Android Development Tutorial V3 Presentation Transcript

  • 1. japan linux symposium android development tutorial tokyo, october 2009 diego torres milano diego@codtech.com copyright © 2009  cod technologies ltd  www.codtech.com
  • 2. “I have always wished that my  computer would be as easy to  use as my telephone. My wish has come true. I no longer know how to use my  telephone.” ­­ Bjarne Stroustrup copyright © 2009  cod technologies ltd  www.codtech.com
  • 3. agenda ● introduction to android ● development environment ● building blocks ● your first android application ● testing and performance copyright © 2009  cod technologies ltd  www.codtech.com
  • 4. introduction to android after this section you will... ● identify unique features of  android platform ● compare android against  other platforms ● understand android building  blocks copyright © 2009  cod technologies ltd  www.codtech.com
  • 5. what is android ? ● android is the first complete, open  and free mobile platform ● developed by Open Handset  Alliance ● software stack than includes – operating system – middleware – key applications – rich set of APIs Portions of this page are reproduced from work created and shared by  Google and used according to terms described in the Creative  Commons 2.5 Attribution License. copyright © 2009  cod technologies ltd  www.codtech.com
  • 6. is android linux ? NO, android is not linux ! android is based on a linux kernel   but it's not GNU/Linux ● no native windowing  system ● no glibc support ● no GNU/Linux utilities copyright © 2009  cod technologies ltd  www.codtech.com
  • 7. so is android java ? NO, android is not java ! android is not an implementation  of any of the Java variants ● uses the java language ● implements part of the  Java5 SE specification ● runs on a dalvik virtual  machine instead of JVM copyright © 2009  cod technologies ltd  www.codtech.com
  • 8. android linux kernel android is based on a linux 2.6 kernel, providing rnel, p ● security ● memory management ● process management ● network stack ● driver model ● abstraction layer kernel source: source.android.com copyright © 2009  cod technologies ltd  www.codtech.com
  • 9. linux kernel enhancements android introduces some linux kernel patches ● alarm ● ashmem ● binder ● power management ● low memory killer (no swap space available) ● logger copyright © 2009  cod technologies ltd  www.codtech.com
  • 10. unique platform characteristics android characteristics not found on other platforms ● open source ● “all applications are equal” model ● dalvik virtual machine copyright © 2009  cod technologies ltd  www.codtech.com
  • 11. other characteristics interesting features as well, but they are more  common across other mobile platforms ● application framework enabling reuse of components ● integrated browser based on WebKit OSS engine ● 3D graphics based on the OpenGL ES ● SQLite for structured data storage ● media support for common audio, video, and still images ● camera, GPS, compass, and accelerometer copyright © 2009  cod technologies ltd  www.codtech.com
  • 12. android architecture written in  C/C++ written  in java register  based  VM courtesy of Google copyright © 2009  cod technologies ltd  www.codtech.com
  • 13. android development environment after this section you will... ● be aware of the components  needed to start developing ● know the tools available on  the android sdk copyright © 2009  cod technologies ltd  www.codtech.com
  • 14. development environment ubuntu is the perfect choice ● supported and tested by  Google ● all the necessary tools  available ● 32bit installation highly  recommended copyright © 2009  cod technologies ltd  www.codtech.com
  • 15. development environment Eclipse is an extensible development  platform ● much more than an IDE ● unfortunately no Eclipse  3.4 packages ● download from  http://eclipse.org and  install ● android ADT plugin copyright © 2009  cod technologies ltd  www.codtech.com
  • 16. java ● installed from ubuntu repositories ● packages matching sun­java6­* diego@bruce:~$ java -version java version "1.6.0_16" Java(TM) SE Runtime Environment (build 1.6.0_16- b01) Java HotSpot(TM) Client VM (build 14.2-b01, mixed mode, sharing) copyright © 2009  cod technologies ltd  www.codtech.com
  • 17. android SDK 1.6 and ADT ● download from http://developer.android.com  and install to /opt directory ● create symbolic link /opt/android-sdk to  point to installed SDK ● add site  https://dl­ssl.google.com/android/eclipse/ to eclipse software updates for ADT copyright © 2009  cod technologies ltd  www.codtech.com
