XPages have ushered in a new era for application development on the IBM Lotus Domino platform. This session will take you beneath the surface of XPages and into the inner workings of server-side …

XPages have ushered in a new era for application development on the IBM Lotus Domino platform. This session will take you beneath the surface of XPages and into the inner workings of server-side JavaScript, the language that allows you to easily add truly advanced features to your applications. By the end of this deep-dive session, you'll know how to use server-side JavaScript in the following ways: create events that dynamically manipulate interface components based on user interaction; and use scope caching to improve performance and usability and leverage closures
and other design patterns to create reusable object-oriented server-side JavaScript. You'll also learn how to make your XPages more powerful with "managed beans" and other Java classes, as well as create advanced re-usable components by passing Java and server-side JavaScript objects to custom controls.

Published in: Sports, Technology
0 Comments
1 Like
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
3,944
On Slideshare
0
From Embeds
0
Number of Embeds
2
Actions
Shares
0
Downloads
160
Comments
0
Likes
1
Embeds 0
No embeds

Report content
Flagged as inappropriate Flag as inappropriate
Flag as inappropriate

Select your reason for flagging this presentation as inappropriate.

Cancel
No notes for slide

Transcript

  • 1. AD111 Harnessing the Power of Server-Side JavaScript and Other Advanced XPage Techniques Tim Tripcony | GROUP Experts - XMage Stephan H. Wissel | IBM - Lotus Technology & Productivity Advisor
  • 2. Agenda ● What exactly is Server Side Java Script (SSJS) ● Common practices: pattern & anti-pattern ● Code samples The REAL Agenda: code, code, code 2
  • 3. Server-side JavaScript is JavaScript ● all ECMAScript 3 keywords, operators and syntax still apply ▬ var myNumber = 0; ▬ var myArray = [ ]; // preferred over new Array(); ▬ var myObject = { }; // preferred over new Object(); ▬ function foo(){return "bar";} ▬ var depends = someBoolean ? "default" : "other"; ● ECMAScript scope rules apply, including closure ▬ More in the Demo section 3
  • 4. Server-side JavaScript is not JavaScript (1) ● browser-specific globals not available ▬ window ▬ document ▬ location ● Platform-specific globals and JSF-specifics ▬ session: current NotesSession ▬ database: current NotesDatabase, equal to session.getCurrentDatabase() ▬ param: URL parameters and post data ▬ context & facesContext: current state data and direct access to servlet engine 4
  • 5. Server-side JavaScript is not JavaScript (2) ● @functions (e.g. @UserName() ) ● scope variables ▬ requestScope ▬ viewScope ▬ sessionScope ▬ applicationScope ● Optional type declarations ● Seamless Java™ integration 5
  • 6. Agenda ● What exactly is Server Side Java Script (SSJS) ● Common practices: pattern & anti-pattern ● Code samples 6
  • 7. The use of context ● getUser(): access to name, roles, groups, and more ● getUrl(): no more String parsing to get query string parameters and other URL info ● getUserAgent(): server-side browser detection ● redirectToPage() / redirectToHome(): easy programmatic navigation 7
  • 8. The use of facesContext ● getResponseWriter() / getResponseStream(): send your own output to the browser (like Print in LotusScript) ● getExternalContext(): direct access to the servlet ▬ getRequest() ▬ GetResponse() ● You need to understand the difference between the ResponseWriter and ResponseStream ▬ Writer doesn't take binary data ▬ Stream excludes Writer ▬ Can only use one per request
  • 9. JavaScript Closures ● An object returned from a function has access to variables defined within that function ▬ Includes arguments passed to the function ● This allows for OOP constructs in JavaScript objects ▬ Private properties ▬ Private functions ▬ Inheritance without .prototype 9
  • 10. Take advantage of XPages' JSF heritage ● Java Objects at your disposal ▬ java.util: powerful storage and iteration ▬ java.net: easy access to remote data ▬ Core JSF packages and IBM's implementation ● Get to the servlet ● Write your own servlet (you are on your own here) 10
  • 11. Write agent Style code in XPages ● Control the rendering ● Get the output writer ● Get the output stream (one of the two) ● Use cases: ▬ Replace web agent (?OpenAgent) ▬ Output other formats (PDF, ODF) 11
  • 12. The use of scope ● requestScope: storage for anything needed multiple times in the same HTTP request ● viewScope: survives for the life of a page - including partial and full refresh events ● sessionScope: "shopping cart" storage - survives for the duration of a user's session, BUT can expire even if the user is still logged in (set in application properties to balance server performance with application performance) ● applicationScope: storage shared among all users of the NSF - any data that numerous users are likely to need but shouldn't be queried on every request 12
  • 13. Anti-Pattern: What always goes wrong ● The network is fast and reliable ● Configuration parameters are retrieved through @DBLookup ● Connect to JDBC without a session pool ● Use data binding when you access data, not anything else 13
  • 14. Everybody's favorite objects ● UI Elements ▬ Create a control programmatically ▬ Update control properties via event handlers ● DOMUtil ▬ Parse DXL and other XML ● cookie ▬ Set and read cookies using .put() and .get() 14
  • 15. Error Handling ● try/catch: provide individual operations that might fail a specific response to failure ● Enable “Display default error page” during development and testing ● Create custom error pages to display uncaught exceptions 15
  • 16. Debugging ● print(): send a single String statement to server log and console ● _dump(): send detailed info about any object to log and console 16
  • 17. Unit Tests ● Courtesy of Lorcan McDonald (IBM Lab Dublin) ● Available on OpenNTF ● Enables Test Driven Development (get used to it) http://openntf.org/internal/ontfcatalog.nsf/topicThread.xsp?action=openDocument&documentId=9C66A4F3854E61BE852575A1003C6CAD 17
  • 18. Reaching out to Java ● Put source into webcontent/source ● Add directory to Java build path ● Package name required ● Define like a JavaScript variable: var xy = new com.acme.RoadRunner(); xy.foolCoyote(“Meep Meep”); 18
  • 19. Managed Beans ● Concept inherited from JSF underpinnings ● Bean is described in XML declaration ● Can be used in JavaScript expressions ● Automatically loaded when needed ● Bound to a specific scope ● Take advantage of Java capabilities (e.g. Connection pooling, threading etc) 19
  • 20. Agenda ● What exactly is Server Side Java Script (SSJS) ● Common practices: pattern & anti-pattern ● Code samples 20
  • 21. Application Chat ● Application Context ● Synchronized Access ● Closure ● Periodic partial refresh 21
  • 22. Shopping Cart ● Session Context ● Closure ● Java integration 22
  • 23. Cached Search ● Application Context ● Managed Bean ● Network handling 23
  • 24. Q&A 24
