  • 1. SULPHATE ATTACK
  • 2. WHERE DOES SULPHATE ATTACK OCCUR?
    • SULPHATE ATTACK OCCURS MOST COMMONLY IN……..
    • MORTAR CONCRETE (FOUNDATIONS & FLOORS)
    • RISING WALLS
    • FLUE LINERS & CHIMNEYS
  • 3. SULPHATE ATTACK IN MORTAR
    • THIS OCCURS WHEN…
    • THE SOLUBLE SULPHATE SALTS WITHIN SOME CLAY BRICKS REACT WITH A CONSTITUENT (TRICALCIUM ALUMINATE) OF THE PORTLAND CEMENT WITHIN MORTAR
  • 4. SULPHATE ATTACK IN MORTAR CONTINUED.
    • THE RESULT OF THIS REACTION IS THE FORMATION OF CALCIUM SULFOALUMINATE, A CRYSTAL WHICH EXPANDS DURING ITS FORMATION - CAUSING CRACKING WITHIN THE MORTAR JOINT
  • 5. WHEN DOES IT OCCUR IN MORTAR ?
    • ONLY OCCURS ON BRICKWORK WHICH HAS BEEN EXPOSED TO SATURATION.
    • THESE INCLUDE AREAS SUCH AS RISING WALLS, PARAPETS, BRICK CAPPINGS, CHIMNEY STACKS OR WHEN BRICKWORK HAS BEEN EXPOSED TO AN EXCEPTIONAL AMOUNT OF RAINFALL
  • 6. SIGNS & EFFECTS SIGNS OF SULPHATE ATTACK IN MORTAR?
    • MORTAR JOINTS TURNING A LIGHTER COLOUR AND BEGINNING TO CRACK IN THEIR CENTRE
    • INSIDE OF THE MORTAR JOINT CRUMBLING
    • EXPANSION OF THE JOINT LEADING TO SPALLING OF THE BRICK FACE OR DISTORTION OF THE WALL
  • 7.
  • 8. Prevention
    • PREVENT BRICKWORK BECOMING SATURATED WHERE POSSIBLE USE FROST RESISTANT BRICKS THAT CONTAIN SMALL AMOUNTS OF SALT
    • USE SULPHATE-RESISTING CEMENT – WHICH CONTAINS LIMITED AMOUNTS OF TRI-CALCIUM ALUMINATE. (STRONG MORTAR MIXES (1:4) CAN ALSO HELP PREVENT ITS OCCURRENCE)
    • ALTHOUGH A CEMENT RICH MORTAR CONTAINS MORE OF THE CONSTITUENTS THAT REACT WITH THE SULFATES, DENSER MORTARS RESIST WATER PENETRATION & ARE MORE ABLE TO RESIST DISRUPTION
  • 9. SULPHATE ATTACK IN CONCRETE
    • CONCRETE IN CONTACT WITH SOIL THAT CONSISTS OF HIGH LEVELS OF SULPHATE CAN SUFFER ATTACK.
    • MEASURES OF SULPHATE LEVELS IN SOILS ARE OFTEN TAKEN AND TESTED TO CHECK WHETHER SPECIAL CEMENTS NEED TO BE INCORPORATED INTO A CONCRETE MIX TO PREVENT SUCH ATTACK
  • 10. SULPHATE RESISTING CEMENT
    • CONCRETE LAID IN SOILS CONTAINING SULPHATE SHOULD NOT CONTAIN ORDINARY PORTLAND CEMENT. INSTEAD IT SHOULD CONTAIN SULPHATE RESISTING CEMENT
  • 11. SULPHATE ATTACK IN CONCRETE
  • 12. SULPHATE ATTACK IN RISING WALLS
    • BECAUSE RISING WALLS ARE EXPOSED TO SOIL SULPHATES AND SATURATION THEY ARE PARTICULARLY VULNERABLE TO SULPHATE ATTACK.
    • BOTH THE BLOCK AND THE MORTAR NEED TO BE RESISTANT TO SULPHATE ATTACK
  • 13. EXTERNAL ATTACK
    • AS SULPHATES IN BRICKS CAN DISSOLVE IN RAINWATER, THEY CAN MIGRATE INTO THE MORTAR JOINTS CAUSING EXPANSION DUE TO THEIR REACTION WITH TRICALCIUM ALUMINATE IN THE CEMENT
  • 14. SULPHATE ATTACK IN FLUE LINERS & CHIMNEYS
    • DUE TO THE EXPOSED NATURE OF A CHIMNEY STACK IT MAY BE VULNERABLE TO SULPHATE ATTACK.
    • SULPHATE ATTACK CAN OCCUR EXTERNALLY AND/OR INTERNALLY ON A CHIMNEY
  • 15.
    • A COMMON EFFECT SULPHATE ATTACK HAS ON CHIMNEYS IS TO CAUSE IT TO LEAN SIGNIFICANTLY
    Image Source: www. e​n​v​i​r​o​n​m​e​n​t​7​.​u​w​e​.​a​c​.​u​k​/​r​e​s​o​u​r​c​e​s​/​c​o​n​ s​t​r​u​c​t​i​o​n​s​a​m​p​l​e​/​C​o​n​w​e​b​/​h​e​a​t​i​n​g​/​c​h​i​m​n​ e​y​s​/​s​e​c​t​i​o​n​6​.​h​t​m
  • 16. INTERNAL ATTACK
    • A RESULT OF WATER VAPOURS BEING PRESENT IN GASES TRAVELLING UP THE FLUE WHICH OFTEN CONTAIN SULPHER DIOXIDES
    • WHEN THE GASES MEET A COLD POINT IN THE FLUE - CONDENSATION OCCURS (WHICH CONTAINS SULPHER DIOXIDE)
    • THEN MIGRATES INTO THE MORTAR JOINTS BETWEEN THE FLUELINERS FORMING CALCIUM SULFOALUMINATE AND SUBSEQUENTLY, SULPHER ATTACK.
  • 17. REPAIR
    • SULPHATE ATTACK IS VIRTUALLY IMPOSSIBLE TO STOP. RE-BUILDING IS USUALLY THE ONLY OPTION!!
    • However…….
  • 18. SULPHATE ATTACK? SALT EROSION? WALL TIE FAILURE? WHICH ONE?? Sulphate Attack? Wall Tie Failure? How do we know it isn’t all three causes? Salt Erosion?
  • 19. As trained ISSE surveyors….
    • THE PROPERTY IS EVALUATED BY MEANS OF A COMPREHENSIVE INSPECTION CHECK LIST WHICH TAKES INTO ACCOUNT:
    • THE PRESENCE OF MOISTURE IN INTERNAL WALLS
    • THE TYPE OF SOIL IS EXAMINED FOR LIKELIHOOD OF SULPHATES AND THE GEOLOGICAL MAP IS USED TO FLAG AREAS OF HIGH SULPHATE CONTENT
    • IN STRUCTURAL MATTERS SUCH AS WALL TIES A TIE CAN BE LOCATED WITH A METAL DETECTOR AND THE END CHECKED FOR CORROSION – AGE OF STRUCTURE IS ALSO IMPORTANT
    • IN THE CASE OF WALL TIES BUILDINGS OVER 50 YEARS OLD ARE AT RISK THUS THE INSTALLATION OF NEW TIES WOULD BE RECOMMENDED TO RESTORE STABILITY WHERE TIES HAVE CORRODED
    • A SAMPLE OF MASONRY CAN ALSO BE TESTED FOR PRESENCE OF SULPHATE

×
