  • Transcript

    • 1.
      • Emanuele Della Valle
      • [email_address]
      • http://emanueledellavalle.org
      Data in RDF
    • 2. Share, Remix, Reuse — Legally
      • This work is licensed under the Creative Commons Attribution 3.0 Unported License.
      • Your are free:
        • to Share — to copy, distribute and transmit the work
        • to Remix — to adapt the work
      • Under the following conditions
        • Attribution — You must attribute the work by inserting
          • “ © applied-semantic-web.org” at the end of each reused slide
          • a credits slide stating: these slides are partially based on “Data in RDF” by Emanuele Della Valle http://applied-semantic-web.org/2010/03/02_RDF.ppt
      • To view a copy of this license, visit http://creativecommons.org/licenses/by/3.0/
    • 3. Data Interchange: RDF
    • 4. RDF in a nutshell Looking for a flexible data model
      • Why
        • Application are always changing (competitive environment)
        • People are always adding more features
        • Graceful evolution is important
      • Optimal: relational model
        • Relational model is remarkably flexible
        • Supports graceful evolution
          • Change => Add another table
          • Existing queries are unaffected
        • Easily accommodates new data
          • Without affecting existing queries
        • Allows data to be easily combined ("joined") in new ways
        • 25+ years of relational database experience
    • 5. RDF in a nutshell Resource Description Framework
      • The adaptation of the relational model to the Web give rise to RDF
      • From tuples to triples
      • Any relational data can be represented as triples
        • Row Key --> Subject
        • Column --> Property
        • Value --> Value
    • 6. RDF in a nutshell Representing relational data in RDF (almost)
      • E.g., drug data
      • Represented in RDF (almost)
      BB.2 Anxiolytics C 16 H 21 NO 2 Propranolol Propranololo プロプラノロール Category Formula Is a Drug Legend resource literal Name Drug Category Formula BB.2   Anxiolytics C 16 H 21 NO 2 Drug Name BB.2 Propranolol BB.2 Propranololo BB.2 プロプラノロール
    • 7. RDF in a nutshell Representing relational data in RDF (almost)
      • Two important problems
        • Once out of the database internal ID (e.g., BB.2) becomes useless
        • Once out of the database internal names of schema element (e.g., Category) becomes useless as well
      • RDF solves it by using URI
        • Internal ID should be replaced by URI
        • Internal schema names should be replaced by URI
        • Values do (always) not need to be URI-fied
      http://dbpedia.org/resource/Propranolol http://dbpedia.org/resource/Category:Anxiolytics C16H21NO2 http://www.w3.org/2004/02/skos/core#subject http://dbpedia.org/ontology/formula http://www.w3.org/2000/01/rdf-schema#label http://dbpedia.org/ontology/Drug http://www.w3.org/1999/02/22-rdf-syntax-ns#type Legend resource literal Propranolol Propranololo プロプラノロール
    • 8.
      • Which URI should we use?
        • Popular ones! Data merge will take place automatically!
      RDF in a nutshell Representing data in RDF Q/A 1/4 http://dbpedia.org/resource/Propranolol http://dbpedia.org/resource/Category:Anxiolytics http://www.w3.org/2004/02/skos/core#subject + http://dbpedia.org/resource/Propranolol http://dbpedia.org/ontology/knownFor http://dbpedia.org/resource/Propranolol http://dbpedia.org/resource/Category:Anxiolytics http://www.w3.org/2004/02/skos/core#subject = http://dbpedia.org/ontology/knownFor http://dbpedia.org/resource/James_W._Black http://dbpedia.org/resource/James_W._Black
    • 9.
      • Where do I find popular URIs?
        • A difficult question with no clear answer
        • The best place to keep an eye on is
          • the Linking Open Data Project http://esw.w3.org/topic/SweoIG/TaskForces/CommunityProjects/LinkingOpenData
          • and in particular the following pages of the Wiki
            • Data Sets http://esw.w3.org/topic/TaskForces/CommunityProjects/LinkingOpenData/DataSets
            • Semantic Web Search Engines http://esw.w3.org/topic/TaskForces/CommunityProjects/LinkingOpenData/SemanticWebSearchEngines
            • Common Vocabularies http://esw.w3.org/topic/TaskForces/CommunityProjects/LinkingOpenData/CommonVocabularies
        • I normally use
          • Sindice API through sameas.org
            • e.g. http://sameas.org/html?q=propranolol&x=0&y=0
      RDF in a nutshell Representing data in RDF Q/A 2/4
    • 10.
      • What is a value? When shall we URI-fy a value?
        • Literals cannot be used to merge different data set
        • E.g., what if we what to merge two resources based on their labels?
