Building a platform from open source
Dustin Whittle

Overview
Why symfony?
symfony vs. ysymfony
What does scaling really mean?
Social Search: Delicious and Answers
International: ShopGenie.co.uk, FoxyTunes, Wretch.cc
Yahoo! Open Strategy
What is the Yahoo! Open Stack?
Developer Tools
YUI, Design Patterns, Tutorials
Data & Social APIs
YQL: Yahoo! Query Language
Profiles, Connections, Updates, …
Geo, Flickr, Delicious, Upcoming
YOS SDK for PHP

Who am I?
Working with symfony since open source
symfony Core Team Member
Responsible for the development and support of ysymfony at Yahoo!
Worked with Y! Answers, Delicious, Y! Widgets, Y! Bookmarks, Yahoo! Application Platform
Developer advocacy for Yahoo! Developer Network
Consultant
Commercial symfony support + training (USA)

EXAMPLES | TUTORIALS | CODE SAMPLES
developer.yahoo.com

W3C | MICROFORMATS | OAUTH | OPENID | OPENSOCIAL
YAHOO! embraces open standards

YUI | BROWSER PLUS | DESIGN PATTERNS | R3 | YSLOW + PERFORMANCE RULES
YAHOO! gives back to open source

Conferences | Hack Days | HackU | Tech Talks | YDN Theater
YAHOO! ENGAGES COMMUNITIES WITH OPEN HACK EVENTS around the world

Users
LoadBalancers
Frontend
Backend
Linux
ysymfony/ YUI
Apache
Custom Modules
PHPAPC, PEAR, PECL, Custom Extensions
UserAPI
MySQL/Memcache
Web Services
Ad API

Why a frontend platform?
Rasmus says “frameworks are not well suited for Yahoo!”
Build applications to requirements
Do exactly what you need: no more, no less
Understand that frameworks add a lot of overhead
Choosing functional components is a better fit
Despite choosing open source or building your own
Everyone uses a framework
If you use open source, use only the pieces you need

Y! needs from a frontend platform
Fit existing environment (RHEL/PHP5/Apache)
Development Cycle – How easy to develop, test, and deploy?
Clean separation between data, logic, and display (MVC)
Independent model layer to fit service oriented architecture
Extensible and pluggable
Internationalization and localization support
Detailed documentation and active community of support
Open source and ability to contribute back

Why a framework at all?
Another software layer (ysymfony, yphp, yapache)
Factors out common patterns
Code Layout
Configuration
URL Routing
Authentication / Security
Form Validation / Repopulation
Internationalization / Localization
Encourages good design
Abstraction > Consistency > Maintainability

The choice to adopt symfony?
Philosophy
Full-stack framework for building complex web applications
Adopt best ideas from anywhere, using existing code if available (Mojavi, Prado, Rails, Django)
Design
Clean separation between Model, View, and Controller
Controller using modules and actions
Views using templates in straight PHP with helpers
Easy to reuse view modules to compose a page
Layouts, Components, Partials, Slots

The choice to use symfony
Configurability / Flexibility
Features we do not want are easily disabled
Use of factories for easy customization
Documentation / Support Community
The Definitive Guide to symfony
Askeet, Jobeet, Cookbooks, Advents
Active community with wiki, mailing lists, forums, irc channel

Why ysymfony for Yahoo! teams?
Eliminate common patterns by adding a layer on PHP
Code layout/structure (MVC)
Configuration
Internationalization
ysymfony is just a toolkit
Learn one set of tools
Shift between multiple projects
Consistency
Long term maintainability through platform

How Yahoo! uses symfony
Full Stack
Yahoo! Bookmarks
Yahoo! Answers
Delicious
Yahoo! Widgets
Yahoo! Application Platform
ShopGenie.co.uk, Foxytunes, Wretch.cc
Internal Dashboards + Reporting Tools
Components
Dependency Injection
Forms
Caching (APC/Memcache)
Routing

symfony MVC framework

A look at Yahoo! Answers
http://answers.yahoo.com
Yahoo! Answers is the largest collection of human knowledge on the Web with more than 135 million users and 515 million answers worldwide (Yahoo! Internal Data, March 2008).
Yahoo! Answers is the 2nd ranked education & reference site on the web (comScore)
Available in 26 markets and 12 languages

Yahoo! Answers at the beginning
Started as a small development team on PHP4 from a fork of Yahoo! Taiwan Knowledge+
Launched December 2005 by December 2006 there were 60 million users and 65 million answers
The code base eventually became difficult to maintain and iterate new features
Large distributed development teams (US / UK)

The big picture
A complete platform for building web applications from frameworks
PHP Framework
JavaScript Framework
CSS Framework
UI Design Patterns + Best Practices
Development Tools (logger, profiler, debugger, docs)
Unit + Functional Testing Frameworks (LIME / YUI Test)
Deployment Tools (rsync deployment system)

