Low Latency “OLAP” with HBase     Cosmin Lehene | Adobe© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confi...
What we needed … and built      OLAP Semantics      Low Latency Ingestion      High Throughput      Real-time Query AP...
Building Blocks      Dimensions, Metrics      Aggregations      Roll-up, drill-down, slicing and dicing, sorting© 2012 ...
OLAP 101 – Queries example                 Date                           Countr                        City            OS...
OLAP 101 – Queries example      Rolling up to country level:                                               Country    vis...
OLAP – Runtime Aggregation vs. Pre-aggregation      Aggregate at runtime                                                 ...
Pre-aggregation      Data needs to be summarized            Can’t visualize 1B data points (no, not even with Retina dis...
SaasBase      We tune both      pre-aggregation level                                                      vs.    runtim...
SaasBase Domain Model Mapping© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential.   9
SaasBase - Domain Model Mapping© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential.   10
SaasBase - Ingestion, Processing, Indexing, Querying© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confiden...
SaasBase - Ingestion, Processing, Indexing, Querying© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confiden...
Ingestion© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential.   13
Ingestion throughput vs. latency      Historical data (large batches)            Optimize for throughput      Increment...
Large, granular input strategies      Slow listing in HDFS            Archive processed files      Filtering input     ...
Ingestion – Bulk Import      HFileOutputFormat (HFOF)            100s X faster than HBase API            No need to rec...
HFOF – FileSizeDatePartitioner      1 partition(reduce) / day for initial import      Uneven reduce (partitions) due to ...
Processing© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential.   18
Processing      Processing involves reading the Input (files, tables, events), pre-       aggregating it (reducing cardin...
Processing for OLAP semantics            GROUP BY (process, query)            COUNT, SUM, AVG, etc. (process, query)    ...
SaasBase vs. SQL Views Comparison© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential.   21
reports.json entities definition© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential.   22
Processing Performance      read, map, partition, combine, copy, sort, reduce, write      Read:            Scan.setCach...
Processing Performance      Hot (in memory) vs. Cold (on disk, on network) data            Minimize I/O from disk/networ...
Indexing© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential.   25
HBase natural order: hierarchical representation© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential...
Indexing - Why      Example: top 10 cities            ~50K [country, city] combinations per day            Top 10 citie...
Indexing with HBase “10” < “2”  GROUP BY year, month, country, city ORDER BY visits DESC LIMIT 10      Lexicographic sort...
Query Engine      Always reads indexed, compact data      Query parsing      Scan strategy            Single vs. multi...
Conclusions      OLAP semantics on a simple data model            Data as first class citizen            Domain Specifi...
Thank you!                                                               Cosmin Lehene @clehene                           ...
© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential.
OLAP 101 - Rollup                             Countr                                                Visits   Sale         ...
OLAP 101 - Slicing  Date                       Countr                   City                    OS             Browser    ...
OLAP 101 – Sorting, TOP n  Date                       Countr                   City                    OS        Browser  ...
