Geometry Processingで学ぶSparse Matrix Geometry Processingで学ぶSparse Matrix Presentation Transcript

  • GEOMETRY PROCESSINGで学ぶ SPARSE MATRIX 2012/3/18 Tokyo.SciPy #3 齊藤 淳 Jun Saito @dukecyto
  • 本日の概要 Laplacian Mesh Processingを通じてsparse matrix一般、scipy.sparseの理解を深める !! = ! − !L !
  • Computer Graphics Animation (c) copyright 2008, Blender Foundation / www.bigbuckbunny.org
  • Computer Graphics Animation Modeling Animation Rendering•  作る •  動かす •  絵にする
  • SIGGRAPH 2011 Papers Categories Modeling Animation Rendering Images•  Understanding •  Capturing & •  Stochastic •  Drawing, Painting Shapes Modeling Humans Rendering & and Stylization•  Mapping & •  Facial Animation Visibility •  Tone Editing Warping Shapes •  Call Animal Control! •  Volumes & Photons •  By-Example Image•  Capturing •  Contact and •  Real-Time Synthesis Geometry and Constraints Rendering •  Image Processing Appearance •  Example-Based Hardware •  Video Resizing &•  Geometry Simulation •  Sampling & Noise Stabilization Processing •  Fluid Simulation •  Stereo & Disparity•  Discrete Differential •  Fast Simulation •  Interactive Image Geometry Editing•  Geometry •  Colorful Acquisition•  Surfaces•  Procedural & Interactive Modeling•  Fun With Shapes
  • SIGGRAPH 2011 Papers Categories Modeling Animation Rendering Images•  Understanding •  Capturing & •  Stochastic •  Drawing, Painting Shapes Modeling Humans Rendering & and Stylization•  Mapping & •  Facial Animation Visibility •  Tone Editing Warping Shapes •  Call Animal Control! •  Volumes & Photons •  By-Example Image•  Capturing •  Contact and •  Real-Time Synthesis Geometry and Constraints Rendering •  Image Processing Appearance •  Example-Based Hardware •  Video Resizing &•  Geometry Simulation •  Sampling & Noise Stabilization Processing •  Fluid Simulation •  Stereo & Disparity•  Discrete Differential •  Fast Simulation •  Interactive Image Geometry Editing•  Geometry •  Colorful Acquisition•  Surfaces•  Procedural & Interactive Modeling•  Fun With Shapes
  • Geometry Processingとは Geometry processing, or mesh processing, is a fast-growingarea of research that uses concepts from applied mathematics,computer science and engineering to design efficientalgorithms for the¨  acquisition¨  reconstruction¨  analysis¨  manipulation¨  simulation¨  transmissionof complex 3D models. http://en.wikipedia.org/wiki/Geometry_processing
  • Triangle Meshによる形状の表現
  • Differential Coordinates ¨  形状の局所的な特徴 ¤  方向は法線、大きさは平均曲率の近似 γ 1 1 δi = ∑ ( vi − v ) ∫γ ( vi − v ) ds di v∈N ( i ) len(γ ) v∈ Discrete Laplace-Beltrami operator Continuous Laplace-Beltrami operator [Sorkine 2005]
  • Discrete Laplace Operator “Majority of Applications contemporary geometry processing tools rely on Mesh Parameterization discrete Laplace Fairing / Smoothing operators” Denoising [Alexa 2011] Manipulation / Editing Compression Shape Analysis Physical Simulation
  • Laplacian Mesh Processing
  • Graph Laplacian(a.k.a. Uniform Laplacian, Topological Laplacian) http://en.wikipedia.org/wiki/Laplacian_matrix
  • Cotan-Weighted Laplacian 緑: Graph Laplacian赤: Cotan-Weighted Laplacian 1 1 !!! = cot !!" + cot !!" (!! − !! ) 4!(!! ) 2 !∈! ! [Sorkine 2005]
  • Stanford 3D Scan Repository ¨  Stanford Bunny ¤  頂点数: 35,947 ¤  35,947 x 35,947 = 1.2 G
  • Stanford 3D Scan Repository ¨  Dragon ¤  頂点数: 566,098 ¤  566,098 x 566,098 = 298G
  • 疎行列 Sparse Matrix 成分のほとんどがゼロである ことを活用した形式で行列を 記憶・演算 “Sparse matrices are widely used in scientific computation, especially in large-scale optimization, structural and circuit analysis, computational fluid dynamics, and, generally, the numerical solution of partial differential equations.” Sparse Matrices in MATLAB: Design and Implementation
  • 疎行列 Sparse Matrix 成分のほとんどがゼロである ことを活用した形式で行列を 記憶・演算 Laplacian Matrixは ¨  sparse ¨  symmetric ¨  positive semi-definite
  • Python Sparse Matrix Packages SciPy SparsePySparseCVXOPT
  • Python Sparse Matrix Packages SciPy SparsePySparseCVXOPT
  • From OpenOpt doc... “Unfortunately, sparse matrices stillremains one of most weak features inPython usage for scientific purposes”
  • From OpenOpt doc... “Unlike MATLAB, Octave, and a number of othersoftware, there is not standard Python library forsparse matrices: someone uses scipy.sparse, someonePySparse, someone (as CVXOPT) uses its own libraryand/or BLAS, someone just uses 3 columns (for thenumber indexes and value). SciPy developers refusedto author of scipy.sparse to include it into NumPy, Ithink its a big mistake, probably now it would been aunified standard. Still I hope in future numpy versionsdifference in API for handling sparse and densearrays will be removed. “
  • 基本的な流れ 構築に適した形 演算に適した形式式で行列を作る に変換し演算を行う A = lil_matrix((N,N))! A = A.tocsr()! A[i,j] = a! A = A.dot(D)! ! f = factorized(A)! x = f.solve(b)!
