What you need to know to have a healthy SharePoint environmentEnrique LimaPinnacle of Indianaelima@pinnacleofindiana.comTw...
   Enrique Lima   elima@pinnacleofindiana.com   SharePoint Practice Lead   Pinnacle of Indiana   Microsoft Community ...
   Try to stay awake!   Importance of SQL Server   SharePoint and SQL Server   Capacity Planning   Configuration   P...
   Industry seems to be focused more on the    development of the SharePoint solutions   Little focus on infrastructure ...
   SharePoint 2010 Health Analyzer   Routine database maintenance     Check database integrity (DBCC CHECKDB)     Defr...
   SQL Server configuration     Do not enable auto-create statistics     Set max degree of parallelism (MAXDOP) to 1   ...
   Know your limits, Software Boundaries   Yes, there is a formula:     Database size = ((D × V) × S) + (10 KB × (L + (...
   Number of Docs (D) 200,000   Average Size of Docs (S) 250KB   List Items (L) 600,000   Number of non-current versio...
   Boundaries     Absolute limit     Example: 2GB document size limit   Thresholds     A default value that cannot be...
SharePoint 2007   SharePoint 2010Items per view           2000              5000Docs per Library         5M               ...
   Plan for your SQL Server spread.   Negotiate Volume     Size     Placement   LUNs are a precious thing …   … but ...
Drive Letter                   Purpose       LUN   Negotiated                                                     LUNC:   ...
   Of course it can be virtualized.   Virtual is not as forgiving as Physical   Know and work with memory management  ...
   IMPORTANT TO CAPACITY PLAN MEMORY    CORRECTLY FOR LARGE NUMBER OF CPUS     Rule of thumb: 4-6GB per core   Worker T...
   Adjust the Out of Box Memory Limit   If Virtual:     Configure a minimum of memory to work with     Be careful with...
   Measure I/O Performance     SQLIO     CrystalDiskMark   NTFS Allocation and Sector Alignment   Be mindful of Thin ...
   SharePoint 2010 heavily uses the tempdb system    database   Don’t forget that tempdb is used for other    purposes, ...
   Simple   Bulk-logged   Full
   Organizations will use SharePoint to store content     It starts by referring to it as a “next generation file share”...
   Get to know SQL Server   Get to know SharePoint   Understand the Metrics and Performance    Counters
   http://mtme.me/7b8619
   Storage and SQL Server capacity planning    and configuration.    http://technet.microsoft.com/en-    us/library/cc298...
Upcoming SlideShare
Loading in...5
×

Sql Health in a SharePoint environment

2,209

Published on

What you need to know to have a healthy SharePoint environment

Published in: Technology
0 Comments
0 Likes
Statistics
Notes
  • Be the first to comment

  • Be the first to like this

No Downloads
Views
Total Views
2,209
On Slideshare
0
From Embeds
0
Number of Embeds
4
Actions
Shares
0
Downloads
19
Comments
0
Likes
0
Embeds 0
No embeds

