    Hw09   Production Deep Dive With High Availability Hw09 Production Deep Dive With High Availability Presentation Transcript

    • Hadoop at ContextWeb Alex Dorman, VP Engineering Paul George, Sr. Systems Architect October 2009
    • ContextWeb: Traffic
      • ADSDAQ – Online Advertisement Exchange
      • Traffic –
        • up to 6,000 Ad requests per second.
        • 7bln Ad requests per month
        • 5,000+ Active Publisher and Advertiser accounts
      • Account reports are updated every 15 minutes
      • About 50 internal reports for business users updated nightly
    • ContextWeb Architecture highlights
      • Pre – Hadoop aggregation framework
        • Logs are generated on each server and aggregated in memory to 15 minute chunks
        • Aggregation of logs from different servers into one log
        • Load to DB
        • Multi-stage aggregation in DB
        • About 20 different jobs end-to-end
        • Could take 2hr to process through all stages
        • 200mln records was the limit
    • Hadoop Data Set
      • Up to 120GB of raw log files per day. 60GB compressed
      • 60 different aggregated data sets 25TB total to cover 1 year (compressed)
      • 50 different reports for Business and End Users
      • Major data sets are updated every 15 minutes
    • Hadoop Cluster
      • 40 nodes/320 Cores (DELL 2950)
      • 100TB total raw capacity
      • CentOS 5.3 x86_64
      • Hadoop 0.18.3-CH-0.2.1 (Cloudera), migrating to 0.20.x
      • NameNode high availability using DRBD Replication.
      • Log collection using custom scripts and Scribe
    • Hadoop Cluster
      • In-house developed Java framework on top of hadoop.mapred.*
      • PIG and Perl Streaming for ad-hoc reports
      • OpsWise scheduler
      • ~2000 MapReduce job executions per day
      • Exposing data to Windows: WebDav Server with WebDrive clients
      • Reporting Application: Qlikview
      • Cloudera support for Hadoop
    • Architectural Challenges
      • How to organize data set to keep aggregated data sets fresh.
        • Logs constantly appended to the main Data Set. Reports and aggregated datasets should be refreshed every 15 minutes
      • Mix of .NET and Java applications. (70%+ .Net, 30%- Java)
        • How to make .Net application write logs to Hadoop?
      • Some 3 rd party applications to consume results of MapReduce Jobs (e.g. reporting application)
        • How make 3 rd party or internal Legacy applications to read data from Hadoop ?
      • Backward and forward compatibility of our data sets
        • every month we are adding 3-5 new data points to our logs
    • The Data Flow
    • Partitioned Data Set: Date/Time
      • Date/Time as main dimension for Partitioning
      • Segregate results of MapReduce jobs into Monthly, Daily or Hourly Directories
      • Use MultipleOutputFormat to segregate output to different files
      • Reprocess only what has changed – check DateTime in filename to determine what is affected. Data Set is regenerated if input into MR job contains data for this Month/Day/Hour.
      • Use PathFilter to specify what files to process
    • Partitioned Data Set: Revisions
      • Need overlapping jobs:
        • 12:00 -12:10 Job 1.1 A->B
        • 12:10-12:20 Job 1.2 B->C 12:15-12:25 Job 2.1 A->B !!! Job 1.2 is still reading set B !!!
        • 12:20-12:30 Job 1.3C->D 12:25-12:35 Job 2.2 B->C
        • 12:35-12:45 Job 2.3 C->D
      • Use revisions:
        • 12:00 -12:10 Job 1.1 A.r1->B.r1
        • 12:10-12:20 Job 1.2 B.r1->C.r1 12:15-12:25 Job 2.1 A.r2->B.r2
        • 12:20-12:30 Job 1.3 C.r1->D.r1 12:25-12:35 Job 2.2 B.r2->C.r2
        • 12:35-12:45 Job 2.3 C.r2->D.r2
      • Assign revision (timestamp) when generate output
        • Use MultipleOutputFormat to segregate output to different files
      • Use highest available revision number when selecting input
        • Use PathFilter to specify revisions to process
      • Clean up “old” revisions after some grace period
    • Partitioned Data Set: processing flow
    • Workflow
      • Opswise scheduler
    • Logical Schemas and Headers
      • Meta data repository to define list of columns in all data sets
      • Each file has headers as the first line
      • Job configuration files that define source and target
      • Columns are mapped dynamically based on the schema file and header information
      • Each data set can have individual files of different format
      • No need to modify source code if a new column is added or if order of columns has changed
      • Support for default values if a column is missing in older file
      • Easy to export to external applications (DB, reporting apps)
    • Getting Data in and out
      • Mix of .NET and Java applications. (70%+ .Net, 30%- Java)
        • How to make .Net application write logs to Hadoop?
      • Some 3 rd party applications to consume results of MapReduce Jobs (e.g. reporting application)
        • How make 3 rd party or internal Legacy applications to read data from Hadoop ?