  • 18. android sdk updater & avd $ android copyright © 2009  cod technologies ltd  www.codtech.com
  • 19. emulator $ emulator @1.5_r3 copyright © 2009  cod technologies ltd  www.codtech.com
  • 20. dalvik debug monitor $ ddms copyright © 2009  cod technologies ltd  www.codtech.com
  • 21. zipalign ● optimizes the way an application is packaged ● potentially makes your application and system  run faster ● android accesses resources efficiently where  they are aligned on 4­byte boundaries ● ADT automatically align release packages $ zipalign -c -v 4 my.apk copyright © 2009  cod technologies ltd  www.codtech.com
  • 22. sqlite database browser $ sudo apt-get install sqlitebrowser copyright © 2009  cod technologies ltd  www.codtech.com
  • 23. android building blocks after this section you will... ● recognize the fundamental  building blocks ● use these building blocks to  create applications ● understand applications  lifecycle copyright © 2009  cod technologies ltd  www.codtech.com
  • 24. building blocks copyright © 2009  cod technologies ltd  www.codtech.com
  • 25. Activities ● Activities are stacked  like a deck of cards ● only one is visible ● only one is active ● new activities are  placed on top copyright © 2009  cod technologies ltd  www.codtech.com
  • 26. Activities lifecycle rectangles are callbacks where we can implement operations performed on state changes copyright © 2009  cod technologies ltd  www.codtech.com
  • 27. Activities states ● active – at the top of the stack ● paused – lost focus but still visible – can be killed by LMK ● stopped – not at the top of th stack ● dropped – killed to reclaim its memory copyright © 2009  cod technologies ltd  www.codtech.com
  • 28. Views ● Views are basic building blocks ● know how to draw themselves ● respond to events ● organized as trees to build up GUIs ● described in XML in layout resources copyright © 2009  cod technologies ltd  www.codtech.com
  • 29. Views and Viewgroups ● Views and  Viewgroups trees  build up complex  GUIs ● android framework is  responsible for – measuring – laying out – drawing copyright © 2009  cod technologies ltd  www.codtech.com
  • 30. pattern: load layout android compiles the XML layout code that is  later loaded in code usually by public void onCreate(Bundle savedInstanceState) { ... setContentView(R.layout.filename); ... } copyright © 2009  cod technologies ltd  www.codtech.com
  • 31. pattern: ids using an unique id in a XML View definition  permits locating it later in Java code private View name; public void onCreate(Bundle savedInstanceState) { ... name = (View) findViewById(R.id.name); ... } copyright © 2009  cod technologies ltd  www.codtech.com
  • 32. Intents ● Intents are used to move from Activity to Activity ● describes what the application wants ● provides late runtime binding primary attributes attribute description action the general action to be performed, such as VIEW, EDIT, MAIN, etc. data the data to operate on, such as a person record in the contacts database, as URI copyright © 2009  cod technologies ltd  www.codtech.com
  • 33. intent playground install from android market or from http://codtech.com/android/IntentPlayground.apk copyright © 2009  cod technologies ltd  www.codtech.com
  • 34. Services ● services run in the background ● don't interact with the user ● run on the main thread of the process ● is kept running as long as – is started – has connections copyright © 2009  cod technologies ltd  www.codtech.com
  • 35. Notifications ● notify the user about  events ● sent through  NotificationManager ● types – persistent icon – turning leds – sound or vibration copyright © 2009  cod technologies ltd  www.codtech.com
  • 36. ConentProviders ● ContentProviders are objects that can – retrieve data – store data ● data is available to all applications ● only way to share data across packages ● usually the backend is SQLite ● they are loosely linked to clients ● data exposed as a unique URI copyright © 2009  cod technologies ltd  www.codtech.com
  • 37. AndroidManifest.xml ● control file that tells  the system what to do  and how the top­level  components are  related ● it's the “glue” that  actually specifies  which Intents your  Activities receive ● specifies permissions copyright © 2009  cod technologies ltd  www.codtech.com
  • 38. your first android application after this section you will... ● create your own android map  project ● design the UI ● externalize resources ● react to events ● run the application copyright © 2009  cod technologies ltd  www.codtech.com