          • BRCA may refer to different thing on the Web e.g., try http://en.wikipedia.org/wiki/BRCA
        • URI-fy any value that can be eventually used to merge different dataset and leave the other values as literals
      RDF in a nutshell Representing data in RDF Q/A 3/4 BRCA http://www.w3.org/2000/01/rdf-schema#label BRCA http://www.w3.org/2000/01/rdf-schema#label + = ?
    • 11. RDF in a nutshell Other data structure in RDF
      • Trees can be represented in RDF
      • Anything can be represented in RDF
    • 12. RDF in a nutshell Serializing RDF
      • Three alternatives to write triples, in
        • RDF/XML: Standard serialization in XML
          • <Description about=”subject”>
          • <property>value</property>
          • </Description>
          • e.g., http://dbpedia.org/data/Propranolol.rdf
          • Check-out the triples using http://www.w3.org/RDF/Validator/
        • NTriples: Simple (verbose) reference serialization (for specifications only) ‏
        • <http:// ... subject> <http:// ... predicate> “value” .
          • http://www.w3.org/RDF/Validator/ARPServlet?URI=http%3A%2F%2Fdbpedia.org%2Fresource%2FPropranolol&PARSE=Parse+URI%3A+&TRIPLES_AND_GRAPH=PRINT_TRIPLES&FORMAT=PNG_EMBED
        • N3 and Turtle: Developer-friendly serializations
          • :subject :property “value” .
          • e.g. http://dbpedia.org/data/Propranolol.n3
    • 13. RDF in a nutshell Serializing RDF in Turtle - namespaces
      • URI terms can be abbreviated using namespaces
        • @prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
        • @prefix dbpedia: <http://dbpedia.org/resource/> .
        • @prefix dbpedia-owl: <http://dbpedia.org/ontology/> .
        • dbpedia:Propranolol rdf:type dbpedia-owl:Drug .
      • <http://www.w3.org/1999/ 02/22-rdf-syntax-ns#type> = ' a '
        • dbpedia:Propranolol a dbpedia-owl:Drug .
    • 14. RDF in a nutshell Serializing RDF in Turtle - Literals
      • Literals: &quot;Propranolol&quot;
        • Literals with language tags: &quot; プロプラノロール &quot;@jp
        • @prefix rdfs: <http://www.w3.org/2000/01/rdf-schema#> .
        • dbpedia:Propranolol rdfs:label &quot;Propranolol&quot;@en .
        • dbpedia:Propranolol rdfs:label &quot;Propranololo&quot;@it .
        • dbpedia:Propranolol rdfs:label &quot; プロプラノロール &quot;@jp .
        • Typed literals: &quot;3.14&quot;^^xsd:float
        • dbpedia:Propranolol dbpprop:molecularWeight &quot;259.34&quot;^^xsd:float .
    • 15. RDF in a nutshell Serializing RDF in Turtle - Convience Syntax
      • Abbreviating repeated subjects:
        • dbpedia:Propranolol rdfs:label &quot;Propranololo&quot;@it .
        • dbpedia:Propranolol dbpprop:molecularWeight &quot;259.34&quot;^^xsd:float .
      • ... is the same as ...
        • dbpedia:Propranolol rdfs:label &quot;Propranololo&quot;@it ;
        • dbpprop:molecularWeight &quot;259.34&quot;^^xsd:float .
      • Abbreviating repeated subject/predicate pairs:
        • dbpedia:Propranolol rdfs:label &quot;Propranolol&quot;@en .
        • dbpedia:Propranolol rdfs:label &quot;Propranololo&quot;@it .
        • dbpedia:Propranolol rdfs:label &quot; プロプラノロール &quot;@cn .
        • ... is the same as ...
        • dbpedia:Propranolol rdfs:label &quot;Propranolol&quot;@en ,
        • &quot;Propranololo&quot;@it ,
        • &quot; プロプラノロール &quot;@cn .
    • 16. RDF in a nutshell Serializing RDF in XML - basics
      • W3C standardized an RDF/XML syntax [1]
      • The basic idea is to insert an XML element for each node (sobject and value) and arch (predicate)
      • Es.
