SuRF – Tapping into the Web of Data<br />Cosmin Basca<br />Digital Enterprise Research Institute, Galway<br />cosmin.basca...
Outline<br />About DERI<br />Why Semantic Web?<br />Linked Open Data (LOD)<br />RDF (Resource Description Framework)<br />...
DERI – http://www.deri.ie/<br />Digital Enterprise Research Institute (DERI): <br />http://www.deri.ie/<br />main goal: en...
Outline<br />About DERI<br />Why Semantic Web?<br />Linked Open Data (LOD)<br />RDF (Resource Description Framework)<br />...
Why ?<br />Develop Web applications that allow <br />Data Integration<br />Flexibility<br />Schema definition and modeling...
There is a Wealth of (RDF) data out there<br />6<br />
Popular Semantic Web Vocabularies<br />FOAF = for describing people and social network connections between them   http://x...
Linked Open Data - Growth<br />8<br />
Linked Open Data - Growth<br />9<br />
Linked Open Data - Growth<br />10<br />
The data model<br />Traditional Approach use the Relational model<br />Usually leads to big ugly Schemas<br />11<br />
The RDF (Graph) Data model<br />Flexible<br />Support for both schema and data evolution during runtime<br />Simple model<...
The RDF (Graph) Data model<br />13<br />Subject<br />Object<br />Predicate<br />A triple<br />is a <br />Eric<br />Person<...
Example RDF graph describing Eric Miller (RDF Primer) – human readable format<br />14<br />Person<br />is a <br />Eric<br ...
Example RDF graph describing Eric Miller (RDF Primer) – machine readable format<br />15<br />http://w3.org/2000/10/swap/pi...
The RDF (Graph) Data model – Identification <br />URI’s provide strong references<br />The URIref is a an unambiguous poin...
SPARQL – Querying the Semantic Web<br />SPARQL is to RDF what SQL is to Relational tables<br />Expressive, designed with t...
Levels of Data abstraction<br />18<br />Direct SPARQL<br />Access<br />O-RDF Mapper <br />SuRF<br />
O-RDF Mapper, Why?<br />Clean OO design<br />Increased productivity<br />model is free from persistence constraints<br />S...
O-RDF Mapper, How?<br />How do we see RDF data?<br />As a SET of triples?<br />As a SET of resources?<br />The resource vi...
Outline<br />About DERI<br />Why Semantic Web?<br />Linked Open Data (LOD)<br />RDF (Resource Description Framework)<br />...
SuRF – Semantic Resource Framework<br />Inspired by ActiveRDF<br />Developed in DERI for ruby<br />Expose RDF as sets of r...
SuRF – Architecture<br />23<br />
SuRF – Architecture – Currently supported plugins<br />24<br />Add your own plugins, extend:<br />surf.store.plugins.RDFRe...
SuRF - installation<br />Available on PyPi<br />easy_install –U surf (to get the latest)<br />Open-source available on Goo...
Outline<br />About DERI<br />Why Semantic Web?<br />Linked Open Data (LOD)<br />RDF (Resource Description Framework)<br />...
DBpedia public SPARQL endpoint - read-only<br />Create the store proxy<br />from surf import*<br />	store = Store(reader=&...
SuRF – simple example<br />DBpedia public SPARQL endpoint - read-only<br />Get all Phill Collins albums<br />all_albums=Ph...
Outline<br />About DERI<br />Why Semantic Web?<br />Linked Open Data (LOD)<br />RDF (Resource Description Framework)<br />...
SuRF – integrate into Pylons<br />Create a blog on top of an RDF database<br />Replace SQLAlchemy with SuRF<br />Download ...
SuRF – Pylons Blog <br />~/MyBlog/development.ini: In the [app:main] section add<br />rdf_store = localhost<br />rdf_store...
SuRF – Pylons Blog <br />~/MyBlog/myblog/model/__ init __.py<br />from surf import *	<br />definit_model(session):<br />		...
SuRF – Pylons Blog <br />Create the template mkdir ~/MyBlog/myblog/templates/blog<br />~/MyBlog/myblog/templates/blog/inde...
SuRF – Tapping into the Web of Data<br />Can tap into the web of Data<br />SPARQL endpoints<br />Local or remote RDF Store...
exit()<br />cosmin.basca@deri.prg<br />http://code.google.com/p/surfrdf/<br />easy_install –U surf<br />35<br />