  • 39. designing the UI this simple UI designs  contains ● the window title ● a spinner (drop down  box) containing the  available locations ● a map displaying the  selected location ● zoom buttons copyright © 2009  cod technologies ltd  www.codtech.com
  • 40. create project android target version unique package name copyright © 2009  cod technologies ltd  www.codtech.com
  • 41. create test project test package name copyright © 2009  cod technologies ltd  www.codtech.com
  • 42. run configurations if phone is connected android target version copyright © 2009  cod technologies ltd  www.codtech.com
  • 43. default application ● auto­generated  application template ● default resources – icon – layout – strings ● default  AndroidManifest.xml ● default run  configuration copyright © 2009  cod technologies ltd  www.codtech.com
  • 44. create the layout ● remove layout ● add a RelativeLayout ● add a View (MapView not  supported by ADT) ● replace View by  com.google.android.m aps.MapView ● change id to MapView ● add a Spinner filling  parent width copyright © 2009  cod technologies ltd  www.codtech.com
  • 45. run the application ● com.google.android. maps it's an optional  library not included by  default ● edit Android Manifest ● add Uses Library  com.google.android.m aps as Application  node copyright © 2009  cod technologies ltd  www.codtech.com
  • 46. google maps api key ● checking DDMS logcat we find java.lang.IllegalArgumentException: You need to specify an API Key for each MapView. ● to access Google Maps we need a key ● application must be signed with the same key ● key can be obtained from Google ● MapView should include android:apiKey="0GNIO0J9wdmcNm4gCV6S0nlaFE8bHa9W XXXXXX" copyright © 2009  cod technologies ltd  www.codtech.com
  • 47. obtaining google maps api key ● $ keytool -list -alias androiddebugkey -keystore ~/.android/debug.k eystore your fingerprint ● http://code.google.co m/android/maps­api­ signup.html copyright © 2009  cod technologies ltd  www.codtech.com
  • 48. MapActivity ● checking DDMS logcat again java.lang.IllegalArgumentException: MapViews can only be created inside instances of MapActivity. ● change base class to MapActivity ● fix imports ● add unimplemented methods copyright © 2009  cod technologies ltd  www.codtech.com
  • 49. where is the map ? ● still no map displayed ● check DDMS logcat ● errors displayed ● a permission is missing – INTERNET ● add it to Manifest copyright © 2009  cod technologies ltd  www.codtech.com
  • 50. finally our map still some problems ... ● spinner is covered android:layout_alignPa rentTop="true" ● spinner has no prompt prompt: @string/prompt ● externalize resource  value Select a location copyright © 2009  cod technologies ltd  www.codtech.com
  • 51. pattern: adapters an Adapter object acts as a bridge between an  AdapterView and the underlying data for that view ArrayAdapter<CharSequence> adapter = ArrayAdapter.createFromResource( this, R.array.array, android.R.layout.layout); view.setAdapter(adapter); The Adapter is also responsible for making a View for each item in the  data set. copyright © 2009  cod technologies ltd  www.codtech.com
  • 52. pattern: resources resources are external files (that is, non­code files)  that are used by your code and compiled into your  application at build time. <resources> <string-array name=”array”> <item>item</item> </string-array> </resources> res = getResources().getType(id); copyright © 2009  cod technologies ltd  www.codtech.com
  • 53. locations.xml <?xml version="1.0" encoding="UTF-8"?> <resources> <!-- No support for multidimensional arrays or complex objects yet (1.6r1) --> <string-array name="location_names"> <item>Akihabara Convention Hall</item> <item>Hotel Villa Fontaine</item> <item>Narita Intl. Airport</item> </string-array> <string-array name="locations"> <item>35.699434,139.772079,16</item> <item>35.669012,139.765384,14</item> <item>35.773118,140.379181,12</item> </string-array> </resources> http://android.codtech.com/jls2009/locations.xml copyright © 2009  cod technologies ltd  www.codtech.com
  • 54. complete the class ● create the locations array field locations = getResources().getStringArray(R.array.locations); ● find the views (ids pattern) spinner = (Spinner) findViewById(R.id.Spinner01); mapView = (MapView) findViewById(R.id.MapView); ● create the adapter final ArrayAdapter<CharSequence> adapter = ArrayAdapter.createFromResource(this, R.array.location_names, android.R.layout.simple_spinner_item); spinner.setAdapter(adapter) copyright © 2009  cod technologies ltd  www.codtech.com
