    • 1. Automated Deployment With Phing
      Or: How I Will Replace You With A Very Small Shell Script
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      1
    • 2. Who
      Daniel Cousineau
      Senior Software Applications Developer
      Texas A&M University
      Division of Student Affairs
      Department of IT
      http://www.toosweettobesour.com/
      @dcousineau
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      2
    • 3. The Problem
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      3
    • 4. Human beings make mistakes
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      4
    • 5. We aren’t as accurate each repetition
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      5
    • 6. Machines don’t have this problem
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      6
    • 7. They do the same thing every time (supposedly)
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      7
    • 8. At Any Given Time
      New Code
      New Configuration
      New Database Schema
      New Static Files
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      8
    • 9. A Lot To Remember
      Did you remember to upload ALL new files?
      Did you remember to update your DB?
      Did you remember to correct your config?
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      9
    • 10. Even Worse
      Did you clear your caches?
      Did you delete that old file/plugin?
      In the upload process, was your configuration overwritten?
      Did you upload ALL the changed files?
      When did you last upload?
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      10
    • 11. The Solution
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      11
    • 12. Automation!
      Build scripts!
      We are programmers after all…
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      12
    • 13. ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      13
      Don’t Do More Work Than You Have To!
    • 14. ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      14
      Work Hard At Being Lazy!
    • 15. What is Automation?
      Automated deployment means a single command
      Locks your live site
      Uploads changed files
      Clears caches and temporary files
      Updates the database schema
      Runs other cron tasks
      Unlocks your live site
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      15
    • 16. Why Do We Automate?
      Deployment is tricky
      Repetition degrades quality
      She sells sea shells by the sea shore
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      16
    • 17. When Is Automation Used?
      All the time!
      Staging
      Live
      Probably best to use it on your dev box too!
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      17
    • 18. The Basics
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      18
    • 19. Tools of the Trade
      Build System
      Phing
      Apache ANT
      Capastrano
      Plain PHP or BASH or BAT Files
      File Transfer
      Rsync (*NIX Environments)
      Xcopy (Windows Environments)
      Configuration Management
      Database Migration
      DBDeploy
      Doctrine
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      19
    • 20. Phing Philosophy
      Build scripts contains "Targets"
      Targets should be small and specialized.
      Example Targets:
      clean
      Clear temporary and cached files
      copy
      Copy files to their intended destination
      migrate
      Upgrade the database schema
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      20
    • 21. Phing Philosophy
      Targets can have dependencies
      Target "live" can depend on clean, copy, and migrate
      Meaning, when we run the "live" target, it first runs clean, copy, then migrate
      And any tasks they depend on
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      21
    • 22. Installing Phing
      pear channel-discover pear.phing.info
      pear install phing/Phing
      Want all the little dependencies?
      pear config-set preferred_state alpha
      pear install –alldepsphing/Phing
      pear config-set preferred_state stable
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      22
    • 23. Running Phing
      $> phing –v
      Lists Phing version
      Phing expects to find a file "build.xml" in the current directory
      build.xml defines the targets
      You can use the "-f <filename>" flag to specify an alternate build file like
      $> phing -f build-live.xml
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      23
    • 24. Syntax
      XML
      If you don’t already know it, you have bigger problems
      Variables
      ${variablename}
      Conventions
      Psuedo-Namespaces using periods
      ${namespace.variable.name}
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      24
    • 25. Basic Conventions
      build.xml
      Central repository of your top-level tasks
      build-*.xml
      Can be included into build.xml.
      Usually for grouping by target (dev, staging, live) or task (migrate, test, etc.)
      build.properties
      Technically an INI file that contains variables to be included by build files.
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      25
    • 26. Basic build.xml
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      26
      <?xml version="1.0" encoding="UTF-8"?>
      <project name="ZendCon" default="default" basedir=".">
      <property file="build.properties" />
      <target name="default">
          <echo message="Howdy World!" />
      </target>
      </project>
    • 27. Basic build.properties
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      27
      source.directory = /src
      ## Database Configuration
      db.user = username
      db.pass = password
      db.host = localhost
      db.name = database
    • 28. File Transfer
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      28
    • 29. Techniques
      Built in Phing Copy Task
      Cross Platform
      Slow
      Not over network
      Version Control Checkout/Update
      Syncs deleted files
      User created files usually ignored
      Rsync
      Great for *NIX environments.
