Windows® Server 2008 R2: Develop With New Parallel Computing Technologies<br />Clint Edmonson<br />Architect Evangelist<br...
Agenda<br />The Shift!<br /><ul><li>Why parallel computing?   </li></ul>The Platform!<br />The Process!<br />The Tools!<br />
Moore’s LawOur Old Friend Gordon Moore<br />From http://www.intel.com/technology/mooreslaw/<br />“The number of transistor...
Why Can’t We Continue to Scale Up?Heat!<br />Increased clock speed == increases power usage<br />Increased power usage == ...
Solution: Scale OutMulti-core / Many-core<br />Multi-core<br />Two or more independent cores (or CPUs)<br />Homogenous arc...
The Free Lunch is Over<br />
How to Program for Parallel ComputingThe “Many-core Shift”<br />Platform must manage resources effectively<br />Programs m...
Agenda<br />The Platform!<br /><ul><li>Parallel computing platform</li></ul>The Process!<br />The Tools!<br />The Shift!<b...
Got CPUs? Get R2… Your Apps Will Fly!<br />
Windows Server 2008 R2Platform Hardware Trends<br />Power Efficiency<br />Multicore & NUMA<br />64-bit<br />Virtualization...
Helpful Terminology<br />Logical processor (a.k.a. thread execution engine)<br />Core<br />A processing unit<br />With hyp...
Windows Organizes Many-Cores via GroupNew with Windows 7 and Windows Server 2008 R2<br />Group<br />NUMA = Non-Uniform Mem...
Processor GroupsGroups, 4 Nodes, 8 Sockets, 32 Cores, 4 LPs/Core = 128 LPs<br />Group<br />Group<br />NUMA Node<br />NUMA ...
Windows on 256 Processors<br />A SQL Server Transaction Processing Workload<br />video<br />
Agenda<br />The Process!<br /><ul><li>Introducing parallelism into your applications</li></ul>The Tools!<br />The Shift!<b...
Visual Studio 2010 (.NET Developer)Tools, Programming Models, Runtimes<br />Tools<br />Programming Models<br />Parallel LI...
Demystifying Parallel Programming<br />Parallel Extensions Make It Easy<br />demo<br />
3 Ways to Express Parallelism in Your Apps<br />Imperative Task Parallelism (fine grained)<br />Imperative Data Parallelis...
Imperative Task Parallelism<br />Fine-grained parallelism<br />Express potential parallelism via expressions and statement...
Imperative Data Parallelism<br />Structured parallelism<br />Mechanisms used to express common imperative data-oriented op...
Declarative Data Parallelism<br />PLINQ<br />Implementation of LINQ-to-objects that execute queries in parallel<br />Expre...
Visual Studio 2010 (C++ Developer)Tools, Programming Models, Runtimes<br />Tools<br />Programming Models<br />Agents <br /...
Agenda<br />The Tools!<br /><ul><li>Visual Studio 2010</li></ul>The Shift!<br />The Platform!<br />The Process!<br />
Debugging Parallel ApplicationsNew in Visual Studio®2010<br />Two new debugger tool windows:<br />“Parallel Tasks”<br />“P...
Demystifying Parallel Programming<br />Debugging A Parallel Application<br />demo<br />
Parallel Performance AnalyzerCore Utilization View<br />Profiling tools support multi-core/parallel execution<br />Identif...
Parallel Performance AnalyzerThread Blocking View<br />Measure time for interesting segments<br />Hide uninteresting threa...
Parallel Performance AnalyzerCore Execution / Thread Migration View<br />Each core in a swim lane<br />One color per threa...
SummaryCall-to-Action<br />Start learning to think in parallel<br />Consider how your solution will scale on multi-core sy...
Learn More About Windows Server 2008 R2<br />Resources<br /><ul><li>Microsoft.com