        • < rdf:RDF
        • xmlns:rdf=&quot;http://www.w3.org/1999/02/22-rdf-syntax-ns#”
        • xmlns:skos=&quot;http://www.w3.org/2004/02/skos/core#&quot;
        • < rdf:Description
        • rdf:about =&quot;http://dbpedia.org/resource/Propranolol&quot;> < skos:subject >    < rdf:Description
        • rdf:about =&quot;http://dbpedia.org/resource/Category:Anxiolytics&quot;/>
        • </ skos:subject >
        • </rdf:Description>
        • </rdf:RDF>
      [1] RDF/XML Syntax Specification available at http://www.w3.org/TR/rdf-syntax-grammar/ dbpedia:Propranolol category:Anxiolytics skos:subject property element Root tag
    • 17. RDF in a nutshell Serializing RDF in XML - abbreviation
      • A possible abbreviation is using rdf:resource in the property elements
      • Es.
        • < rdf:RDF
        • xmlns:rdf=&quot;http://www.w3.org/1999/02/22-rdf-syntax-ns#”
        • xmlns:skos=&quot;http://www.w3.org/2004/02/skos/core#&quot;
        • <rdf:Description rdf:about=&quot;http://dbpedia.org/resource/Propranolol&quot;> <skos:subject
        • rdf:resource =&quot;http://dbpedia.org/resource/Category:Anxiolytics&quot;/>
        • </rdf:Description>
        • </rdf:RDF>
    • 18. RDF in a nutshell Serializing RDF in XML - abbreviation
      • Encoding Literals
        • datatype
        • <rdf:Description rdf:about=&quot;http://dbpedia.org/resource/Propranolol&quot;> <dbpprop:molecularWeight
        • rdf:datatype=&quot;http://www.w3.org/2001/XMLSchema#float&quot;
        • >259.34 </dbpprop:molecularWeight >
        • </rdf:Description>
        • Language tag
        • <rdf:Description rdf:about=&quot;http://dbpedia.org/resource/Propranolol&quot;> <rdfs:label xml:lang=&quot;it&quot;> Propranololo </rdfs:label >
        • </rdf:Description>
      dbpedia:Propranolol dbpprop:molecularWeight dbpedia:Propranolol rdfs:label “ Propranololo”@it &quot;259.34&quot;^^xsd:float
    • 19. RDF in a nutshell Serializing RDF in XML – rdf:type abbreviation
      • It’s possible to abbreviate rdf:type
        • Es.
        • Long form
        • <rdf:Description rdf:about=&quot; http://dbpedia.org/resource/Propranolol &quot;>
          • <rdf:type rdf:resource=&quot;http://dbpedia.org/ontology/Drug&quot;/>
          • </rdf:Description>
        • Abbreviated form
          • <dbpedia-owl:Drug rdf:about=&quot; http://dbpedia.org/resource/Propranolol &quot; />
      dbpedia:Propranolol http://dbpedia.org/ontology/Drug rdf:type
    • 20. RDF in a nutshell Serializing RDF in XML – more statements 1/3
      • E.g.
      • can be
        • listed
          • <rdf:Description rdf:about=&quot; http://dbpedia.org/resource/Propranolol &quot;>
          • <rdf:type rdf:resource=&quot;http://dbpedia.org/ontology/Drug&quot;/>
          • </rdf:Description>
        • <rdf:Description rdf:about=&quot;http://dbpedia.org/resource/Propranolol&quot;> <skos:subject rdf:resource =&quot;http://dbpedia.org/resource/Category:Anxiolytics&quot;/>
        • </rdf:Description>
        • nested
          • <rdf:Description rdf:about=&quot; http://dbpedia.org/resource/Propranolol &quot;>
          • <rdf:type rdf:resource=&quot;http://dbpedia.org/ontology/Drug&quot;/>
          • <skos:subject rdf:resource =&quot;http://dbpedia.org/resource/Category:Anxiolytics&quot;/>
          • </rdf:Description>
        • shortened to a minimum
          • <dbpedia-owl:Drug rdf:about=&quot; http://dbpedia.org/resource/Propranolol &quot; >
          • <skos:subject rdf:resource =&quot;http://dbpedia.org/resource/Category:Anxiolytics&quot;/>
          • </dbpedia-owl:Drug>
      dbpedia:Propranolol category:Anxiolytics skos:subject http://dbpedia.org/ontology/Drug
    • 21. RDF in a nutshell Serializing RDF in XML – more statements 2/3
      • E.g.
