Client-Side Performance Sucks Craig Walker, Chief Technology Officer And what you can do to make it suck less. www.xero.com

Your typical internal network:
Easier to control
Easier to predict
Knowledge of almost everything from LAN speed to operating system

There's a reason why the words “world” and “wide” are in the acronym Control and knowledge are limited to your own environment. Even how the packets fly around the internet is out of your control. www.xero.com

The HTTP Request Server Browser Receive Last Byte Send Last Byte Send Data Establish Connection Initial Connection Open Socket Initial HTTP Request First Byte Receive First Byte Send First Byte Content Download ISP Get IP DNS Lookup

5% Server side performance often not the problem with response time 95% Most of the response time is taken up here

25% 75%

Empty Cache Primed Cache

Focus on the front-end
75-95% of the end-user response time for Xero customers is spent on the front end
Much easier to optimise than server side performance
Greater potential for improvement – especially from an end-users point-of-view
Proven to work

Performance === Usability www.xero.com

The giants who’s shoulders I’m standing on
Yahoo! Exceptional Performance team
http://developer.yahoo.com/performance/
Steve Souders
Former Chief of Performance at Yahoo!
Now at Google
Creator of YSlow and the 14 Rules
Author of High Performance Web Sites
Stoyan Stefanov, Patrick Meenan, Julien Lecomte, Stuart Colville, Ed Eliot and many more …

Zip It!
Significantly reduces download size – 60-80% saving on text based content
90% of browsers support compression
Benefits ALL users
Zip everything you can
html (aspx), js, css, xml, txt, json (ashx, axd)
Benefits you too:
Reduces traffic costs
Doesn’t require code changes

Fly’s down Zipped

Reduce HTTP Requests
Less components means a faster page
Every request is an overhead
Combine scripts
Combine CSS
Combine images into CSS Sprites
Don’t rely on cache: 304’s are still requests

CSS Sprites
Combine all small images into one large image
Use CSS to control the displaying of each image

The designers want what? 11 Images 11 HTTP Requests 3.3 KB total size

Obey your thirst ® 1 Image 1 HTTP Request 1.6 KB total size

And the CSS? <div class="buttons"> <span class="large green button"> <button type="button"> <span class="checkbox icon"> Approve </span> </button> </span> <span class="large blue button"> <button type="button"> <span> Save </span> </button> </span> <span class="large red button"> <button type="button"> <span class="delete icon"> Delete </span> </button> </span> <span class="medium gray button"> <button type="button"> <span class="delete icon"> Cancel </span> </button> </span> </div>
.buttons span.button {
background:transparent url(buttons.png) no-repeat 0 0;
}
.buttons span.button button, .buttons span.button a {
background:transparent url(buttons.png) no-repeat 100% -120px;
}
.buttons span.blue {
background-position: 0 -30px;
}
.buttons span.blue button, .buttons span.blue a {
background-position: 100% -150px;
}
.buttons span.red {
}
.buttons span.red button, .buttons span.red a {
}
.buttons span.green {
}
.buttons span.green button, .buttons span.green a {
}
The HTML The CSS

Maximise Parallel Downloads
Most browsers are limited to 6 connections total and 2 connections per hostname
Increase the number of hostnames to increase the number of parallel downloads (e.g., go.xero.com, gos1.xero.com, gos2.xero.com)
Don’t overdo it! (DNS lookups are expensive so limit 2-4 domains)
Browser Parallel Downloads Firefox 2 2 Firefox 3 6 Internet Explorer 7 2 Internet Explorer 8 6 Safari 3.1 4 Safari 4.0 4

Maximise Parallel Downloads
Stepped download
(with 1 hostname)
Increased parallelism (using 2 hostnames)

Use a CDN
Content Delivery Network
Distributes content closer to the last mile
Distribute your static content before distributing your dynamic content
Akamai most popular but very expensive
Xero utilises a rudimentary CDN using IP lookup to determine location

How it works: Images JS CSS <xsl:value-of select="Page:RegisterCSS('/common/style/xero.css','screen')"/> <xsl:value-of select="Page:RegisterJavascript('/common/scripts/xero.js'"/> <link rel="stylesheet" type="text/css" media="screen" href="https://nzs1.xero.com/common/style/xero.css" /> <script type="text/javascript" src="https://nzs2.xero.com/common/scripts/xero.js"></script> GET Request Response with HTML document Get location from IP

Maximise the cache
Understand the ratio of cached vs uncached
Add an Expires header
Not just for images – should be used on all static content
Set a “Never expire” or far future expires policy if you can
Reduces HTTP requests – once component is served, the browser never asks for it again
Date stamping in file names makes it easier
Remove ETags
ETags are another caching mechanism – sent with every request
Uniquely created per web server – not good in web farms
Just turn them off and use Expires headers instead

CSS external and on top
Move all inline CSS to external style sheets for both reuse and caching
Put all style sheet references at the top
Firefox and IE will block rendering until all the CSS is downloaded
Use <link> and NOT @import
In IE @import is the same as putting <link> at the bottom

JavaScript external and on the bottom
Move scripts to external files for both reuse and caching
Promotes better script design
Push scripts as low as possible
Often difficult with document.write or with inline calls requiring loaded JavaScript
Be pragmatic – think about splitting JavaScript into “must be loaded” and “can be loaded on demand”
Scripts will block both downloading and rendering until parsed
Remove duplicate scripts (IE has a habit of downloading them again)

Notice the parallel download here … … until we hit the JavaScript files where they come down sequentially, blocking any other downloads

Minify all static content
CSS, JavaScript, XML, JSON, HTML can all be minified
Not a replacement for gzipping but is a perfect accompaniment to it
Lots of tools:
JSMin
CSSTidy
YUI Compressor
JavaScript obfuscation can also be useful – just test that your app still works afterwards

Optimise images
Use PNGs instead of GIFs
Avoid alpha filters – can block rendering and freeze the browser
PNG8 is best and supported by IE6 (yes – even with transparency)
Optimise further with PNGOUT or PNGCRUSH
Make sure you have a favicon.ico
Every browser will request it
Best not to respond with a 404
Make it small and cacheable

Preloading …
Preload components you’ll need in the future
Unconditional preload
Xero login page preloads all core components so that the dashboard experience is better
Conditional preload
Often based on where you think a user might go to next

Reduce cookie weight
Cookie’s are sent back with every request
Keep cookie size small and only store what’s required – use server-side storage for everything else
Consider cookie free domains for static content

Keep it clean
Choose a good Ajax library – don’t go writing this stuff yourself
Always asynchronous
Use JSON over XML
Accessing JSON faster and cheaper
Less overhead than XML
Use GET requests over POSTs wherever possible
POST is a 2-step process: send headers, send body
POST without a body is essentially a GET anyway
And make sure the response is zipped!

Things to take away
Focus on the front-end
Be an advocate for your users
Don’t let designers get in the way of performance
But they will so optimise, optimise, optimise!

YSlow
Firebug extension
Grades performance – not about response times but about how well a site has adopted the techniques suggested
Response time inversely proportional to YSlow score – get as close to an A as possible to get the maximum performance gain

Fiddler
Microsoft built HTTP debugging proxy
Inspect HTTP traffic, tamper with incoming and outgoing data and debug performance issues
Works with all browsers

AOL PageTest
Internal AOL utility gone public
Browser plug-in for Internet Explorer
Visually displays underlying requests and provides suggestions on how to improve your response times
Also available as an external web-based tester at www.webpagetest.org

Any questions? www.xero.com