What does Yahoo! change?
Minor changes to fit our environment
Most changes are easily implemented via factories/plugins
Dropped the ORM and pushed down the stack (SOA)
Added a parallel API Dispatcher (ysfAPIClientPlugin)
Added dimensions to configurations (ysfDimensionsPlugin)
Integrated R3 translation/template management (ysfR3Plugin)
R3 - http://developer.yahoo.com/r3/
Created a build and deployment solution (ysfBuildPlugin)
Uses internal tools for packaging/deployment
Integrate support for Y! User Interface libraries (ysfYUIPlugin)

Propel or Doctrine or ???
No ORM for large projects
Doctrine for medium sized projects
Service Oriented Architecture
Platforms/Backendsas services (reusable to all)
Thin Controller/Fat Model (where model == services)
Use PHP as the frontend glue
No heavy lifting in PHP = Push down the stack
Java/C++/Erlang + JSON/XML

Localizing with dimensions
Cascading Configuration based on YAML
Framework -> Project -> Application -> Module
Extending the cascade to be based on dimensions
Dimensions can be anything (and can be chained together)
Data Center + Environment for customizing configurations
Culture for localizing user interface + data
Theme for customizing look and feel
User info (is user on corporate intranet?)
Caching

symfony I18n + L10n
Translation + Template Management
Integrated with symfony i18n + view layers
<r3:trans>hello</r3:trans> vs __(‘hello’)
Dictionary Management (YALA)
SQLite/XLIFF Backend
Added additional tasks
Importing/Exporting XLIFF dictionary
Generating sample translations for projects
Find missing strings

A build and deployment system
Aggregate and minify stylesheets and javascripts
Rewrite templates, css, js for CDN (Akamai, S3, …)
Generate translations for configurations + templates
Generate configuration cache
Aggregate core classes + remove debug statements
Run lint, unit, functional tests
Package applications as .tgz
Deployment via packages
Integrated with Yahoo! internal tools

Hello World Performance
Hello world benchmarks are generally not a useful measurement
You don’t use a framework to write hello world
die(‘hello world’);
Performance is relative to the features you use
ORM
I18N
Output Escaping
Forms/Validation
Ability to scale != performance

What does it mean to scale?
A system whose performance improves after adding hardware, proportionally to the capacity added, is said to be a scalable system.
High Availability + Scalability + Performance
Bigger dataset, more traffic, maintainable
Not about performance
PHP is slow, but it is very rarely your bottleneck
Languages do not scale, architectures do
Planning to grow and planning to fail
Capacity Planning
Business Continuity Planning

Scaling – Planning
Planning hardware purchases and hosting options to have as much as you need without breaking your wallet
Partitioning and distributing databases to support large datasets and simultaneous transactions
Offline transactions and queuing
Monitoring your applications to find and clear bottlenecks
Providing service APIs and using services from other providers to increase your site's reach and capabilities
Think Minimal, Plan to grow, Plan to fail

Scaling – The basics in PHP
PHP is rarely the bottleneck (even though it can be slow)
“Most performance comes not from the language, but from application design” – Rasmus
Share Nothing Architecture
Independent, self-sufficient, no single point of contention
No local storage = No PHP Sessions
Use a database (works for distributed)
Use a small signed cookie (ideal)
Important data in database
Individual expiration on session objects
Small data items
Use a distributed cache
Memcache
Forget about small efficiencies
Premature optimization is the root of all evil.
“ vs. ‘, echo vs. print

Scaling Databases – The basics
Drop the ORM
It’s a choice of convenience over performance
Master/Slave Replication
First steps
Helps with reads, writes are still bottleneck
Partitioning
Segmenting data
Sharding (horizontal partitioning)
Segmenting data onto different physical machines
Make problems smaller, easier to grow

Improving latency with Caching
Always use PHP opcode cache (APC, Xcache, etc)
Use for routing and i18n cache
Memcache (distributed cache)
Use for view cache
Distributed invalidation can be a pain
sfViewCacheManager makes this easy!
Be intelligent about cache_keys (uri, user, state)
There is a fine line to caching
At what point do you spend more time managing the cache, than reading from it?

Tweaking Performance
Do not use .htaccess (move to real apache config)
Set a minimal include path
Increase realpath_cache_size + realpath_cache_ttl
Use apc.stat=0
Don’t use features you do not need
Disable in settings.yml/ factories.yml
Use core_compile to aggregate classes to reduce file i/o
Remove debug statements + optimize file lookups
sfOptimizerPlugin / project:optimize
Use @routeName and use caching for factories

Symfony (v2)
Symfony 2 is a set of cohesive yet decoupled components
This makes it much easier to use single component to solve a single problem
Which makes it easier to build micro frameworks that solve very specific problems
Yahoo! Teams generally prefer solutions that are specific to their exact problem
Selling the full stack can be difficult when a team only wants a few components
Symfony 2 is the right direction, even if it breaks backwards compatability

