defining an architecture is easy•  It is hard to create the right   architecture•  Need feedback•...
NO BROKEN WINDOWS
Broken Windows Theory•  Once windows are not   repaired…•  …vandals will break more•  …break into the building•  …•  Accep...
Broken Windows in Architecture•  Compromises on quality will   become out of hand•  Might speed up a project for   a limit...
But…•  There might still be broken windows•  There might be more and less skilled   developers•  What do I do?
STRATEGIC DESIGN
Domain Driven Design•  “Tackling Complexity   in the Heart of   Software”•  E.g. Ubiquitous   Language   for Code, Develop...
Strategic Domain Driven Design•  Bounded Context:   Model used only in a specific   part of the system•  Context Map:   Tr...
Strategic Domain Driven Design•  Can be used to manage   quality•  What are the core business   domains?•  Focus on qualit...
Strategic Domain Driven Design•  Acknowledges that not all developers are   equals•  …and not all parts of a system will h...
CARE ABOUT ARCHITECTUREAND CODE
Care About Architecture and Code•  You can draw diagrams until the end of time•  It’s the code and the architecture in the...
MEASURE AND REDUCE
Measure and Reduce•  No way to know all code by heart•  Still: You and the team need to understand   the state of the proj...
Sonar•    Server that integrates a lot of systems•    Static code analysis (Findbugs, PMD etc)•    Lines of Code, classes•...
Draw Conclusions!•  Do not try to enforce a certain value for a   metric!•  Metrics are used to reduce information and   g...
DEPENDENCIES MATTER!
Dependency Management•  Essential for measuring architecture•  i.e. what is the structure in the code?•  Why are Dependenc...
What is Architecture?•  Architecture is the decomposition of systems   in parts•  No large or complex parts•  No cyclic de...
Normal Dependencies•  A and B might be   packages or classes                             Component A•  B depends on A, i.e...
Cyclic Dependency•  B depends on A and A on   B                              Component A•  Changes in A impact B•  Changes...
Bigger cyclic dependencies Component A                Component B Component C
Measure Dependencies!•  …otherwise they will get out of hand•  Cyclic dependencies mean:  –  It should be separated accord...
Care about                You are Not an    Architecture is Code and                                           Quality    ...
Wir suchen Sie alsØ    Software-Architekt (m/w)Ø    Projektleiter (m/w)Ø    Senior Software Engineer (m/w)Ø    Kommen ...
