A Deep Dive into the
    Flex 3 Framework
    Joshua Jamison
    EffectiveUI
    www.effectiveui.com
    January 30th, 2009
...
Introductions

       Who am I?


       Joshua Jamison

                Software Architect at EffectiveUI
          

 ...
What will we talk about today?

       Several topics that help you maximize Flex’s power


       Things many beginner -...
Data Binding




                                                                                 ®




                  ...
The Problem




                                                                  Need a way to sync views with changing d...
The Scenario




                        Scenario: A value object with some text that should be displayed on a label




 ...
Roll-my-own solution


       I have a VO that contains some text I need to display on the screen





        public cla...
Roll-my-own solution


       How will I know when the text eld on this object changes? I’ll have it dispatch

       eve...
Roll-my-own solution


       In the view, I’ll listen for those events:





                  private var _vo : BoringV...
Roll-my-own solution




                                                     Ugh. Annoying. Too much code for so simple a...
Flex’s solution: data binding


        Data binding is a contract between two objects: one promises to dispatch events

...
Flex’s solution: data binding


       Mark the object and its property as [Bindable], use curly braces, and away you go.
...
The Basic Idea


        A property of a component changes


        The property’s component res off an event indicating ...
MXML Example (with curly braces), binding to a property


        To bind to a property, simply put a reference to the pro...
Metadata


        What is it?


                   Metadata is information that tells the compiler how components are us...
Metadata


         Where should [Bindable] metadata be placed?


                   Before a public class de nition
    ...
Metadata


        Why use a custom event type?


                   It’s more efficient than using the default PropertyCha...
MXML Example (with curly braces), binding to a function


        Functions can be used as a source for data binding


  ...
MXML Example (with curly braces), binding to XML data


        Can bind directly to XML data


                   XML do...
MXML Example: using <Binding> tag


        The MXML <Binding> tag accomplishes the same thing as curly braces


        ...
What does the generated code buy you?


        Brevity


        Lots of error handling


        Binding to expression...
Binding in Actionscript: bindProperty() and bindSetter()


        Bindings can be created in Actionscript code, too


  ...
Common problem: performance in Cairngorm


        Too many bindable elds on the model doesn’t perform well!


        Wh...
Common problem: two-way binding


        Problem: two elds should update each other


        Simple solution: Create tw...
StyleManager




                                                                                 ®




                  ...
StyleManager: Styling 101


        “Styles” differ from “Properties” in the way they are set, maintained, and accessed in
...
StyleManager: Styling 101


        Styles are inheritable


                   Styles must propagate to their children, ...
StyleManager: Styling 101


        Every time a style is set, the framework has to keep track of:


                   A...
Style Precedence


        Global, Type, Class, Attribute





    *Image courtesy Juan Sanchez and Andy McIntosh

      ...
Adding styles to components in AS3


        To add styles to individual components, use UIComponent.getStyle and setStyle...
Using StyleManager to manage Assets


       You can embed assets through the StyleManager


                   Advantage...
Using the StyleManager


        Other things you can do with the StyleManager:


                   Make changes to exis...
Load style declarations at runtime


        Uses different CSS les for the different themes


        Load the style decla...
Example: swap styles from a SWF at runtime




Example courtesy of Juan Sanchez and Andy McIntosh



                     ...
Example: swap styles from a SWF at runtime




Example courtesy of Juan Sanchez and Andy McIntosh



                     ...
Example: clearing and restoring styles


        Same example as before, but a few new buttons / handlers:


public funct...
StyleManager demo:
                                                    ThemeSwap
                                         ...
In case it doesn’t work live: “Obsidian” theme




                                                                       ...
In case it doesn’t work live: iTunes 7 Theme




                                                                       ®
...
In case it doesn’t work live: Windows Vista theme




                                                                    ...
More info?


        Creating Visual Experiences with Flex 3.0, by Juan Sanchez and Andy McIntosh


                   St...
Collections




                                                                                ®




                    ...
What is a collection?


        Data comes in many formats


                   Objects
            

                  ...
Why do we need collections?


        Collections:


                   Abstract the format of the data from the display ...
So, what are collections really?


        Classes that implement IList, ICollectionView


                   IList is an...
IList


        Interface for working with linear data


                   Interesting methods:
            

         ...
ICollectionView


        Interface for sorting, ltering, and interacting with linear and hierarchical data


           ...
ListCollectionView


        Implements IList


        Implements ICollectionView


        Consequently, components ex...
ArrayCollection, XMLListCollection


        The two classes in the Flex framework that inherit from ListCollectionView

...
Where are collections useful?


        Various classes can all use collection objects as their data source; these are cal...
Review: why do we need collections?


        Collections:


            1. Abstract the format of the data from the disp...
1. Abstract the data format


        The <mx:TileList> can accept many different types of data sources, including an

   ...
2. Update views when data changes


        One of the main reasons to use collections is so that when the data contained ...
3. Consistent data manipulation operations


        Both ArrayCollection and XMLListCollection inherit from ListCollectio...
4. Sorted views


        Collections provide a mechanism to sort the view of the data without changing the

        unde...
5. Filtered views


        Collections also offer an easy way to lter data


        Simply set the lterFunction property...
Hierarchical Data


        Representing hierarchical data in XML is trivial, since XML itself is natively

        hiera...
Cursors


        Classes used to navigate through collection objects


        Provide convenient, consistent ways to ac...
Common Problem: Manipulating a view component
immediately after changing the data provider

        Setting the dataProvid...
Common Problem: Not seeing expected changes in the view


        If the objects stored in a collection are not [Bindable]...
SystemManager




                                                                                  ®




                ...
SystemManager: overview

       “Root” of the Flex swf


       First class that is instantiated


       Controls and c...
SystemManager: 2 frame swf

       Flex apps currently publish to a 2 frame SWF

                1st frame (small): Syste...
SystemManager: 2 frame walkthrough



                        SystemManager
                                              ...
SystemManager: 2 frame walkthrough

                                                                           Frame 2 pla...
SystemManager: what is it good for?

       Dispatches browser-resize events


       Detecting if assets have been embed...
SystemManager: what else is it good for?

       Getting a reference to the root object

                SystemManager.st...
SystemManager Pitfalls: Multiple Child Lists

       PopUp windows added through PopUpManager.addPopUp or createPopUp do n...
SystemManager Pitfalls: The Root

       The system manager tries to own “_root”

                May manipulate the root...
Resources


        Michael Labriola’s 2008 360|Flex San Jose talk about Data Binding: “Diving in the Data

        Bindi...
Thank you!

  Joshua Jamison
  joshua.jamison@effectiveui.com
  twitter: cephus
  brightkite: cephus




                  ...
