Scale Your Data Tier with Windows Server AppFabric<br />Chris Dufour, ASP MVP<br />Software Architect, Compuware<br />chri...
Agenda<br />
Simple<br />Do the simplest thing that will possibly work<br />
Scalability<br />Able to support the required quality of service as the system load increases<br />-Wiktionary<br />
Typical Web Architecture<br />
Web Explosion<br />Web Site’s too slow!!<br />Where did my shopping cart go?<br />IIS/ASP.NET<br />IIS/ASP.NET<br />IIS/AS...
Agenda<br />
Data Near Processing<br />Cache<br />Cache<br />Browser<br />Smart Client<br />Cache<br />Web Service<br />Cache<br />ASP....
Good but…<br />Cache is scoped to machine  / process<br />Machines die<br />Processes recycle<br />Cache memory is limited...
What if?<br />You could have as much cache as you wanted?<br />You could share a giant cache across servers, services and ...
Windows Server AppFabric<br />AppFabric<br />CACHING<br />WORKFLOW HOSTING<br />SERVICE HOSTING<br />MONITORING<br />SCALE...
Unified Cache View<br />What is AppFabric Caching?<br />An explicit, distributed, in-memory application cache for all kind...
AppFabric Cache<br />
Data Distribution - Partitioned Cache<br />…<br />Web Tier<br />ASP.Net App<br />ASP.Net App<br />ASP.Net App<br />Caching...
Scale Test Output<br />Load<br />1 Cache Server<br />As load increases, <br />throughput fails <br />to scale <br />latenc...
Add a Second Cache Server<br />Load<br />Load Max<br />Throughput increases<br />Latency decreases<br />Caching Tier<br />...
Add a Second Cache Server<br />Load<br />Caching Tier<br />Throughput<br />Latency<br />
Associated Press<br />Caches metadata and news<br />Serves 16 million hits per day<br />Increased the amount of cached dat...
System.Web.Cache<br />
AppFabricDataCache<br />
Copy Client DLLs<br />Update Web.config<br />…<br />.NET 3.5 SP1 OR .NET 4<br /><hosts><br />      <host name="BL1CDB80837...
Usage Pattern – Cache Aside  (Explicit Caching)<br />//  Read from Cache<br />Toy toyObj = (Toy)<br />catalog.Get("toy-101...
Administration<br />PowerShell cmdlets are used to administer the cache cluster	<br />Rich set of cmdlets for <br />Cache ...
Hello AppFabric Cache<br />
Using PowerShell<br />Remember – PowerShell can also be called from .NET Code!<br />
Security<br />Domain Based Security Option<br />Domain Account / Local Account based Authentication<br />Only authorized s...
Logical Hierarchy<br />AppFabric Caching Service<br />AppFabric Caching Service<br />AppFabric Caching Service<br />AppFab...
AppFabric Caching API<br />// Create instance of cachefactory (reads appconfig)<br />DataCacheFactory fac = new DataCacheF...
Access APIs – Tagging Items<br />Tag hotItem  = new Tag("hotItem");<br />catalog.Put("toy-101", new Toy("Puzzle"),<br />ne...
Types of Data<br />Grocery Shop<br /> Web Tier<br />Shopping Cart<br />Grocery Inventory<br />Distributed Cache<br />     ...
Reference Data – Performance<br />Catalog data doesn’t change often<br />Unnecessary network cost to access from different...
Reference Data – Bulk Get<br />Bulk Fetch from region<br />200-300k ops per second<br />Fewer network calls<br />Catalog.B...
Activity Data – Session Integration<br />Load Balance Requests<br />No more sticky routing<br /><sessionState  mode="Custo...
Application<br />Application<br />Activity Data - Availability<br />PUT<br />Get(K2)<br />AppFabric Caching Client<br />Ap...
Resource Data - Optimistic Locking<br />GetCacheItem returns a version object<br />Every update to an object internally in...
Resource Data - Pessimistic Locking<br />Client1: <br />GetAndLock ("k1")<br />Client3:<br /> Get ("k1")<br />Client2:<br ...
Data Race<br />GET<br />GET<br />GET<br />
Lock Non-Existent Key<br />GET/LOCK<br />GET/LOCK<br />GET/LOCK<br />Cache  Service<br />Cache  Service<br />Caching  Serv...
Composite Race<br />CALL<br />WAIT<br />WAIT<br />Cache  Service<br />Cache  Service<br />Caching  Service<br />
Composite Race<br />PUT<br />UNLOCK<br />GET<br />GET<br />Cache  Service<br />Cache  Service<br />Caching  Service<br />
Resource/Activity Data – Tracking Changes<br />Cache Event notifications<br />Register on any client to notify changes<br ...
Register Notification for Key “K3"<br />Call Delegate<br />Store Last LSN <br />Application<br />Map Keys to Partition<br ...
Agenda<br />
Pre-Fetch<br />Hospital<br />Data Center<br />
Pre-Fetch<br />Remote Clinic<br />Hospital<br />Slow!!<br />Data Center<br />WAN<br />
Pre-Fetch<br />Hospital<br />Remote Clinic<br />Data Center<br />Cache  Service<br />WAN<br />
Agenda<br />
Web Platform Installer<br />
Select Enterprise<br />
Install AppFabric<br />
Install AppFabric<br />
endpoint.tv<br />
AppFabric on MSDN<br />http://msdn.microsoft.com/AppFabric<br />