  • Graph Laplacian(a.k.a. Uniform Laplacian, Topological Laplacian) http://en.wikipedia.org/wiki/Laplacian_matrix
  • Graph Laplacian in scipy.sparse from scipy import sparse!!N = len(points)!L = sparse.lil_matrix((N, N))!for vids in faces:! L[vids, vids] = 1!D = sparse.spdiags(L.sum(axis=0), 0, N, N)!L = L.tocsc()-D!
  • Graph Laplacian in scipy.sparse from scipy import sparse!!N = len(points)!L = sparse.lil_matrix((N, N))!for vids in faces:! L[vids, vids] = 1!D = sparse.spdiags(L.sum(axis=0), 0, N, N)!L = L.tocsc()-D!
  • points and faces from Maya !import numpy as np!import pymel.core as pm!!mesh = pm.PyNode(‘bunny’)!points = np.array(mesh.getPoints())!faces = np.array(mesh.getVertices()! ! ! [1]).reshape(mesh.numFaces(),3)!
  • Graph Laplacian in scipy.sparse from scipy import sparse!!N = len(points)!L = sparse.lil_matrix((N, N))!for vids in faces:! L[vids, vids] = 1!D = sparse.spdiags(L.sum(axis=0), 0, N, N)!L = L.tocsc()-D!
  • Sparse Matrix Storage Formats 構築に適した形式 演算に適した形式¨  LIst of Lists ¨  Compressed Sparse (LIL) Row (CSR) ¨  Compressed Sparse¨  COOrdinate lists (COO) Column (CSC) ¨  Block Sparse Row¨  Dictionary Of Keys (BSR) (DOK) ¨  DIAgonal (DIA)
  • sparse.lil_matrixLIst of Lists (LIL) 形式 ¨  データ構造 ¨  利点 ¤  行毎に非ゼロ要素の ¤  柔軟なslice ソートされた列インデッ ¤  他のmatrix形式への変 クスを保持するarray 換が速い ¤  対応する非ゼロ要素の ¨  欠点 値も同様に保持 ¤  LIL+ LIL が遅い (CSR/¨  用途 CSC推奨) ¤  行列の構築用 ¤  column slicingが遅い ¤  巨大な行列を構築する (CSC推奨) 際にはCOOも検討する ¤  行列ベクトル積が遅い と良い (CSR/CSC推奨)
  • sparse.csr_matrixCompressed Sparse Rows (CSR)形式 ¨  CSC: 行と列が逆 ¨  利点¨  データ構造 ¤  高速な演算 CSR + CSR, CSR * CSR,等. ¤  Row slicingが速い ¤  行列ベクトル積が速い ¨  欠点 ¤  Column slicingが遅いA = [1 2 3 1 2 2 1] 非ゼロ要素リスト! (CSC推奨)(IA = [1 1 1 2 3 3 4] i行)!IA = [1 4 5 7] ! ¤  他のmatrix形式への変JA = [1 2 3 4 1 4 4] j列! 換が遅い (そうでもない?後述ベンチマーク参照)A, IA’, JAを保持 http://ja.wikipedia.org/wiki/%E7%96%8E%E8%A1%8C%E5%88%97
  • sparse.dia_matrixDIAgonal (DIA)形式 ¨  帯行列に適した形式¨  オフセットを指定可能>>> data = array([[1,2,3,4]]).repeat(3,axis=0)!>>> offsets = array([0,-1,2])!>>> dia_matrix( (data,offsets),shape=(4,4)).todense()!matrix([[1, 0, 3, 0],! [1, 2, 0, 4],! [0, 2, 3, 0],! [0, 0, 3, 4]])!
