  • 1. A workhorse named Mule
  • 2. The speaker  Mule in Action, co­author  Project despot of Mule JCR Transport  Common Retry Policies  HTML Dashboard  Mule Community Committee Member  Lead of NxBRE  Judge for the Jolt Awards  And a few other stuff...
  • 3. Non­agenda  eMule  Mule pre 2.2.0, EE  Tutorial  Works on my machine  Alternative configurations
  • 4. Agenda  Introduction  Exploration  Construction  In Action
  • 5. Introduction
  • 6. What is Mule? ”Mule is a lightweight messaging framework and  highly distributable object broker”
  • 7. What? No ESB? No SOA?  ESB is a deployment topology  Mule can be deployed as ESB  But also: ESN, Hub and spoke...  SOA can leverage an ESB  Just an extra tool in a tool box  Mule has no dogma nor methodology  More on this later...
  • 8. And what about Java?  Written in Java  Leverages zillions of Java open source  libraries  Can do a lot without Java though  XML and Groovy can go a long way
  • 9. Genesis  Founded by Ross Mason  SourceForge project created in April 2003  Version 1.0 in April 2005  Moved to CodeHaus  Architecture based on:  EIP  SEDA
  • 10. EIP  Enterprise Integration Patterns  Hohpe & Woolf (2004)  Gave Mule its lingo  Endpoints, Transformers...  Routers, Bridge...  Gives us patterns & iconography   http://www.enterpriseintegrationpatterns.com
  • 11. SEDA  Staged Event­Driven Architecture  Welsh (2001)  Disciplined approach to overload management  Event­driven application  Stages connected by queues  Graceful degradation under load  By default Mule is asynchronous and SEDA
  • 12. What's in a name? ”After  working  on  a  couple  of  bespoke  ESB  systems,  I  found  that  there  was  a  lot  of  infrastructure  work  to  be  done  before  you  can  really start thinking about implementing any logic.  I regard this infrastructure work as 'donkey work' as  it  needs  doing  for  every  project.  I  preferred  Mule over Donkey and Ass just didn't seem right. A  Mule  is  also  commonly  referred  to  as  a  carrier  of load, moving it form one place to another. The  load  we  specialise  in  moving  is  your  enterprise  information.”     Ross Mason
  • 13. Donkey work Integration App 1 Broker App 2 App 3
  • 14. Mule work Adaptation, Transformation & Routing App 1 Mule App 2 App 3
  • 15. Mule's dual nature
  • 16. Mule's dual nature ”Mule is a lightweight messaging framework and  highly distributable object broker”
  • 17. Lightweight messaging  framework Mule Your Application
  • 18. Highly distributable object broker Mule Mule
  • 19. Dual competition  Integration  frameworks  Camel ✔ Strictly EIP  Spring Integration ✔ DI oriented  ESBs  Apache, WSO2,  ✔ Web service  OW, JBoss oriented  Big vendors ✔ Tooling ✔ Doodleware
  • 20. Dual offer  Community Edition  Stable “enough”  Upgrades can be rocky  Enterprise Edition  Supported, stabler  Enterprise features  MQSeries connectors, retry policies  Monitoring tool (MuleHQ)
  • 21. Key benefits I  Proven product  Used in many world­class applications  Sound architecture  Drastically refined in Mule 2  Numerous protocols and extensions  From MuleSource and MuleForge  Spring & Maven oriented
  • 22. Key benefits II  Good tooling  Mule IDE  Galaxy  Active community  Support, MuleForge  Shared code base CE / EE  Professional support available
  • 23. Main drawbacks  Unified messaging abstraction  Acts as a potential keyhole on the real deal  Brings its own idiosyncrasies  Like any framework...  Standards based but not standards compliant  But what standards? JBI? SCA?  Not fully EIP but uses much of its lingo
  • 24. Exploration
  • 25. ”A messaging framework”  Mule is about abstraction and adaptation  Message  Protocol  As a framework  You can code to it  Wisely  You can extend almost every aspect of it  Wisely
  • 26. Message abstraction MuleMessage Payload Properties Attachment Exception
  • 27. Message abstraction  Payload  HTTP body, File content  Properties  HTTP Headers, JMS properties  Attachments  SOAP parts, Email parts  Exception  Related to the current message processing
