MongoUK 2012 Presentation Transcript

  • 1. Activity Streams on Cloud Foundry with MongoDB and Node.js MongoUK - 2012 By Monica Wilkinson and Andy Piper © 2012 VMware, Inc. All rights reservedWednesday, June 20, 12
  • 2. Andy Piper social bridgebuilder, techie Developer Advocate @ Cloud Foundry 15 years in enterprise middleware & messaging social web enthusiast OSS supporter / contributor excited by “what’s next”, Internet of Things, etc. @andypiper apiper@vmware.com CONFIDENTIAL 2Wednesday, June 20, 12
  • 3. About Monica Wilkinson Loves the web and data portability. Developer Advocate @ Cloud Foundry 12 years development experience. Last 5 years in Social Web Open Web Standards Advocate Contact Me: @ciberch mwilkinson@vmware.com CONFIDENTIAL 3Wednesday, June 20, 12
  • 4. Agenda 1.Overview of Cloud Foundry 2.What is Activity Streams ? 3.Building an Activity Stream Engine CONFIDENTIAL 4Wednesday, June 20, 12
  • 5. About Cloud Foundry The first Open PaaS Multi(n) Languages, Frameworks, Services & Clouds Open Source CONFIDENTIAL 5Wednesday, June 20, 12
  • 6. Traditional web app architecture ! Browser client Web Application ! Monolithic WAR / other deployment artefact StoreFront ! RDBMS AccountingService MySQL Desktop Database Apache Browser InventoryService “easy” to... ShippingService ! develop ! test Container (e.g. Tomcat) ! deploy ! scale ...apart from: provisioning, setup, need to replicate, shard, scale to massive numbers of mobile clients, provide polyglot support, run multiple dev teams, collaborate... CONFIDENTIAL 6Wednesday, June 20, 12
  • 7. Need to handle massive loads and the data explosion Scalable architectures! ! Application tier: •Replicated/clustered servers •Modular so that components can be scaled differently •Asynchronous architecture - communication via a message broker ! Database tier: •Replication •Sharding •Polyglot persistence: Relational, NoSQL, NewSQL databases CONFIDENTIAL 7Wednesday, June 20, 12
  • 8. Modern application architecture billing web applicationDesktop Browser Accounting Service StoreUI Native Mobile NodeJS NodeJS inventory web application Application front-end MySQL StoreUI application StoreUI InventoryService HTML5 mobile application StoreUI Redis shipping web application RabbitMQ Mongo ShippingService CONFIDENTIAL 8Wednesday, June 20, 12
  • 9. Platform-as-a-Service is the solution Deployment Services Easy deployment SQL databases Application management NoSQL databases + Easy scaling up and down Message Broker CONFIDENTIAL 9Wednesday, June 20, 12
  • 10. The Open Platform as a Service “Deploy and scale applications in seconds, without locking yourself into a single cloud or vendor” , xible n, Fle Ope e ple, l Si m Sc alab CONFIDENTIAL 10Wednesday, June 20, 12
  • 11. Cloud Foundry open PaaS - Choice of clouds OSS community Private( Ap I) Data Services CP Clouds( pli vFabric ( ca ce Postgres tio r fa nS e Int er Public v ic r ide eI Msg Services ov Clouds nt e Pr r fa vFabric RabbitMQTM d ou ce Cl Micro Other Services Clouds to h: d eploy c) ! bos et N EW PIs (AWS n at e C Additional partner services … alter CONFIDENTIALWednesday, June 20, 12
  • 12. Multi-cloud flexibility is critical to long-term success ! Make use of both public and private clouds without rewriting your applications ! Protect against vendor lock-in ! Meet different compliance and geographical needs ! Accommodate peak loads while optimizing costs ! Manage your growth and changing needs over time CONFIDENTIAL 12Wednesday, June 20, 12
  • 13. Getting Started on Cloud Foundry CONFIDENTIAL 13Wednesday, June 20, 12
  • 14. Register! http://cloudfoundry.com/signup optional promo CONFIDENTIAL 14Wednesday, June 20, 12
  • 15. Ways to use Cloud Foundry command line... IDE plugin... toolchain plugin... Cloud IDEs CONFIDENTIAL 15Wednesday, June 20, 12
  • 16. Example vmc commands $"gem"install"vmc $"vmc"target"<any"cloud> $"vmc"login"<credentials> $"vmc"push"<my7app> " "">"bind"services?"Yes $"vmc"update"<my7app> $"vmc"instances"<my7app>"+100" CONFIDENTIAL 16Wednesday, June 20, 12
  • 17. Logging into CloudFoundry.com$"vmc"target"api.cloudfoundry.comSuccessfully"targeted"to"""""""""[http://api.cloudfoundry.com]$"vmc"loginAttempting"login"to"""[http://api.cloudfoundry.com]Email:"apiper@vmware.comPassword:"********Successfully"logged"into"""[http://api.cloudfoundry.com] CONFIDENTIAL 17Wednesday, June 20, 12
  • 18. Cloud Foundry Integration plugin for Eclipse CONFIDENTIAL 18Wednesday, June 20, 12
  • 19. What is Activity Streams ? CONFIDENTIAL 19Wednesday, June 20, 12
  • 20. http://activityStrea.ms ! Activity Streams is a simple open specification used to describe social actions around the web. ! The goal of Activity Streams is data portability ! Some publishers of Activity Streams: Socialcast, MySpace, Facebook and G+ ! The default format is JSON but Atom is also supported. The JSON format was added after we saw some initial limitations with JSON ! Core concepts are: Actor, Verb, Object and Target CONFIDENTIAL 20Wednesday, June 20, 12
  • 21. Actor -> Monica Verb -> Pinned(Bookmarked) Object -> Rosa Parks’ Bio Page Target -> Female Leaders Board Source -> Pinterest Published -> MLK Day 2012 © 2012 VMware, Inc. All rights reservedWednesday, June 20, 12
