Hadoop Summit 2012 | Optimizing MapReduce Job Performance

  • 27,898 views
Uploaded on

Optimizing MapReduce job performance is often seen as something of a black art. In order to maximize performance, developers need to understand the inner workings of the MapReduce execution framework …

Optimizing MapReduce job performance is often seen as something of a black art. In order to maximize performance, developers need to understand the inner workings of the MapReduce execution framework and how they are affected by various configuration parameters and MR design patterns. The talk will illustrate the underlying mechanics of job and task execution, including the map side sort/spill, the shuffle, and the reduce side merge, and then explain how different job configuration parameters and job design strategies affect the performance of these operations. Though the talk will cover internals, it will also provide practical tips, guidelines, and rules of thumb for better job performance. The talk is primarily targeted towards developers directly using the MapReduce API, though will also include some tips for users of higher level frameworks.

More in: Technology , Business
  • Full Name Full Name Comment goes here.
    Are you sure you want to
    Your message goes here
No Downloads

Views

Total Views
27,898
On Slideshare
0
From Embeds
0
Number of Embeds
18

Actions

Shares
Downloads
0
Comments
6
Likes
124

Embeds 0

No embeds

Report content

Flagged as inappropriate Flag as inappropriate
Flag as inappropriate

Select your reason for flagging this presentation as inappropriate.

