  • 1. Diagnosing and RepairingData Anomalies in Process ModelsAhmed AwadHassoPlattner Institute, Potsdam, GermanyGero Decker HassoPlattner Institute, Potsdam, GermanyNielsLohmann University of Rostock, Germany
  • 2. Correctness of Process Models
    widely accepted: soundness
    no deadlocks
    no livelocks
    proper termination
    no dead activities
    These are control flow aspects!
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 3. Example Process: Insurance Claim Handling
    sound: every claim will eventually be closed
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 4. Data in BPMN
    Data objects
    Data states (no explosion)
    Object life cycles /control flow refinement
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 5. Process Model with Data
    This model contains five deadlocks!
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 6. Classes of Errors
    too restrictive preconditions (close and fraudulent claims)
    implicit routing (XOR vs. fraud evaluation)
    implicit execution order (pay vs. file)
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 7. Outline
    control flow + data flow = interesting problems ✔
    formalization BPMN’s data aspects
    detection, diagnosing, and repairing of data anomalies
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 8. 2
    FormalizationBPMN’s dataaspects
  • 9. BPMN and Petri nets
    BPMN:
    a graphical notion
    support of concurrency
    Petri nets:
    a graphical notion
    support of concurrency
    formal foundation
    broad tool support
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
    Dijkman et al. definePetri net semanticsfor BPMN’s control flow
  • 10. Petri net formalization (control flow)
    pattern-based translation
    complete example (control flow):
    analysis tools can check soundness
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 11. BPMN and Petri nets (2)
    BPMN:
    a graphical notion
    support of concurrency
    several aspects in one model
    Petri nets:
    a graphical notion
    support of concurrency
    formal foundation
    broad tool support
    simple composition notions
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 12. Formalization of BPMN’s data objects
    changing a state
    reading a state
    changing to several possible states
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 13. Data flow models
    data flow models for settlement and claim data object
    control flow model
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 14. Bringing it all together
    synchronization of data flow and control flow by transition fusion
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 15. 3
    Detection,diagnosing,and repair ofdata anomalies
  • 16. Detection of data anomalies
    standard soundness checker (Woflan, LoLA) will find deadlocks
    provides counterexample (= trace)
    does not differentiate data flow and control flow
    gives no diagnosis/repair information
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 17. Diagnosis data anomalies
    exploit information on model:
    control flow is sound
    place models either control flow or data flow
    each data object can only be in one state
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 18. Diagnosing and fixing too restrictive preconditions
    Problem: if data is set to [a], activity B is disabled
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 19. Diagnosing and fixing too restrictive preconditions
    control flow is sound
    deadlock in composite model: missing data tokens
    for each deadlock:
    determine missing data tokens
    change model
    data tokens are present, or
    drop data dependency
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 20. Diagnosing and fixing implicit routing
    decision [b] vs. [c] has to be synchronized with XOR-split
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 21. Diagnosing and fixing implicit routing
    partition state space with respect to data states
    if a decision inside a partition leads to a deadlock, this decision is “unsynchronized”
    synchronize decisions according to data
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 22. Diagnosing and fixing implicit execution order
    transitions A and B are in concurrent the control flow model,but share data place
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 23. Take home points
    data objects can introduce errors to a model
    Petri nets allow for compositional models of data and control flow
    data anomalies can be detected, diagnosed,and (sometimes) automatically fixed
    Future work:
    automated mapping back to the BPMN model
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09
  • 24. Final slide
    Thank you for your attention!
    Your todos:
    discuss with me
    talk to Ahmed and Gero
    attend the soundness talk(Thursday, after the keynote)
    get the slides athttp://slideshare.net/correctsystems
    Diagnosing and Repairing Data Anomalies in Process Models
    07.09.09

×
