Electric Fields and Forces
Electrification by Friction Electric charge, or `electricity', can come from batteries and generators. But some materials ...
Two Types of Charge <ul><li>Polythene and Perspex can be charged by rubbing them with a dry, woollen cloth. </li></ul>

<ul><li>When two charged polythene rods are brought close together, they repel (try to push each other apart). </li></ul><...
<ul><li>However, a charged polythene rod and a charged Perspex rod attract each other. </li></ul><ul><li>Experiments like ...
Conservation of Charge <ul><li>Where do charges come from? </li></ul><ul><li>Everything is made of tiny particles called a...
<ul><li>Electrons have a negative (‑) charge.  </li></ul><ul><li>Protons have an equal positive (+) charge. </li></ul><ul>...
<ul><li>Normally, atoms have equal numbers of electrons and protons, so the  net  (overall) charge on a material is zero. ...
<ul><li>Rubbing materials together does not  make  electric charge. It just  separates  charges that are already there. </...
Question <ul><li>If a million electrons are transferred in one rub by a cloth, what are the resulting charges in Coulombs ...
Solution <ul><li>If a million electrons are transferred in one rub by a cloth, what are the resulting charges in Coulombs ...
Conductors and Insulators <ul><li>When some materials gain charge, they lose it almost immediately. This is because electr...
Conductors <ul><li>Conductors  are materials that let electrons pass through them. </li></ul><ul><li>Metals are the best e...
Insulators <ul><li>Insulators are materials that hardly conduct at all. </li></ul><ul><li>Their electrons are tightly held...
Semiconductors <ul><li>Semiconductors  are `in‑between' materials. </li></ul><ul><li>They are poor conductors when cold, b...
Electrostatic Induction <ul><li>Attraction of uncharged objects </li></ul><ul><li>A charged object will attract any unchar...

<ul><li>The previous diagram shows what happens if a positively charged rod is brought near a small piece of aluminium foi...


Coulomb’s Law <ul><li>The force between two point charges is directly proportional to the product of the charges and inver...
Equations <ul><li>F    q 1  q 2  / r 2 </li></ul><ul><li>Or  F = k q 1  q 2  / r 2 </li></ul><ul><li>Where k = 1/4 πε 0 <...
Applying Coulomb’s Law <ul><li>To determine the net force on a charge due to two or more other charges, you must use vecto...
Questions <ul><li>1. Find the force when </li></ul><ul><li>(a) 2 protons are placed 1mm apart </li></ul><ul><li>(b) proton...
Electric Field <ul><li>A resultant force changes motion. </li></ul><ul><li>Many everyday forces are pushes or pulls betwee...
<ul><li>Fields of these three types have common features as well as important differences. </li></ul><ul><li>An electric f...
<ul><li>In words,the magnitude of  E  is  the force per unit charge and its direction is that of  F   (i.e. of the force w...
<ul><li>To determine the net field strength on a charge due to two or more other charges, use must use vector addition. </...
Uniform Electric Field <ul><li>The field between two parallel plates can be calculated by </li></ul>

Field Patterns <ul><li>An electric field can be represented by electric field lines.These are drawn so that  </li></ul><ul...
Positive   Charge +
A hollow sphere
Upcoming SlideShare
Loading in...5
×

Electric Fields

2,591

Published on

Published in: Technology, Business
0 Comments
5 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
2,591
On Slideshare
0
From Embeds
0
Number of Embeds
0
Actions
Shares
0
Downloads
0
Comments
0
Likes
5
Embeds 0
No embeds