      Almost guaranteed to be installed on
      Linux, BSD, Mac OSX
      Can be installed on Windows
      Xcopy
      Good for Windows environments
      Faster than Phing Copy
      Not over network
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      29
    • 30. Pitfalls
      Cleanup Deleted Source Files
      Usually only a problem when you have * include patterns
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      30
    • 31. Pitfalls
      User created files are a HUGE pitfall
      /htdocs/images/upload
      Sync programs usually will delete content your deployment machine doesn’t have
      What if user upload are mixed in with files you want to manage?
      Solutions
      Keep user created content completely separated. The further up the file tree and consolidated the better.
      Separate static file server, Amazon S3, or other style CDNs
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      31
    • 32. Executing External Tools
      Nearly all file transfer tools will be external commands
      For this we need the Exec task
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      32
      <exec command="cp file1 file2" />
    • 33. Rsync
      So many different options you’re best off finding your own tutorials or reading MAN pages
      rsync -aCvz
      -e 'ssh -i /path/to/ssh-key'
      ${project.basedir}/src
      user@domain: ${staging.deployment.directory}/
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      33
    • 34. Rsync Options Of Note
      -a archive-mode
      Recursive copy, preserve everything, etc.
      -C cvs-exclude
      Ignore .cvs, .svn, and other version control artifacts
      -v verbose
      Know EXACTLY what’s going on
      -z compress
      Compress information transmitted
      -e alternative remote shell
      Use a custom SSH command (namely use key-pair)
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      34
    • 35. Xcopy
      Best when your live deployment process involves copying to a network share on Windows machines
      xcopy
      ${project.basedir}${source.directory}*
      ${staging.deployment.directory}
      /D /I /Y /S /E
      /Exclude:${project.basedir}staging.deployment.exclude
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      35
    • 36. Xcopy Options Of Note
      /d
      Update only those files that are different (timestamps)
      /i
      Creates target directories if they don’t exist
      /y
      Do not prompt
      /s
      Copy all directories and sub-directories…
      /e
      …Even if the directories are empty
      /exclude
      Exclude files based on glob patterns
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      36
    • 37. Xcopy Exclude File Example
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      37
      mp
      uploads
    • 38. Configuration Management
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      38
    • 39. Techniques
      Check incoming domain
      www.domain.com means load production configuration
      localhost/domain.com means load development configuration
      Check for an environment file
      Contents of DOCUMENT_ROOT/.env determine configuration
      Copy over during deployment
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      39
    • 40. Check Incoming Domain
      Pros
      No chance for error
      Cons
      Detection is a weak link
      Especially when development, staging, and live have different web servers (e.g. Apache to IIS)
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      40
    • 41. Check for an Environment File
      Pros
      Consistent regardless of Server or OS changes
      Easy to repair
      Quick FTP or SSH
      Easy Testing
      Just swap file contents
      Cons
      Forget to copy changes?
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      41
    • 42. Copy Over During Deployment
      Pros
      Images and CSS now manageable
      Reduce redundancy
      Simple to repurpose regular push command
      Cons
      Difficult to manage
      Forget to copy changes?
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      42
    • 43. Which one to choose?
      Depends on your application architecture
      Depends on your environment
      You’ll know what’s best for your project
      I use a combination of Environment File and Copy Over During Deployment
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      43
    • 44. Database Migration
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      44
    • 45. Database Deployment Philosophy
      “Versions” often referred to as “Deltas”
      Each Delta has an UP and a DOWN script
      UP makes the changes
      DOWN reverts the changes
      Each change should be a non-destructive schema change
      Unless of course you need data alteration
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      45
    • 46. DBDeploy Philosophy
      Each delta is 2 native SQL scripts
      Separated by --//@undo
      Database version is stored in a special table
      Version X was applied at TIMESTAMP…
      Beware corruption!
