WPF with MVVM: From the Trenches<br />
Brent Edwards<br />Senior Consultant with Magenic<br />BrentE@magenic.com<br />@brentledwards<br />brentedwards.net<br />
Why ‘From the Trenches’?<br />
What We Will Cover<br /><ul><li>What is MVVM?
Cool WPF concepts
What is it?
Why is it cool?
How is it used?
Helpful tricks to make life easier
Useful tools that make debugging suck less
Develop sample app as we go</li></li></ul><li>What is MVVM?<br />
What is MVVM?<br />Model<br />Business logic<br />Business Object<br />View<br />Presentation<br />XAML<br />View Model<br...
Why is MVVM Cool?<br />Separates Presentation from Functionality<br />Promotes testability<br />Works great with Data Bind...
Cost of MVVM<br />No built in IDE support<br />All interactions must be manually wired up<br />New and shiny, but fragment...
Cool WPF Concepts<br />
DataContext<br />What is it?<br />A way to give elements a scope for data binding<br />Why is it cool?<br />Makes it easy ...
DataContext<br />How is it used?<br />Statically<br />OR<br />
DataContext<br />How is it used?<br />Dynamically<br />From code<br />
Data Binding<br />What is it?<br />A way for applications to present and interact with data<br />Why is it cool?<br />Simp...
Data Binding<br />How is it used?<br />Binding syntax in XAML<br />Two Way (Default Behavior)<br />Implement INotifyProper...
Commanding<br />What is it?<br />A way to bind commands to a DataContext<br />Why is it cool?<br />Can wire UI events to f...
Commanding<br />How is it used?<br />Expose ICommand property on View Model<br />Assign a command to the property<br />Pri...
Commanding<br />[Demo]<br />
Data Templates<br />What is it?<br />A way to define the presentation of your data<br />Why is it cool?<br />Can give a ‘l...
Data Templates<br />How is it used?<br />
Data Templates<br />[Demo]<br />
Data Triggers<br />What is it?<br />Set style properties based on data values<br />Why is it cool?<br />Change presentatio...
Data Triggers<br />How is it used?<br />
Data Triggers<br />[Demo]<br />
Value Converters<br />What is it?<br />Converts data value to format required by UI<br />Why is it cool?<br />Easy way to ...
Value Converters<br />How is it used?<br />Implement IValueConverter<br />Convert, ConvertBack<br />Include in Resources w...
Value Converters<br />[Demo]<br />
Data Template Selectors<br />What is it?<br />Select DataTemplate based on custom logic<br />Why is it cool<br />Select Da...
Data Template Selectors<br />How is it used?<br />Inherit from DataTemplateSelector<br />Add properties for the DataTempla...
Data Template Selectors<br />How is it used?<br />Add DataTemplateSelector to XAML<br />Use it!<br />ContentControl<br />L...
Data Template Selectors<br />[Demo]<br />
Helpful Tricks<br />[To make life easier]<br />
Event Aggregator / Message Bus<br />What is it?<br />Centralized location to route [Events | Messages]<br />Why is it cool...
Event Aggregator / Message Bus<br />How is it used?<br />Use an IOC container<br />Castle Windsor<br />Implement as a Sing...
Event Aggregator / Message Bus<br />[Demo]<br />
Navigation<br />The Problem<br />Views coupled with other Views<br />View Models know about Views<br />No separation of co...
Navigation<br />A Solution<br />Some Convention, Some Configuration<br />Leverage [Event Aggregator | Message Bus]<br />Le...
Navigation<br />Convention<br />View Models all have default constructors<br />View Models have an optional Load method wi...
Navigation<br />Configuration – Key Players<br />ViewTargets<br />ViewConfiguration<br />ViewController<br />ViewResult<br...
Navigation<br />Configuration - ViewTargets<br />Enumerates the views which can be navigated to<br />The glue that sticks ...
Navigation<br />Configuration - ViewConfiguration<br />Pairs a View with an optional View Model<br />Associated to a ViewT...
Navigation<br />Configuration - ViewController<br />The only object that interacts with the UI framework<br />Listens for ...
Navigation<br />Configuration – ViewFactory<br />Resolves ViewConfiguration for the requested View<br />Dynamically create...
Navigation<br />Configuration – ViewResult<br />Result of the dynamic build process<br />Has the built View along with any...
Navigation<br />[Demo]<br />
Modal Dialogs<br />Problem<br />Modal dialogs stall tests<br />[MessageBox| OpenFileDialog| PrintDialog]<br />How can you ...
Modal Dialogs<br />Option 1<br />Wrap them up!<br />Define interface<br />IMessageShower<br />Define implementation<br />M...
Modal Dialogs<br />Option 2<br />[Event Aggregator | Message Bus]<br />Create [Events | Messages]<br />Create class listen...
Modal Dialogs<br />[Demo]<br />
Magic with ContentControl<br />The Problem<br />Editable View and Read Only View<br />Views have identical layout<br />Tex...
Magic with ContentControl<br />A Solution – ContentControl!<br />DataTriggers<br />Give different presentation depending o...
Magic with ContentControl<br />[Demo]<br />
Useful Tools<br />[To make debugging suck less]<br />
Snoop<br />Inspects visual tree<br />Shows properties<br />Shows events<br />Can show 3D representation<br />