No notes for slide

Electric Fields

  1. 1. Electric Fields and Forces
  2. 2. Electrification by Friction Electric charge, or `electricity', can come from batteries and generators. But some materials become charged when they are rubbed. Their charge is sometimes called electrostatic charge or `static electricity'. It causes sparks and crackles when you take off a pullover, and if you slide out of a car seat and touch the door, it may even give you a shock.
  3. 3. Two Types of Charge <ul><li>Polythene and Perspex can be charged by rubbing them with a dry, woollen cloth. </li></ul>
  4. 5. <ul><li>When two charged polythene rods are brought close together, they repel (try to push each other apart). </li></ul><ul><li>The same thing happens with two charged Perspex rods. </li></ul>
  5. 6. <ul><li>However, a charged polythene rod and a charged Perspex rod attract each other. </li></ul><ul><li>Experiments like this suggest that there are two different and opposite types of electric charge. </li></ul><ul><li>These are called positive (+) charge and negative (‑) charge: </li></ul>
  6. 7. Conservation of Charge <ul><li>Where do charges come from? </li></ul><ul><li>Everything is made of tiny particles called atoms. </li></ul><ul><li>These have electric charge inside them. </li></ul><ul><li>There is a central nucleus made up of protons and neutrons. </li></ul><ul><li>Orbiting the nucleus are much lighter electrons </li></ul>
  7. 8. <ul><li>Electrons have a negative (‑) charge. </li></ul><ul><li>Protons have an equal positive (+) charge. </li></ul><ul><li>Neutrons have no charge. </li></ul>
  8. 9. <ul><li>Normally, atoms have equal numbers of electrons and protons, so the net (overall) charge on a material is zero. </li></ul><ul><li>However, when two materials are rubbed together, electrons may be transferred from one to the other. </li></ul><ul><li>One material ends up with more electrons than normal and the other with less. </li></ul><ul><li>So one has a net negative charge, while the other is left with a net positive charge. </li></ul>
  9. 10. <ul><li>Rubbing materials together does not make electric charge. It just separates charges that are already there. </li></ul><ul><li>Charge is always conserved in any action, the distribution of charge is changed. </li></ul>
  10. 11. Question <ul><li>If a million electrons are transferred in one rub by a cloth, what are the resulting charges in Coulombs of </li></ul><ul><li>(i) 3 rubs of polythene </li></ul><ul><li>(ii) 5 rubs of Perspex </li></ul><ul><li>(iii) the rods from (i) and (ii) are made to touch </li></ul>
  11. 12. Solution <ul><li>If a million electrons are transferred in one rub by a cloth, what are the resulting charges in Coulombs of </li></ul><ul><li>(i) 3 million*-1.6e-19 = -4.8e-13C </li></ul><ul><li>(ii) 5 million*1.6e-19 = 8e-13C </li></ul><ul><li>(iii) -4.8e-13C+8e-13C= 3.2e-13C </li></ul>
  12. 13. Conductors and Insulators <ul><li>When some materials gain charge, they lose it almost immediately. This is because electrons flow through them or the surrounding material until the balance of negative and positive charge is restored. </li></ul>
  13. 14. Conductors <ul><li>Conductors are materials that let electrons pass through them. </li></ul><ul><li>Metals are the best electrical conductors. </li></ul><ul><li>Some of their electrons are so loosely held to their atoms that they can pass freely between them. </li></ul><ul><li>These free electrons also make metals good thermal conductors. </li></ul><ul><li>Most non‑metals conduct charge poorly or not at all, although carbon (in the form of graphite) is an exception. </li></ul>
  14. 15. Insulators <ul><li>Insulators are materials that hardly conduct at all. </li></ul><ul><li>Their electrons are tightly held to atoms and are not free to move ‑ although they can be transferred by rubbing. </li></ul><ul><li>Insulators are easy to charge by rubbing because any electrons that get transferred tend to stay where they are. </li></ul>
  15. 16. Semiconductors <ul><li>Semiconductors are `in‑between' materials. </li></ul><ul><li>They are poor conductors when cold, but much better conductors when warm. </li></ul>
  16. 17. Electrostatic Induction <ul><li>Attraction of uncharged objects </li></ul><ul><li>A charged object will attract any uncharged object close to it. For example, the charged screen of a TV will attract dust. </li></ul>
