Ubiquitous Information Architecture: Building for change and Web 3.0 Chris Thorne Information Architect BBC

Me An Information Architect. Playing in metadata and the web since 1999. Before that a Multimedia Research Scientist (for Philips Electronics).

An Information Architect.

Playing in metadata and the web since 1999.

Before that a Multimedia Research Scientist (for Philips Electronics).

About the BBC The largest broadcasting corporation in the world Mission: To inform, educate and entertain. Public service broadcaster, established by a Royal Charter and funded by the licence fee that is paid by UK households. Services include: 8 national TV channels plus regional programming, 10 national radio stations, 40 local radio stations and an extensive website, bbc.co.uk.

The largest broadcasting corporation in the world

Mission: To inform, educate and entertain.

Public service broadcaster, established by a Royal Charter and funded by the licence fee that is paid by UK households.

Services include: 8 national TV channels plus regional programming, 10 national radio stations, 40 local radio stations and an extensive website, bbc.co.uk.

My Part of the BBC - Provides web technology for the whole of the BBC. - Primary customers - BBC Audio, Music and Mobile.

- Provides web technology for the whole of the BBC.

- Primary customers - BBC Audio, Music and Mobile.

My Part of the BBC /Programmes – a multiplatform dynamic semantic publishing service to support all programmes broadcast by the BBC.

/Programmes – a multiplatform dynamic semantic publishing service to support all programmes broadcast by the BBC.

My Part of the BBC /Programmes – a multiplatform dynamic semantic publishing service to support all programmes broadcast by the BBC.

/Programmes – a multiplatform dynamic semantic publishing service to support all programmes broadcast by the BBC.

My Part of the BBC /music – a multiplatform dynamic published semantic service to support music activities by the BBC.

/music – a multiplatform dynamic published semantic service to support music activities by the BBC.

My Part of the BBC - Multiplatform PC, Mac, Mobile (WAP, iphone et al) and future devices and platforms.

PC, Mac, Mobile (WAP, iphone et al) and future devices and platforms.

As Information Architects We play a key role in determining: How information systems interact. How information is stored. How users and businesses get the most out of these systems and services.

We play a key role in determining:

How information systems interact.

How information is stored.

How users and businesses get the most out of these systems and services.

The world around us is changing…… ‘ Ever more pervasive, ever harder to perceive, computing has leapt off the desktop and insinuated itself into everyday life. Such ubiquitous information technology “everyware” – will appear in many different contexts and take a wide variety of forms, but it will effect almost every one of us, whether we’re aware of it or not”. [‘Everyware: The dawning age of ubiquitous computing’ – Adam Greenfield]

‘ Ever more pervasive, ever harder to perceive, computing has leapt off the desktop and insinuated itself into everyday life. Such ubiquitous information technology “everyware” – will appear in many different contexts and take a wide variety of forms, but it will effect almost every one of us, whether we’re aware of it or not”.

[‘Everyware: The dawning age of ubiquitous computing’ – Adam Greenfield]

Mobile Devices

Kiosks and multi user devices

Public Information/Advertising

Discound/Credit/Travel Cards and readers

Radios using the web

Even TV is changing – the web is on TV

And how is the web? :-)

Where we are now – web 2.0

Computers can’t help much

The Apple=Apple=Apple problem. A computer struggles to understand the different ‘Apples’.

A computer struggles to understand the different ‘Apples’.

Web 2.0 - Too many Silos. If you want to use a web 2.0 service in your website, you have to persuade your engineers and developers to learn a new API, with new data formats and new interfaces.

If you want to use a web 2.0 service in your website, you have to persuade your engineers and developers to learn a new API, with new data formats and new interfaces.

The Semantic Web is not just academic….

The Semantic Web is not just academic….

The challenges include everyday life. Its hard getting to work. Its hard shopping for stuff. Its hard to socialise…… These user journeys are part of our everyday lives and yet the web and current everyware isn’t that much help.

Its hard getting to work.

Its hard shopping for stuff.