  • 28. Protocol abstraction  Handled by ”transports”  Connectors and endpoints  Message adapters and transformers  Inbound interactions  Receive (event)  Request (polling)  Outbound interactions  Send (request/response)  Dispatch (asynchronous)
  • 29. Protocol adaptation  At connector level  Handles interactions   At message level  Message adaptation  Raw data access  Specific additional transformation  e.g. Object ↔ JMS Message transformers
  • 30. Protocol adaptation Inbound Protocol Adaptation Mule Transformation Mule Specific Message Message
  • 31. Protocol adaptation Outbound Mule Transformation Mule Adaptation Protocol Message Message Specific
  • 32. Unified payloads?  File transport  Stream  java.io.File  JMS transport  Map, String...  IMAP transport  String
  • 33. xmlns:context="http://www.springframework.org/schema/context" xmlns:file="http://www.mulesource.org/schema/mule/file/2.2" xmlns:jms="http://www.mulesource.org/schema/mule/jms/2.2" xmlns:xm="http://www.mulesource.org/schema/mule/xml/2.2" xsi:schemaLocation=" http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans-2.5.xsd http://www.springframework.org/schema/context http://www.springframework.org/schema/context/ spring-context-2.5.xsd http://www.mulesource.org/schema/mule/core/2.2 http://www.mulesource.org/schema/mule/core/2.2/mule.xsd http://www.mulesource.org/schema/mule/file/2.2 http://www.mulesource.org/schema/mule/file/2.2/mule-file.xsd http://www.mulesource.org/schema/mule/jms/2.2 http://www.mulesource.org/schema/mule/jms/2.2/ mule-jms.xsd http://www.mulesource.org/schema/mule/xml/2.2 http://www.mulesource.org/schema/mule/xml/2.2/ mule-xml.xsd" > <notifications dynamic="true"> Need help! <notification event="ENDPOINT-MESSAGE"/> </notifications> <global-property name="jms.url" value="vm://localhost"/> <jms:activemq-connector name="jmsConnector" specification="1.1" brokerURL="${jms.url}"/> <file:connector name="FileConnector" streaming="false" autoDelete="true" pollingFrequency="1000"> <file:expression-filename-parser/> </file:connector> <model name="jmsInboundModel"> <service name="jmsInboundService"> <inbound> <jms:inbound-endpoint topic="backup-reports" > <transformers> <jms:jmsmessage-to-object-transformer/> </transformers> </jms:inbound-endpoint>   </inbound>
  • 34. Mule's anatomy
  • 35. Mule's anatomy Service Service Mule Service Service
  • 36. Mule service  Wider definition than strict SOA  Both inbound and outbound are considered  Service can have business logic or not  Message routing is done by services  Role defined by messaging style  Four main styles
  • 37. Request Response Request Client Service Response
  • 38. Asynchronous Dispatch Client Service
  • 39. Synchronous Request Request Client Service Service Response Response
  • 40. Async Request Response Request Dispatch Client Service Service Response Response
  • 41. Combined styles Request Dispatch Client Service Service Response
  • 42. Other inbound styles Listen Source Service Poll Source Service Request Source Service
  • 43. Mule's service anatomy Service ?
  • 44. Mule's service anatomy Inbound Outbound Routing Component Routing Response
  • 45. Mule's service routing anatomy Inbound Outbound Transformers Transformers Endpoints Endpoints Router Router Component Response
  • 46. Endpoints  Communication ”touch points”  Configured  Locally in services  Inbound and outbound  Globally  Named  “Unbound”  Used locally in or out
  • 47. Endpoints  Inbound <jms:inbound-endpoint topic="events" />  Outbound <file:outbound-endpoint path="./events" />  Global <jms:endpoint name="events.in" topic="events" /> ... <inbound-endpoint ref="events.in" />
  • 48. Endpoints URI  Two equivalent endpoints: <jms:inbound-endpoint topic="events" /> <inbound-endpoint address="jms://topic/events" />  Prefer rich XML schema style  Generic style exists for extensibility  In code, URI style prevails
  • 49. Routers  Routing behavior for endpoints  Smart “switching” and filtering  Aggregation, multicasting...  Configured locally in services  Different families  Inbound  Outbound  Async­reply
  • 50. Routers <inbound> <jms:inbound-endpoint topic="events" /> <jdbc:inbound-endpoint queryKey="eventsQuery"/> </inbound> <outbound> <multicasting-router> <jms:outbound-endpoint topic="events"/> <file:outbound-endpoint path="./events" /> </multicasting-router> <outbound>
