Intro to OpenStack QuantumDan Wendlandt – Quantum Hacker & PTL          dan@nicira.com       twitter - danwendlandt
Caveats• “Contents may shift in flight”   – Quantum is a young and rapidly evolving project. My     focus will be on big p...
Outline• Why Quantum?• What is Quantum?  – Basic Concepts & Demo  – High-level System Architecture• Current Project Status...
Why Quantum?
What is OpenStack?• Open Source Cloud Software…• A collection of “cloud services”• Each service includes:  – A tenant-faci...
In the beginning..*-as-a-Service Capability      OpenStack Service         Compute                       Nova             ...
Why Quantum?• Networking was sub-component of Nova• Two Key Problems:  #1: Limited technology “baked in” to design.  #2: N...
Problem #1: Technology Limitations• Cloud stresses networks like never before:   – High-density multi-tenancy, massive sca...
Why Quantum? Reason #1• New networking technologies are emerging to try and  tackle these challenges.   –   Software-defin...
Problem #2: No Tenant Control• Cloud tenants want to replicate rich  enterprise network topologies:   – Ability to create ...
Why Quantum? Reason #2• Base Quantum API lets tenants create multiple  private networks, control IP addressing on them.• Q...
All is Right with the World…*-as-a-Service Capability   OpenStack Service        Compute                     Nova         ...
Why Quantum? Questions?
What is Quantum?
Quantum Basics (by analogy to Nova)                                     Nova                            Quantum*-as-a-serv...
API Abstractions             VM1                VM2           virtual serverNova        10.0.0.2           10.0.0.3       ...
Quantum Rest API Abstraction Details• Virtual Networks:   – Equivalent to a “virtual VLAN”, a dedicated L2 segment.   – Ex...
Old Model: Static Nova Networking       TenantA-VM1    TenantB-VM1     TenantA-VM2   TenantA-VM3         88.0.0.2       88...
Quantum Model: Dynamic Network     Creation + Association                           TenantA-VM2           TenantA-VM3     ...
Demo!  What could possibly go wrong?Questions on Quantum Basics or Demo?
Quantum Architecture Basics• At no time during demo did tenant see the technology  used to implement L2 isolation (VLANs, ...
Plugin Architecture• Plugins perform two main tasks:  – Process API calls: store the results of all network    + port call...
Quantum Architecture (simple)API Clients                    Quantum Server                                                ...
Quantum Architecture (adv.)                                                                                     ExternalAP...
Current Project Status
Project Status: Essex Cycle•   Started at Diablo summit, “incubated” for Essex, “core” in Folsom.•   Available at: http://...
Project Status: Who should use Quantum?• “Early adopters” already putting Quantum into  trial & production OpenStack deplo...
Future Directions• More and more Plugins  – Already have a pipeline of additional plugins...• Merge with Melange IP Addres...
Play with Quantum•   New integrated with DevStack•   http://wiki.openstack.org/QuantumDevstack•   Use nova-manage to creat...
Frequently Asked Questions• Is OpenFlow required for Quantum  – A: Nope! OpenFlow is just one technology that    Quantum e...
Thanks! Questions / Comments?          Come join us:  http://wiki.openstack.org/Quantum     netstack@lists.launchpad.net  ...
Bonus Slides
Basic Quantum + Nova API FlowAPI Client                                      Quantum                           Nova Server...
Simple VLAN Plugin Example• Plugin assumes all VLANs are trunked to all  hypervisors (similar to nova-network)• When new q...
Example Quantum + Nova Architecture                                             Dashboard /                               ...
Common Question: Can I run multiple        plugins at once?•   A “plugin” is NOT a “driver” *•   A “plugin” is NOT a “driv...
A plugin is not a driver• A plugin registers to handle all Quantum API  calls in a “group” (e.g., all network/port calls)....
Why separate plugins + drivers?• Plugins may make decisions that are technology,  but not device-specific (e.g., mapping q...