  • 22. With Timeline Actions Posting with a richer protocol like Activity Streams allows you to do: - Richer messages and links - Aggregate - Assign relevance © 2012 VMware, Inc. All rights reservedWednesday, June 20, 12
  • 23. Example in JSON CONFIDENTIAL 23Wednesday, June 20, 12
  • 24. What is an Activity Stream Engine ? ! An activity stream engine allows you to publish events and subscribe to events. ! Many activity stream engines support aggregation of events via Streams. ! Many activity stream engines support fanning out activities to subscribers. CONFIDENTIAL 24Wednesday, June 20, 12
  • 25. So how did we build this Activity Stream Engine on Cloud Foundry ? CONFIDENTIAL 25Wednesday, June 20, 12
  • 26. Building an Activity Streams Engine CONFIDENTIAL 26Wednesday, June 20, 12
  • 27. What should we use to store Activities ?Key-Value Column Document Graph Redis, Cassandra, MongoDB Neo4J Riak HBase CONFIDENTIAL 27Wednesday, June 20, 12
  • 28. Mongo DB schema-less documents are perfect for ActivitiesKey-Value Column Document Graph MongoDB (so easy) CONFIDENTIAL 28Wednesday, June 20, 12
  • 29. About MongoDB 1. No-SQL database development : { 2. Stores JSON-style tools: many, documents with language_support: superb, embedded documents = agility: high 3. Horizontally scalable }, production: { 4. Full Indexing Support speed: fast 5. Open Source so great fault_tolerance: true ORMs and drivers. scalability: high CONFIDENTIAL 29Wednesday, June 20, 12
  • 30. Step 1- Build the persistence Model var MediaLinkHash = {         duration: Number,         height: Number,         width: Number,         url: String     };     var ActivityObjectHash = {        id: {type: String},        image: MediaLinkHash,        displayName: {type: String},        summary: {type: String},        content: {type: String},        url: {type:String},        author: {type: ObjectId, ref: activityObject},        published: {type: Date, default: Date.now},        updated: {type: Date, default: Date.now},        objectType: {type: String},        attachments: [{type: ObjectId, ref: activityObject}],        upstreamDuplicates: [String],        downstreamDuplicates: [String]     };     var ActivityObjectSchema = new Schema(ActivityObjectHash)     this.ActivityObject = mongoose.model(activityObject, ActivityObjectSchema); CONFIDENTIAL 30Wednesday, June 20, 12
  • 31.     var ActivitySchema = new Schema({        id: {type: String},        verb: {type: String},        url: {type: String},        title: {type: String},        content: {type: String},        icon: MediaLinkHash,        object: ActivityObjectHash,        actor: ActivityObjectHash,        target: {type: ObjectId, ref: activityObject},        published: { type: Date, default: Date.now},        updated: { type: Date, default: Date.now},        inReplyTo: {type: ObjectId, ref: activity}    });    this.Activity = mongoose.model(activity, ActivitySchema);    return this;}; CONFIDENTIAL 31Wednesday, June 20, 12
  • 32. Step 2 - Expose helpers for the queries ! The most important is to be able to list the activities in descending order by published time. ! It is also important to hydrate any objects for which we have references ! With Mongoose you can do:  ! this.getActivityStream = function(n, fx) { Activity.find().sort(published, descending).limit(n).populate(target).run (fx);     } ! https://github.com/ciberch/activity-streams-mongoose CONFIDENTIAL 32Wednesday, June 20, 12
  • 33. How do we make our engine faster and more scalable ? ! Add support for PubSub ! In a PubSub model as soon as an event is published it gets sent to all the subscribers. ! The Publisher doesn’t know who the subscribers are, it simply knows where to publish. ! Redis has nice support for Pub Sub http://redis.io/topics/ pubsub CONFIDENTIAL 33Wednesday, June 20, 12
  • 34. Using Socket.io ! Server Side: • Subscribe to a Stream • When there is a new event send it to the client as JSON ! Client Side • Add support to publish activities to the Stream • Change the client rendering to use ActivityStrea.ms ! Benefits • Richer messaging • Activity Syndication CONFIDENTIAL 34Wednesday, June 20, 12
  • 35. Demo Part 1: App 1 and walkthrough http://blog.cloudfoundry.com/ 2012/05/17/node-activity-streams-app-1/ Part 2: App 2 and walkthrough http://blog.cloudfoundry.com/ 2012/06/05/node-activity-streams-app-2/ Part 3: http://asms.cloudfoundry.com © 2012 VMware, Inc. All rights reservedWednesday, June 20, 12
  • 36. Thank You - Questions ? Cloud Foundry Activity Streams Libraries are at: https://github.com/organizations/cloudfoundry-samples http://cloudfoundry.com Questions: @cloudfoundry, @ciberch or @andypiper © 2012 VMware, Inc. All rights reservedWednesday, June 20, 12
  • 37. Resources Primary Site: cloudfoundry.com Open Source Site: cloudfoundry.org Twitter: @cloudfoundry or #cloudfoundry Blog: blog.cloudfoundry.com FB: facebook.com/cloudfoundry Documentation: docs.cloudfoundry.com Full “bootcamp” presentation: slidesha.re/cf-bootcamp © 2012 VMware, Inc. All rights reservedWednesday, June 20, 12
