How to build Kick Ass Games in the Cloud How to build Kick Ass Games in the Cloud Presentation Transcript

  • Christian SchalkGoogle Developer AdvocateWith special guest speaker, Proppy! How to Build Kick Ass Games in the Cloud
  • About the Speaker Christian Schalk Day Job ● Developer Advocate for Googles Cloud Technology ○ App Engine, Google Storage, Prediction API, BigQuery ... ● Mostly Server-Side Java Background ○ "JavaServer Faces: The Complete Reference" Co-Author ● Havent developed video games since the Commodore-64! Yes, Im old school ;-)
  • Agenda ● PlayN Technology ● Hands on with PlayN ○ Getting Started ○ Building a game from scratch w/ Proppy ● Deploying your game to the cloud ● Setting up an RPC mechanism ● Integrating w/ Google Plus ● Summary
  • First, Some Questions... ● Thinking of building a game for the Web? ? ○ Would you use Flash? ○ or HTML5? ● What if you wanted to port your game to Mobile? ○ Do you need an entirely separate code base?
  • First, Some Questions... ● Thinking of building a game for the Web? ? ○ Would you use Flash? ○ or HTML5? ○ Answer: Doesnt Matter!! Can do both! ● What if you wanted to port your game to Mobile? ○ Do you need an entirely separate code base? ○ Answer: NO!
  • First, Some Questions... ● Thinking of building a game for the Web? ? ○ Would you use Flash? ○ or HTML5? ○ Answer: Doesnt Matter!! Can do both! ● What if you wanted to port your game to Mobile? ○ Do you need an entirely separate code base? ○ Answer: NO! How is this Possible!??
  • Introducing PlayN!! One Game. Many Platforms.Formerly known as "ForPlay"
  • What is PlayN? ● An open source technology for building cross-platform games ● Core game code is platform agnostic ● Develop games in Java ○ Familiar language/toolset ● Leverages Google Web Toolkit ○ Compiles to JS/HTML5, (among other platforms) ● Free and Open Source (alpha) ○ http://code.google.com/p/playn
  • PlayN API Structure PlayN API Flash impl.Implementations for Java, HTML5(GWT/JS), Android, Flash
  • Components of PlayNExtend PlayN.Game PlayN.*Fully generic gaming components. Core game logic is fully platformindependent!
  • PlayN Cross Platform Magic● Game uses core PlayN abstractions, is unaware of which platform is running● The only platform-specific code is in the entry point for each platform: PlayN.run(new MyGame()); PlayN.run(new MyGame());
  • Other PlayN Benefits● Built-in physics engine based on proven OpenSource technologies ● Box2D ○ C++ 2D Physics engine by Erin Catto ● JBox2D ○ A port of Box2D from C++ to Java ● GWTBox2D ○ A port of JBox2D from Java to JavaScript
  • Benefits of GWT Abstraction● GWT Compiler optimizes code for size ○ Removes unused code ○ Evaluates when possible at compile time ○ Heavily obfuscated result code● Smaller compiled code - faster load time● Optimized caching, avoids unnecessary network IO
  • The PlayN Game LoopSimilar to other gaming platforms public class MyGame implements Game { public void init() { // initialize game. } public void update(float delta) { // update world. } public void paint(float alpha) { // render world. } }
  • PlayN RenderingCan easily with different screen parameters // Resize to the available resolution on the current device. graphics().setSize( graphics().screenWidth(), graphics().screenHeight() ); // Keep the same aspect ratio. float sx = graphics().screenWidth() / (float) WIDTH; float sy = graphics().screenHeight() / (float) HEIGHT; // Fit to the available screen without stretching. graphics().rootLayer().setScale(Math.min(sx, sy));
  • PlayN Drawing API
  • PlayN Layer System
  • Layer Types● Layers have distinct sizes and transforms● Used to optimize
  • IO System: Platform Abstractions ● Pointer ○ Most general screen event ○ Works everywhere ● Mouse ○ Left, right, mid buttons & wheel ● Touch ○ Pressure, size, multitouch
  • IO System: Input Devices pointer().setListener(new Pointer.Adapter() { public void onPointerStart(Pointer.Event event) { // Handle mouse down event. } // ...Same pattern for onPointerEnd, onPointerDrag }); keyboard().setListener(new Keyboard.Adapter() { public void onKeyDown(Event event) { // Handle key down event. } // ... Same pattern for onKeyUp });
  • Asset Management public interface AssetManager { Image getImage(String path); Sound getSound(String path); void getText(String path, ResourceCallback callback); boolean isDone(); int getPendingRequestCount(); }
  • Agenda ● PlayN Technology ● Hands on with PlayN ○ Getting Started ○ Building a game from scratch w/ Proppy ● Deploying your game to the cloud ● Setting up an RPC mechanism ● Integrating w/ Google Plus ● Summary
  • Requirements for getting started with PlayN ● Core Requirements ○ Java 6 SDK ○ Apache Ant ○ Maven ○ App Engine SDK ○ Android SDK ● Requirements with Eclipse ○ Eclipse IDE Indigo 3.7 (Or earlier version w/ Maven) ○ Google Plugin for Eclipse ○ Android Plugin for Eclipse
  • Building/Installing PlayN ● PlayN 1.0 is now available in Maven Central! ○ Wiki will be updated soon, but can simply create a Maven project ● Or can clone a copy of PlayN ○ git clone https://code.google.com/p/playn ● Then... ○ cd playn (directory where your copy is location) ○ mvn install (or ant install) ● Running showcase sample app with Mvn ○ cd playn/sample/showcase/core ○ mvn compile exec:java ● Running showcase sample app with Ant ○ cd playn/sample/showcase ○ ant run-java
  • Demo: How to get started w/ PlayN http://code.google.com/p/playn
  • Building a new project in PlayN● From the command line: ○ mvn archetype:generate -DarchetypeGroupId=com.googlecode.playn -DarchetypeArtifactId=playn-archetype ○ ...● From Eclipse ○ Select File → New → Project..., then select Maven → Maven Project in the dialog that pops up, then click Next. ■ Click Next again unless you wish to specify a custom workspace location. ■ Check Include snapshot archetypes in the dialog and then double click on the playn-archetype in the list of archetypes ○ ...
