  1. 1. Extending Groovys Swing User Interface in Builder to Build Richer Applications Danno Ferrin, Intelligent Software Solutions, Inc. James Williams, Spatial Networks, Inc. BOF-5110 Speaker’s logo here (optional)
  2. 2. <ul><ul><li>Learn how to customized Groovy’s SwingBuilder to add custom widgets and non-visual components. </li></ul></ul>
  3. 3. Not always an enterprise question… <ul><li>BUT WILL IT </li></ul><ul><li>S C A L E </li></ul><ul><li>? </li></ul>
  4. 4. Agenda <ul><li>Ways to Extend SwingBuilder </li></ul><ul><li>FactoryBuilderSupport Overview </li></ul><ul><li>Case Study: SwingXBuilder </li></ul>
  5. 5. First some Terminology <ul><li>nodeName( argument, attr : value, attr2 : value) { … } </li></ul><ul><li>Node </li></ul><ul><ul><li>Syntactically a method call, but it represents a widget or bean </li></ul></ul><ul><li>Argument </li></ul><ul><ul><li>The un-named method argument for the node </li></ul></ul><ul><ul><li>As of Groovy 1.5 there can be only one </li></ul></ul><ul><li>Attribute </li></ul><ul><ul><li>Any named parameter in the node </li></ul></ul><ul><ul><li>Names cannot be duplicated – enforced by the Compiler </li></ul></ul><ul><li>Child Content </li></ul><ul><ul><li>The closure after the method </li></ul></ul><ul><ul><li>Usually executed by the builder </li></ul></ul>
  6. 6. Agenda <ul><li>Ways to Extend SwingBuilder </li></ul><ul><li>FactoryBuilderSupport Overview </li></ul><ul><li>Case Study: SwingXBuilder </li></ul>
  7. 7. Issues of Scale How you extend should be driven by how much the extension is used <ul><li>Magic Nodes </li></ul><ul><ul><li>bean(), widget(), container() </li></ul></ul><ul><li>Individual Factory Registration </li></ul><ul><ul><li>Automatic Bean Factory </li></ul></ul><ul><ul><li>Custom Factory </li></ul></ul><ul><li>Builder Suite </li></ul><ul><ul><li>Example: SwingXBuilder </li></ul></ul><ul><li>CompositeBuilder </li></ul><ul><ul><li><Coming Soon> </li></ul></ul><ul><li>Single use of particular widgets </li></ul><ul><li>Multiple uses of a few types </li></ul><ul><li>Multiple use of a lot of types </li></ul><ul><li>Multiple uses from multiple suites </li></ul>
  8. 8. Magic Nodes <ul><li>bean(…) </li></ul><ul><ul><li>Accepts any object </li></ul></ul><ul><ul><li>Not added to parent </li></ul></ul><ul><ul><li>No child content </li></ul></ul><ul><li>widget(…) </li></ul><ul><ul><li>Accepts any java.awt.Component </li></ul></ul><ul><ul><li>Added to parent java.awt.Container </li></ul></ul><ul><ul><li>No child content </li></ul></ul><ul><li>container(…) </li></ul><ul><ul><li>Accepts any java.awt.Container </li></ul></ul><ul><ul><li>Added to parent java.awt.Container </li></ul></ul><ul><ul><li>Accepts child content </li></ul></ul>
  9. 9. Magic Nodes <ul><li>An instance of the object must be passed in as the argument </li></ul><ul><li>Attributes are applied as JavaBeans properties </li></ul><ul><li>Semi-Magic Nodes </li></ul><ul><ul><li>Most existing nodes can become magic nodes </li></ul></ul><ul><ul><li>Argument must match node type </li></ul></ul>
