Memcached
             http://download.tangent.org/talks/Memcached%20Study.pdf




Thursday, April 23, 2009
memcached is a high-performance, distributed memory object
                           caching system, generic in nature, b...
Who?
                     • Facebook
                     • Yahoo
                     • Amazon
                     • Liv...
Why?
                           (aka why would I...)‫‏‬




Thursday, April 23, 2009
Thursday, April 23, 2009
LiveJournal

                     • Origin of memcached
                     • 30G of cache. Terabytes of data
           ...
Mixi

                     • Memcached on dedicated servers
                     • 300 servers in production (reuse old
  ...
Thursday, April 23, 2009
Patrick Lenz
                           Eins.de
                           http://poocs.net




Thursday, April 23, 2009
Grazr



Thursday, April 23, 2009
100+ Nodes
                  2gigs a Node         Processing



                                                    Incomi...
How



Thursday, April 23, 2009
Server

                     • Slab Allocator
                     • Libevent based
                     • Simple Protocol...
Clients


                     •     Client hashes Key to Server List (distribution)‫‏‬

                     •     Serial...
Consistent Hash




Thursday, April 23, 2009
So what should I ask?

                     • How do I dump data?
                     • How is it redundant? *
          ...
Details on the Server?

                           • set/get/replace/add
                           • append/prepend
     ...
Platforms

                     • FreeBSD and Linux are top tier
                     • Windows exists
                   ...
Examples



Thursday, April 23, 2009
Ruby



Thursday, April 23, 2009
 # Set up client object

                            require 'memcache'
                            servers = ['127.0.0.1:...
# Get; fall through to Rails' MySQL load if missing

                            key = "recent_posts"
                    ...
# Ghetto locking implementation for memcache-client
                            # from http://fauna.rubyforge.org/svn/inte...
PHP



Thursday, April 23, 2009
/**
           * Initalize Memcache object and add local server 127.0.0.1 using port 11211
           */
          $cache ...
/** Look in cache, if not found, set object (misses null) **/
                       if (!$user = $cache->get($user_key)) ...
/* Get user counter value (does not handle add fail) */
                       if (!$counter = $cache->get($counter_key)) ...
/* Print out stats from memcached server */
                           print_r($cache->getStats());

                     ...
C



Thursday, April 23, 2009
libmemcached

                     • C/C++ (many language wrappers)
                     • Multiget support
              ...
memcached_st *memc;
                           memcached_return rc;
                           memc= memcached_create(NULL...
memcached_server_st *servers;
                 memcached_st *memc= memcached_create(NULL);
                 char servernam...
char *key= "foo";
                           char *value;
                           size_t value_length= 8191;
          ...
memcached_return rc;
            char *keys[]= {"fudge", "son", "food"};
            size_t key_length[]= {5, 3, 4};
     ...
Memcached foo;
                           char *value_set= "Data for server A";
                           char *master_ke...
Application Integration



Thursday, April 23, 2009
lighttpd/mod_memcache
                    • Cache files from disk
                    • Specify mime/types
                ...
Apache (mod_memcached)‫‏‬
                    • CAS operations exposed
                    • GET/PUT/DELETE operations
   ...
NGINX
                     • Support variable Time outs
                     • Based on Perl
                     • http:/...
Memcached Functions
                          for MySQL
                         (and Drizzle)



Thursday, April 23, 2009
Overview...

                     • Uses UDF API and libmemcached
                     • Manage memcached Cluster via SQL
...
Thursday, April 23, 2009
Installation

                     •     CREATE FUNCTION memc_servers_add RETURNS INT SONAME
                           "l...
Functions Available
                     • memc_servers_set();
                     • memc_servers_behavior_set()
        ...
Setting via SELECT
           select id, url, memc_set(concat('feeds', md5(url)), url) from feeds;

           select memc...
Trigger
          DROP TRIGGER IF EXISTS feed_insert;
          CREATE TRIGGER feed_insert BEFORE INSERT ON feeds FOR EACH...
Memcached Replication
                      via MySQL

                  INSERT INTO table_a VALUES (“key”, “value”, “valu...
Implementation



Thursday, April 23, 2009
Limits

                     • Key Size (250 bytes) (1.2 <)‫‏‬
                     • Data Size (under 1 megabyte)‫‏‬
    ...
LRU
                    • Least recently accessed items are up for
                           eviction

                  ...
Threads
                    • No single-threading in versions past 1.2
                    • Great for large instances (16...
Slab Allocator

                     • Memory permanently allocated from OS
                     • Classes created by chun...
Binary Protocol

                            24             HEADER                  Required
                            b...
Binary Protocol
                            MAGIC          Opcode              Key Length
                             (1 ...
Response Header
                            MAGIC          Opcode              Key Length
                             (1 ...
Tools



Thursday, April 23, 2009
Protocol

                     • Telnet’able (see doc/protocol.txt)‫‏‬
                     • Store commands are binary (n...
Thursday, April 23, 2009
memcached-tool

                     • Example minimal monitoring tool
                     • Shows details of server stat...
libmemcached Tools

                     • memcp
                     • memrm
                     • memstat
             ...
MRTG


                     • Plenty of interfaces monitored
                     • Old technology, been around forever


...
Thursday, April 23, 2009
...and others

                     • Cacti
                      • http://dealnews.com/developers/cacti/
                ...
Current Connections




Thursday, April 23, 2009
Requests Per Second




Thursday, April 23, 2009
DTrace

                     • User static DTrace probes to probe
                           application logic

          ...
Tuning



Thursday, April 23, 2009
Connections
                     • Don't fear setting -c (max conns) too high!
                     • Watch 'listen_disabl...
Memory
                     • Don't set -m (max bytes) too high
                     • -m only controls memory for stored ...
Things to remember!
                     • Memcached is great for scaling, but abuse
                           will slow ...
Shrink data!
                     • Especially if you use multiget, try to use
                           shorter keys

  ...
Future Solutions!
                     • Evaluate the binary protocol in 1.3
                     • New tricks will be pos...
1.2.8
                     • Bugfixes
                     • New stats
                      • listen_disabled_num
        ...
1.3.* Beta

                     • Scalability improvements
                     • New stats (per-slab get/miss/etc counte...
ASCII Protocol vs Binary Protocol (memcached-1.3.1 Development Branch)
         task completion time (secs)




          ...
Future
            • 1.4.0 stable
             • Multiple Engine Support
             • Durable
             • Highly Thre...
More Resources...
                     • http://danga.com/memcached/
                     • #memcached on Freenode
       ...
