Smart Search   and Beyond
Who?            Chris Davenport       Production Leadership TeamSmart Search and Beyond
Solving the search problemSmart Search and Beyond
Old Joomla Search Sucks!                    Cannot rank by                     relevance across                     conten...
Table of Contents01   Smart Search so far02   Smart Search in action03   Smart Search under the hood04   Smart Search tips...
A Short History ‣ Old Joomla Search  • Introduced in Mambo  • Largely unchanged since ‣ JXTended Finder for Joomla 1.5 ‣ F...
Smart Search for Joomla 2.5 ‣ Separate index ‣ Auto-completion ‣ Facetted search ‣ Relevancy ordering ‣ Did you mean? ‣ .....
Table of Contents01   Smart Search so far02   Smart Search in action03   Smart Search under the hood04   Smart Search tips...
Auto-completionSmart Search and Beyond
Another exampleSmart Search and Beyond
Another exampleSmart Search and Beyond
Table of Contents01   Smart Search so far02   Smart Search in action03   Smart Search under the hood04   Smart Search tips...
Under the hoodSmart Search and Beyond
A problem in two halvesSmart Search and Beyond
First half: Indexing             INDEX             Raw dataSmart Search and Beyond
Second half: Querying     Search    INDEX   Search     queries           resultsSmart Search and Beyond
Search resultsSearch results are rendered purely fromdata in the index, not the raw data.Smart Search and Beyond
IndexingSmart Search and Beyond
Indexing      Parsing          Stemming    Tokenisation        Analysis Token aggregation   Term weighting     Filtration ...
Terms indexSmart Search and Beyond
Parsing ‣ Extract plain text from raw data  • HTML, RTF supported out-of-the-box  • PDF, MS Word could be supported ‣ For ...
Tokenisation ‣ Fold to lowercase ‣ Special handling for plus, dash, comma,   dot and quotes ‣ Remove non-alphanumerics ‣ R...
Token aggregationOn a clear disk you can seek foreveron             a              clearon a           a clear        clea...
Filtration ‣ “Stop word removal”  • Not removed, just given a low weight ‣ jos_finder_terms_common ‣ English only  • Other...
Stemmingfishingfished               fishfisherfishSmart Search and Beyond
Stemming ‣ “Snowball” is used by default  • Danish, German, English, Spanish, Finnish,    French, Hungarian, Italian, Norw...
Morphological analysis ‣ Currently uses Soundex ‣ Not used in search as such ‣ Used for the “Did you mean?” feature ‣ If n...
Term weightingContext         MultiplierTitle           1.7Text            0.7Meta            1.2Path            2.0Miscel...
ClassificationSmart Search and Beyond
Taxonomies ‣ “Content maps” in Administrator ‣ Basis for facetted search ‣ Multi-level taxonomies not fully   supported (y...
Taxonomies - drop-downsSmart Search and Beyond
Taxonomies - checkboxesSmart Search and Beyond
Taxonomies - linksSmart Search and Beyond
Database ERDSmart Search and Beyond
Smart Search Plug-ins               /plugins   /content     /finder     /system    /finder   /categories   /highlight     ...
Smart Search Plug-inscontent/finder           finder/[type]  onContentBeforeSave         onFinderBeforeSave   onContentAft...
Query parsing                      URI argument      Query stringTerms                 q=Some+text       Some textPhrases ...
Results rendering ‣ com_finder  • search                  Search results    ‣ default.php           page    ‣ form.php    ...
Layout overrides exampleSmart Search and Beyond
Alternative overrideSmart Search and Beyond
Table of Contents01   Smart Search so far02   Smart Search in action03   Smart Search under the hood04   Smart Search tips...
Tips and tricksSmart Search and Beyond
Tips and tricks ‣ HTML Parser  • Invalid HTML can confuse the parser  • Invalid UTF8 is ignored  • Text in attributes is i...
When to do a purge ‣ Indexing is incremental so most of the time you dont   need to. ‣ Changes to taxonomies that do not i...
Tuning Smart Search ‣ Use the CLI for indexing  • http://docs.joomla.org/Setting_up_automatic_Smart_    Search_indexing ‣ ...
Table of Contents01   Smart Search so far02   Smart Search in action03   Smart Search under the hood04   Smart Search tips...
Where next?Smart Search and Beyond
Search Working Group ‣ Meeting at J and Beyond  • 19 May 2012 11:30 AM ‣ Stable ready for merge July 2012 ‣ Joomla 3.0 rel...
Improved language support ‣ Improve common word support ‣ Improve stemmer support  • Native PHP stemmers? ‣ Improve morpho...
Other possibilities ‣ Preserve static filters on purge/index ‣ Decouple indexing via message queues ‣ Easier support for r...
Search API ‣ Very important going forward ‣ Too big a leap for Joomla 3.0 ‣ Develop in parallel during 3.x cycle ‣ Use in ...
Documentationhttp://docs.joomla.org/Category:Smart_SearchSmart Search and Beyond
Questions?Smart Search and Beyond
Dont forget   Search Working Group         Meeting    Saturday 19 May 2012          11:30 AMSmart Search and Beyond
Haystack - Mark Duncan CC-BY-SA 2.0 Generic http://commons.wikimedia.org/wiki/File%3AHaystack_-_geograph.org.uk_-_462934.j...
