  • 1. BPEL Analyzing BPEL4Chor - Verification and Partner Synthesis   designed to describe a service orchestration   … respectively a single service   invoked services’ behaviors are not described   BPEL processes can be automatically analyzed (BPM 2006; project Tools4BPEL) 2
  • 2. BPEL4Chor Analyzing BPEL4Chor - Verification and Partner Synthesis   extension to describe choreographies behaviors topology grounding 3
  • 3. An Example Choreography Analyzing BPEL4Chor - Verification and Partner Synthesis   taken from the paper introducing BPEL4Chor   one traveler, one agency, several airline instances 4
  • 4. Analyzing BPEL4Chor - Verification and Partner Synthesis 5
  • 5. Analyzing BPEL4Chor Choreographies Analyzing BPEL4Chor - Verification and Partner Synthesis   “Classical” properties:   deadlock-freedom, livelock-freedom, no dead activities (a.k.a. Soundness)   Messages:   Does there exist a state in which more than one message is pending on a communication channel?   What is the minimal/maximal number of messages to be sent to reach a final state?   Behavior:   Will a participant always receive an answer?   Can a participant enforce the execution of an activity? 6
  • 6. Translating BPEL4Chor into a Petri Net Analyzing BPEL4Chor - Verification and Partner Synthesis   Extend compiler BPEL2oWFN BPEL2oWFN Static Analysis BPEL processes Translation Instantiation Composition Structural Reduction Petri net topology   BPEL4Chor requires instantiation and composition 7
  • 7. Instantiation Analyzing BPEL4Chor - Verification and Partner Synthesis …   example for two airline instances t1 … trip <receive  wsu:id="ReceiveTripOrder"  /> price.1 <forEach  wsu:id="fe_RequestPrice„   t2 t3 price.2                  parallel="yes">    <scope> quote.1        <sequence>            <invoke  wsu:id="RequestPrice"  /> t4 t5 quote.2            <receive  wsu:id="ReceiveQuote"  />        </sequence>    </scope> t6 </forEach> order.1 <opaqueActivity  name="SelectAirline"  /> <invoke  wsu:id="OrderTickets"  /> t7 t8 order.2 … … 8
  • 8. Composition Analyzing BPEL4Chor - Verification and Partner Synthesis   each service is translated into an open workflow net with an interface   open workflow nets can be composed   resulting net has no interface (standard Petri net) 9
  • 9. Analysis Result Analyzing BPEL4Chor - Verification and Partner Synthesis   Choreography can deadlock!   each participant is correct (controllable, sound…)   deadlock very subtle! 10
  • 10. Case Study airline instances Analyzing BPEL4Chor - Verification and Partner Synthesis 1 5 10 100 1000 places 20 63 113 1013 10013 transitions 10 41 76 706 7006 states  14 3483 9806583   exponential states  14 561 378096 growth  states  11 86 261 18061 1752867 states  11 30 50 410 4010  complete/unreduced linear  symmetry reduction growth   partial order reduction  symmetry reduction and partial order reduction  out of memory (>2 GB) 11
  • 11. Analyzing BPEL4Chor - Verification and Partner Synthesis 12
  • 12. Partner Synthesis Analyzing BPEL4Chor - Verification and Partner Synthesis   new setting: design phase of choreography   one participant description is missing   goal: synthesize missing participant description 13
  • 13. Translation Analyzing BPEL4Chor - Verification and Partner Synthesis   incomplete choreography is translated with BPEL2oWFN   translationyields an open workflow net with interface to missing participant 14
  • 14. Partner Synthesis (1) Analyzing BPEL4Chor - Verification and Partner Synthesis Fiona Partner synthesis open workflow net open workflow net (incomplete choreography) (synthesized participant)   Fiona can synthesize a partner if one exists   partner is correct by design   partner’s behavior is based on communication   no internal behavior is synthesized   order of messages is as relaxed as possible 15
  • 15. Partner Synthesis (2) Analyzing BPEL4Chor - Verification and Partner Synthesis oWFN2BPEL Retranslation open workflow net abstract BPEL process (synthesized participant) (synthesized participant)   partner’s behavior can be described using BPEL   derived BPEL process is abstract   has to be refined to an executable process 16
  • 16. Limits of the Partner Synthesis Analyzing BPEL4Chor - Verification and Partner Synthesis   can only synthesize one partner:   If more than one airline instance is synthesized, the generated partners explicitly synchronize.   airline instances would communicate timeouts: one instance would be forced to wait for a message   can be a starting point for diagnosis   causalitiesof messages might be ignored   order and invoice messages might be concurrent   can be fixed using constraints 17
  • 17. Take-home Points Analyzing BPEL4Chor - Verification and Partner Synthesis   BPEL4Chor choreographies can be analyzed   … to find very subtle errors   … even with thousands of participants   … automatically using the proposed tool chain   BPEL4Chor choreographies can be completed   … by synthesizing the missing participant   … to guarantee a deadlock-free choreography   ... automatically using the proposed tool chain Thank you very much! 18
