  • Should:
    * Represent the services offered by the page to the test developer
    * Internally knows the details about how these services are offered and the details of UI elements that offer them
    * Return other page objects to model the user’s journey through the application
    * Different results of the same operation modeled differently
  • Should not:
    * Expose details about user interface elements
    * Make assertions about the state of the UI













  • SWTBot Tutorial

    1. 1. SWTBot Essentials Chris Aniszczyk http://aniszczyk.org caniszczyk@gmail.com
    2. 2. Agenda introduction exercises setting up the environment SWTBot API how does it work? conclusion and Q&A
    3. 3. UI Testing It’s not easy, natural brittleness... manual vs. automated testing deciding what to test
    4. 4. UI Testing Challenges
    5. 5. Challenges Identifying Controls
    6. 6. Challenges Similar looking controls
    7. 7. Similar looking controls
    8. 8. Moving controls
    9. 9. Challenges Sending “events” to controls
    10. 10. Challenges Manage SWT Threading
    11. 11. Challenges Tests to be non-blocking
    12. 12. Challenges Run in a separate thread Still manage synchronization between threads
    13. 13. Challenges Internationalization (i18n) and Localization (L10n)
    14. 14. Challenges Readability
    15. 15. Hands on exercises! Learn by doing.
    16. 16. All exercises focus around... creating a java project “MyFirstProject” create a java class type in a program that prints “Hello, World” execute the program verify that the program printed “Hello, World”
    17. 17. Exercise 0: Setup Test01.java
    18. 18. Objectives Setup SWTBot Run a test with the SWTBot launch configuration
    19. 19. Setting up the Environment Use Eclipse 3.6 Install SWTBot via update site http://www.eclipse.org/swtbot/downloads.php
    20. 20. Create a plugin project “org.eclipse.swtbot.examples”
    21. 21. Setup Dependencies org.eclipse.ui org.eclipse.core.runtime org.eclipse.swtbot.eclipse.finder org.eclipse.swtbot.junit4_x org.eclipse.swtbot.swt.finder org.junit4
    22. 22. Create a new plugin project
    23. 23. Create a simple Test @RunWith(SWTBotJunit4ClassRunner.class) public class Test01 { @Test public void thisOneFails() throws Exception { fail("this test fails"); } @Test public void thisOnePasses() throws Exception { pass(); } }
    24. 24. Run the first test
    25. 25. SWTBot API Introduction
    26. 26. Finding widgets SWTWorkbenchBot bot = new SWTWorkbenchBot(); SWTBot[Widget] widget = bot.[widget][With][Matcher(s)](); SWTBotText text = bot.textWithLabel("Username:"); Think of the bot as something that can do tasks for you (e.g., find widgets, click on them, etc.)
    27. 27. Finding obscure widgets Use matchers and WidgetMatcherFactory! withLabel("Username:") Matcher pushButtonToProceedToNextStep = allOf( withMnemonic("Finish") widgetOfType(Button.class), withText("&Finish") withStyle(SWT.PUSH), inGroup("Billing Address") withRegex("Proceed to step (.*) >") widgetOfType(Button.class) ); withStyle(SWT.RADIO) withTooltip("Save All") SWTBotButton button = new SWTBotButton( withRegex("Welcome, (.*)") (Button) bot.widget(pushButtonToProceedToNextStep) );
    28. 28. Performing actions button.click() // click on a button // chain methods to make them concise bot.menu("File").menu("New").menu("Project...").click(); tree.expand("Project").expand("src").expand("Foo.java").contextMenu("Delete").clic k(); // delete Foo.java list.select("Orange", "Banana", "Mango"); // make a selection in a list list.select(2, 5, 6); // make a selection using indexes
    29. 29. Exercise 1: Hello SWTBot SWTBotTest01.java
    30. 30. Objectives Get introduced to the SWTBot API SWTWorkbenchBot is your friend Tasks beforeClass() - close the welcome view canCreateANewProject() - create a java project Run the test! Ensure SWTBot logging works
    31. 31. beforeClass() @BeforeClass public static void beforeClass() throws Exception { bot = new SWTWorkbenchBot(); bot.viewByTitle("Welcome").close(); }
    32. 32. canCreateANewProject() @Test public void canCreateANewJavaProject() throws Exception { bot.menu("File").menu("New").menu("Project...").click(); SWTBotShell shell = bot.shell("New Project"); shell.activate(); bot.tree().select("Java Project"); bot.button("Next >").click(); bot.textWithLabel("Project name:").setText("MyFirstProject"); bot.button("Finish").click(); }
    33. 33. Seeing log messages?