      • can be
        • listed
          • <rdf:Description rdf:about=&quot;http://dbpedia.org/resource/Propranolol&quot;>
          • <skos:subject rdf:resource =&quot;http://dbpedia.org/resource/Category:Anxiolytics&quot;/>
          • </rdf:Description>
          • <rdf:Description rdf:about=&quot;http://dbpedia.org/resource/Category:Anxiolytics&quot;>
          • <skos:broader
          • rdf:resource =&quot;http://dbpedia.org/resource/Category:Psycholeptics&quot;/>
        • </rdf:Description>
        • nested
          • <rdf:Description rdf:about=&quot; http://dbpedia.org/resource/Propranolol &quot;>
          • <skos:subject>
          • <rdf:Description rdf:about =&quot;http://dbpedia.org/resource/Category:Anxiolytics&quot;>
          • <skos:broader
          • rdf:resource =&quot;http://dbpedia.org/resource/Category:Psycholeptics&quot;/>
          • </rdf:Description>
          • </skos:subject>
          • </rdf:Description>
      dbpedia:Propranolol category:Anxiolytics skos:subject Category:Psycholeptics skos:broader
    • 22. RDF in a nutshell Serializing RDF in XML – more statements 3/3
      • E.g.
      • Applying all abbreviations becomes
        • <dbpedia-owl:Drug rdf:about=&quot; http://dbpedia.org/resource/Propranolol &quot; >
        • <rdfs:label xml:lang=&quot;it&quot;>Propranololo</rdfs:label>
        • <skos:subject>
        • <skos:concept r df:about =&quot;http://dbpedia.org/resource/Category:Anxiolytics&quot;>
        • <skos:broader>
        • <skos:concept
        • r df:about =&quot;http://dbpedia.org/resource/Category:Psycholeptics&quot;/>
        • </skos:broader>
        • </skos:concept>
        • </skos:subject>
        • </dbpedia-owl:Drug>
      dbpedia:Propranolol category:Anxiolytics skos:subject Category:Psycholeptics skos:broader http://dbpedia.org/ontology/Drug skos:concept “ Propranololo”@it rdfs:label
    • 23. RDF in a nutshell Merging XML files (representing an RDF model)
      • Suppose you have to merge the two following XML
      • Merging the XML trees is difficult, but being RDF …
        • <Drug rdf:about=&quot;Propranolol&quot;>
        • <skos:subject>
        • <skos:concept rdf:about=&quot;Anxiolytics&quot;/>
        • </skos:subject >
        • <excretion>
        • <AnatomicalStructure rdf:about=&quot;Kidney&quot;/>
        • </excretion>
        • </Drug>
        • <skos:concept rdf:about=&quot; Anxiolytics &quot;
        • skos:isSubjectOf=&quot; Propranolol &quot;>
        • <canDamage>
        • < AnatomicalStructure
        • rdf:about=&quot; Kidney &quot;/>
        • </canDamage>
        • </skos:concept>
      Propranolol Anxiolytics Drug rdf : type rdf : type skos:subject Concept Kidney rdf : type AnatomicalStructure excretion Propranolol Anxiolytics rdf : type Concept Kidney rdf : type AnatomicalStructure canDamage skos:isSubjectOf
    • 24. RDF in a nutshell Merging XML files 2/2
      • It’s (just) a matter to merge the two RDF graphs
      • NOTE: It works out nicely because both RDF/XML documents refer to the same resources and use the same vocabularies.
      U Propranolol Anxiolytics Drug rdf : type rdf : type skos:subject Concept Kidney AnatomicalStructure canDamage excretion skos:isSubjectOf rdf : type
    • 25. Publishing RDF as Linked Data Principles
      • Things must be identified with dereferenceable HTTP URIs.
      • If such a URI is dereferenced asking for the MIME-type application/rdf+xml, a data source must return an RDF/XML description of the identified resource.
          • Information Resources
          • Non-Information Resources
      • Besides RDF links to resources within the same data source, RDF descriptions should also contain RDF links to resources provided by other data sources
    • 26. Publishing RDF as Linked Data More on Content Negotiation
      • Approach
      • E.g.