Its hard to socialise……

These user journeys are part of our everyday lives and yet the web and current everyware isn’t that much help.

Semantic Web – A web for machines. Trying to build a web of things (including documents) that machines can understand. So machines can help us solve everyday problems more easily.

Trying to build a web of things (including documents) that machines can understand.

So machines can help us solve everyday problems more easily.

Idea 1 ‘ Everyware’ is here now and will increasingly influence our everyday lives.

‘ Everyware’ is here now and will increasingly influence our everyday lives.

Idea 1 continued But it needs a lot of improvement. (we still have a job, yay!)

But it needs a lot of improvement.

(we still have a job, yay!)

Idea 2 The Semantic web will succeed. It will be web 3.0, web 4.0 or web 5.0…… Semantic web will power significant amounts of everyware.

The Semantic web will succeed.

It will be web 3.0, web 4.0 or web 5.0……

Semantic web will power significant amounts of everyware.

Idea 3 Information Architects need to engage with semantic web and ‘everyware’…..

Information Architects need to engage with semantic web and ‘everyware’…..

Idea 4 We can build now for a semantic future, where the web is supporting a variety of information services and devices.

We can build now for a semantic future, where the web is supporting a variety of information services and devices.

Idea 4 continued … .even if we’re building microsites.

… .even if we’re building microsites.

Idea 4 continued … .even if they are statically published.

… .even if they are statically

published.

… ..The BBC and others are doing this now.

… ..The BBC and others are doing this now.

Semantic Web – machine readable data Trying to explain: Who What Where When To machines……

Trying to explain:

Who

What

Where

When

To machines……

The BBC Semantic Ambition:

Progress so far:

Progress so far:

Progress so far:

Bbc.co.uk/music Powered by musicbrainz data. 440825 artist profiles and growing. BBC is not solely responsible for maintaining and growing the database - but is able to contribute BBC effort to the benefit of the whole web.

Powered by musicbrainz data.

440825 artist profiles and growing.

BBC is not solely responsible for maintaining and growing the database - but is able to contribute BBC effort to the benefit of the whole web.

Semantic Web - How does it work? Standardised building blocks – XML, RDF, Ontologies, HTTP Allows easier exchange, crawling and use of data.

Standardised building blocks – XML, RDF, Ontologies, HTTP

Allows easier exchange, crawling and use of data.

Semantic Web - Layers of a cake?

Semantic Web - Example RDF statements Statement 1: Chris - Knows - Michael. Statement 2: Chris - Lives in - London Statement 3: Chris - Age - 34. Ie simple statements about things. Aka ‘triples’ - dbpedia.org has 116.7 million triples.

Semantic web - Linked Data Principles Use URIs as names for things. Use HTTP URIs so that people can look up those names. When someone looks up a URI, provide useful RDF information. Include RDF statements that link to other URIs so that they can discover related things. Tim Berners-Lee 2007 http://www.w3.org/DesignIssues/LinkedData.html

Use URIs as names for things.

Use HTTP URIs so that people can look up those names.

When someone looks up a URI, provide useful RDF information.

Include RDF statements that link to other URIs so that they can discover related things.

Tim Berners-Lee 2007

http://www.w3.org/DesignIssues/LinkedData.html

In other words Based on standard web etiquette. BUT….. Without unique URIs and persistent URIs, people aren’t going to like using your data. Each time they want to know something its in a different place? You’re having a laugh :-).

Based on standard web etiquette. BUT…..

Without unique URIs and persistent URIs, people aren’t going to like using your data.

Each time they want to know something its in a different place? You’re having a laugh :-).

Semantic Web, Restful design, Google juice Publishing semantic data, like maximising google ‘pagerank’, relies on persistence. The URIs you use should be persistent. Otherwise your google juice/other companies/users/machines get lost.

Publishing semantic data, like maximising google ‘pagerank’, relies on persistence.

The URIs you use should be persistent.

Otherwise your google juice/other companies/users/machines get lost.