No notes for slide

Sql Health in a SharePoint environment

  1. 1. What you need to know to have a healthy SharePoint environmentEnrique LimaPinnacle of Indianaelima@pinnacleofindiana.comTwitter: @enriquelima
  2. 2.  Enrique Lima elima@pinnacleofindiana.com SharePoint Practice Lead Pinnacle of Indiana Microsoft Community Contributor Member of the Geekswithblogs.net Community - Influencer  http://geekswithblogs.net/enriquelima @enriquelima - twitter.com/enriquelima Member of INETA
  3. 3.  Try to stay awake! Importance of SQL Server SharePoint and SQL Server Capacity Planning Configuration Physical vs. Virtual Processor Memory Storage tempdb Content In Closing
  4. 4.  Industry seems to be focused more on the development of the SharePoint solutions Little focus on infrastructure  SQL Server  Storage  Capacity / Performance Planning  Disaster Recovery  High-Availability Management does not even know SharePoint runs on SQL Server SQL Server can be “scary stuff” Get to know the Health Analyzer and it’s “quirks”. Database maintenance for SharePoint Server 2010
  5. 5.  SharePoint 2010 Health Analyzer Routine database maintenance  Check database integrity (DBCC CHECKDB)  Defragmenting indexes – rebuild/reorg.  Fill Factor Monitor Performance  SQL Server Perspective ▪ CPU ▪ Memory ▪ Disk I/O
  6. 6.  SQL Server configuration  Do not enable auto-create statistics  Set max degree of parallelism (MAXDOP) to 1  Configure SQL Server connection aliases for each database server in your farm  Autogrowth setting for file size ▪ Content ▪ Search
  7. 7.  Know your limits, Software Boundaries Yes, there is a formula:  Database size = ((D × V) × S) + (10 KB × (L + (V × D)))  D = # of Docs  V = # of non-current versions  S = Avg. Size of Docs  L = List Items
  8. 8.  Number of Docs (D) 200,000 Average Size of Docs (S) 250KB List Items (L) 600,000 Number of non-current versions (V) 2 (Assume max 10 allowed) Database size = (((200,000 x 2)) × 250) + ((10 KB × (600,000 + (200,000 x 2))) = 110,000,000 KB or 105 GB
  9. 9.  Boundaries  Absolute limit  Example: 2GB document size limit Thresholds  A default value that cannot be exceeded unless the value is modified  Exceeding threshold may impact performance  Example: Document size limit of 50MB by default Supported Limit  Defined by testing and represent a known limitation of the product  Exceeding supported limit may cause unexpected results, significant performance degradation or other detrimental effects  Example: Support 500,000 site collections per web app.
  10. 10. SharePoint 2007 SharePoint 2010Items per view 2000 5000Docs per Library 5M 10 MDatabase Size 100GB 200GB (1TB for workloads)Content DB per Web App 100 300
  11. 11.  Plan for your SQL Server spread. Negotiate Volume  Size  Placement LUNs are a precious thing … … but so is the performance of your environment
  12. 12. Drive Letter Purpose LUN Negotiated LUNC: System (OS) 1 1D: User Data 2 2L: SQL Log Files 3 3P: Page File 4 1R: Local Backup Store 5 5S: SQL Server System Databases 6 2T: TempDB 7 4
  13. 13.  Of course it can be virtualized. Virtual is not as forgiving as Physical Know and work with memory management Understand SQL Server in Virtual environments will test more than just compute. Disk I/O, SQL I/O is very important
  14. 14.  IMPORTANT TO CAPACITY PLAN MEMORY CORRECTLY FOR LARGE NUMBER OF CPUS  Rule of thumb: 4-6GB per core Worker Thread configuration: CPUs 32-bit 64-bit Up to 4 256 512 8 288 576 16 352 704 32 480 960
  15. 15.  Adjust the Out of Box Memory Limit If Virtual:  Configure a minimum of memory to work with  Be careful with over allocation of memory in the pool Magic Formula:  Memory to Allocate = Server Memory * 0.8
  16. 16.  Measure I/O Performance  SQLIO  CrystalDiskMark NTFS Allocation and Sector Alignment Be mindful of Thin Provisioning Separation of I/O intensive databases  Content  Search Do not forget about  Versioning  Recycle Bin Mind your Free Space
  17. 17.  SharePoint 2010 heavily uses the tempdb system database Don’t forget that tempdb is used for other purposes, some of which are I/O intensive  DBCC CHECKDB  Index Rebuilds Best practices:  Multiple data files ▪ On separate LUN ▪ Equal in size ▪ Auto-growth in MB (decent size) Log file on separate LUN
  18. 18.  Simple Bulk-logged Full
  19. 19.  Organizations will use SharePoint to store content  It starts by referring to it as a “next generation file share”  But can (hopefully) evolve to a Corporate Knowledge approach All content is stored in one or more content databases  “All eggs are in one basket”  Disaster recovery is critical  Availability is important Performance of content database(s) is key to the user experience  Capacity planning  Performance planning Provisioning of DBs  Central Admin  DBA Created
  20. 20.  Get to know SQL Server Get to know SharePoint Understand the Metrics and Performance Counters
  21. 21.  http://mtme.me/7b8619
  22. 22.  Storage and SQL Server capacity planning and configuration. http://technet.microsoft.com/en- us/library/cc298801.aspx Software boundaries and limits. http://technet.microsoft.com/en- us/library/cc262787.aspx Database Types. http://technet.microsoft.com/library/cc67886 8(office.14).aspx
