dbi servicesCloud Control 12c                           Pierre Sicot                           Senior Consultant          ...
Cloud Control 12cAgenda                  Agenda                  i.       Introduction                  ii.      Installat...
Cloud Control 12cIntroduction Grid Control became Cloud Control (by the way, beta releases  were named Grid Control 12g)...
Cloud Control 12cInterface presentation Cloud Control 12c demo     Environment         Oracle Cloud Control 12c        ...
dbi servicesAgenda                  Agenda                  i.       Introduction                  ii.      Installation  ...
Cloud Control 12cInstallation Globally the installation has become much easier All components are installed smoothly in ...
Cloud Control 12cInstallation Enterprise Manager 12c binaries are bigger than 11g version JDK, WebLogic and EM 12c are i...
Cloud Control 12cInstallation EM 12c needs more resources                             12c                     11g        ...
Cloud Control 12c   Installation        A lot of pre-requisites checks during installation                               ...
Cloud Control 12cInstallation summary Installation of Cloud Control 12c became much easier than Grid  Control 11g Weblog...
dbi servicesAgenda                   Agenda                   i.       Introduction                   ii.      Installatio...
Cloud Control 12cDeployment Several methods are available to deploy the agents       Setup discovery using IP scan (not...
Cloud Control 12cDeployment GUI Agent deployment methods13   www.dbi-services.com    26.04.2012 © dbi services
Cloud Control 12cDeployment GUI To deploy the agent on a target, we have first to discover a host  manually :14    www.db...
Cloud Control 12cDeployment GUI The deployment procedure uses named credentials Oracle uses /usr/local/bin/sudo, a symbo...
Cloud Control 12cDeployment GUI An older release of the agent cannot be present on the system,  you have to un-install or...
Cloud Control 12cDeployment GUI Remote prerequisites checks are performed:17   www.dbi-services.com                      ...
Cloud Control 12cDeployment GUI Finally the agent is configured on the target host:18    www.dbi-services.com            ...
Cloud Control 12cDeployment GUI Once the agent is installed on the future managed host we can  add non host targets:19   ...
Cloud Control 12cDeployment GUI The agent directory architecture is new :Agent 12c                             Agent11g<a...
Cloud Control 12cDeployment silent mode Silent mode is an alternative to add an agent using the add host  target wizard: ...
Cloud Control 12cDeployment RPM With Linux it is possible to use a RPM based installation Mandatory to have the /usr/lib...
Cloud Control 12cAgent 12c summary Deployment to multiple servers in single step     1. Remote prerequisite checks     2....
Cloud Control 12cAgent 12c summary Consolidated summary of agent 12c from agent home page     1. Performance, usage and r...
dbi servicesAgenda                   Agenda                   i.       Introduction                   ii.      Installatio...
Cloud Control 12cGraphical User Interface New GUI (AJAX based, no more html based or JAVA based) New layout , based on (...
Cloud Control 12cGraphical User Interface Configurable layout (some pages) allowing to configure the  interface according...
Cloud Control 12cService Management Service Management Oriented features and layout (i.e. Incident  and problem managemen...
Cloud Control 12cTarget monitoring – Admin. Groups Administration Groups and Template Collections improve the  management...
Cloud Control 12cTarget monitoring – Templ. Collections Templates collections are composed of “monitoring templates” (of ...
Cloud Control 12cService Management integration Cloud Control 12c introduces some basics of the Service  Management requi...
Cloud Control 12cService Management integration Cloud Control 12c demo      Environment          Oracle Cloud Control 1...
Cloud Control 12cTop new features Brand new interface Monitoring/management of additional products (i.e. Exadata) Impro...
Cloud Control 12cTop new features Compare ADDM periods ASH analytics permits to dig more with better graphics New conce...
dbi servicesAgenda                   Agenda                   i.       Introduction                   ii.      Installatio...
Cloud Control 12cCore messages+    Cloud Control 12c is a real new milestone for the     Enterprise Manager product suite+...
Cloud Control 12cReferences Some very interesting References to get started with Cloud  Control 12c Basic Cloud Control ...
Cloud Control 12cAny Questions? Please Do Ask!      „Have fun with Cloud Control 12c!“38   www.dbi-services.com           ...