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      46
    • 47. DBDeploy Under The Hood
      Connect to the database, read from changelog table, get the most current revision installed
      Retrieve all delta files newer that the current revision
      Revision numbers are based off of alphabetic sorting, name your files accordingly
      Pull all the “UP” changes and concatenate them to a migration script
      Up to YOU to run the migration script
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      47
    • 48. Installing DBDeploy
      Is Phing already installed? Great! So is DBDeploy…
      Create the changelog table
      Track the current version of your DB
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      48
      CREATE TABLE changelog (
        change_number BIGINT NOT NULL,
        delta_set VARCHAR(10) NOT NULL,
        start_dt TIMESTAMP NOT NULL,
        complete_dt TIMESTAMP NULL,
        applied_by VARCHAR(100) NOT NULL,
        description VARCHAR(500) NOT NULL
      );
      ALTER TABLE changelog
      ADD CONSTRAINT Pkchangelog PRIMARY KEY (change_number, delta_set);
    • 49. Basic Delta: 01_init.sql
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      49
      --//
      CREATE TABLE IF NOT EXISTS `users` (
        `id` int(10) unsigned NOT NULL auto_increment,
        `handle` varchar(25) NOT NULL default '',
        PRIMARY KEY  (`id`),
        UNIQUE KEY `users_handle_index` (`handle`)
      ) ENGINE=InnoDB  DEFAULT;
      --//@UNDO
      DROP TABLE IF EXISTS `users`;
      --//
    • 50. Run Migration
      First add a task to your Phing build file
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      50
      <target name="migrate">
      </target>
    • 51. Run Migration
      Generate the SQL migration file
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      51
      <target name="migrate">
      <dbdeploy
      url="mysql:host=${db.host};dbname=${db.name}"
      userid="${db.user}"
      password="${db.pass}"
      dir="${project.basedir}/db/deltas"
      outputfile="${project.basedir}/up.sql"
      undooutputfile="${project.basedir}/down.sql"
      />
      </target>
    • 52. Run Migration
      Execute the SQL script
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      52
      <target name="migrate">
      <dbdeploy
      url="mysql:host=${db.host};dbname=${db.name}"
      userid="${db.user}"
      password="${db.pass}"
      dir="${project.basedir}/db/deltas"
      outputfile="${project.basedir}/up.sql"
      undooutputfile="${project.basedir}/down.sql"
      />
      <exec
      command="/usr/bin/mysql -h${db.local.host} -u${db.local.user}
      -p ${db.local.pass}
      ${db.local.name} < ${project.basedir}/up.sql"
      dir="${project.basedir}"
      checkreturn="true">
      </target>
    • 53. Pitfalls
      Make sure you have a good CLI app for loading a SQL file
      /usr/bin/mysql
      mysql.exe
      Build script travelling across operating systems?
      Write your own Phing task to execute the migration output?
      Was the changelog table created in the first place?
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      53
    • 54. Doctrine Database Migrations
      Integrated into the Doctrine CLI tool
      ./doctrine migrate
      Same philosophies
      BUT, deltas are PHP objects that contain an UP and a DOWN method
      Run using the Phing exec task
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      54
    • 55. Other Database Migration Tools
      http://www.liquibase.org/
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      55
    • 56. Closing Thoughts
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      56
    • 57. Further Resources
      The people around you
      More people than you know automate their deployment
      There are many, many different techniques
      My techniques may suck for your particular setup
      #phpcon freenode
      Many of the speakers hang out there
      Many smart people hang out there
      I HANG OUT THERE!
      Therefore I am smart
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      57
    • 58. Further Resources
      Blogs
      http://phpdeveloper.org
      Documentation
      http://phing.info
      http://dbdeploy.com
      Google
      Experimentation
      Pushing to a local directory
      Pushing to a virtual machine
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      58
    • 59. Questions?
      ZendCon '09
      Automated Deployment With Phing - Daniel Cousineau
      59
    • 60. http://joind.in/937

    ×
