Android Bluetooth Introduction




               Erin Yueh
              2009/06/26





Agenda
    ●   Android Bluetooth architecture
    ●   Related source code
    ●   Init Bluetooth
    ●   Connect with oth...
Android architecture





The diagram above offers a library-oriented

           view of the Bluetooth stack.


Related source code
    ●   Bluez 3.36 (user space and kernel)
        ­ /mydroid/externel/bluez
        ­ /mydroid/kernel...
Init Bluetooth
    ●   /root/init.rc

        mkdir /data/misc/hcid (store device info)
        service dbus /system/bin...
ddms: dalvik debug monitor I.





ddms: dalvik debug monitor II.





Bluetooth headset




    Music player + Dialer

Connect with other BT devices




●
    Bluez: hcid daemon

●
    dbus-daemon: connections between hcid and system server
...
BlueZ D­Bus Architecture





D­Feet: D­Bus viewer and debugger





Dbus­send: send a message to a message
bus





Scan nearby BT devices in Android
    ●   Bluez utility: hcitool scan
    ●   DiscoverDevices: bluez/util/hcid/dbus­api.tx...
Signals





How to pair with a BT device? I. Register
Passkey Agent





II. Request PIN code





RFCOMM (Radio Frequency
Communication)
●
    The Bluetooth protocol RFCOMM is a simple set of
    transport protocols.
●...
Send AT commands via bluetooth
    ●   Connect with Nokia N73 phone
    ●   > sdptool browse 00:18:C5:42:18:78
    ●   > s...
OBEX (Object EXchange)
    ●   a communications
        protocol that
        facilitates the
        exchange of binar...
SOCKET
    ●   UNIX socket
        (AF_BLUETOOTH)
    ●   inter­process
        communication
    ●   like Internet so...
Receive files via BT in Android
    ●   openobex + obexpushd
    ●   Run an OBEX data server in Android
    ●   > obexpu...
Send files via BT in Android
    ●   Openobex + obexftp
    ●   Connect to a RFCOMM connection
    ●   > obex_test ­b BTAD...
Thank You!





Upcoming SlideShare
Loading in...5
×

Android Bluetooth Introduction

100,896

Published on

* Android Bluetooth architecture
* Related source code
* Init Bluetooth
* Connect with other BT devices (dbus)
* RFCOMM
* OBEX (socket)

Published in: Technology, Spiritual
11 Comments
36 Likes
Statistics
Notes
No Downloads
Views
Total Views
100,896
On Slideshare
0
From Embeds
0
Number of Embeds
33
Actions
Shares
0
Downloads
3,693
Comments
11
Likes
36
Embeds 0
No embeds

No notes for slide

Android Bluetooth Introduction

  1. 1. Android Bluetooth Introduction Erin Yueh 2009/06/26
  2. 2. Agenda ● Android Bluetooth architecture ● Related source code ● Init Bluetooth  ● Connect with other BT devices (dbus) ● RFCOMM ● OBEX (socket)
  3. 3. Android architecture
  4. 4. The diagram above offers a library-oriented   view of the Bluetooth stack.
  5. 5.
  6. 6. Related source code ● Bluez 3.36 (user space and kernel) ­ /mydroid/externel/bluez ­ /mydroid/kernel/drivers/bluetooth ­ /mydroid/kernel/net/bluetooth ● Android app framework (java & c++) ­ /mydroid/frameworks/base/core/jni/android_bluetooth_*.cpp  ­ /mydroid/frameworks/base/core/java/android/bluetooth/*.java ­ /mydroid/frameworks/base/services/java/com/android/server/ (SystemServer) ● Android UI application  ­ /mydroid/packages/apps/Phone/src/com/android/phone/ (Phone App) ­ /mydroid/packages/apps/Settings/src/com/android/settings/bluetooth/ (Settings App)
  7. 7. Init Bluetooth  ● /root/init.rc  mkdir /data/misc/hcid (store device info) service dbus /system/bin/dbus­daemon service hcid /system/bin/hcid (disabled) service hfag /system/bin/sdptool add ­­channel=10 HFAG (handsfree, disabled, one shot) service hsag /system/bin/sdptool add ­­channel=11 HSAG (headset, disabled, one shot) ● /root/init.trout.rc service hciattach (disabled)  ● system server decice BT power On or Off from settings value start related services
  8. 8. ddms: dalvik debug monitor I.
  9. 9. ddms: dalvik debug monitor II.
  10. 10. Bluetooth headset Music player + Dialer
  11. 11. Connect with other BT devices ● Bluez: hcid daemon ● dbus-daemon: connections between hcid and system server ● D-Bus is a simple inter-process communication (IPC) system for software applications to communicate with one another. ● dbus-daemon is the D-Bus message bus daemon. D-Bus is first a library that provides one-to-one communication between any two applications; dbus-daemon is an application that uses this library to implement a message bus daemon. Multiple programs connect to the message bus daemon and can exchange messages with one another. ● debug utility: d-feet, dbus-monitor, dbus-send
  12. 12. BlueZ D­Bus Architecture
  13. 13. D­Feet: D­Bus viewer and debugger
  14. 14. Dbus­send: send a message to a message  bus
  15. 15. Scan nearby BT devices in Android ● Bluez utility: hcitool scan ● DiscoverDevices: bluez/util/hcid/dbus­api.txt This method starts the device discovery procedure. This includes an inquiry  procedure and remote device name resolving. On start up this process will  generate a DiscoveryStarted signal and then return DeviceFound singals. If the  procedure has been finished an DiscoveryCompleted signal will be sent. ● Source code: android_server_BluetoothDeviceService.cpp /* Compose the command */ msg = dbus_message_new_method_call(BLUEZ_DBUS_BASE_IFC, nat­>adapter,  DBUS_CLASS_NAME, "DiscoverDevices"); /* Send the command. */ reply = dbus_connection_send_with_reply_and_block(nat­>conn, msg, ­1, &err);
  16. 16. Signals
  17. 17. How to pair with a BT device? I. Register  Passkey Agent
  18. 18. II. Request PIN code
  19. 19. RFCOMM (Radio Frequency  Communication) ● The Bluetooth protocol RFCOMM is a simple set of  transport protocols. ● RFCOMM is sometimes called Serial Port Emulation.  ● The Bluetooth Serial Port Profile is based on this protocol. ● In the protocol stack, RFCOMM is bound to L2CAP ● RFCOMM provides a simple reliable data stream to the  user, similar to TCP. It is used directly by many telephony  related profiles as a carrier for AT commands
  20. 20. Send AT commands via bluetooth ● Connect with Nokia N73 phone ● > sdptool browse 00:18:C5:42:18:78 ● > sudo rfcomm connect 0 00:18:C5:42:18:78 2 ● minicom ● > AT ● > AT+CGMR ● > AT+CGMI
  21. 21. OBEX (Object EXchange) ● a communications  protocol that  facilitates the  exchange of binary  objects between  devices. ● in the protocol stack,  OBEX is bound to  RFCOMM
  22. 22. SOCKET  ● UNIX socket  (AF_BLUETOOTH) ● inter­process  communication  ● like Internet socket recv() send() ● client­server
  23. 23. Receive files via BT in Android ● openobex + obexpushd   ● Run an OBEX data server in Android ● > obexpushd ● listen RFCOMM connections ● File permission
  24. 24. Send files via BT in Android ● Openobex + obexftp ● Connect to a RFCOMM connection ● > obex_test ­b BTADDR CHANNEL ● > obexftp ­b BTADDR ­B CHANNEL ­­list
  25. 25. Thank You!