  • Sparse Matrix Format Benchmark:Construction Benchmark by modified bench_sparse.py in SciPy distribution
  • Sparse Matrix Format Benchmark:Conversion Benchmark by modified bench_sparse.py in SciPy distribution
  • Sparse Matrix Format Benchmark:Matrix Vector Product Benchmark by modified bench_sparse.py in SciPy distribution
  • Graph Laplacian in scipy.sparse from scipy import sparse!!N = len(points)!L = sparse.lil_matrix((N, N))!for vids in faces:! L[vids, vids] = 1!D = sparse.spdiags(L.sum(axis=0), 0, N, N)!L = L.tocsc()-D!
  • Fancy indexingの仕様の違い sparse.lil_matrix numpy.array >>> L = sparse.lil_matrix((N,N))! >>> Ldense = np.zeros((N,N))!>>> ix = [1,3,4]! >>> ix = [1,3,4]!>>> L[ix,ix] = 1! >>> Ldense[ix,ix] = 1!>>> L.todense()! >>> Ldense!matrix([[ 0., 0., 0., 0., 0.],! array([[ 0., 0., 0., 0., 0.],! [ 0., 1., 0., 1., 1.],! [ 0., 1., 0., 0., 0.],! [ 0., 0., 0., 0., 0.],! [ 0., 0., 0., 0., 0.],! [ 0., 1., 0., 1., 1.],! [ 0., 0., 0., 1., 0.],! [ 0., 1., 0., 1., 1.]])! [ 0., 0., 0., 0., 1.]])!
  • 補足: numpy.ix_() >>> Ldense = np.zeros((N,N))!>>> ix = [1,3,4]!>>> Ldense[np.ix_(ix,ix)] = 1!>>> Ldense!array([[ 0., 0., 0., 0., 0.],! [ 0., 1., 0., 1., 1.],! [ 0., 0., 0., 0., 0.],! [ 0., 1., 0., 1., 1.],! [ 0., 1., 0., 1., 1.]])!
  • Graph Laplacian in scipy.sparse from scipy import sparse!!N = len(points)!L = sparse.lil_matrix((N, N))!for vids in faces:! L[vids, vids] = 1!D = sparse.spdiags(L.sum(axis=0), 0, N, N)!L = L.tocsc()-D!
  • 細かい演算の仕様 !# LがCSC,CSRだとNotImplementedError!L -= D!!# OK!L = L-D!
  • Laplacian Mesh Fairing ! ! = ! − !L !A Signal Processing Approach To Fair Surface Design[Taubin 95]
  • Mesh Fairing in scipy.sparse from scipy.sparse import linalg as spla!!A = sparse.identity(L.shape[0]) - _lambda * L!solve = spla.factorized(A.tocsc())!x = solve(points[:,0])!y = solve(points[:,1])!z = solve(points[:,2])!new_points = np.array([x, y, z]).T!!# Set result back to Maya mesh!mesh.setPoints(new_points)!
  • Mesh Fairing in scipy.sparse from scipy.sparse import linalg as spla!!A = sparse.identity(L.shape[0]) - _lambda * L!solve = spla.factorized(A.tocsc())!x = solve(points[:,0])!y = solve(points[:,1])!z = solve(points[:,2])!new_points = np.array([x, y, z]).T!!# Set result back to Maya mesh!mesh.setPoints(new_points)!
  • Solving sparse linear system ¨  sparse.linalg.factorized(A) ¤  AのLU分解結果を保持したlinear system solver関数を 返す ¤  AはCSC形式で渡す必要がある SparseEfficiencyWarning: splu requires CSC matrix format
  • Mesh Fairing in scipy.sparse from scipy.sparse import linalg as spla!!A = sparse.identity(L.shape[0]) - _lambda * L!solve = spla.factorized(A.tocsc())!x = solve(points[:,0])!y = solve(points[:,1])!z = solve(points[:,2])!new_points = np.array([x, y, z]).T!!# Set result back to Maya mesh!mesh.setPoints(new_points)!
  • Solving sparse linear system # Error! 右辺はベクトルのみ!new_points = solve(points)!!# 仕方がないので一列ずつ!x = solve(points[:,0])!y = solve(points[:,1])!z = solve(points[:,2])!new_points = np.array([x, y, z]).T!