Do it yourself for cheap
Open source software = Free
Apache
PHP
MySQL
Memcache / Perlbal / MogileFS / Squid / Gearman
symfony / Doctrine / Propel / Swift
Nagios / Cacti
Amazon Shared Infrastructure = Cheap
EC2 Cloud
S3 Storage + Cloudfront
SimpleDB

Y! OS – The Open Stack

What Yahoo! offer developers
Yahoo! Developer Network
Developer Tools (YUI, etc)
Social APIs
Profiles
Connections
Updates
Data APIs
Flickr, Delicious, Search, etc
Yahoo! Query Language
Yahoo! Application Platform
OpenSocial

developer.yahoo.com

What is Yahoo! Developer Network?
The Yahoo! Developer Network offers open source tools and open data APIs to make it easy for developers to build applications and mashups.
50+ APIs / Web Services
Developer Dashboard to create/manage Oauth applications
Tutorials + Code Samples on using our apis
Complete API Documentation
Yahoo! User Interface libraries
ASTRA Flash Components
Design Patterns Library
Evangelism: Conferences / Theater / Blogs / Events

JavaScript Framework
Utilities - YAHOO, Dom, Event, Animation, Browser History Manager, Connection Manager, Cookie, DataSource, Drag and Drop, Element, Get, ImageLoader, JSON, Resize, Selector, Loader
Controls / Widgets - AutoComplete, Button, Calendar, Charts, Color Picker, DataTable, ImageCropper, Rich Text Editor, Slider, Uploader
Container (Module, Overlay, Panel, Tooltip, Dialog), Layout Manager, Menu, TabView, TreeView
Debug – Logger, Profiler, Test
Y! Developer Network – YUI Javascript

CSS Foundation
Reset - Neutralizes browser CSS styles
Base - Applies consistent style foundation
Fonts - Foundation for typography and font-sizing
Grids - Thousands of wireframe layouts
User Interface Design Patterns Library
Proven solutions to common interfaces
http://developer.yahoo.com/ypatterns/
Grade Browser Support / Progressive Enhancement
Y! Developer Network – YUI CSS

More than 275 functional examples
http://developer.yahoo.com/yui/examples/
YSlow + Performance Rules
http://developer.yahoo.com/performance
YUI Blog
http://yuiblog.com/
Mailing List @ Yahoo! Groups
http://tech.groups.yahoo.com/group/ydn-javascript/
Y! Developer Network – Documentation

A Query Language for the Web
SELECT * FROM INTERNET

Thousands of web services that provide valuable data
Require developers to read documentation and form URLs/queries.
Data is isolated and can not be combined
Needs combining, tweaking, shaping even after it gets to the developer.
Before YQL

SQL-Like Language
Synonymous with Data access
Familiar to developers
Expressive enough to get the right data
Self Describing - show, desc table
Allows you to query, filter and join data across Web Services.
Y! Open Stack – YQL

YQL – Open Tables
Twitter
Google
Facebook
Friendfeed
Wesabe
Whitepages
Zillow
Search
Weather
Flickr
Upcoming
Delicious
Dopplr
Github
New York Times
Shopping
…any web service can be as easy as SQL
Available on github - http://github.com/spullara/yql-tables/

YQL – Open Tables

select * from social.connections
select * from delicious.feeds.popular
select * from flickr.photos.interestingness
select * from friendfeed.status
select * from github.checkins
YQL - Examples

OAuth Endpoint
http://query.yahooapis.com/v1/yql?q=...
Public Endpoint
http://query.yahooapis.com/v1/public/yql?q=
YQL Console
http://developer.yahoo.com/yql/console
YQL – API End Points

Books worth reading

(I will be around for the whole event, so please say hello and ask questions)
Questions?

enjoy the rest ofsymfonylive 2010
EXAMPLES | TUTORIALS | CODE SAMPLES
developer.yahoo.com

Want to join Yahoo?We are hiring!

http://imsardine.wordpress.com	323
http://www.symfonylab.com	267
http://symfony.com	250
http://www.symfony-project.org	161
http://swik.net	123
http://developer.yahoo.net	103
http://www.techgig.com	97
http://developer.yahoo.com	65
http://www.phphatesme.com	51
http://www.slideshare.net	24
http://coderwall.com	13
http://raulbarraltamayo.wordpress.com	5
http://webcache.googleusercontent.com	4
http://www.phpframeworks.com	2
http://static.slidesharecdn.com	2
http://www.useseo.com	2
http://feeds2.feedburner.com	1
http://translate.googleusercontent.com	1
http://127.0.0.1:8795	1
http://www.hanrss.com	1
https://ioio.nu	1
http://localhost:3000	1

Building A Platform From Open Source At Yahoo

by Dustin Whittle on Feb 17, 2010

Accessibility

Categories

Upload Details

Usage Rights

22 Embeds 1,498

Statistics

Building A Platform From Open Source At Yahoo Presentation Transcript