    34. 34. How does it work? Magic?
    35. 35. )"*#(+,,( -"#$%&'( !"#$%&'(
    36. 36. Redundancy and Failure Proofing
    37. 37. )"*#(+,,( -"#$%&'( !"#$%&'(
    38. 38. Find all widgets Depth first traversal of UI elements 1.Find top level widgets 1.Find children of each widget 2.For each child do (1) and (2)
    39. 39. Finding widgets public SWTBotTree treeWithLabelInGroup(String l, String g, int i) { // create the matcher Matcher matcher = allOf( widgetOfType(Tree.class), withLabel(l), inGroup(g) ); // find the widget, with redundancy built in Tree tree = (Tree) widget(matcher, index); // create a wrapper for thread safety // and convinience APIs return new SWTBotTree(tree, matcher); }
    40. 40. Thread Safety Tests should run in non-ui thread query state of a widget change state of a widget
    41. 41. Thread Safety (Query state) public class SWTBotCheckBox { public boolean isChecked() { // evaluate a result on the UI thread return syncExec(new BoolResult() { public Boolean run() { return widget.getSelection(); } }); } }
    42. 42. Thread Safety(change state) public class SWTBotCheckBox { public void select() { asyncExec(new VoidResult() { public void run() { widget.setSelection(true); } }); notifyListeners(); } protected void notifyListeners() { notify(SWT.MouseDown); notify(SWT.MouseUp); notify(SWT.Selection); } }
    43. 43. Exercise 2: More SWTBot SWTBotTest02.java
    44. 44. Objectives Tasks canCreateANewJavaClass() create a new java class: HelloWorld Source folder: MyFirstProject/src Package: org.eclipsecon.project Click Finish! Run the test!
    45. 45. canCreateANewJavaClass() @Test public void canCreateANewJavaClass() throws Exception { bot.toolbarDropDownButtonWithTooltip("New Java Class").menuItem("Class").click(); bot.shell("New Java Class").activate(); bot.textWithLabel("Source folder:").setText("MyFirstProject/src"); bot.textWithLabel("Package:").setText("org.eclipsecon.project"); bot.textWithLabel("Name:").setText("HelloWorld"); bot.button("Finish").click(); }
    46. 46. Exercise 3: SWTBotEditor SWTBotTest03.java
    47. 47. Objectives Tasks canTypeInTextInAJavaClass() open a file: HelloWorld.java set some text in the Java file canExecuteJavaApplication() Run the Java application Run the test!
    48. 48. canTypeInTextInAJavaClass() @Test public void canTypeInTextInAJavaClass() throws Exception { Bundle bundle = Activator.getContext().getBundle(); String contents = FileUtils.read(bundle.getEntry("test-files/HelloWorld.java")); SWTBotEditor editor = bot.editorByTitle("HelloWorld.java"); SWTBotEclipseEditor e = editor.toTextEditor(); e.setText(contents); editor.save(); }
    49. 49. canExecuteJavaApplication() @Test public void canExecuteJavaApplication() throws Exception { bot.menu("Run").menu("Run").click(); // FIXME: verify that the program printed 'Hello World' }
    50. 50. SWTBotEditor
    51. 51. Exercise 4: Matchers SWTBotTest04.java
    52. 52. Objectives Learn about SWTBot and the Matcher API Tasks canExecuteJavaApplication() Run the Java application Grab the Console view Verify that “Hello World” is printed Run the tests!