  • Cotan-Weighted Laplacian 緑: Graph Laplacian赤: Cotan-Weighted Laplacian 1 1 !!! = cot !!" + cot !!" (!! − !! ) 4!(!! ) 2 !∈! ! [Sorkine 2005]
  • Cotan Laplacian in scipy.sparse (1/2) def laplacian_cotan(points, faces):! EDGE_LOOP = [(0,1,2),(0,2,1),(1,2,0)]! N = len(points)! point_area = np.zeros(N)! L = sparse.lil_matrix((N, N))! for vids in faces:! point_area[vids] += area_triangle(points[vids]) /3.0! for i in EDGE_LOOP:! v0 = vids[i[0]]! v1 = vids[i[1]]! v2 = vids[i[2]]! e1 = points[v1] - points[v2]! e2 = points[v0] - points[v2]!
  • Cotan Laplacian in scipy.sparse (2/2) cosa = np.dot(e1, e2) / math.sqrt(np.dot(e1,e1) * np.dot(e2, e2))! sina = math.sqrt(1 - cosa * cosa)! cota = cosa / sina! w = 0.5 * cota! L[v0, v0] -= w! L[v0, v1] += w! L[v1, v1] -= w! L[v1, v0] += w! D = sparse.spdiags(0.25/point_area, 0, N, N)! return D.dot(L.tocsc())!
  • Cotan Laplacian in scipy.sparse (2/2) cosa = np.dot(e1, e2) / math.sqrt(np.dot(e1,e1) * np.dot(e2, e2))! sina = math.sqrt(1 - cosa * cosa)! cota = cosa / sina! w = 0.5 * cota! L[v0, v0] -= w! L[v0, v1] += w! L[v1, v1] -= w! L[v1, v0] += w! D = sparse.spdiags(0.25/point_area, 0, N, N)! return D.dot(L.tocsc())!
  • 行列積について # Denseに変換されてしまう!np.dot(D, L)!!# Sparseのまま行列積!D.dot(L)!
  • Laplacian Matrix構築Cythonによる高速化 ¨  Python: 2.6秒¨  Cython: 1.8秒¨  Cython + Dense: 0.8秒! ¤ あまり大きくないMeshならばDenseで Laplacianを作った方が速い
  • ファイル入出力 ¨  numpy.savetxt() >>> io.savemat(sparsetest.mat, {lil: L.tolil(), ¤  Sparse Matrixでは使えない csr: L.tocsr()}, oned_as=row)¨  scipy.io.savemat() / >>> M = io.loadmat(‘sparsetest.mat) loadmat() >>> M[lil] ¤  MATLAB .mat形式で保存 <5x5 sparse matrix of type <type numpy.float64> ¤  Sparse Matrixは強制的に CSCで保存される with 9 stored elements in Compressed Sparse Column format> >>> M[csr] <5x5 sparse matrix of type <type numpy.float64> with 9 stored elements in Compressed Sparse Column format>
  • MATLAB vs. SciPy – Sparse Matrices MATLAB SciPy Sparse ¨  sparse()で行列を作る ¨  内部形式(denseも含 だけ! め)を意識して使う¨  後の演算はdenseと全 ¨  形式によって同じ演 く同じ 算、関数が使えない¨  内部形式はCSC ケースがある
  • まとめ ¨  Sparse matrix一般 ¤  よく使われるデータ構造を理解した¨  scipy.sparse ¤  使い方の基本がわかった ¤  いいところ n  やりたいことはできる。実用可能。 n  Mesh Processingが省メモリで計算可能。〜1000倍のオーダーで 速くなる。 ¤  悪いところ n  ドキュメントされていない仕様が多過ぎ。 n  ndarrayと透過的に使えるようにしてください L¨  Laplacian Mesh Processingはおもしろいですよ J
  • Future Work ¨  scipy.sparse.linalg の調査 ¤  Iterative sparse linear system solver系¨  Mesh Processingのもうちょっと深いネタを紹介
  • Further Readings [Sorkine 2005] Sorkine, Olga.“Laplacian Mesh Processing” Eurographics 2005http://igl.ethz.ch/projects/Laplacian-mesh-processing/STAR/STAR-Laplacian-mesh-processing.pdf ¤  Mesh Laplacianの基礎と応用に関するまとめ
  • Further Readings Levy, Bruno and Zhang, Hao.“Spectral Mesh Processing” ACM SIGGRAPH 2010http://alice.loria.fr/WIKI/index.php/Graphite/SpectralMeshProcessing ¤  Laplacianの特異値分解を用いてMeshの周波数解析
  • Further Readings [Alexa 2011] Alexa, Marc and Wardetzky, Max.“Discrete Laplacians on General Polygonal Meshes”ACM SIGGRAPH 2011http://cybertron.cg.tu-berlin.de/polymesh/ (ソースコード有) ¤  Discrete Laplacianを一般的なポリゴンメッシュに対し定義