    • Getting Data in and out: WebDAV driver
      • WebDAV server is part of Hadoop source code tree
        • Needed some minor clean up. Was co-developed with IponWeb. Available http://www.hadoop.iponweb.net/Home/hdfs-over-webdav
      • There are multiple commercial Windows WebDav clients you can use (we use WebDrive) http://www.webdrive.com/
      • Linux
        • Mount Modules available from http://dav.sourceforge.net/
    • Getting Data in and out: WebDav
    • QlikView Reporting Application
      • In-memory DB
      • AJAX support for integration into WEB portals
      • TXT files are supported
      • Understands headers
      • WebDav allows to load data directly from Hadoop
      • Coming soon: generation of Qlikview files as output of Hadoop MR jobs
    • High Availability for NameNode/JobTracker
      • Goals
      • Availability! (But not stateful)
        • Failed jobs resubmitted by workflow scheduler
        • Target < 5 minutes of downtime per incident
      • Automatic fail over with no human action required.
        • No phone calls, no experts required
        • Alert that it happened, not that it needs to be fixed
      • Allow for maintenance windows
      • Avoid at all cost
        • Whenever possible, use redundancy inside of the box
        • Disks (RAID 1), network bonding, dual power supplies
    • Redundant Network Architecture
        • Use Linux bonding
          • See bonding.txt from Linux kernel docs.
          • Throughput advantage
            • Observed at 1.76Gb/s
          • We use LACP, aka 802.3ad, aka mode=4 .
            • http://en.wikipedia.org/wiki/Link_Aggregation_Control_Protocol
            • Must be supported by your switches.
          • On the data nodes, too. Great for rebalancing.
        • Keep nodes on different switches
          • Use a dedicated cross over connection, too
    • Software Packages We Use for HA
      • Linux-HA Project’s Heartbeat
        • ( http://www.linux-ha.org )
        • Default resource manager, haresources
        • Manages multiple resources:
          • Virtual IP address
          • DRBD Disk and file system
          • Hadoop init scripts (from Cloudera’s distribution)
      • DRBD by LINBIT
        • ( http://www.drbd.org )
        • “ DRBD can be understood as network based raid-1.”
    • Replication of NameNode Metadata
      • DRBD Replication.
        • Block level replication, file system agnostic
        • File system is active on only one node at a time
        • We use synchronous replication
        • Move only the data that you need! (metadata, not the whole system)
        • 2.6mm Files, 33k dirs, 60TB = 1.3GB meta data (not a lot to move)
        • Still consider running your secondary namenode on another machine and/or NFS dir!
        • LVM snapshots
        • /getimage?getimage=1
        • /getimage?getedit=1
    • In the Unlikely Event of a Water Landing
          • Order of Events, the magic of Heartbeat
          • Detect the failure (“deadtime” from ha.cf)
          • Virtual IP fails over.
          • DRBD system switches primary node. (/proc/drbd status)
          • File system fsck and mount at /hadoop.
          • Hadoop processes started via Cloudera init scripts.
          • Optionally, original master is rebooted (if it’s still alive)
          • End to end fail over time approximately 15 seconds.
      •
    • In the Unlikely Event of a Water Landing
          • Order of Events, the magic of Heartbeat
          • Detect the failure (“deadtime” from ha.cf)
          • Virtual IP fails over.
          • DRBD system switches primary node. (/proc/drbd status)
          • File system fsck and mount at /hadoop.
          • Hadoop processes started via Cloudera init scripts.
          • Optionally, original master is rebooted (if it’s still alive)
          • End to end fail over time approximately 15 seconds.
          • Does it work?
      •
    • In the Unlikely Event of a Water Landing
          • Order of Events, the magic of Heartbeat
          • Detect the failure (“deadtime” from ha.cf)
          • Virtual IP fails over.
          • DRBD system switches primary node. (/proc/drbd status)
          • File system fsck and mount at /hadoop.
          • Hadoop processes started via Cloudera init scripts.
          • Optionally, original master is rebooted (if it’s still alive)
          • End to end fail over time approximately 15 seconds.
          • Does it work?
          • Yes!! 6 failovers in the past 18 months
      •
    • In the Unlikely Event of a Water Landing
          • Order of Events, the magic of Heartbeat
          • Detect the failure (“deadtime” from ha.cf)
          • Virtual IP fails over.
          • DRBD system switches primary node. (/proc/drbd status)
          • File system fsck and mount at /hadoop.
          • Hadoop processes started via Cloudera init scripts.
          • Optionally, original master is rebooted (if it’s still alive)
          • End to end fail over time approximately 15 seconds.
          • Does it work?
          • Yes!! 6 failovers in the past 18 months
          • (only 3 were planned)
      •
    • Other Options to Consider
        • (or: How I Learned to Stop Worrying and Start Over From the Beginning)
        • Explore additional resource management systems
          • ie., OpenAIS + Pacemaker: N+1, N-to-N
          • Be resource aware, not just machine aware
        • Consider additional file system replication methods
          • ie., GlusterFS, Red Hat GFS
          • SAN/iSCSI backed
        • Virtualized solutions?
        • Other things I don’t know about yet
          • Solutions to the problem exist
          • Work with something you’re comfortable with
        • http://www.cloudera.com/blog/2009/07/22/hadoop-ha-configuration/