    53. 53. canExecuteJavaApplication() @Test public void canExecuteJavaApplication() throws Exception { bot.menu("Run").menu("Run").click(); SWTBotView view = bot.viewByTitle("Console"); Widget consoleViewComposite = view.getWidget(); StyledText console = bot.widget(WidgetMatcherFactory.widgetOfType(StyledText.class), consoleViewComposite); SWTBotStyledText styledText = new SWTBotStyledText(console); assertTextContains("Hello World", styledText); }
    54. 54. Matchers Under the covers, SWTBot uses Hamcrest Hamcrest is a framework for writing ‘match’ rules SWTBot is essentially all about match rules bot.widget(WidgetMatcherFactory.widgetO fType(StyledText.class), consoleViewComposite);
    55. 55. WidgetMatcherFactory
    56. 56. Creating matchers WidgetMatcherFactory is your friend! withText("Finish") withLabel("Username:") withRegex("Proceed to step (.*)") widgetOfType(Button.class) withStyle(SWT.ARROW, "SWT.ARROW")
    57. 57. Combining matchers allOf(matchers...) anyOf(matchers...) not(matcher) allOf(anyOf(matchers...), matchers...)
    58. 58. Exercise 5: Waiting SWTBotTest05.java
    59. 59. Objectives Learn about waiting and SWTBot Condition API Tasks afterClass() Select the Package Explorer view Select MyFirstProject Right click and delete the project Run the test!
    60. 60. afterClass() @AfterClass public static void afterClass() throws Exception { SWTBotView packageExplorerView = bot.viewByTitle("Package Explorer"); packageExplorerView.show(); Composite packageExplorerComposite = (Composite) packageExplorerView.getWidget(); Tree swtTree = (Tree) bot.widget(WidgetMatcherFactory.widgetOfType(Tree.class), packageExplorerComposite); SWTBotTree tree = new SWTBotTree(swtTree); tree.select("MyFirstProject"); bot.menu("Edit").menu("Delete").click(); // the project deletion confirmation dialog SWTBotShell shell = bot.shell("Delete Resources"); shell.activate(); bot.checkBox("Delete project contents on disk (cannot be undone)").select(); bot.button("OK").click(); bot.waitUntil(shellCloses(shell)); }
    61. 61. Handling long operations describe a condition poll for the condition at intervals wait for it to evaluate to true or false of course there’s a timeout SWTBot has an ICondition
    62. 62. ICondition
    63. 63. Handling Waits private void waitUntil(ICondition condition, long timeout, long interval) { long limit = System.currentTimeMillis() + timeout; condition.init((SWTBot) this); while (true) { try { if (condition.test()) return; } catch (Throwable e) { // do nothing } sleep(interval); if (System.currentTimeMillis() > limit) throw new TimeoutException("Timeout after: " + timeout); } }
    64. 64. Conditions is your friend
    65. 65. Building Abstractions
    66. 66. Abstractions are good! They simplify writing tests for QA folks Build page objects for common “services” Project Explorer The Editor The Console View The main menu bar, tool bar
    67. 67. Model Capabilities Create a project Delete a project Create a class Execute a class more...