  10. 10. Magic Nodes Example <ul><li>bean(model, propertyChanged: { panel.repaint() } ) </li></ul><ul><li>widget(new JXMonthPanel(), </li></ul><ul><li>selectedBackground:Color.YELLOW) </li></ul><ul><li>container(new JXTitlePane(), title:&quot;Demo”) { </li></ul><ul><li>// whatever you would add in the JXTitlePane </li></ul><ul><li>} </li></ul>
  11. 11. Individual Factory Registration <ul><li>First, what are the characteristics of the Widget? </li></ul><ul><li>Well behaved JavaBeans </li></ul><ul><ul><li>No-args constructor </li></ul></ul><ul><ul><li>Bean can be fully configured via properties </li></ul></ul><ul><li>Complex Beans/Objects </li></ul><ul><ul><li>Only constructors with arguments </li></ul></ul><ul><ul><li>Some features configured only by constructor </li></ul></ul><ul><ul><ul><li>Example: JFrame, JWindow, JDialog owner </li></ul></ul></ul><ul><ul><li>Non-JavaBeans style properties/configuration </li></ul></ul>
  12. 12. Individual Factory Registration <ul><li>Well behaved JavaBeans may use registerBeanFactory(…) </li></ul><ul><ul><li>All lifecycle methods are automated </li></ul></ul><ul><ul><li>No fancy processing </li></ul></ul><ul><ul><li>Child nodes added via JComponent.add(child [,constraints]) </li></ul></ul><ul><li>Complex Beans/Objects must use registerFactory(…) </li></ul><ul><ul><li>Must implement groovy.util.Factory </li></ul></ul><ul><ul><li>May extend groovy.util.AbstractFactory </li></ul></ul><ul><ul><ul><li>newInstance(builder, name, arg, attrs) is the only unimplemented method </li></ul></ul></ul>
  13. 13. Builder Suite <ul><li>Logical progression from creating factories </li></ul><ul><li>Subclass SwingBuilder </li></ul><ul><ul><li>Do magic in the Constructor </li></ul></ul><ul><ul><li>SwingBuilder factories can be over-ridden </li></ul></ul><ul><ul><li>SwingBuilder factories can be renamed – </li></ul></ul><ul><ul><ul><li>getFactories().each {k, v -> registerFactory(&quot;j&quot; + k, v) } </li></ul></ul></ul>
  14. 14. Builder Suite <ul><li>But what if I want multiple suites? </li></ul><ul><ul><li>JideSplitButton </li></ul></ul><ul><ul><li>JXMap </li></ul></ul><ul><ul><li>JRibbon </li></ul></ul><ul><li>Ways to Add more than one suite </li></ul><ul><ul><li>Manually add via magic nodes </li></ul></ul><ul><ul><li>Manual add factories after construction </li></ul></ul><ul><ul><li>Hand roll a custom suite </li></ul></ul><ul><li>This can be burdensome…. </li></ul>
  15. 15. Composite Builder <ul><li>Coming Soon </li></ul><ul><ul><li>Won’t be in Groovy 1.6 core </li></ul></ul><ul><li>The Idea </li></ul><ul><ul><li>Declare a builder that is a composite of other builders </li></ul></ul><ul><ul><li>Have each builder use a common Binding </li></ul></ul><ul><ul><li>Allow children of one builder to nest inside another </li></ul></ul><ul><ul><ul><li>Widgets from different libraries </li></ul></ul></ul><ul><ul><ul><li>Nesting non-GUI Widgets </li></ul></ul></ul><ul><ul><ul><ul><li>tree() { rootFolder { treeNode(); treeNode(); treeNode(); } } </li></ul></ul></ul></ul>
  16. 16. The Vision <ul><ul><li>def builder = new CompositeBuilder( SwingBuilder, ogb:ObjectGraphBuilder, jx:SwingXBuilder, jide:JIDEBuilder, fl:FlamingoBuilder, nodeName: randomFactory ) builder.jxframe { ribbon { editActionsGroup, saveActionsGroup } </li></ul></ul><ul><ul><li>jidepopup(visible:false) { … popup contents … } } </li></ul></ul>
