Distributed Design and Architecture of Cloud Foundry


Distributed Design and Architecture of Cloud Foundry

on

  • 12,989 views

In this session we will dig deep into Cloud Foundry's core architecture and design principles. We will discuss the challenges around scaling and operating a large scale service as we combined the PaaS ...

In this session we will dig deep into Cloud Foundry's core architecture and design principles. We will discuss the challenges around scaling and operating a large scale service as we combined the PaaS and traditional IaaS layers, and how we achieve multiple updates per week to the system with no perceived downtime. Allowing user to download a single virtual machine that is a complete replica of the service presented some challenges as well, and we will discuss our approach to offering up the downloadable private cloud.

Statistics

Views

Total Views
12,989
Views on SlideShare
10,540
Embed Views
2,449

Actions

Likes
56
Downloads
858
Comments
0

7 Embeds 2,449

http://www.scoop.it 2425
http://webcache.googleusercontent.com 8
http://www.techgig.com 6
http://a0.twimg.com 5
http://paper.li 2
http://www.m.techgig.com 2
http://twitter.com 1
More...

Accessibility

Categories

Upload Details

Uploaded via as Adobe PDF

Usage Rights

© All Rights Reserved

Report content

Flagged as inappropriate Flag as inappropriate
Flag as inappropriate

Select your reason for flagging this presentation as inappropriate.

Cancel
  • Full Name Full Name Comment goes here.
    Are you sure you want to
    Your message goes here
    Processing…
Post Comment
Edit your comment

    Distributed Design and Architecture of Cloud Foundry Distributed Design and Architecture of Cloud Foundry Presentation Transcript

