BUILDING RESPONSIVE    DRUPAL SITES
Drupal Consulting, Development, and Training      evolvingweb.ca | 514-844-4930                Suzanne Kennedy, Co-founder...
• Mobile   First• Responsive       Design• Building   a Responsive Drupal Theme• Designing   Responsive Elements• Tools   ...
WHAT IS MOBILE FIRST?• Design       your website for the mobile experience (phones, tablets, and everything in between)• A...
WHAT IS RESPONSIVE    DESIGN?
RESPONSIVE DESIGN• Create       a single site and design framework that adapts to any browser size• Tweak the design at di...
http://mattkersley.com/responsive/
RESPONSIVE DESIGN               PROCESS1. Create a Flexible Width website2. Set limits for large screens if needed3. Figur...
WHAT WORKS ON MOBILE?• Make   links big enough to touch• Show   the most important information• Show   only the most impor...
DESIGN APPROACHES• Prototype   rather than make mockups• No   pixel-perfect design• Allow   the design for mobile to impac...
HOW TO BUILD ARESPONSIVE DRUPAL THEME?
MEDIA QUERIES
MEDIA QUERY COMPONENTS• Media Type   (i.e. screen or print)• Media   Feature (i.e. max-width, min-width)
TARGETING LARGE SCREENS              Use the min-width media feature<link rel="stylesheet" type="text/css"media="screen an...
TARGETING SMALL SCREENS              Use the max-width media feature<link rel="stylesheet" type="text/css"media="screen an...
DEVICE ORIENTATIONorientation: landscape   orientation: portrait
OTHER MEDIA FEATURES• min-device-width• max-device-width• resolution• color• aspect-ratio
IN YOUR DRUPAL THEMEInline in your CSS files:@media screen and (min-width: 960px) {         left-column {              floa...
IN YOUR DRUPAL THEMEIn your .info file:stylesheets[screen and (min-width: 960px)][] = css/screen-min-960.cssstylesheets[scr...
BROWSER ISSUES
ANDROID DEVICESYou need to set the viewport meta tag to make media          queries work on android devices.<?php   $meta_...
INTERNET EXPLORER                 Versions 6-8 don’t support media queriesIn your .info file:stylesheets-conditional[lt IE ...
DESIGNING RESPONSIVE      WEBSITES
LAYOUT
http://www.lukew.com/ff/entry.asp?1514
evolvingweb.ca
owltastic.com
palentir.net
palentir.net
foodsense.is
workatplay.com
workatplay.com
barackobama.com
HORIZONTAL MENUS
VERTICAL MENUS
smashingmagazine.com
workatplay.com
IMAGES
img {        max-width: 100%;}
ADAPTIVE IMAGE MODULEAdd an ‘Adaptive effect’ to your image styles to  resize images based on device detection       drupa...
ADVERTISING!
bostonglobe.com
smashingmagazine.com
smashingmagazine.com
FORMS
Form elements are too wide
input,select {  max-width: 100%;}
jquerymobile.comdrupal.org/project/jquerymobile
TABLES
Avoid usingtables for grids
TABULAR DATA
Tabular Data
Tabular Data
denver2012.drupal.org
OTHER IDEAS• Use   Google Charts to show a pie chart instead of a table• Provide   a CSV download of the data
PANELS
palentir.net
palentir.net
CSS TO ADJUST PANEL
SEARCH
drupalsun.com
drupalsun.com
drupalsun.com
BANNERS
happycoghosting.com
happycoghosting.com
foodsense.is
foodsense.is
IFRAMES
iframe {  max-width: 100%;}
DECORATIVE ELEMENTS
css-tricks.com
css-tricks.com
CRAFTING YOUR CSS
CSS 3: FONT-FACE@font-face {    font-family: Futura;    src: url("../fonts/Futura-Book.otf");  }h2 {       font-family: Fu...
CSS3: BORDER-RADIUS         www.css3.info  #example {    -moz-border-radius: 15px;    border-radius: 15px;  }
OTHER CSS ADVICE• Avoid absolute positioning• Avoid setting absolute heights and widths
TOOLS AND RESOURCES
DRUPAL THEMES & MODULES
RESPONSIVE THEMES• Omega Theme• Adaptive Theme• Square    Grid• Twitter   Bootstrap• Others...
DRUPAL MODULEShttp://drupal.org/project/adaptive_image http://drupal.org/project/touch_icons http://drupal.org/project/jqu...
ARTICLES• Evolving Web: http://evolvingweb.ca/story/responsive-theming- how-apply-responsive-design-techniques-drupal-them...
OTHER RESOURCES• Media      Features: http://www.w3.org/TR/css3-mediaqueries/ #media1• Drupal    Base Themes: http://group...
VIDEOS FROM DRUPALCON•   Mobile First: http://denver2012.drupal.org/keynote/luke-wroblewski•   Responsive Theming + Omega ...
CHALLENGES
canada.gc.ca
TRAINING PROGRAMWe offer public and private Drupal training sessions.              evolvingweb.ca/training
THANK YOU!
