New Horizons in Bariatric Surgery – endoluminal treatments for weight regain after gastric bypass: Elliot R Goodman MD Bar...
Background <ul><li>150,000-200,000 bariatric operations done a year </li></ul><ul><li>Weight loss of 67-75% EBWL in 80% of...
Background <ul><li>Estimated 10% - 20%  will regain some weight at 5 and 10 years </li></ul><ul><li>Usually a nadir weight...
Weight loss  trajectory after gastric bypass:
Background <ul><li>Review of Literature on Reoperative Bariatric Surgery </li></ul><ul><ul><li>838 patients - open reopera...
Background: <ul><li>2008 ASMBS Member Survey </li></ul><ul><ul><li>What is the weight loss expectation for an endoluminal ...
Endoluminal Gastric Pouch Reduction (EGPR) StomaphyX TM
Endoluminal Gastric Pouch Reduction <ul><li>StomaphyX TM   (EndoGastric Solutions, Redmond WA) </li></ul><ul><ul><li>FDA a...
Endoluminal Gastric Pouch Reduction <ul><li>Procedure </li></ul><ul><ul><li>Average 20-40 3-0 polypropylene fasteners per ...
Diagram for fasteners H H H H H H
Endoluminal Gastric Pouch Reduction
Endoluminal Gastric Pouch Reduction Pre anastomosis Post anastomosis
Endoluminal Gastric Pouch Reduction Gastro-esophageal Junction
Fluoroscopic evidence of stomal narrowing after EGPR with Stomaphyx: GJ stoma before EGPR Stoma after EGPR
Serosa-to-serosa Fusion Full thickness tissue plication and serosa-to-serosa  fusion seen in several animal models
Beth Israel Medical Center results 2008-9 (N=64) Age (years) 47.5  (24-66) Female / Male 92% female / 8% male Height (inch...
Median BMI before StomaphyX 39.85 (25.9-54.9) Median BMI post Stomaphyx 37.75(25.1-55.2) Median follow up(months) 6(1-13) ...
Median weight loss (lbs.) post StomaphyX  15.5(3.3-67) Median OR time 50 (35-130) Median reduction in gastric pouch length...
RESULTS: <ul><li>Dumping syndrome improved </li></ul><ul><li>GERD improved </li></ul>
Endoluminal Gastric Pouch Reduction <ul><li>3 patients underwent repeat procedure due to unsatisfactory results. </li></ul...
Latest data pooled  from 3 large US centers  (BIMC, OSU and Alvarado Hospital): <ul><li>124 patients underwent EGPR at thr...
Latest data (con): <ul><li>EGPR reduced pouch length by 50(+/-24)% </li></ul><ul><li>Mean number of plications 22(+/-9) </...
Predictive factors: <ul><li>Weight loss after EGPR significantly correlated with weight loss after initial GB (p=0.001) </...
Endoluminal Gastric Pouch Reduction <ul><li>Mechanism of Weight loss </li></ul><ul><li>Reduction in size of pouch </li></u...
The ROSE Procedure (by USGI):
R epair  O f  S urgery  E ndolumenal-ROSE Repair of Dilated Gastric Pouch and Stoma Post RYGBP Dilated Stoma Post ROSE Pro...
ROSE with the USGI IOP Dilated pouch and stoma Stoma restoration: Use EOS to create circumferential folds around stoma  Cr...
ROSE Registry | Site, Patient Mix <ul><li>9 sites collectively enrolled 116 patients  </li></ul><ul><ul><li>Targeted cross...
ROSE Registry | Design, Demographics INCLUSION CRITERIA:  Broadly defined to collect clinical experience across the full s...
ROSE Registry | Safety Findings Intra-Op No significant intra-op complications <ul><li>Early in the experience: </li></ul>...
ROSE Registry | Acute Procedural Success PRE-PROCEDURE 2.6 cm POST-PROCEDURE 0.5 cm INTRA-OP STOMA CHANGE Cases Completed ...
Stoma/Pouch Reduction Achieved Cases Completed  N=112/116  (97%) Mean Final Stomal Diameter 11.5 mm Mean % Stomal Reductio...
Results-6 Month Weight Loss  *based on target BMI 25kg/m 2 6 Month Endpoint (N=96) Mean for  Total Registry Max for Indivi...
ROSE WEIGHT LOSS WITH STOMA REDUCTION SUBSET 12 MONTHS N=73 (min, max) 12 MONTHS N=22 (30% of N) (final stoma <10mm) MEAN ...
Grouped Variable Analysis  6 month ROSE Data Best Positive Group Predictors for %EWL at 6 months * *using linear regressio...
Analysis/Discussion <ul><li>Success post-bypass predicted ROSE success at 6 months (p=.006) </li></ul><ul><ul><li>Top 20% ...
Durability of Plications at 12 (and 24 Month) Endoscopy 24 month EGD post-ROSE 12 month EGDs  post-ROSE <ul><li>Anchors vi...
The IOP System for Revision <ul><li>ROSE plications have been shown to be durable </li></ul><ul><li>ROSE proves to be a sa...
<ul><li>Apollo Endosurgery  Overstitch System: </li></ul>
Overstitch : <ul><li>General application endoluminal platform </li></ul><ul><li>Fits over a therapeutic upper endoscope </...
Apollo Endosurgery  Overstitch  pilot study for weight regain ( Thompson et al , 2011): <ul><li>Aim: To demonstrate techni...
Patient Characteristics: Average pre-bypass weight 342.2+/-75.4lbs Average nadir weight 206.23+/-57.6lbs Average weight at...
Patient Characteristics: <ul><li>22 RYGB patients presented with weight regain </li></ul>Age 48+/-9 yrs Gender 16/22 (73%)...
Technique: <ul><li>Outlet reduction: </li></ul><ul><li>Tissue ablation (APC) </li></ul><ul><li>Interrupted stitches at the...
Results: <ul><li>Technical success: 100% </li></ul><ul><li>Post-stomal diameter 5.6+/-1.9mm </li></ul>Outlet (n=11) Pouch ...
Results: n=18 patients Average weight loss 22.5+/-13.4lbs Average follow-up time 3 months % weight regain loss 60.4% % exc...
Stoma vs. Pouch: Outlet reduction  n=10 Outlet/pouch reduction n=8 Average weight loss 15.6lbs 30.9lbs Average follow-up t...
Conclusions: <ul><li>EGPR procedures are safe and can produce almost 50% loss of regained weight after 6-12 months </li></...
