How to monitor the  $H!T out of Hadoop Developing a comprehensive open approach to monitoring hadoop clusters
Relevant Hadoop Information <ul><li>From 3 – 3000 Nodes </li></ul><ul><li>Hardware/Software failures “common” </li></ul><u...
Monitoring Software <ul><li>Nagios –  </li></ul><ul><ul><li>Red Yellow Green Alerts, Escalations </li></ul></ul><ul><ul><l...
Cacti <ul><li>Performance Graphing System </li></ul><ul><li>RRD/RRA Front End </li></ul><ul><li>Slick Web Interface </li><...

hadoop-cacti-jtg <ul><li>JMX Fetching Code w/ (kick off) scripts </li></ul><ul><li>Cacti templates For Hadoop </li></ul><u...
Hadoop JMX
Sample Cluster P1 <ul><li>NameNode & SecNameNode </li></ul><ul><ul><li>Hardware RAID </li></ul></ul><ul><ul><li>8 GB RAM <...
A Sample Cluster p2 <ul><li>Slave (hadoopdata1-XXXX) </li></ul><ul><ul><li>JBOD 8x 1TB SATA Disk </li></ul></ul><ul><ul><l...
Prerequisites <ul><li>Nagios (install) DAG RPMs </li></ul><ul><li>Cacti (install) Several RPMS </li></ul><ul><li>Liberal n...
Alerts & Escalations <ul><li>X nodes * Y Services = < Sleep </li></ul><ul><li>Define a policy  </li></ul><ul><ul><li>Wake ...
Wake Me Up’s <ul><li>NameNode </li></ul><ul><ul><li>Disk Full (Big Big Headache) </li></ul></ul><ul><ul><li>RAID Array Iss...
Don’t Wake Me Up’s <ul><li>Or ‘Wake someone else up’ </li></ul><ul><li>DataNode </li></ul><ul><ul><li>Warning Currently Fa...
Monitoring Battle Plan <ul><li>Start With the Basics </li></ul><ul><ul><li>Ping, Disk </li></ul></ul><ul><li>Add Hadoop Sp...
The Basics Nagios <ul><li>Nagios (All Nodes) </li></ul><ul><ul><li>Host up (Ping check) </li></ul></ul><ul><ul><li>Disk % ...
The Basics Cacti <ul><li>Cacti (All Nodes) </li></ul><ul><ul><li>CPU (full CPU) </li></ul></ul><ul><ul><li>RAM/SWAP  </li>...
Disk Utilization
RAID Tools <ul><li>Hpacucli – not a Street Fighter move </li></ul><ul><ul><li>Alerts on RAID events (NameNode)  </li></ul>...
Before you jump in <ul><li>X Nodes * Y Checks * = Lots of work </li></ul><ul><li>About 3 Nodes into the process … </li></u...
Nagios <ul><li>Answers “IS IT RUNNING?” </li></ul><ul><li>Text based Configuration </li></ul>
Cacti <ul><li>Answers “HOW WELL IS IT RUNNING?” </li></ul><ul><li>Web Based configuration  </li></ul><ul><ul><li>php-cli t...
Monitoring Battle Plan Thus Far <ul><li>Start With the Basics </li></ul><ul><ul><li>Ping, Disk !!!!!!Done!!!!!! </li></ul>...
Add Hadoop Specific Alarms <ul><li>Hadoop Components with a Web Interface </li></ul><ul><ul><li>NameNode 50070 </li></ul><...
nagios_check_commands.cfg <ul><li>Component Failure </li></ul><ul><li>(Future) Newer Hadoop will have XML status  </li></u...
Monitoring Battle Plan <ul><li>Start With the Basics </li></ul><ul><ul><li>Ping, Disk (Done) </li></ul></ul><ul><li>Add Ha...
JMX Graphing <ul><li>Enable JMX </li></ul><ul><li>Import Templates </li></ul>
JMX Graphing
JMX Graphing
JMX Graphing

Standard Java JMX
Monitoring Battle Plan Thus Far <ul><li>Start With the Basics !!!!!!Done!!!!! </li></ul><ul><ul><li>Ping, Disk </li></ul><...
Add JMX based Alarms <ul><li>hadoop-cacti-jtg is flexible </li></ul><ul><ul><li>extend fetch classes </li></ul></ul><ul><u...
Quick JMX Base Walkthrough  <ul><li>url, user, pass, object specified from CLI </li></ul><ul><li>wantedVariables, wantedOp...
Extend for NameNode
Extend for Nagios
Monitoring Battle Plan <ul><li>Start With the Basics !DONE! </li></ul><ul><ul><li>Ping, Disk </li></ul></ul><ul><li>Add Ha...
Review <ul><li>File System Growth </li></ul><ul><ul><li>Size </li></ul></ul><ul><ul><li>Number of Files </li></ul></ul><ul...
The Future <ul><li>JMX Coming to JobTracker and TaskTracker (0.21) </li></ul><ul><ul><li>Collect and Graph Jobs Running </...
