NOSQL, NO? Introductory presentation
RELATIONAL SQL                            ACID Relational algebra             Optimal for ad-hoc queries Tables, Colu...
POPULAR RDBMS MySQL                  Informix SQL Server             Progress Oracle                 Pervasive Post...
SQL Unified language to create and query both data and metadata Similar to English Verbose(!) Can get complex for non-...
SQL EXAMPLES If you can say what you mean, you can query the existing data Results are near-instant when querying based ...
SQL EXAMPLES Not so readable for non-trivial queriesselect "MP" tip_prometa, mprac.broj broj_racuna, mprac_stavke.kolicin...
RDBMS SCALING Vertical scaling     •   Better CPU, more CPUs     •   More RAM     •   More disks     •   SAN Partitionin...
PARTITIONING With many rows and heavy usage, partitioning is a must What to partition     • Tables     • Indexes     • V...
RDBMS SHARDING Sharding means using several databases where each represents partof data (500 clients on one server, anoth...
RDBMS METADATA Metadata: data describing other data RDBMS structures are explicitly defined, and each data type isoptimi...
NOSQL “Not SQL”, “Not only SQL” Core NoSQL databases invented mostly because RDBMS madelife very hard for huge and heavy...
NOSQL TYPES Wide Column Store / Column Families Document Store Key Value / Tuple Store Graph Databases Object Databas...
4 MAIN DATA MODELS Key-Value Stores BigTable Clones (aka "ColumnFamily") Document Databases Graph DatabasesSource: htt...
KEY/VALUE STORES Lineage: Amazons Dynamo paper and Distributed HashTables. Data model: A global collection of key-value ...
BIGTABLE CLONES Lineage: Googles BigTable paper. Data model: Column family, i.e. a tabular model where each row atleast ...
DOCUMENT DATABASES Lineage: Inspired by Lotus Notes. Data model: Collections of documents, which contain key-valuecollec...
GRAPH DATABASES Lineage: Draws from Euler and graph theory. Data model: Nodes & relationships, both which can hold key-v...
POPULAR NOSQL Hadoop / Hbase     MemcacheDB Cassandra          Voldemort Amazon SimpleDB    Hypertable MongoDB     ...
NOSQL CHARACTERISTICTS Almost infinite horizontal scaling Very fast Performance doesn’t deteriorate with growth (much)...
REAL-WORLD USE Cassandra      •   Facebook (original developer, used it till late 2010)      •   Twitter      •   Digg   ...
WHY NOSQL? Handles huge databases (I know, I said it before) Redundancy, data is pretty safe on commodity hardware Supe...
PERFORMANCE RDBMS uses buffer to ensure ACID properties NoSQL does not guarantee ACID and is therefore much faster We d...
SCALING Simple web application with not much traffic     • Application server, database server all on one machine
SCALING More traffic comes in     • Application server     • Database server
SCALING Even more traffic comes in     • Load balancer     • Application server x2     • Database server
SCALING Even more traffic comes in     • Load balancer x N         • easy     • Application server x N         • easy    ...
SQL SLOWDOWN Not linear! http://www.slideshare.net/rightscale/scaling-sql-and-nosql-databases-in-the-cloud
NOSQL SCALING Need more storage?     • Add more servers! Need higher performance?     • Add more servers! Need better r...
SCALING SUMMARY You can scale SQL databases (Oracle, MySQL, SQL Server…)     • This will cost you dearly     • If you don...
RAM Why map/reduce? I just need some simple queries. Tomorrow Iwill need some other queries…. SQL databases are optimize...
WORKING SET In real-world use working set is much less than complete database     • For analytics 99% of queries will be ...
WORKING SET WOES Foursquare has millions of users and working set the same as the database They used a single 66GB Amazo...
MAP/REDUCE Google’s framework for processing highly distributableproblems across huge datasets using a large number ofcom...
MAP/REDUCE Process split into two phases     • Map          • Take the input, partition it delegate to other machines    ...
MAP/REDUCE EXAMPLE You need to write two functions Count different words in a set of documents
MONGODB Document store Basic support for dynamic (ad hoc) queries Query by example (nice!)
MONGODB Conditional Operators     • <, <=, >, >=     • $all, $exists, $mod, $ne, $in, $nin, $nor, $or, $and, $size, $type...
MONGODB    Data is stored as BSON (binary JSON)         •    Makes it very well suited for languages with native JSON sup...
CASSANDRA Written in: Java Protocol: Custom, binary (Thrift) Tunable trade-offs for distribution and replication (N, R,...
HBASE     Written in: Java     Main point: Billions of rows X millions of columns     Modeled after BigTable     Map/r...
REDIS   Written in: C/C++   Main point: Blazing fast   Disk-backed in-memory database,   Master-slave replication   S...
COUCHDB    Written in: Erlang    Main point: DB consistency, ease of use    Bi-directional (!) replication, continuous ...
HADOOP Apache project A framework that allows for the distributed processing of largedata sets across clusters of comput...
HADOOP   Created by Doug Cutting, who named it after his sons toy elephant   Hadoop subprojects        •    Cassandra   ...
HADOOP See http://www.slideshare.net/hadoop/practical-problem-solving-with-apache-hadoop-pig Uses Java, but allows strea...
HADOOP Uses distributed file system (HDFS)     • Designed to hold very large amounts of data (terabytes or even       pet...
HIVE A petabyte-scale data warehouse system for Hadoop Easy data summarization, ad-hoc queries Query the data using a S...
PIG Platform for analyzing large data sets High-level language for expressing data analysis programs Compiler produces ...
PIG LATIN Pig Latin – high level Map/Reduce programming Equivalent to SQL for RDBMS systems. Pig Latin can be extended ...
MY MONGODB
MY MONGODB
SUMMARY NoSQL is a great problem solver if you need it Choose your NoSQL platform carefully as each is designed forspeci...