        • Resource identifier
          • http://dbpedia.org/resource/Propranolol
        • RDF representation describing Propranolol
          • http://dbpedia.org/ data /Propranolol .rdf
        • HTML representation describing Propranolol
          • http://dbpedia.org/ page /Propranolol
      • Test it! http://idi.fundacionctic.org/vapour
    • 27. Publishing RDF as Linked Data Recipes for Serving Information as Linked Data
      • Recipes [1]
      • Serving static RDF files
      • Serving information stored in a DB as (virtual) RDF
      • Using a RDF storage with a Linked Data Interface
      • Wrap API to serve (virtual) RDF
      • [1] http://www4.wiwiss.fu-berlin.de/bizer/pub/LinkedDataTutorial/
    • 28. Publishing RDF as Linked Data Recipe 1 - Serving static RDF files 1/3
      • IDEA: negotiate content using Apache mod_rewrite by writing a .htaccess file
      • Directory layout
        • apachedocumentroot/
          • examples/
            • .htaccess
            • content/
              • file.html
              • file.rdf
      • Expected behavior
        • Requesting http://localhost/examples/file
        • a HTML browser is redirected to http://localhost/examples/content/file.html
        • a Linked Data application is redirected to http://localhost/examples/content/file.rdf
    • 29. Publishing RDF as Linked Data Recipe 1 - Serving static RDF files 2/3
      • # Turn off MultiViews
      • Options –MultiViews
      • # Rewrite engine setup
      • RewriteEngine On
      • RewriteBase /examples
      • # Rewrite rule to serve HTML content from the vocabulary URI if requested
      • RewriteCond %{HTTP_ACCEPT} !application/rdf+xml.*(text/html|application/xhtml+xml)
      • RewriteCond %{HTTP_ACCEPT} text/html [OR]
      • RewriteCond %{HTTP_ACCEPT} application/xhtml+xml [OR]
      • RewriteCond %{HTTP_USER_AGENT} ^Mozilla/.*
      • RewriteRule ^example/$ content/file.html [R=303]
      • # Rewrite rule to serve RDF/XML content if requested
      • RewriteCond %{HTTP_ACCEPT} application/rdf+xml
      • RewriteRule ^example/ content/file.rdf [R=303]
      • # Rewrite rule to serve RDF/XML content by default
      • RewriteRule ^example/ content/file.rdf [R=303]
      • [source: http://www.w3.org/TR/swbp-vocab-pub/#recipe4example ]
    • 30. Publishing RDF as Linked Data Recipe 1 - Serving static RDF files 3/3
      • Testing the configuration
      http://localhost/examples/ file http://localhost/examples/ content/file.html http://localhost/examples/content/file.html http://localhost/examples/ file http://localhost/examples/ content/file.rdf http://localhost/examples/content/file.rdf
    • 31. Publishing RDF as Linked Data Recipe 2 - DB as (virtual) RDF
      • General Idea
      • Ready to use solutions
        • D2R Server
          • http://sites.wiwiss.fu-berlin.de/suhl/bizer/d2r-server/index.html#quickstart
        • OpenLink Virtuoso
          • http://virtuoso.openlinksw.com/Whitepapers/pdf/Virtuoso_SQL_to_RDF_Mapping.pdf
          • http://virtuoso.openlinksw.com/Whitepapers/pdf/Deploying_Linked_Data_Final1.pdf
        • Triplify
          • http://triplify.org/Overview
    • 32. Publishing RDF as Linked Data Recipe 3 - RDF storage + Linked Data Interface
      • General Idea
      • Ready to use solutions
        • Pubby : a Linked Data interfaces to SPARQL endpoints.
          • http://www4.wiwiss.fu-berlin.de/pubby/
    • 33. Publishing RDF as Linked Data Recipe 4 - Wrap API to serve (virtual) RDF
      • General Idea
      • No “general” solutions, only ad hoc ones
        • Virtuoso Sponger : a framework for developing Linked Data wrappers (called cartridges) around different types of data sources
          • http://virtuoso.openlinksw.com/dataspace/dav/wiki/Main/VirtSponger
          • http://virtuoso.openlinksw.com/dataspace/dav/wiki/Main/VirtSpongerCartridgeSupportedDataSources
        • SIOC Exporters
          • http://sioc-project.org/exporters
      [source http://sites.wiwiss.fu-berlin.de/suhl/bizer/pub/Bizer-ESWC2007-RDFbookmashup.pdf ]
    • 34. Publishing RDF as Linked Data Which recipe should I use?
      • How much data do you want to serve?
        • several hundred RDF triples: recipe 1
        • Larger dataset: recipe 2, 3 and 4
      • How is your data currently stored?
        • In a relational database: recipe 2
        • Available through an API: recipe 4
        • As RDF dump: recipe 3
      • How often does your data change?
        • Frequently: recipe 2 and 4
        • Rarely: recipe 1 and 3
    • 35. RDF in a nutshell RDF Resources
      • RDF at the W3C - primer and specifications
        • http://www.w3.org/RDF/
      • Semantic Web tools - community maintained list; includes triple store, programming environments, tool sets, and more
        • http://esw.w3.org/topic/SemanticWebTools
      • 302 Semantic Web Videos and Podcasts - includes a section specifically on RDF videos
        • http://www.semanticfocus.com/blog/entry/title/302-semantic-web-videos-and-podcasts/
    • 36. credits
      • Some slides are derived from
        • “ How to Publish Linked Data on the Web” by Chris Bizer, Richard Cyganiak and Tom Heath http://sites.wiwiss.fu-berlin.de/suhl/bizer/pub/LinkedDataTutorial/

    ×