  • 51. Transformers  Message payload  Generic  Bytes to string, compression, XSLT...  Transport  JMS to object, String to email...  Message properties  CRUD  Round trip alter egos
  • 52. Transformers  Configured  Locally on endpoints  In / response and out  Globally  Named  Used locally in or response  Sometimes invisible (transport)  Can be composed  Rolling your own is rare
  • 53. Transformers <xm:xslt-transformer name="DocbookToFO" xsl-file="docbook-fo.xsl" /> ... <inbound-endpoint ref="docs.in.sync" > <transformers> <gzip-uncompress-transformer /> <transformer ref="DocbookToFO" /> </transformers> <response-transformers> <gzip-compress-transformer /> </response-transformers> </inbound-endpoint>
  • 54. Components  Messaging behavior  Bridge, Log  Reflection message builder  Remote service proxy  Business behavior  Instantiation by Mule or Spring  Pure POJO or Mule aware  Can be pooled
  • 55. Components <log-component /> <test:component/> <component> <singleton-object class="com.acme.Component" /> </component> <component> <spring-object bean="yourBean" /> </component> <pooled-component class="com.acme.Component" />
  • 56. http://www.springframework.org/schema/beans/spring-beans-2.5.xsd http://www.springframework.org/schema/context http://www.springframework.org/schema/context/ spring-context-2.5.xsd http://www.mulesource.org/schema/mule/core/2.2 http://www.mulesource.org/schema/mule/core/2.2/mule.xsd http://www.mulesource.org/schema/mule/file/2.2 http://www.mulesource.org/schema/mule/file/2.2/mule-file.xsd http://www.mulesource.org/schema/mule/jms/2.2 http://www.mulesource.org/schema/mule/jms/2.2/ mule-jms.xsd http://www.mulesource.org/schema/mule/xml/2.2 http://www.mulesource.org/schema/mule/xml/2.2/ mule-xml.xsd" > <notifications dynamic="true"> <notification event="ENDPOINT-MESSAGE"/> </notifications> Pwned! <global-property name="jms.url" value="vm://localhost"/> <jms:activemq-connector name="jmsConnector" specification="1.1" brokerURL="${jms.url}"/> <file:connector name="FileConnector" streaming="false" autoDelete="true" pollingFrequency="1000"> <file:expression-filename-parser/> </file:connector> <model name="jmsInboundModel"> <service name="jmsInboundService"> <inbound> <jms:inbound-endpoint topic="backup-reports" > <transformers> <jms:jmsmessage-to-object-transformer/> </transformers> </jms:inbound-endpoint> </inbound> <outbound> <pass-through-router> <file:outbound-endpoint path="./data/reports" outputPattern="BACKUP-REPORT-#[function:dateStamp]"/>   </pass-through-router>
  • 57. Service configuration <service name="eventsWriter"> <inbound> <jms:inbound-endpoint topic="events" /> </inbound> <outbound> <pass-through-router> <file:outbound-endpoint path="./events" /> </pass-through-router> </outbound> </service>
  • 58. Service configuration <service name="eventsWriter"> <inbound> <jms:inbound-endpoint topic="events" /> </inbound> <bridge-component /> <outbound> <pass-through-router> <file:outbound-endpoint path="./events" /> </pass-through-router> </outbound> </service>
  • 59. Anything else?  Connectors  Transport specific configuration  Model  Shared configuration & behavior for services  Interceptors  To add cross­cutting concerns around  components
  • 60. The mysterious Mule client
  • 61. The mysterious Mule client  Why a client?  In­memory access to an instance  Message generation  Functional testing  Remote access to an instance  Proprietary remote invoker  Raw transport usage
  • 62. Mule client interactions (some)  Dispatch muleClient.dispatch("jms://queue", map, null);  Send MuleMessage response = muleClient.send("vm://channel", payload, props);  Request MuleMessage requested = muleClient.request("file://events/01.dat", 0);
  • 63. Construction
  • 64. What do we build?  Standalone  Embedded  Project structure  Java application  NetBoot  Web application  Repository artifacts  EJB application  JCA resource
  • 65. Just ship it!  A Mule project is just a bunch of XML files  Tinker with them a little  Ship them to production  And you are good to go!  Right?
  • 66.