Cancel
    No notes for slide

Transcript

  • 1. June 14, 2012Optimizing MapReduce JobPerformanceTodd Lipcon [@tlipcon]
  • 2. Introductions • Software Engineer at Cloudera since 2009 • Committer and PMC member on HDFS, MapReduce, and HBase • Spend lots of time looking at full stack performance • This talk is to help you develop faster jobs – If you want to hear about how we made Hadoop faster, see my Hadoop World 2011 talk on cloudera.com2 ©2011 Cloudera, Inc. All Rights Reserved.
  • 3. Aspects of Performance • Algorithmic performance – big-O, join strategies, data structures, asymptotes • Physical performance – Hardware (disks, CPUs, etc) • Implementation performance – Efficiency of code, avoiding extra work – Make good use of available physical perf3 ©2011 Cloudera, Inc. All Rights Reserved.
  • 4. Performance fundamentals • You can’t tune what you don’t understand – MR’s strength as a framework is its black-box nature – To get optimal performance, you have to understand the internals • This presentation: understanding the black box4 ©2011 Cloudera, Inc. All Rights Reserved.
  • 5. Performance fundamentals (2) • You can’t improve what you can’t measure – Ganglia/Cacti/Cloudera Manager/etc a must – Top 4 metrics: CPU, Memory, Disk, Network – MR job metrics: slot-seconds, CPU-seconds, task wall-clocks, and I/O • Before you start: run jobs, gather data5 ©2011 Cloudera, Inc. All Rights Reserved.
  • 6. Graphing bottlenecks This job might be CPU-bound in map phase Most jobs not CPU-bound Plenty of free RAM, perhaps can make better use of it? Fairly flat-topped network – bottleneck?6 ©2011 Cloudera, Inc. All Rights Reserved.
  • 7. Performance tuning cycle Identify Address Run job bottleneck bottleneck -Graphs - Tune configs -Job counters - Improve code -Job logs - Rethink algos -Profiler results In order to understand these metrics and make changes, you need to understand MR internals.7 ©2011 Cloudera, Inc. All Rights Reserved.
  • 8. MR from 10,000 feet InputFormat Map Sort/ Fetch Merge Reduce OutputFormat Task Spill Task8 ©2011 Cloudera, Inc. All Rights Reserved.
  • 9. MR from 10,000 feet InputFormat Map Sort/ Fetch Merge Reduce OutputFormat Task Spill Task9 ©2011 Cloudera, Inc. All Rights Reserved.
  • 10. Map-side sort/spill overview • Goal: when complete, map task outputs one sorted file • What happens when you call OutputCollector.collect()? Map Task 2. Output Buffer fills up. Contents sorted, partitioned .collect(K,V) and spilled to diskMapOutputBuffer IFile1. In-memory bufferholds serialized, Map-side IFile IFileunsorted key-values Merge 3. Map task finishes. All IFile IFiles merged to single IFile per task10 ©2011 Cloudera, Inc. All Rights Reserved.
  • 11. Zooming further: MapOutputBuffer (Hadoop 1.0) 12 bytes/rec kvoffsets (Partition, KOff, VOff) per record io.sort.record.percent * io.sort.mb kvindices 4 bytes/rec 1 indirect-sort indexio.sort.mb per record kvbuffer R bytes/rec Raw, serialized (1-io.sort.record.percent) (Key, Val) pairs * io.sort.mb 11 ©2011 Cloudera, Inc. All Rights Reserved.
  • 12. MapOutputBuffer spill behavior • Memory is limited: must spill – If either of the kvbuffer or the metadata buffers fill up, “spill” to disk – In fact, we spill before it’s full (in another thread): configure io.sort.spill.percent • Performance impact – If we spill more than one time, we must re- read and re-write all data: 3x the IO! – #1 goal for map task optimization: spill once!12 ©2011 Cloudera, Inc. All Rights Reserved.
  • 13. Spill counters on map tasks • ratio of Spilled Records vs Map Output Records – if unequal, then you are doing more than one spill • FILE: Number of bytes read/written – get a sense of I/O amplification due to spilling13 ©2011 Cloudera, Inc. All Rights Reserved.
  • 14. Spill logs on map tasks indicates that the metadata buffers 2012-06-04 11:52:21,445 INFO before the data buffer map output: filled up MapTask: Spilling record full = true 2012-06-04 11:52:21,445 INFO MapTask: bufstart = 0; bufend = 60030900; bufvoid = 228117712 2012-06-04 11:52:21,445 INFO MapTask: kvstart = 0; kvend = 600309; length = 750387 2012-06-04 11:52:24,320 INFO MapTask: Finished spill 0 2012-06-04 11:52:26,117 INFO MapTask: Spilling map output: record full = true 2012-06-04 11:52:26,118 INFO MapTask: bufstart = 60030900; bufend = 120061700; bufvoid = 228117712 2012-06-04 11:52:26,118 INFO MapTask: kvstart = 600309; kvend = 450230; length = 750387 2012-06-04 11:52:26,666 INFO MapTask: Starting flush of map output 2012-06-04 11:52:28,272 INFO MapTask: Finished spill 1 2012-06-04 spills total! maybeINFO MapTask: Finished spill 2 3 11:52:29,105 we can do better?14 ©2011 Cloudera, Inc. All Rights Reserved.
  • 15. Tuning to reduce spills • Parameters: – io.sort.mb: total buffer space – io.sort.record.percent: proportion between metadata buffers and key/value data – io.sort.spill.percent: threshold at which spill is triggered – Total map output generated: can you use more compact serialization? • Optimal settings depend on your data and available RAM!15 ©2011 Cloudera, Inc. All Rights Reserved.
  • 16. Setting io.sort.record.percent • Common mistake: metadata buffers fill up way before kvdata buffer • Optimal setting: – io.sort.record.percent = 16/(16 + R) – R = average record size: divide “Map Output Bytes” counter by “Map Output Records” counter • Default (0.05) is usually too low (optimal for ~300byte records) • Hadoop 2.0: this is no longer necessary! – see MAPREDUCE-64 for gory details16 ©2011 Cloudera, Inc. All Rights Reserved.
  • 17. Tuning Example (terasort) • Map input size = output size – 128MB block = 1,342,177 records, each 100 bytes – metadata: 16 * 1342177 = 20.9MB • io.sort.mb – 128MB data + 20.9MB meta = 148.9MB • io.sort.record.percent – 16/(16+100)=0.138 • io.sort.spill.percent = 1.017 ©2011 Cloudera, Inc. All Rights Reserved.