  17. 17. The code as of Today <ul><li>Called ‘UberBuilder’ </li></ul><ul><ul><li>Available on SVN (only for the brave…) </li></ul></ul><ul><ul><li>https://svn.codehaus.org/groovy/trunk/groovy/modules/griffon/ </li></ul></ul><ul><li>GUIBuilder is an auto composite of a few builders </li></ul><ul><ul><li>SwingBuilder </li></ul></ul><ul><ul><li>SwingXBuilder </li></ul></ul><ul><ul><li>JIDEBuilder </li></ul></ul><ul><ul><li>GraphicsBuilder </li></ul></ul><ul><li>Not quite soup yet… </li></ul>
  18. 18. Agenda <ul><li>Ways to Extend SwingBuilder </li></ul><ul><li>FactoryBuilderSupport Overview </li></ul><ul><li>Case Study: SwingXBuilder </li></ul>
  19. 19. Factory Lifecycle
  20. 20. Delegate Closures <ul><li>Some steps can be intercepted without a Factory </li></ul><ul><ul><li>addPreInstantiateDelegate, addPostInstantiateDelegate, addAttributeDelegate </li></ul></ul><ul><ul><ul><li>{FactoryBulderSupport builder, Object node, Map attributes -> … } </li></ul></ul></ul><ul><ul><li>addPostNodeCompleteDelegate </li></ul></ul><ul><ul><ul><li>{FactoryBulderSupport builder, Object parent, Object node -> … } </li></ul></ul></ul><ul><li>Delegates handle all nodes </li></ul><ul><ul><li>No picking and choosing, each closure must handle every call </li></ul></ul><ul><li>Some built-in tasks done via delegates </li></ul><ul><ul><li>Handling of constraints: attributes </li></ul></ul><ul><ul><li>Handling of id: attributes </li></ul></ul><ul><ul><li>Handling of bind() and attributes </li></ul></ul>
  21. 21. Agenda <ul><li>Ways to Extend SwingBuilder </li></ul><ul><li>FactoryBuilderSupport Overview </li></ul><ul><li>Case Study: SwingXBuilder </li></ul>
  22. 22. SwingXBuilder <ul><li>Google Summer of Code 2007 project </li></ul><ul><ul><li>James Williams – Nova Southeastern University, FL </li></ul></ul><ul><li>Proof of concept for SwingBuilder extension </li></ul><ul><li>First Groovy builder in 100% Groovy </li></ul><ul><ul><li>SwingBuilder later ported to Groovy </li></ul></ul>
  23. 23. Summary <ul><li>SwingBuilder extension is easy </li></ul><ul><li>Choose your extension method based on frequency of use </li></ul><ul><li>FactoryBuilderSupport FTW </li></ul><ul><li>Look to SwingXBuilder to see how it’s been done </li></ul>
  24. 24. For More Information <ul><li>TS-5098 </li></ul><ul><ul><li>Friday at 12:10 in EP 305 </li></ul></ul><ul><ul><li>Covers more of the SwingBuilder basics not covered here </li></ul></ul><ul><li>Groovy </li></ul><ul><ul><li>http://groovy.codehaus.org </li></ul></ul><ul><li>Builders mentioned in this presentation </li></ul><ul><ul><li>http://groovy.codehaus.org/Swing+Builder </li></ul></ul><ul><ul><li>http://groovy.codehaus.org/SwingXBuilder </li></ul></ul><ul><ul><li>http://groovy.codehaus.org/JideBuilder </li></ul></ul><ul><ul><li>http://groovy.codehaus.org/GraphicsBuilder </li></ul></ul><ul><li>Groovy Swing team blogs </li></ul><ul><ul><li>http://jroller.com/aalmiray </li></ul></ul><ul><ul><li>http://www.jameswilliams.be/blog </li></ul></ul><ul><ul><li>http://www.shemnon.com/speling </li></ul></ul>
  25. 25. Danno Ferrin, Intelligent Software Solutions, Inc. James Williams, Spatial Networks, Inc. BOF-5110 Speaker’s logo here (optional)