  • 67. No escape from SD laws!  Practices  Middleware development  TDD  Repeatable builds  Repeatable deployments  Tools  SCM  Continuous integration
  • 68. Middleware development  practices  Do not get coupled with the middleware  Contain Mule related code to Mule aware  classes  Transformers, interceptors  Caching  Time­outs  Efficient logging and manageability
  • 69. Unit Testing  For components, transformers...  Outside of Mule  xUnit
  • 70. Functional Testing  For routing, configuration...  Test­scoped instance  Mule client  Test component  Substitution endpoints  In­memory infrastructure  Jitr
  • 71. Integration Testing  For Mule instance in situation  Complex because heterogeneous  Test messages  Test services  Secondary endpoints  soapUI, HermesJMS  Test Driven EAI  Hohpe & Istvanik (2002)     http://bit.ly/tdeai
  • 72. Other Testing  Load tests  Use JMeter  Profiling  Use the YourKit Profiler Pack
  • 73. Asynchronous testing challenge
  • 74. Asynchronous testing (lucky) Test Thread Mule Thread Start Mule Send test message Process message Perform assertions Stop Mule
  • 75. Asynchronous testing Test Thread Mule Thread Start Mule Send test message Perform assertions Process message Stop Mule
  • 76. Asynchronous testing Fixed Test Thread Mule Thread Start Mule Send test message Process message Await latch (n) Latch down Perform assertions Stop Mule     http://bit.ly/tasync
  • 77. Unleashing Mule
  • 78. Unleashing Mule I  Generic knowledge  Maven  Spring
  • 79. Maven  Mule is available as a set of artifacts  Core, transports, modules  With petazillions of dependencies  Distribution packs them all  Specific archetypes  New project  New transport  Galaxy publication
  • 80. Spring  Code is independent from Spring  Configuration is fully Spring XML  With specific schemas  Use Spring configuration practices  DI, properties, multiple files...  Use Spring goodness  Specific elements,  MBean exporter...  Mule's context can use a Spring parent  Bean reuse
  • 81. Unleashing Mule II  Specific knowledge  VM Transport  Transport configuration  Expressions  Scripting  Entry point resolvers  Notifications
  • 82. VM Transport  In­memory named pipe  Direct or queuing  Can be disk persistent  What you can not solve with one service  You solve it with two services  And a VM Queue in between!
  • 83. Transport configuration  Know the underlying transport  Understand what Mule hides & controls  Learn the configuration options  Including alternative adapters, transformers  Leverage the transport­specific properties  Inbound and outbound  Read the source code
  • 84. Expressions  Dynamic properties in configuration  #[evaluator:expression]  Filters, transformers, endpoint URIs  Usually evaluated on the current message  Standalone and Mule­wide evaluators exist  Many evaluators available  Groovy, XPath, Map Payload, OGNL...  Can also be invoked from code
  • 85. <message-properties-transformer name="SetTo"> <add-message-property key="toAddresses" value="#[xpath:/Receipts/SendToEmail]" /> </message-properties-transformer> ... <smtp:outbound-endpoint host="${smtp.host}" port="${smtp.port}" from="${smtp.fromAddress}" subject="${smtp.subject}" transformer-refs="SetTo StringToEmailMessage" />
  • 86. Scripting  Any JSR­223 engine  Groovy bundled with the scripting module  Rhino bundled with JDK 1.6  Transformers, components, expressions  Good for non­generic ones  Concise syntax (i.e. non­Java)  Inlined or standalone scripts  Spring Scripted Beans are also an option
  • 87. <scripting:transformer name="toUpperCase"> <scripting:script engine="groovy"> return payload.toUpperCase() </scripting:script> </scripting:transformer> <scripting:component> <scripting:script engine="js"> if (payload.search("STATUS: CRITICAL") != -1) { message.setProperty("PRIORITY", 'HIGH') } return message </scripting:script> </scripting:component> <expression-filter evaluator="groovy" expression="message.payloadAsBytes.length>1024" />
  • 88. Entry point resolvers  Secret behind Mule­free components  Locate the method to call  Several resolvers available  Reflection, array, no argument, method name  By default, Mule uses a set of resolvers  Add a transformation in front to better resolve  By type or directly by name
  • 89. Notifications  Internal notification framework  Extreme diversity of events  Mule lifecycle, routing, errors, time­outs...  Standard consumers  JMX, Log4J, publish to endpoint  Custom consumers  Components, interceptors...