  • 18. More tips on spill tuning • Biggest win is going from 2 spills to 1 spill – 3 spills is approximately the same speed as 2 spills (same IO amplificatoin) • Calculate if it’s even possible, given your heap size – io.sort.mb has to fit within your Java heap (plus whatever RAM your Mapper needs, plus ~30% for overhead) • Only bother if this is the bottleneck! – Look at map task logs: if the merge step at the end is taking a fraction of a second, not worth it! – Typically most impact on jobs with big shuffle (sort/dedup)18 ©2011 Cloudera, Inc. All Rights Reserved.
  • 19. MR from 10,000 feet InputFormat Map Sort/ Fetch Merge Reduce OutputFormat Task Spill Task19 ©2011 Cloudera, Inc. All Rights Reserved.
  • 20. Reducer fetch tuning • Reducers fetch map output via HTTP • Tuning parameters: – Server side: tasktracker.http.threads – Client side: mapred.reduce.parallel.copies • Turns out this is not so interesting – follow the best practices from Hadoop: Definitive Guide20 ©2011 Cloudera, Inc. All Rights Reserved.
  • 21. Improving fetch bottlenecks • Reduce intermediate data – Implement a Combiner: less data transfers faster – Enable intermediate compression: Snappy is easy to enable; trades off some CPU for less IO/network • Double-check for network issues – Frame errors, NICs auto-negotiated to 100mbit, etc: one or two slow hosts can bottleneck a job – Tell-tale sign: all maps are done, and reducers sit in fetch stage for many minutes (look at logs)21 ©2011 Cloudera, Inc. All Rights Reserved.
  • 22. MR from 10,000 feet InputFormat Map Sort/ Fetch Merge Reduce OutputFormat Task Spill Task22 ©2011 Cloudera, Inc. All Rights Reserved.
  • 23. Reducer merge (Hadoop 1.0) Yes: RAMManager fetch to RAM-to-disk RAM merges Remote Map Fits in Outputs RAM? (via HTTP) 1. Data accumulated in RAM is merged to No: fetch disk files to disk Local Disk IFile2. If too many disk disk-to-disk Mergedfiles accumulate, IFile merges iteratorthey are re-merged IFile Reduce Task 3. Segments from RAM and disk are23 merged into the reducer code ©2011 Cloudera, Inc. All Rights Reserved.
  • 24. Reducer merge triggers • RAMManager – Total buffer size: mapred.job.shuffle.input.buffer.percent (default 0.70, percentage of reducer heapsize) • Mem-to-disk merge triggers: – RAMManager is mapred.job.shuffle.merge.percent % full (default 0.66) – Or mapred.inmem.merge.threshold segments accumulated (default 1000) • Disk-to-disk merge – io.sort.factor on-disk segments pile up (fairly rare)24 ©2011 Cloudera, Inc. All Rights Reserved.
  • 25. Final merge phase • MR assumes that reducer code needs the full heap worth of RAM – Spills all in-RAM segments before running user code to free memory • This isn’t true if your reducer is simple – eg sort, simple aggregation, etc with no state • Configure mapred.job.reduce.input.buffer.percent to 0.70 to keep reducer input data in RAM25 ©2011 Cloudera, Inc. All Rights Reserved.
  • 26. Reducer merge counters • FILE: number of bytes read/written – Ideally close to 0 if you can fit in RAM • Spilled records: – Ideally close to 0. If significantly more than reduce input records, job is hitting a multi- pass merge which is quite expensive26 ©2011 Cloudera, Inc. All Rights Reserved.
  • 27. Tuning reducer merge • Configure mapred.job.reduce.input.buffer.percent to 0.70 to keep data in RAM if you don’t have any state in reducer • Experiment with setting mapred.inmem.merge.threshold to 0 to avoid spills • Hadoop 2.0: experiment with mapreduce.reduce.merge.memtomem.enabled27 ©2011 Cloudera, Inc. All Rights Reserved.
  • 28. Rules of thumb for # maps/reduces • Aim for map tasks running 1-3 minutes each – Too small: wasted startup overhead, less efficient shuffle – Too big: not enough parallelism, harder to share cluster • Reduce task count: – Large reduce phase: base on cluster slot count (a few GB per reducer) – Small reduce phase: fewer reducers will result in more efficient shuffle phase28 ©2011 Cloudera, Inc. All Rights Reserved.
  • 29. MR from 10,000 feet InputFormat Map Sort/ Fetch Merge Reduce OutputFormat Task Spill Task29 ©2011 Cloudera, Inc. All Rights Reserved.
  • 30. Tuning Java code for MR • Follow general Java best practices – String parsing and formatting is slow – Guard debug statements with isDebugEnabled() – StringBuffer.append vs repeated string concatenation • For CPU-intensive jobs, make a test harness/benchmark outside MR – Then use your favorite profiler • Check for GC overhead: -XX:+PrintGCDetails – verbose:gc • Easiest profiler: add –Xprof to mapred.child.java.opts – then look at stdout task log30 ©2011 Cloudera, Inc. All Rights Reserved.
  • 31. Other tips for fast MR code • Use the most compact and efficient data formats – LongWritable is way faster than parsing text – BytesWritable instead of Text for SHA1 hashes/dedup – Avro/Thrift/Protobuf for complex data, not JSON! • Write a Combiner and RawComparator • Enable intermediate compression (Snappy/LZO)31 ©2011 Cloudera, Inc. All Rights Reserved.
  • 32. Summary • Understanding MR internals helps understand configurations and tuning • Focus your tuning effort on things that are bottlenecks, following a scientific approach • Don’t forget that you can always just add nodes! – Spending 1 month of engineer time to make your job 20% faster is not worth it if you have a 10 node cluster! • We’re working on simplifying this where we can, but deep understanding will always allow more efficient jobs32 ©2011 Cloudera, Inc. All Rights Reserved.
  • 33. Questions? @tlipcontodd@cloudera.com