Google pagerank maximising – what we know... Do good stuff. Practice RESTfull principles. Put your ‘good stuff’ in one place only. Keep it there forever. Get your H1s right. Tell others so they link to it. Get companies with a high page rank to link to it.

Do good stuff.

Practice RESTfull principles.

Put your ‘good stuff’ in one place only.

Keep it there forever.

Get your H1s right.

Tell others so they link to it.

Get companies with a high page rank to link to it.

Restful design principles in brief: If the contents of a page changes state, the URI changes. This means personalisation using cookies can be bad – if a page has changed state without changing the URI. Use AJAX/Flash with caution. [see http://en.wikipedia.org/wiki/Representational_State_Transfer]

If the contents of a page changes state, the URI changes.

This means personalisation using cookies can be bad – if a page has changed state without changing the URI.

Use AJAX/Flash with caution.

[see http://en.wikipedia.org/wiki/Representational_State_Transfer]

Semantic Web – machine readable data Trying to explain: Who What Where When To machines……

Trying to explain:

Who

What

Where

When

To machines……

Who and What … ..The problem is they change……but we want them to remain at the same URI…..

… ..The problem is they change……but we want them to remain at the same URI…..

Who and What change - some examples: Prince, symbol, slave etc

Prince, symbol, slave etc

Who and What change - some examples: Victoria Beckham, Victoria Adams, Posh Spice etc

Victoria Beckham, Victoria Adams, Posh Spice etc

Who and What change - some examples: Eg. What can similarly change over time – PC started off as IBM PC, now there are Dell PCs, Acer PCs, the term PC is more known than IBM PC. How to futureproof and allow for changing names and changing products?

Eg. What can similarly change over time – PC started off as IBM PC, now there are Dell PCs, Acer PCs, the term PC is more known than IBM PC.

How to futureproof and allow for changing names and changing products?

Ambiguity is useful (sometimes) Rather than use a persons name to identify them (which may change) use an identifier. This identifier must be persistent.

Rather than use a persons name to identify them (which may change) use an identifier.

This identifier must be persistent.

Identifiers example - GUIDs type of identifier used in software applications in order to provide a reference number which is unique in any context. Total number of unique keys (2 128 or 3.4×10 38 ) 16- byte (128-bit) number. most commonly written in text as a sequence of hexadecimal digits such as: 3F2504E0-4F89-11D3-9A0C-0305E82C3301

type of identifier used in software applications in order to provide a reference number which is unique in any context.

Total number of unique keys (2 128 or 3.4×10 38 )

16- byte (128-bit) number.

most commonly written in text as a sequence of hexadecimal digits such as:

3F2504E0-4F89-11D3-9A0C-0305E82C3301

Identifiers to the max: Webscale identifiers The same identifier is used by several organisations to uniquely identify the same thing. Eg Music brainz identifier for Victoria Beckham is: ce8dbfe4-3ce7-41e9-9bb3-13e35c053318 Eg Music Brainz identifier for Prince is: 070d193a-845c-479f-980e-bef15710653e

The same identifier is used by several organisations to uniquely identify the same thing.

Eg Music brainz identifier for Victoria Beckham is:

ce8dbfe4-3ce7-41e9-9bb3-13e35c053318

Eg Music Brainz identifier for Prince is:

070d193a-845c-479f-980e-bef15710653e

http://musicbrainz.org/artist/070d193a-845c-479f-980e-bef15710653e

http://www.last.fm/mbid/070d193a-845c-479f-980e-bef15710653e

http://www.bbc.co.uk/music/artists/070d193a-845c-479f-980e-bef15710653e

070d193a-845c-479f-980e-bef15710653e The musicbrainz identifier for the artist ‘Prince’. It doesn’t change, even if he changes his name. This allows carefully built URIs involving Prince to be persistent. It is webscale because it is understood by more than one website. This enables BBC, Musicbrainz and LastFM to exchange data about an artist easily.

The musicbrainz identifier for the artist ‘Prince’.

It doesn’t change, even if he changes his name. This allows carefully built URIs involving Prince to be persistent.