  • 55. almost there ● map is displayed ● spinner is displayed ● drop down is  displayed ● but there's no  selection button ... adapter. setDropDownViewResource( android.R.layout. simple_spinner_dropdown_item ); copyright © 2009  cod technologies ltd  www.codtech.com
  • 56. respond to events ● when an item is  selected map should  be centered at that  location spinner. setOnItemSelectedListener( new OnItemSelectedListener() { }); ● in the listener invoke  goToSelectedLocation(ar g2); copyright © 2009  cod technologies ltd  www.codtech.com
  • 57. goToSelectedLocation protected void goToSelectedLocation(int position) { String[] loc = locations[position].split(","); double lat = Double.parseDouble(loc[0]); double lon = Double.parseDouble(loc[1]); int zoom = Integer.parseInt(loc[2]); GeoPoint p = new GeoPoint((int)(lat * 1E6), (int)(lon * 1E6)); mapController  should be  Log.d(TAG, "Should go to " + p); initialized in  onCreate mapController.animateTo(p); mapController.setZoom(zoom); } http://android.codtech.com/jls2009/goToSelectedLocation.txt copyright © 2009  cod technologies ltd  www.codtech.com
  • 58. more events ● turn map clickable android:clickable="true” ● override onKeyDown switch (keyCode) { case KeyEvent.KEYCODE_I: mapController.zoomIn(); break; case KeyEvent.KEYCODE_O: mapController.zoomOut(); break; case KeyEvent.KEYCODE_S: mapView.setSatellite( !mapView.isSatellite()); break; } http://android.codtech.com/jls2009/onKeyDown.txt copyright © 2009  cod technologies ltd  www.codtech.com
  • 59. zoom controls ● add a FrameLayout ● align to parent bottom ● in onCreate ... zoomControls = (ViewGroup)findViewById( R.id.FrameLayout01); ... mapView.setBuiltInZ oomControls(true); zoomControls.addView( mapView.getZoomControls()); copyright © 2009  cod technologies ltd  www.codtech.com
  • 60. we did it ! ● Some things to try – select a location – pan – zoom in – zoom out – toggle satellite copyright © 2009  cod technologies ltd  www.codtech.com
  • 61. japanese localization existing resource new  language copyright © 2009  cod technologies ltd  www.codtech.com
  • 62. japanese application ● resources  automatically selected ● match phone locale ● no programming  needed copyright © 2009  cod technologies ltd  www.codtech.com
  • 63. hierarchyviewer – tree properties selected view highlighted selected view copyright © 2009  cod technologies ltd  www.codtech.com
  • 64. hierarchyviewer ­ zoom selected  pixel pixel color copyright © 2009  cod technologies ltd  www.codtech.com
  • 65. “Remember that there is no  code faster than no code” ­­ Taligent's Guide to Designing Programs copyright © 2009  cod technologies ltd  www.codtech.com
  • 66. testing and performance after this section you will... ● understand the best practices  to develop for android ●  identify the alternatives to test  units, services and applications ● performance copyright © 2009  cod technologies ltd  www.codtech.com
  • 67. best practices ● consider performance, android is not a desktop ● avoid creating objects ● use native methods ● prefer virtual over interface ● prefer static over virtual (if no object access required) ● avoid internal getter/setters ● declares constants final ● avoid enums copyright © 2009  cod technologies ltd  www.codtech.com
  • 68. testing ● android sdk 1.6 features – creation of test projects – ActivityUnitTestCase to run isolated unit tests – ServiceTestCase to test services – ActivityInstrumentationTestCase2 to run functional  tests of activities ● ApiDemos includes some test samples ● monkey, generates pseudo­random of user  events copyright © 2009  cod technologies ltd  www.codtech.com
  • 69. 1000000 1500000 2000000 2500000 3000000 500000 0 Add a local variable Add a member variable Call String.length() Call empty static native method Call empty static method performance Call empty virtual method Call empty interface method Call Iterator:next() on a HashMap Call put() on a HashMap Inflate 1 View from XML Inflate 1 LinearLayout with 1 TextView copyright © 2009  cod technologies ltd  www.codtech.com Inflate 1 LinearLayout with 6 View Inflate 1 LinearLayout with 6 TextView Launch an empty activity Time
  • 70. traceview // start tracing to sdcard Debug.startMethodTracing(“mytrace”); copyright © 2009  cod technologies ltd  www.codtech.com
  • 71. dmtracedump $ sudo apt­get install graphviz copyright © 2009  cod technologies ltd  www.codtech.com
  • 72. “If things seem under control,  you're not going fast enough.” ­­ Mario Andretti copyright © 2009  cod technologies ltd  www.codtech.com
  • 73. thank you android development tutorial tokyo, october 2009 diego torres milano diego@codtech.com copyright © 2009  cod technologies ltd  www.codtech.com
