Upgrading to Apache Tomcat 7Filip Hanik, Systems Engineer                                © 2009 VMware Inc. All rights res...
Agenda   Introduction   Specification changes (Servlet 3.0)   New features (Incl. WebSocket Deep Dive)   Current statu...
Introduction Apache Tomcat committer & PMC member Vmware Employee and Sales Engineer Weekend Warrior with US Army Reser...
What about you? Who’s running Apache Tomcat 6? Who’s running Apache Tomcat 5 or older?                                  ...
What do the version numbers mean? 7.0.22 • 7 major version • 0 minor version • 22 build number Major • New JSRs / Specif...
What do the version numbers mean? 7.0.22 • 7 major version • 0 minor version • 22 build number Minor • 4.0 vs 4.1 • 5.0 ...
What do the version numbers mean? 7.0.22 • 7 major version • 0 minor version • 22 build number Build Number • Incremente...
When to upgrade? Starts with application developers Need new features in Java Need new features in Servlet specificatio...
So what changed?                   9
Specification Changes                        10
New version of Java Less invasive as technology matures 1.5 to 1.6 should be seamless Moving to 1.6 is beneficial from ...
Asynchronous Servlets No more thread per request model Servlet API still uses blocking programming model • Async is more...
Annotations Alternative to XML configuration Requires scanning of libraries Will slow down startup time • Performance c...
Web Fragments Libraries can ship with its partial web.xml configuration • Eases including frameworks Requires scanning o...
Session Management Session tracking • Cookie, URL or SSL ID Session cookie can be configured • name • domain • path • co...
Programmatic Login Easier integration with alternative authentication solutions Calling login/logout • Directly within a...
Other changes JSP 2.2 • JSP property group additions • New omit attribute for <jsp:attribute .../> Expression Language 2...
New featuresTomcat evolves too                     18
Management JMX remote lifecycle listener  Allows JMX communication through firewall jconsole (or JMX client) url       ...
ManagementManager application can differentiate between primary, backup andproxy sessions                                 ...
Performance Limit loaded JSPs with LRU cache GZIP compressed output streams can now be flushed Remove bottleneck in ses...
Performance Tomcat jdbc-pool Alternative to commons-dbcp Well fitted for multi core machines Documented at tomcat.apac...
Resources New singleton attribute  Create new object on JNDI lookup New closeMethod attribute  Close resources upon sh...
Deployment Support parallel deployment Existing sessions go to the original applications New users go to the new applic...
Deployment Copying of  /META-INF/context.xml to  $CATALINA_BASE/<engine>/<host>/contextname.xml now optional and disab...
Deployment Improved memory leak detection and prevention Prevents common memory leaks during undeployment Warns on unpr...
Security Cross-site request forgery (CSRF) protection filter CSRF protection added to manager application    • role name...
Security Graceful handling of users book-marking the login page Session IDs generated using SecureRandom by default SSL...
Embedding and Extending New o.a.catalina.startup.Tomcat class for embedding Binary and source JARs provided for Apache M...
Embedding and Extending New o.a.catalina.startup.Tomcat class for embedding Adding a servlet                            ...
Code clean-up   Generics   Better definition of Lifecycle interface   Comet classes have moved to o.a.catalina.comet  ...
Windows Windows installer detects 32-bit or 64-bit JVM and installs correct native binaries Windows native authenticatio...
Current status Apache Tomcat 7 is stable as of 7.0.6  Current release is 7.0.27 Continuing to provide a release a month...
What to expect from an upgrade Tomcat 4 to Tomcat 7 Tomcat 5 to Tomcat 7 Tomcat 6 to Tomcat 7                          ...
Web SocketsNew in Tomcat 7.027  Part of HTML 5                      35
WebSockets – Bi-drectional protocol (binary/text)                                                    36
Event Based on both Server and Client                                        37
Client - Initiating a WebSocket                                  38
Client - Initiating a WebScoket                                  39
Network – Opening WebSocket Request                                      40
In Tomcat 7 – Extend WebSocketServlet                                        41
In Tomcat 7 – Create a StreamInbound object                                              42
43
Network – Opening WebSocket - Response                                         44
Socket Opened – First Event                              45
46
Client - Send a Message                          47
In Tomcat 7 – Receive the message                                    48
49
50
Client – Receive the Message                               51
Future Plans   Servlet 3.1 addition   Commons DBCP v2   Socket IO   Keep on top of open bugs   Continue reviewing enh...
Useful Resources                   53
Useful resources http://www.tomcatexpert.com http://tomcat.apache.org  • http://blogs.apache.org/tomcat Mailing lists  ...
References             55
References TomcatExpert.com http://www.tomcatexpert.com/blog/2012/04/24/websockets-tomcat-7 http://www.tomcatexpert.com/b...
Vmware Supported Platform                            57
Questions            58