It is webscale because it is understood by more than one website.

This enables BBC, Musicbrainz and LastFM to exchange data about an artist easily.

In fact, identifiers are useful for all websites……..

Google and identifiers in URLs. Persistence is most important. Other sites link to you = higher page rank. Users can bookmark and share persistent content. If you move your pages to new URLs you lose google juice. [ok you can put in a HTTP 301, but its still bad, as Tim BL says ‘Cool URIs don’t change’] [see: http://www.w3.org/Provider/Style/URI ]

Persistence is most important.

Other sites link to you = higher page rank.

Users can bookmark and share persistent content.

If you move your pages to new URLs you lose google juice.

[ok you can put in a HTTP 301, but its still bad, as Tim BL says ‘Cool URIs don’t change’]

[see: http://www.w3.org/Provider/Style/URI ]

Identifiers – Helping us cope with change. Avoid losing your google juice when names change. Unique alpha numeric codes used to uniquely identify a thing. Must be persistent. Use the same identifier across several companies to make information exchange easier.

Avoid losing your google juice when names change.

Unique alpha numeric codes used to uniquely identify a thing.

Must be persistent.

Use the same identifier across several companies to make information exchange easier.

How BBC designs Persistant URIs - tips Persistent URIs are built from our knowledge of the domains we work in…….

Persistent URIs are built from our knowledge of the domains we work in…….

/Programmes Domain

Domain modelling tips: You’re modelling things not web pages. Trying to understand the relationships between the things. I As work with domain experts to model the domain and understand it. Its hard, it takes time to get something you believe in, but it’s a really really important step in semantic web design.

You’re modelling things not web pages.

Trying to understand the relationships between the things.

I As work with domain experts to model the domain and understand it.

Its hard, it takes time to get something you believe in, but it’s a really really important step in semantic web design.

Consider the Episode… Can have a parent brand or series…… Episode 4 of Top Gear series 10 for example…… What is the URI?

URI of Top Gear Series 10 episode 4. Could be: bbc.co.uk/programmes/topgear/series10/episode4.shtml But we don’t put our technology (.shtml) into the URI.

Could be: bbc.co.uk/programmes/topgear/series10/episode4.shtml

But we don’t put our technology (.shtml) into the URI.

We don’t put technology into the URI If users want the document, they don’t mind what technology delivers it, they just want the information at that URI. They don’t want to have to go to different URIs on different devices. Why do they have to remember? Remember everyware? Multiplatform is going to become more of an issue. The technology used might change over the next few years.

If users want the document, they don’t mind what technology delivers it, they just want the information at that URI.

They don’t want to have to go to different URIs on different devices. Why do they have to remember?

Remember everyware? Multiplatform is going to become more of an issue.

The technology used might change over the next few years.

URI of Top Gear Series 10 episode 4 ctd. Could be: bbc.co.uk/topgear/series10/episode4 But from our discussions with the domain masters (editorial staff). The same episode could be broadcast by different brands (Top Gear, Best of Top Gear, Top Gear Take 2 etc). The episode could be reused across different series. The episode could change its title over its lifetime.

Could be:

bbc.co.uk/topgear/series10/episode4

But from our discussions with the domain masters (editorial staff).

The same episode could be broadcast by different brands (Top Gear, Best of Top Gear, Top Gear Take 2 etc).

The episode could be reused across different series.

The episode could change its title over its lifetime.

URI of Top Gear Series 10 episode 4. Oh dear.

URI of Top Gear Series 10 episode 4. In fact the URI of the document about this episode is: http://www. bbc .co.uk/programmes/b0087f0s

URI design and change http://www.bbc.co.uk/programmes/b0087f0s We’ve taken out everything that can change . We’re using our own identifier ( http://www.bbc.co.uk/programmes/b0087f0s ) to label it because there wasn’t a suitable webscale identifier already in semantic web for programmes, and because everything else (title, series, brand etc) could change.