  • Demo: Building a new Game in PlayN
  • Agenda ● PlayN Technology ● Hands on with PlayN ○ Getting Started ○ Building a game from scratch w/ Proppy ■ http://proppy-playn101.appspot.com/ ● Deploying your game to the cloud ● Setting up an RPC mechanism ● Integrating w/ Google Plus ● Summary
  • Agenda ● PlayN Technology ● Hands on with PlayN ○ Getting Started ○ Building a game from scratch w/ Proppy ● Deploying your game to the cloud ● Setting up an RPC mechanism ● Integrating w/ Google Plus ● Summary
  • Deploy your HTML project to the Cloud ● For Google App Engine Deployment, you can easily convert the project to an App Engine Project
  • Deploy your HTML project to the Cloud ● After converting your HTML project to an App Engine project you will have to do... ● Add a WEB-INF/lib/appengine-web.xml file ○ Note: Click Quick Fix in the Errors console of Eclipse ● Before deployment make sure your WEB-INF/lib has the necessary runtime App Engine jar files.
  • Agenda ● PlayN Technology ● Hands on with PlayN ○ Getting Started ○ Building a game from scratch w/ Proppy ● Deploying your game to the cloud ● Setting up an RPC mechanism ● Integrating w/ Google Plus ● Summary
  • Setting up an RPC mechanism ● Building your client code ○ You can use PlayNs Net().Post() call to send data to a server ● Building Your Server ○ PlayN comes with a preliminary Server example code that uses Jetty ■ Is not needed if deploying to App Engine ■ Instead, you can implement your own server by adding an HttpServlet to your project ■ Have it implement the doPost() method ■ Can map it to url: /rpc in web.xml
  • Setting up an RPC mechanism ● Example: A client method to persist a score private void postScore(String payload) { net().post("/rpc", payload, new Callback<String>() { @Override public void onSuccess(String response) { // TODO } @Override public void onFailure(Throwable error) { // TODO } });}
  • Setting up an RPC mechanism ● Example: Server method to persist score sent from clientprotected void doPost(HttpServletRequest req,HttpServletResponse resp) throws ServletException, IOException { String payload = readFully(req.getReader()); Json.Object data = json().parse(payload); String score = data.getString("score"); if (score != null){ persistScore(score, id); } }private void persistScore(String score) {...}
  • Agenda ● PlayN Technology ● Hands on with PlayN ○ Getting Started ○ Building a game from scratch w/ Proppy ● Deploying your game to the cloud ● Setting up an RPC mechanism ● Integrating w/ Google Plus ● Summary
  • Integrating your game with Google+ Visit http://developers.google.com/+ Download the Java Starter App
  • Integrating your game with GooglePlusSample Starter App contains... ● README.txt with steps on: ○ Visiting https://code.google.com/apis/console to enable Google Plus API access for your app ■ To generate your ■ oauth_client_id, ■ oauth_client_secret, ■ google_api_key ● Sample Java classes to redirect game users for OAuth authentication
  • Integrating your game with GooglePlusTo access GooglePlus profile data.. Person profile; try { profile = plus.people.get("me").execute(); } catch (HttpResponseException e) { log.severe(Util.extractError(e)); return; }
  • Integrating your game with GooglePlus Accessing GooglePlus profile data in a JSP page...<a href="<%= profile.getUrl() %>"> <img src="<%= profile.getImage().getUrl() %>?sz=100"/></a>Welcome, <%= profile.getDisplayName() %>
  • Demo: Introducing Cloud WarriorApp Engine Google Storage Game Assets (images/sounds) Game Scores Profile Data http://ae-cloudwarrior.appspot.com
  • PlayN Summary● Open source, cross-platform game abstraction layer ○ Core game logic is platform agnostic● ForPlay abstracts away the core components of a game ○ The game loop, I/O system, and asset management● Write in familiar Java, get performance on multiple platforms ○ Superior Java development/debug ○ GWT allows compilation to fast JavaScript/HTML5● Your assignment: ○ Install PlayN and build a game! ○ http://code.google.com/p/playn/
  • Announcing the New PlayN Developer Site! http://developers.google.com/playn/
  • Q&Aprofiles.google.com/proppyprofiles.google.com/cschalk
  • Thank You!