  • 90. In Action
  • 91. The tough questions
  • 92. The tough questions  SOAP or REST?  Monitoring  Transactions  Auditing  Exception handling  High availability  Security  Hot reload  Scheduling  Governance  Orchestration  Performance
  • 93. SOAP or REST?  SOAP transports  REST transports  CXF  Abdera  Axis  Jersey  Restlet
  • 94. Transactions  Supported by a handful of transports  VM, JDBC, JMS  Mostly useful for bridging  Like Queue to Topic  Consider eventual consistency  Conversation based  Idempotent services  Compensation
  • 95. Exception handling  Exceptions are handled at several levels  Connector and service  Retry policies  Different strategies  Logging, dispatch to endpoint  Transaction roll­back  Exception based outbound router  Localized error handling via fallback
  • 96. Security  Secure endpoints  Authentication and authorization  Secure payload  Encryption  Security manager  Can delegate to Spring Security  Can use JAAS  Transport security handled at connector level
  • 97. Scheduling  Based on Quartz  In inbound router  To regularly send a fix payload  To request an endpoint (polling)  In outbound router   To schedule a delayed dispatch
  • 98. Orchestration  Trivial, short lived  Message flow is the orchestration  Component binding, chaining router  Complex, long lived  Messages trigger worflow steps  jBPM (native)  Orchestrator triggers services  ActiveBPEL (via WS)
  • 99. Chaining router <service name="WeatherDispatchService"> <inbound> <inbound-endpoint ref="WeatherRequest" /> </inbound> <outbound> <chaining-router> <outbound-endpoint ref="WeatherChannel" /> <jms:outbound-endpoint queue="weather" /> </chaining-router> </outbound> </service>
  • 100. Monitoring  Standard Java middleware  Monitor JVM with SNMP or JMX  Monitor Mule with JMX  Monitor external channels  Queues filling up, DB not refreshed...  EE relies on MuleHQ  Based on Hyperic
  • 101. Auditing  Hard with distributed heterogeneous systems  Watermark messages with correlation ID  Standard with JMS  Ad hoc with other transports  Always log correlation ID with all messages  Mule takes great care of correlation ID
  • 102. High availability  Easily achieved with stateless instances  Redundancy & network load balancer  Clustering needed with stateful instances  EE will offer GigaSpaces  Terracotta  DB, in some cases  ID store for idempotent receiver
  • 103. Mythical hot reload  Everybody wants it  Really?  Mule configuration can be hot reloaded  Since 2.2.2  Mule libraries are OSGi bundles  But Mule is not (yet) running on OSGi
  • 104. Governance  Publicly exposed services are commitments  Required by compliance rules  Galaxy  Repository and registry  Versioning  Backwards compatibility check  Galaxy EE is HA
  • 105. Governance EE
  • 106. Performance
  • 107. Performance I  Beware benchmarks  SEDA is tricky to tune  Many thread pools  Some not directly handled by Mule  Threading   Configured with profiles  Affected by transactions, synchrony  Follow MuleSource's methodology
  • 108. Performance II  Consider streaming  Smooks for efficient processing  Tune the transports  HTTP chunking, JMS acking...  Profile first!  YourKit Profiler Pack
  • 109. The big picture
  • 110.
  • 111. To ESB or not? I  ESB in the middle of all service calls  Looks good on slides  But a big mess inside  Remember Jim Webber  “Guerilla SOA”  ESB == “Egregious Spaghetti Boxes”     http://bit.ly/g­soa
  • 112. To ESB or not? II  “A good ESB is a dead ESB”?  Decision points: http://bit.ly/to­esb­or­not  “MuleSource is Open for Integration.”  Don't get confused on branding/naming  ESB is a topology not a tool  There are others...
  • 113. Topology  ESB  JMS backbone  ESN  Direct service to service  Hub & Spoke  Centralized broker  Client / Server  ...
  • 114. Methodology  None officially preached by MuleSource  But lots of experience with many clients  Fits with the one in­house  Nespresso Open Architecture (NesOA)  Read MuleSource's articles  To get the gist of their approach  Pragmatism first!
  • 115. Bottom­up SOA ” I’ve seen firsthand that the more successful enterprises that have adopted SOA have done so at the grassroots level. (...) Certainly many of our customers choose Mule not on a strategic initiative, but because they have pockets of successful implementations and decide to work with us to help pull the pieces together.” http://bit.ly/bup­soa     Ross Mason
  • 116. Time to hit it!
  • 117. Getting started  www.mulesource.org  Download CE, browser user guide  www.mulesource.com  Professional support  http://code.google.com/p/muleinaction/  Mule in Action source code
  • 118. Going further  Submit bug reports  Improve the on­line documentation  Contribute transports, modules, examples  MuleForge  Blog about your Mule adventure  Let MuleSource know
  • 119. Books
  • 120. Thank you!  VIJUG  Manning Publications  VIJUG's sponsors  ... and you!
  • 121. Questions? david@muleinaction.com http://muleinaction.com http://dossot.net