URI design and change continued. http://www.bbc.co.uk/programmes/b0087f0s If it can change (brand, title, series, episode number), we’ve taken it out of the URI.

Categories, taxonomys on the page….not in the URI.

Categories, taxonomys on the page….not in the URI. Because categories and taxonomies will change during the lifetime of the product and your website……

Because categories and taxonomies will change during the lifetime of the product and your website……

URI design to maximise persistance. Know your domain. Work out your business rules. Think about all the things that might change (including each time you redesign the website). Take them out of the URI. www.mycompany.com/products/:product Might be a good place to start, where ‘:product’ is an identifier.

Designing for multiplatform So, how to deliver the document across multiple platforms, at the same URI?

Content negotiation example:

Multiplatform design at the same URI: Delivering the same information but in the most appropriate way for that device. So the RDF document is just the same as the HTML document, but expressed in a different language. The mobile document is the same as the HTML, but perhaps without images, or with the current information emphasised and other information linked to rather than put on the page.

Delivering the same information but in the most appropriate way for that device.

So the RDF document is just the same as the HTML document, but expressed in a different language.

The mobile document is the same as the HTML, but perhaps without images, or with the current information emphasised and other information linked to rather than put on the page.

bbc.co.uk/programmes pages are available in: HTML, RSS, Atom, JSON, RDF, ‘Mobile phone’ representations. Some of these formats are still ‘Beta’ as its something we’re still working on. In fact we can’t do content negotiation on /programmes yet, but we’re planning on doing it, and building our URIs according to that plan.

HTML, RSS, Atom, JSON, RDF, ‘Mobile phone’ representations.

Some of these formats are still ‘Beta’ as its something we’re still working on.

In fact we can’t do content negotiation on /programmes yet, but we’re planning on doing it, and building our URIs according to that plan.

But lets not worry too much: It’s a software engineer thing. So I hope its enough that we know about it. Each representation can be designed to make the best use of that device.

It’s a software engineer thing.

So I hope its enough that we know about it.

Each representation can be designed to make the best use of that device.

Even if we’re not dynamically publishing. We can build persistent URIs, by taking out anything that might change. Then when the site is dynamically served, and can handle multiplatform, we can swap in the dynamically served site at the same URIs. Then we can think about serving different representations for different devices at the same URI.

We can build persistent URIs, by taking out anything that might change.

Then when the site is dynamically served, and can handle multiplatform, we can swap in the dynamically served site at the same URIs.

Then we can think about serving different representations for different devices at the same URI.

Some closing thoughts Think multiplatform, not just web for the PC, and mobile phone but all sorts of ‘everyware’.

Think multiplatform, not just web for the PC, and mobile phone but all sorts of ‘everyware’.

Mobile traffic growing quickly There has been a 15% growth in BBC Mobile since October - now have almost 4m UK users [BBC online reaches 24 million users]

There has been a 15% growth in BBC Mobile since October - now have almost 4m UK users

[BBC online reaches 24 million users]

Ubiquitous User Experience The best user experiences are integrated at every touch point. Big business opportunity?

The best user experiences are integrated at every touch point.

Big business opportunity?

Open your data - stake your claim….. Even if you decide not to build a UX others on the web may be able to do something with your data. Semantic web technologies like RDF offer standard ways to publish data.

Even if you decide not to build a UX others on the web may be able to do something with your data.

Semantic web technologies like RDF offer standard ways to publish data.

Persistence is king…… Above all make your URIs persistent, for your company, for google, and for semantic web.

Above all make your URIs persistent, for your company, for google, and for semantic web.

Thanks! Many thanks to all the /programmes and /music teams, and the IA team: Particularly Michael Smethurst, Deanna Marbeck and Silver Oliver. Many many others…….too many to mention.

Many thanks to all the /programmes and /music teams, and the IA team:

Particularly Michael Smethurst,

Deanna Marbeck and Silver Oliver.

Many many others…….too many to mention.

Contact: [email_address] [email_address] Questions?

Contact:

[email_address]

[email_address]