    • Design and Architecture Derek Collison
    • What is Cloud Foundry?2
    • The OpenPlatform as a Service3
    • What is PaaS?4
    • Or more specifically, aPaaS?5
    • aPaaS • Application Platform as a Service • Applications and Services6
    • aPaaS • Application Platform as a Service • Applications and Services • Not • VMs • Memory • Storage • Networks • CPU7
    • What is OpenPaaS?8
    • OpenPaaS • Multi-Language • Multi-Framework • Multi-Services • Multi-Cloud, Multi-IaaS • Hybrid - Public or Private or Both • OpenSource9
    • OpenPaaS • Multi-Language • Ruby, Java, Scala, Node.js, Erlang, Python, PHP.. • Multi-Framework • Rails, Sinatra, Spring, Grails, Express, Lift • Multi-Services • MySQL, Postgres, MongoDB, Redis, RabbitMQ • Multi-Cloud, Multi-IaaS • vSphere, MicroCloud, OpenStack, AWS10
    • The Open PaaS Ap pli vFabric Private ca ce Postgres tio rfa Data Clouds n e Services Int Se Public rvi er vFabric vid ce RabbitMQTM Msg Services Clouds ro Int dP e Micro rfa ou Clouds ce Other Cl Services11
    • What is our Goal?12
    • What was our Goal? Raise the unit of currency to be the application and its associated services, not the infrastructure13
    • What was our Goal? Best of breed delivery platform for all modern applications and frameworks14
    • What was our Goal? Favor Choice and Openness15
    • How was it Built?16
    • How was it Built? • Kernel (CloudFoundry OSS) • Core PaaS System • Kernel and Orchestrator Shells • Layered on top of IaaS • Orchestrator • IaaS creation, management and orchestration17
    • High Level Clients (VMC, STS, Browser) CF Kernel Orchestrator IaaS Hardware - CPU/Memory/Disk/Network18
    • Basic Premises • Fail Fast • Self Healing • Horizontally Scalable Components • Distributed State • No Single Point of Failure • Should be as simple as possible19
    • Basic Patterns • Event-Driven • Asynchronous • Non-blocking • Independent, Idempotent • Message Passing • Eventually Consistent20
    • Basic Design • All components loosely coupled • Few “Classes”, many “Instances” • Messaging as foundation • Addressing and Component Discovery • Command and Control • JSON payloads • HTTP or File/Blob for data transport21
    • Kernel Components • All dynamically discoverable • Launch and scale in any order • Can come and go as needed • Monitor via HTTP and JSON • Location independent22
    • Kernel Components • Router • CloudController • DEA • HealthManager • Service Provisioning Agent • Messaging System23
    • Logical View Browser VMC client STS plugin (user app access) Routers CloudControllers App App HealthManager Services DEA Pool Messaging24
    • 25 Architecture
    • Messaging26
    • Messaging “The Nervous System”27
    • Messaging Browser VMC client STS plugin (user app access) Routers CloudControllers App App HealthManager Services DEA Pool Messaging28
    • Messaging • Addressing and Discovery • No static IPs or DNS lookups req’d • Just Layer 4 • Command and Control • Central communication system • Dial tone, fire and forget • Protects *itself* at all costs • Idempotent semantics29
    • Router30
    • Router “Traffic Cop”31
    • Router Browser VMC client STS plugin (user app access) Routers CloudControllers App App HealthManager Services DEA Pool Messaging32
    • Router • Handles all HTTP traffic • Maintains distributed routing state • Routes URLs to applications • Distributes load among instances • Realtime distributed updates to routing tables from DEAs33
    • CloudController34
    • CloudController “The King”35
    • CloudController Browser VMC client STS plugin (user app access) Routers CloudControllers App App HealthManager Services DEA Pool Messaging36
    • CloudController • Handles all state transitions • Deals with users, apps, and services • Packages and Stages applications • Binds Services to Applications • Presents external REST API37
    • HealthManager38
    • HealthManager “Court Jester”39
    • HealthManager Browser VMC client STS plugin (user app access) Routers CloudControllers App App HealthManager Services DEA Pool Messaging40
    • HealthManager • Monitors the state of the world • Initial value with realtime delta updates to “intended” vs “real” • Determines drift • Complains to the CloudControllers when something is not correct • No power to change state itself41
    • DEA42
    • DEA “Droplet Execution Agent”43
    • DEA Browser VMC client STS plugin (user app access) Routers CloudControllers App App HealthManager Services DEA Pool Messaging44
    • DEA (Droplet Execution Agent) • Responsible for running all applications • Monitors all applications • CPU, Mem, IO, Threads, Disk, FDs, etc • All apps look same to DEA • start and stop • Express ability and desire to run an application • runtimes, options, cluster avoidance, memory/cpu • Alerts on any change in state of applications • Provides secure/constrained OS runtime • Hypervisor, Unix File and User, Linux Containers* • Single or Multi-Tenant45
    • How does it all Work?46
    • Pushing an App • Client (VMC/STS) pushes meta-data to CC • Client optionally pushes resource signatures (diff analysis, sys wide) • Client pushes app resources to CC • CC puts app together • CC stages app asynchronously • CC binds and stages services • Droplet ready47
    • 48 Architecture
    • Running an App • CC asks DEAs for “help” • First DEA back wins! Simple • CC sends start request to selected DEA • DEA pushes the “green” button • DEA waits and monitors pid and ephemeral port for app to bind • When app is healthy, sends “register” message • Register message is seen by HM and Routers • Routers bind URL to host:port49
    • DEAs answer? • DEAs first determine YES or NO • correct runtime, options, memory, etc • Then calculate a Delay Taint • SHA hash of application • memory • cpu • Taint allows balancing and selection50
    • Scale up & down? • Exact steps as running the app the first time • SHA1 taint helps avoid clustering • memory/cpu taint helps distribute as evenly as possible • Nothing pre-computed • Nothing assumed51
    • Crashes? • If your app stops and we did not tell it to, that is a crash • Crashed apps are immediately detected by DEA and messaged • Routers disconnect route instantly • HM will signal CC • something is wrong • CC will issue run sequence again52
    • 53 Architecture
    • Access to my App? • All routers understand where all instances of your application are running • Will randomly pick backend, not semantically aware. • Will remove routes that are stale or unhealthy • Session stickiness and replication available, but best to avoid if possible54
    • What about Services?55
    • Services Browser VMC client STS plugin (user app access) Routers CloudControllers App App HealthManager Services DEA Pool Messaging56
    • Services • Service Advertisement • Service Provisioning • Gateway fronts multi-backends • Service Nodes scale independent • App and service talk directly • API to register into system • Closure for additional value57
    • Provisioning VMC/STS 1 Routers 2 CloudControllers Services Gateway 3 5 6 4 Service Node Service Node Service Node Application MySQL Redis Redis Messaging58
    • Access (Direct) Browser (user app access) 1 Routers CloudControllers Services Gateway Service Node Service Node Service Node Application MySQL Redis Redis 2 Messaging59
    • Services VMware Dev Tools Partner Dev Tools Cloud Foundry consume Enterprise Services apps consume bind Data Director provision/bind service service broker controller SQLFire core services Relational DB vSphere60
    • Learn more: www.cloudfoundry.org blog.cloudfoundry.com support.cloudfoundry.com61
    • Thank You62
    • Questions? dcollison@vmware.com derek.collison@gmail.com twitter: derekcollison63