    68. 68. Domain Objects
    69. 69. Domain Objects? Represent the operations that can be performed on concepts
    70. 70. Sample Domain Object public class JavaProject { public JavaProject create(String projectName){ // create a project and return it } public JavaProject delete(){ // delete the project and return it } public JavaClass createClass(String className){ // create a class and return it } }
    71. 71. Page Objects http://code.google.com/p/webdriver/wiki/PageObjects
    72. 72. Page Objects? Represent the services offered by the page to the test developer Internally knows the details about how these services are offered and the details of UI elements that offer them Return other page objects to model the user’s journey through the application Different results of the same operation modeled
    73. 73. Page Objects... should not Expose details about user interface elements Make assertions about the state of the UI
    74. 74. A Sample Page Object public class LoginPage { public HomePage loginAs(String user, String pass) { // ... clever magic happens here } public LoginPage loginAsExpectingError(String user, String pass) { // ... failed login here, maybe because one or both of // username and password are wrong } public String getErrorMessage() { // So we can verify that the correct error is shown } }
    75. 75. Using Page Objects // the bad test public void testMessagesAreReadOrUnread() { Inbox inbox = new Inbox(driver); inbox.assertMessageWithSubjectIsUnread("I like cheese"); inbox.assertMessageWithSubjectIsNotUndread("I'm not fond of tofu"); } // the good test public void testMessagesAreReadOrUnread() { Inbox inbox = new Inbox(driver); assertTrue(inbox.isMessageWithSubjectIsUnread("I like cheese")); assertFalse(inbox.isMessageWithSubjectIsUnread("I'm not fond of tofu")); }
    76. 76. LoginPage login = new LoginPage(); HomePage home = login.loginAs("username", "secret"); SearchPage search = home.searchFor("swtbot"); assertTrue(search.containsResult("http://eclipse.org/swtbot"));
    77. 77. Exercise 6: Abstractions SWTBotTest06.java
    78. 78. Objectives Learn about page and domain objects Tasks Create a NewProjectBot Opens the new project wizard Allows you to set the project name and click finish Modify canCreateANewJavaProject() Run the test!
    79. 79. NewProjectBot public class NewProjectBot { private static SWTWorkbenchBot bot; public NewProjectBot() { bot.menu("File").menu("New").menu("Project...").click(); bot.shell("New Project").activate(); bot.tree().select("Java Project"); bot.button("Next >").click(); } public void setProjectName(String projectName) { bot.textWithLabel("Project name:").setText(projectName); } public void finish() { bot.button("Finish").click(); } }
    80. 80. Modify Project Wizard Code @Test public void canCreateANewJavaProject() throws Exception { // use the NewProjectBot abstraction NewProjectBot newProjectBot = new NewProjectBot(); newProjectBot.setProjectName("MyFirstProject"); newProjectBot.finish(); assertProjectCreated(); }
    81. 81. Best Practices & Tips
    82. 82. Logging Turn logging on always, it helps :) http://wiki.eclipse.org/SWTBot/ FAQ#How_do_I_configure_log4j_to_turn_on _logging_for_SWTBot.3F
    83. 83. Slow down executions Useful for debugging at times... SWTBotPreferences.PLAYBACK_DELAY -Dorg.eclipse.swtbot.playback.delay=20 or via code... long oldDelay = SWTBotPreferences.PLAYBACK_DELAY; // increase the delay SWTBotPreferences.PLAYBACK_DELAY = 10; // do whatever // set to the original timeout of 5 seconds SWTBotPreferences.PLAYBACK_DELAY = oldDelay;
    84. 84. Changing Timeout SWTBotPreferences.TIMEOUT -Dorg.eclipse.swtbot.search.timeout=10000 or via code... long oldTimeout = SWTBotPreferences.TIMEOUT; // increase the timeout SWTBotPreferences.TIMEOUT = 10000; // do whatever // set to the original timeout of 5 seconds SWTBotPreferences.TIMEOUT = oldTimeout;
    85. 85. Identifiers In our examples, we used labels as matchers mostly SWTBot allows you to use IDs as matchers IDs are less brittle than labels! text.setData(SWTBotPreferences.DEFAULT_ KEY,”id”) bot.textWithId(“id”)
    86. 86. Page Objects Use Page Objects to simplify writing tests Allows more people than just normal devs to write tests
    87. 87. More SWTBot? Eclipse Forms support in HEAD GEF support is available for graphical editor testing
    88. 88. Questions ? newsgroup: news://news.eclipse.org/eclipse.swtbot web: eclipse.org/swtbot

    ×