  17. 19. <ul><li>The previous diagram shows what happens if a positively charged rod is brought near a small piece of aluminium foil. </li></ul><ul><li>Electrons in the foil are pulled towards the rod, which leaves the bottom of the foil with a net positive charge. </li></ul><ul><li>As a result, the top of the foil is attracted to the rod, while the bottom is repelled. </li></ul><ul><li>However, the attraction is stronger because the attracting charges are closer than the repelling ones. </li></ul>
  18. 22. Coulomb’s Law <ul><li>The force between two point charges is directly proportional to the product of the charges and inversely proportional to the square of the separation </li></ul>+1 +3 r
  19. 23. Equations <ul><li>F  q 1 q 2 / r 2 </li></ul><ul><li>Or F = k q 1 q 2 / r 2 </li></ul><ul><li>Where k = 1/4 πε 0 </li></ul><ul><li>ε 0 is the permittivity of free space </li></ul><ul><li>Therefore Coulomb’s Law can be written as </li></ul><ul><li>F = q 1 q 2 / 4 πε 0 r 2 </li></ul>
  20. 24. Applying Coulomb’s Law <ul><li>To determine the net force on a charge due to two or more other charges, you must use vector addition. </li></ul><ul><li>Find the force and direction due to each of the other charges in turn </li></ul><ul><li>and then resolve these forces to get the resultant force </li></ul>
  21. 25. Questions <ul><li>1. Find the force when </li></ul><ul><li>(a) 2 protons are placed 1mm apart </li></ul><ul><li>(b) proton and electron are placed 10 -9 m apart </li></ul><ul><li>(c) helium nuclei and an electron are 10 -6 m apart </li></ul><ul><li>2. Find the force acting on a +10  C charge placed 60 cm east of a +6  C charge and 40 cm north of a -8  C charge(  C = microcoulombs = 10 -6 C) </li></ul>
  22. 26. Electric Field <ul><li>A resultant force changes motion. </li></ul><ul><li>Many everyday forces are pushes or pulls between bodies in contact. </li></ul><ul><li>In other cases forces arise between bodies that are separated from one another. </li></ul><ul><li>Electric, magnetic and gravitational effects involve such action‑at‑a‑distance forces and to deal with them physicists find the idea of a field of force, or simply a field, useful. </li></ul>
  23. 27. <ul><li>Fields of these three types have common features as well as important differences. </li></ul><ul><li>An electric field is a region where an electric charge experiences a force. </li></ul><ul><li>If a very small, positive point charge Q, the test charge, is placed at any point in an electric field and it experiences a force F, </li></ul><ul><li>then the field strength E (also called the E‑field) at that point is defined by the equation </li></ul><ul><li>E = F/ Q </li></ul>
  24. 28. <ul><li>In words,the magnitude of E is the force per unit charge and its direction is that of F (i.e. of the force which acts on a positive charge). </li></ul><ul><li>Field strength E is thus a vector. </li></ul><ul><li>If F is in newtons (N) and Q is in coulombs (C) then the unit of E is the newton per coulomb (N C ‑1 ). </li></ul><ul><li>A more common but equivalent unit is the volt per metre (V m ‑1 ). </li></ul>
  25. 29. <ul><li>To determine the net field strength on a charge due to two or more other charges, use must use vector addition. </li></ul><ul><li>Find the field strength and direction due to each of the other charges in turn </li></ul><ul><li>and then resolve these field strengths to get the resultant field strength </li></ul><ul><li>Remember that the direction of a field is the direction in which a positive charge would move </li></ul>
  26. 30. Uniform Electric Field <ul><li>The field between two parallel plates can be calculated by </li></ul>
  27. 32. Field Patterns <ul><li>An electric field can be represented by electric field lines.These are drawn so that </li></ul><ul><li>(1) the field line at a point (or the tangent to it if it is curved) gives the direction of E at that point, i.e. the direction in which a positive charge would accelerate, </li></ul><ul><li>(2) the number of lines per unit cross‑section area is proportional to E. </li></ul><ul><li>The field line is imaginary but the field it represents is real. </li></ul>
  28. 33. Positive Charge +
  29. 34. A hollow sphere

×
