WebSockets
and the Real-Time Web

         tossug 2010-07-06
  Chia-liang Kao clkao@clkao.org
clkao
Real-Time
  Web
New information
without refreshing
 the “web-page”
Real-time Spam
COSCUP Regisration
     Status
COSCUP Regisration
     Status
Real-time Annoyance
Real-time
market quotes
DEMO
Outlines
• comet server-push technologies
• websockets introductions
• websockets examples
• frameworks and packages
 supp...
Server-Push

• browser tells server about interested
  information
• information streamed from server to
  browser without...
Comet
Comet
Comet
Comet
The word comet came to English by way of the Latin word cometes. This word, in turn, came
from the Greek word κόμη, ...
Widely used

• gmail
• plurk
• facebook updates
Comet - Long-poll

• Browser connects to an event endpoint
• connection idled when there’s no event
• browser reconnects a...
Comet - Forever IFrame

• Makes use of browser incremental
  rendering
 • IE wants <br/>
 • Safari wants 1KB data
• cross-...
Multi-part XHR
   • multi-part response with boundries:
Content-Type: multipart/mixed; boundary=Foo

--Foo
Content-Type: a...
Multi-part XHR
   • multi-part response with boundries:
Content-Type: multipart/mixed; boundary=Foo

--Foo
Content-Type: a...
Lots of hacks!
Lots of hacks!

• spinning “loading” indicator for FF and IE
Lots of hacks!

• spinning “loading” indicator for FF and IE
• number of connections limits
Lots of hacks!

• spinning “loading” indicator for FF and IE
• number of connections limits
• transport overhead
Lots of hacks!

• spinning “loading” indicator for FF and IE
• number of connections limits
• transport overhead
• webserv...
Lots of hacks!

• spinning “loading” indicator for FF and IE
• number of connections limits
• transport overhead
• webserv...
Enter
WebSockets
Websockets
Websockets

• HTML5 Websockets
Websockets

• HTML5 Websockets
• Bidirectional communication over HTTP
Websockets

• HTML5 Websockets
• Bidirectional communication over HTTP
• Available in latest browsers
Websockets

• HTML5 Websockets
• Bidirectional communication over HTTP
• Available in latest browsers
• or use http://gith...
ws://example.com

wss://example.com
Request:
GET /demo HTTP/1.1
Host: example.com
Connection: Upgrade
Sec-WebSocket-Key2: 12998 5 Y3 1 .P00
Sec-WebSocket-Prot...
Request:
GET /demo HTTP/1.1
Host: example.com
Connection: Upgrade
Sec-WebSocket-Key2: 12998 5 Y3 1 .P00
Sec-WebSocket-Prot...
Request:
GET /demo HTTP/1.1
Host: example.com
Connection: Upgrade
Sec-WebSocket-Key2: 12998 5 Y3 1 .P00
Sec-WebSocket-Prot...
Request:
GET /demo HTTP/1.1
Host: example.com
Connection: Upgrade
Sec-WebSocket-Key2: 12998 5 Y3 1 .P00
Sec-WebSocket-Prot...
Request:
GET /demo HTTP/1.1
Host: example.com
Connection: Upgrade
Sec-WebSocket-Key2: 12998 5 Y3 1 .P00
Sec-WebSocket-Prot...
Request:
GET /demo HTTP/1.1
Host: example.com
Connection: Upgrade
Sec-WebSocket-Key2: 12998 5 Y3 1 .P00
Sec-WebSocket-Prot...
Request:
GET /demo HTTP/1.1
Host: example.com
Connection: Upgrade
Sec-WebSocket-Key2: 12998 5 Y3 1 .P00
Sec-WebSocket-Prot...
Request:
GET /demo HTTP/1.1
Host: example.com
Connection: Upgrade
Sec-WebSocket-Key2: 12998 5 Y3 1 .P00
Sec-WebSocket-Prot...
Request:
GET /demo HTTP/1.1
Host: example.com
Connection: Upgrade
Sec-WebSocket-Key2: 12998 5 Y3 1 .P00
Sec-WebSocket-Prot...
my @keys = map {
    my $k = $env>{'HTTP_SEC_WEBSOCKET_KEY'.$_};
    join('', $k =~ m/d/g) / scalar @{[$k =~ m/ /g]};
} (1...
Messages surrounded
by x{00} and x{ff}
Websockets API
Websockets API

ws = new WebSocket("ws://foo.com:5000”));

ws.onopen = function(ev) { ... }
ws.onmessage = function(ev) { ...
DEMO
WebSockets
Challenges
Browser
Support
Browser
  web-socket-js
Support
  to the rescue!!
Session Management

• Reconnect
• Authentication
• within webserver or standalone?
Scaling
Scaling

• Most likely, you want to work in async
  model for many stateful connections
Scaling

• Most likely, you want to work in async
  model for many stateful connections
• perl: AnyEvent / Twiggy
Scaling

• Most likely, you want to work in async
  model for many stateful connections
• perl: AnyEvent / Twiggy
• ruby: ...
Scaling

• Most likely, you want to work in async
  model for many stateful connections
• perl: AnyEvent / Twiggy
• ruby: ...
WebSockets
 Packages
Perl

• Web::Hippie: AnyEvent and PSGI based
• Web::Hippie::Pipe: integrated message bus
  with AnyMQ
• Mojo
DEMO
Ruby

• em-websockets
• sunshower
• cramp
Others

• phpwebsockets
• Node.js
• Erlang
• Haskell
Thank you!
Bonus
HTML5 EventSource
 Content-Type: text/event-stream
 data: Foo
 id: 123

 data: Bar
 id: 124
  var eventSrc = new EventSour...
